VW TRANSPORTER 1998 – Rear window wipe/wash system (tailgate/boot lid) . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW TRANSPORTER
  4. >VW TRANSPORTER 1998
  5. >VW TRANSPORTER 1998 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW TRANSPORTER 1998 - Windscreen wipe/washer system



Wiring Diagram VW TRANSPORTER 1998 - Windscreen wipe/washer system https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
E22Intermittent wiper switch
HHorn plate
J4Dual tone horn relay
J31Automatic intermittent wash/wipe relay
T4b4-pin connector, behind steering column switch trim
T5c5-pin connector, behind steering column switch trim
T7a7-pin connector, behind steering column switch trim
VWindscreen wiper motor
   C51 Positive connection (X), in windscreen wiper motor wiring harness
*Not for vehicles with multi-function indicator (see multi-function indicator current flow diagram)

Wiring Diagram VW TRANSPORTER 1998 - Rear window wipe/wash system (tailgate/boot lid)



Wiring Diagram VW TRANSPORTER 1998 - Rear window wipe/wash system (tailgate/boot lid) https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J30Rear window wiper/washer relay
E34Rear wiper switch (intermittent operation)
T1Single connector, on rear window wiper/washer relay
T2k2-pin connector, near right tail light
T55-pin connector, behind steering column switch trim
V12Rear window wiper motor
V59Windscreen and rear window washer pump
   60 Earth point -2-, near right tail light
   98 Earth connection, in tailgate/boot lid wiring harness
*Not for vehicles with multi-function indicator (see multi-function indicator current flow diagram)
