Электросхемы СИСТЕМА КРУИЗКОНТРОЛЯ Nissan Altima GLE 2001

СИСТЕМА КРУИЗКОНТРОЛЯ

Электросхема системы круизконтроля для Nissan Altima GLE 2001

Электросхема системы круизконтроля для Nissan Altima GLE 2001 - Список элементов:

• 11n
• 12n
• 16n
• A/t
• Actr out
• Air valve
• Air vlv out
• Ascd brake switch (a/t) (on bracket, above above brake pedal)
• Ascd brake switch (m/t) (on bracket, above above brake pedal)
• Ascd clutch switch (m/t) (on bracket, above clutch pedal)
• Ascd control unit (behind left side of dash)
• Ascd od cut
• Ascd pump (left rear of engine compartment)
• Ascd steering switch
• Brake nc sw
• Brake no sw
• Cancel switch
• Combination meter
• Command gnd
• Command sw
• Cruise
• Cruise lamp
• Cruise signal
• Exterior lights system
• Fuse 12 10a
• Fuse 14 15a
• Fuse 25 10a
• Fuse 8 10a
• Fuse block (under left side of dash)
• G101 (front of right front fender)
• Ground
• Hot at all times
• Hot in on or start
• Ign sw
• M/t
• Main switch
• Nca
• Od cancel
• Park/neutral position relay (a/t)
• Park/neutral position switch (a/t) (on left side of trans)
• Pnk
• Red
• Rel vlv out
• Release valve
• Resume/ accel switch
• Set
• Set lamp out
• Set/ coast switch
• Side of dash) g201
• Spiral cable
• Starting/ charging system
• Stoplight switch (on bracket, above brake pedal)
• Transmission control module (tcm) (under front of center console)
• Transmissions system
• Vacuum motor
• Vacuum mtr
• Vehicle speed sensor (on transaxle)
• Vss in
• Vss out
