Wiring Diagram VW TRANSPORTER 1998 - Battery - starter - alternator
A | Battery |
B | Starter |
C | Alternator |
C1 | Voltage regulator |
D | Ignition/starter switch |
T2e | 2-pin connector, near starter |
T2t | 2-pin connector |
1 | Earth strap, battery body |
2 | Earth strap, gearbox - body |
C10 | Positive connection -1- (30), in headlight wiring harness |
Wiring Diagram VW TRANSPORTER 1998 - Diesel direct injection system control unit - commencement of injection valve - exhaust gas recirculation - charge pressure control - idling switch - kick-down switch - accelerator pedal position sender
F8 | Kick-down switch, for automatic gearbox only |
F60 | Idling switch |
G79 | Accelerator pedal position sender |
J248 | Diesel direct injection system control unit, left in engine compartment |
J317 | Terminal 30 voltage supply relay |
N18 | Exhaust gas recirculation valve |
N75 | Charge pressure control solenoid valve |
N108 | Commencement of injection valve |
T3a | 3-pin connector, under diesel injection pump, up to October 1997 |
T10 | 10-pin connector, behind relay plate |
T10a | 10-pin connector, on front of engine, from November 1997 |
T68 | 68-pin connector |
F25 | Connection -1-, in diesel direct injection system wiring harness |
* | On engine code ACV up to April 1998 |
** | On engine codes AHY, ACV, AJT from May 1998 |
Wiring Diagram VW TRANSPORTER 1998 - Diesel direct injection system control unit - engine speed sender - air mass meter - intake manifold temperature sender
G28 | Engine speed sender |
G70 | Air mass meter |
G72 | Intake manifold temperature sender |
J248 | Diesel direct injection system control unit, left in engine compartment |
J362 | Immobilizer control unit, behind dash panel insert |
T1b | Single connector, behind relay plate |
T1c | Single connector, behind relay plate |
T1x | Single connector, on self-diagnosis junction box |
T3 | 3-pin connector, on front of engine |
T5a | 5-pin connector, on engine code ACV up to April 1998 |
T6b | 6-pin connector, on engine codes AHY, ACV, AJT from May 1998 |
T8b | 8-pin connector, on immobilizer control unit |
T68 | 68-pin connector |
TV14 | Self-diagnosis junction box, above relay plate |
156 | Earth connection, in diesel direct injection wiring harness |
220 | Earth connection (sender earth), in engine wiring harness |
* | On engine code ACV up to April 1998 |
** | On engine codes AHY, ACV, AJT from May 1998 |
Wiring Diagram VW TRANSPORTER 1998 - Diesel direct injection system control unit - pedal switch - fuel temperature sender - modulating piston movement sender - metering adjuster - coolant temperature sender
F36 | Clutch pedal switch |
F47 | Cruise cont. sys. brake pedal switch (diesel direct inj. system) |
G62 | Coolant temperature sender |
G81 | Fuel temperature sender |
G149 | Modulating piston movement sender |
J248 | Diesel direct injection system control unit, left in engine compartment |
N146 | Metering adjuster |
T8a | 8-pin connector, up to October 1997 |
T10 | 10-pin connector, behind relay plate |
T10a | 10-pin connector, on front of engine, from November 1997 |
T68 | 68-pin connector |
220 | Earth connection (sender earth), in engine wiring harness |
F26 | Connection -2-, in diesel direct injection system wiring harness |
Wiring Diagram VW TRANSPORTER 1998 - Diesel direct injection system control unit - needle lift sender - fuel shut-off valve
F | Brake light switch |
G80 | Needle lift sender |
J217 | Automatic gearbox control unit, left lower A-pillar |
J248 | Diesel direct injection system control unit, left in engine compartment |
M22 | Brake and tail light bulb, right |
N109 | Fuel shut-off valve |
T1l | Single connector, behind relay plate (air conditioning system) |
T1m | Single connector, left behind dash panel |
T2 | 2-pin connector, on front of engine |
T3a | 3-pin connector, under diesel injection pump, up to October 1997 |
T6a | 6-pin connector, behind relay plate |
T10a | 10-pin connector, on front of engine, from November 1997 |
T68 | 68-pin connector |
T68a | 68-pin connector, on automatic gearbox control unit |
TV11 | Terminal 54 junction box, above relay plate |
TV13 | Speed signal junction box, above relay plate |
12 | Earth point, in engine compartment, left |
156 | Earth connection, in diesel direct injection wiring harness |
Wiring Diagram VW TRANSPORTER 1998 - Diesel direct injection system control unit - cruise control system - engine glow plugs
E45 | Cruise control system switch |
F4 | Reversing light switch |
J52 | Glow plug relay |
J248 | Diesel direct injection system control unit, left in engine compartment |
Q6 | Glow plugs - (engine) |
S39 | Glow plug motor strip fuse, front left in engine compartment |
T4f | 4-pin connector, behind relay plate |
T4g | 4-pin connector, behind steering column switch trim |
T5 | 5-pin connector, on front of engine |
T68 | 68-pin connector |
TV2 | Terminal 30 junction box |
TV5 | Terminal 15a junction box, above relay plate |
TV20 | Terminal 15a junction box -2-, above relay plate |
F31 | Connection (glow plugs - engine), in diesel direct injection system wiring harness |
Wiring Diagram VW TRANSPORTER 1998 - Continued coolant circulation - fuel gauge sender - coolant shortage indicator sender - coolant temperature gauge sender
F95 | Thermo-switch for coolant circulation run-on |
G | Fuel gauge sender |
G2 | Coolant temperature gauge sender |
G32 | Coolant shortage indicator sender |
T1b | Single connector, behind relay plate |
V51 | Continued coolant circulation pump |
18 | Earth point, on engine block |
Wiring Diagram VW TRANSPORTER 1998 - Dash panel insert - optical and acoustic oil pressure warning - glow period warning lamp - coolant temperature/coolant shortage warning lamp - speedometer sender
F1 | Oil pressure switch |
F22 | Oil pressure switch (0.3 bar) |
G22 | Speedometer sender (Hall sender on gearbox) |
H11 | Oil pressure warning buzzer |
J285 | Control unit with display in dash panel insert |
K3 | Oil pressure warning lamp |
K28 | Coolant temperature/coolant shortage warning lamp |
K29 | Glow period warning lamp |
T28 | 28-pin connector |
18 | Earth point, on engine block |
Wiring Diagram VW TRANSPORTER 1998 - Dash panel insert - fuel gauge - coolant temperature gauge - speedometer - odometer display
G1 | Fuel gauge |
G3 | Coolant temperature gauge |
G21 | Speedometer |
J285 | Control unit with display in dash panel insert |
K2 | Alternator warning lamp |
K105 | Reserve fuel warning lamp, from May 1997 |
L75 | Digital display illumination |
R | Radio |
T2x | 2-pin connector, behind relay plate |
T8 | 8-pin connector, on radio |
T16 | 16-pin connector, in centre of dash panel, self-diagnosis connection for V.A.G. 1551 |
T28 | 28-pin connector |
Y4 | Odometer display |
R6 | Positive connection -1-, in interior light wiring harness |
