VW TRANSPORTER 1999 – Anti-lock brake system (ABS) with electronic differential lock (EDL), Models with tachograph . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW TRANSPORTER 1999 - ABS with EDL control unit - ABS return flow pump - ABS return flow pump relay - ABS warning lamp

A	Battery
F9	Handbrake warning switch
F34	Brake fluid level warning contact
J59	X contact relief relay
J104	ABS with EDL control unit, in engine compartment, left
J105	ABS return flow pump relay
K47	ABS warning lamp
K118	Brake system warning lamp
SB5	Fuse -5- in fuse box/relay plate, below the relay plate
T6	6-pin connector
T28	28-pin connector, on dash panel insert (tachograph housing)
T31	31-pin connector
V39	ABS return flow pump, on ABS with EDL control unit
A20	Connection (15a), in dash panel wiring harness

F	Brake light switch
J104	ABS with EDL control unit, in engine compartment, left
J106	Relay for ABS solenoid valves
M22	Brake and tail light bulb, right
N99	ABS inlet valve, front right
N100	ABS outlet valve, front right
N101	ABS inlet valve, front left
N102	ABS outlet valve, front left
N133	ABS inlet valve, rear right
N134	ABS inlet valve, rear left
N135	ABS outlet valve, rear right
N136	ABS outlet valve, rear left
T31	31-pin connector
TV11	Terminal 54 junction box, orange
TV14	Terminal for self-diagnosis, white

A	Battery
G44	Rear right speed sensor
G45	Front right speed sensor
G46	Rear left speed sensor
G47	Front left speed sensor
J104	ABS with EDL control unit, in engine compartment, left
N166	EDL change-over valve, front right
N167	EDL outlet valve, front right
N168	EDL change-over valve, front left
N169	EDL outlet valve, front left
SA4	Fuse -4- in battery fuse box
T2c	2-pin connector, in longitudinal member, rear right
T2d	2-pin connector, in front right wheel housing
T2e	2-pin connector, in longitudinal member, rear left
T2f	2-pin connector, in front left wheel housing
T31	31-pin connector
J1	Positive (+) connection (30a), in ABS wiring harness
