VW TRANSPORTER 1999 – Cruise control system (CCS), Not for direct injection turbo diesel engine . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW TRANSPORTER
  4. >VW TRANSPORTER 1999
  5. >VW TRANSPORTER 1999 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW TRANSPORTER 1999 - Cruise control system control unit - cruise control system switch



Wiring Diagram VW TRANSPORTER 1999 - Cruise control system control unit - cruise control system switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
E45Cruise control system switch
F4Reversing light switch
J213Cruise control system control unit, behind the dash panel, right
J217Automatic gearbox fuse
J285Control unit with display in dash panel insert
RRadio
T1zSingle connector, behind relay plate
T4f4-pin connector, behind relay plate
T4h4-pin connector, behind steering column switch trim
T88-pin connector, on radio
T10a10-pin connector, behind relay plate
T1212-pin connector
T3232-pin connector, on dash panel insert
T68a68-pin connector, on automatic gearbox control unit
TV5Terminal 15a junction box, green
TV13Terminal for speed signal blue
   33 Earth point, behind dash panel, right
*Only models with manual gearbox
---Only models with automatic gearbox

Wiring Diagram VW TRANSPORTER 1999 - Cruise control system control unit - vacuum pump for automatic speed control - pedal switch



Wiring Diagram VW TRANSPORTER 1999 - Cruise control system control unit - vacuum pump for automatic speed control - pedal switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
FBrake light switch
F36Clutch pedal switch
F47Cruise control system brake pedal switch
J213Cruise control system switch, behind the dash panel, right
M22Brake and tail light bulb, right
T33-pin connector
T3a3-pin connector, behind relay plate
T1212-pin connector
TV11Terminal 54 junction box, orange
V18Vacuum pump for speed automatic control
*Only models with manual gearbox
---Only models with automatic gearbox
