Wiring Diagram VW TRANSPORTER 1999 - Heater control unit B3LC/D3LC - additional air heater



Wiring Diagram VW TRANSPORTER 1999 - Heater control unit B3LC/D3LC - additional air heater https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
A1Second battery, under driver's seat
J65Heater control unit B3LC/D3LC, in intakt duct
S23Heater fuse, under front right seat
S66Fuse for glow plugs, under front left seat
T4a4-pin connector
T4t4-pin connector, under front left seat, self-diagnosis connection
T8k8-pin connector, under front left driver's seat
T12a12-pin connector
T12c12-pin connector, in intake duct
   L32 Connection -1-, in heater unit wiring harness
   L59 Connection (30), in heater unit wiring harness
   L62 Positive (+) connection (30a), in additional heater wiring harness

Wiring Diagram VW TRANSPORTER 1999 - Heater control unit B3LC/D3LC - overheating switch - temperature sensor - fuel pump - flame monitor



Wiring Diagram VW TRANSPORTER 1999 - Heater control unit B3LC/D3LC - overheating switch - temperature sensor - fuel pump - flame monitor https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
F17Overheating switch, in heater
G18Temperature sensor, in heater
G23Fuel pump
G64Flame monitor, in heater
J65Heater control unit B3LC/D3LC, in intakt duct
J372Printed circuit board for temperature sensor, blower motor control unit and glow plug frequency
T22-pin connector
T2a2-pin connector
T4a4-pin connector
T1212-pin connector
T12a12-pin connector
T12c12-pin connector, on intake duct

Wiring Diagram VW TRANSPORTER 1999 - Heater control unit B3LC/D3LC - glow plug - combustion fresh and hot air blower



Wiring Diagram VW TRANSPORTER 1999 - Heater control unit B3LC/D3LC - glow plug - combustion fresh and hot air blower https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
A1Second battery
G40Hall sender
J65Heater control unit B3LC/D3LC, in intakt duct
J372Printed circuit board for temperature sensor, blower motor control unit and glow plug frequency
Q6Glow plug, in heater
T1Single connector
T44-pin connector
T4a4-pin connector
T1212-pin connector
T12a12-pin connector
T12c12-pin connector, on intake duct
V81Combustion, fresh and hot air blower, in heater
   189 Earth connection -1-, in heater unit wiring harness
   253 Earth connection, in heater unit wiring harness

Wiring Diagram VW TRANSPORTER 1999 - Pre-selection clock



Wiring Diagram VW TRANSPORTER 1999 - Pre-selection clock https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E20Switches and instruments, lighting control
E187Pre-selection clock with temperature control
F4Reversing light switch
L21Heater control light bulb
L39Heated rear window switch bulb
L75Digital display illumination
T2b2-pin connector
T8k8-pin connector, under driver's seat
T8l8-pin connector, behind relay plate
T3232-pin connector, on dash panel insert
TV5Terminal 15a junction box, green, 4-pin and 8-pin
TV8Terminal 58b junction box, grey
   30 Earth point -1-, next to relay plate
   A53 Connection (58b), in dash panel wiring harness
