AIR CONDITIONING – Audi 80 Quattro 1991 – SYSTEM WIRING DIAGRAMS

AIR CONDITIONING

Manual A/C Wiring Diagram for Audi 80 Quattro 1991

List of elements for Manual A/C Wiring Diagram for Audi 80 Quattro 1991:

• (in fuse/ relay panel)
• (in instrument panel wiring harness)
• (not
• A/c compressor clutch
• A/c control unit
• A/c flap
• A/c refrig-
• A/c refrigerant
• A/c refrigerant high pressure switch
• Battery (30)
• Blower motor
• Blower resistors
• Blower switch
• Cluster
• Coolant fan
• Coolant fan after run
• Coolant fan after run control unit
• Coolant fan low speed relay
• Coolant fan resistor
• Coolant fan thermo switch
• Ctrl relay
• Diode
• Electronic thermo switch
• Erant low
• Fuel injection control unit
• Fuse 15a
• Fuse 20a
• Fuse 30a
• Fuse/ relay panel
• G206
• G206 (in instrument panel wiring harness)
• Heater fan relay
• High speed coolant fan
• Hot with load reduction relay energized (x)
• Ignition (15)
• Illumi- nation
• Instru-
• Low coolant switch
• Ment
• Nca
• Off
• Outside temp switch
• Pressure
• Pressure safety switch
• Solenoid
• Switch
• Tcm
• Thermo switch
• Used)
