Diagram sections — 25 (41 total)
AIR CONDITIONING ANTI-LOCK BRAKES ANTI-THEFT COMPUTER DATA LINES COOLING FAN DEFOGGERS ENGINE PERFORMANCE EXTERIOR LIGHTS GROUND DISTRIBUTION HEADLIGHTS HORN INSTRUMENT CLUSTER INTERIOR LIGHTS POWER DISTRIBUTION POWER DOOR LOCKS POWER MIRRORS POWER TOP/SUNROOF POWER WINDOWS RADIO SHIFT INTERLOCKS STARTING/CHARGING SUPPLEMENTAL RESTRAINTS TRANSMISSION WARNING SYSTEMS WIPER/WASHER
AIR CONDITIONING Heater Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Heater Wiring Diagram for Daewoo Lanos SE 1999: 18 (below right front of console) (left side of dash) Blower motor (behind right side of dash) Blower motor 4th speed relay (above passenger room fuse box) Blower motor resistor (behind right end of dash) Blower motor switch Engine room relay & fuse box (at left side of engine room) Fuse 20a Fuse 30a G201 G201 (below right front of console) Hot at all times Hot in on Off Passenger room fuse box (behind left kick panel) Red S203 Splice pack 203 Manual A/C Wiring Diagram (1 of 2) for Daewoo Lanos SE 1999 List of elements for Manual A/C Wiring Diagram (1 of 2) for Daewoo Lanos SE 1999: 44 A/c compressor A/c compressor relay A/c control switch A/c indicator A/c pressure sensor (at right rear of engine room) A/c switch Acp B14 Blower motor (behind right side of dash) Blower motor 4th speed relay (above passenger room fuse box) Blower motor resistor (behind right end of dash) Blower motor switch C12 C13 Coolant temperature sensor Defogger system Diode E15 Engine control system Engine room relay & fuse box Engine room relay & fuse box (at left side of engine room) Fuse 10a Fuse 20a Fuse 30a Fuse 80a G102 (front of left front fender) G104 G201 G201 (below right front of console box) Hot at all times Hot in on Interior lights system Nca Off Passenger room fuse box (behind left kick panel) Powertrain control module (under right front seat) Red Relay sw S203 Sens hi Sens lo Sig Splice pack 203 (left side of dash) Switch illumination Manual A/C Wiring Diagram (2 of 2) for Daewoo Lanos SE 1999 List of elements for Manual A/C Wiring Diagram (2 of 2) for Daewoo Lanos SE 1999: 16 87a Cooling fan control relay Cooling fan relay a Cooling fan relay b Engine room relay & fuse box (at left side of engine room) Fuse 10a Fuse 30a G102 (front of left front fender) G103 (front of right front fender) Hot at all times Hot in on Left cooling fan Passenger room fuse box (behind left kick panel) Red Right cooling fan Splice pack 101 (engine room relay & fuse box)
ANTI-LOCK BRAKES Anti-lock Brake Wiring Diagrams for Daewoo Lanos SE 1999 List of elements for Anti-lock Brake Wiring Diagrams for Daewoo Lanos SE 1999: 51 (below glove box) g304 A10 A11 A12 Abs Abs (rh side panel below glove box) Abs motor Abs relay (rh side panel below glove box) Abs warning lamp module B10 B11 B12 Brake Brake oil switch C102 Cluster Data link connector Electronic brake control module (ebcm) Engine room fuse & relay box (left side of engine room) Exterior light system Fr/lh m Fr/lh solenoid Fr/rh m Fr/rh solenoid Fuse 10a Fuse 15a Fuse 40a Fuse 80a G102 (front of left front fender) G104 (on intake) Ground Hydraulic modulator motor pack Ig+ Left front wheel speed sensor Left rear wheel speed sensor Parking brake lamp switch Passenger room fuse box (behind left side) of dash) Pcm system Pnk Powertrain control sysyem Red Red/ Right front wheel speed sensor Right rear wheel speed sensor Rr/lh, rr/rh S303 Serial data Sig Splice pack Splice pack 303 Stop lamp switch
ANTI-THEFT Anti-theft Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Anti-theft Wiring Diagram for Daewoo Lanos SE 1999: 37 Anti-theft & door locking switch Anti-theft control module Anti-theft temper switch Bat + Central door locking relay (behind right kick panel) Data link connector (dlc) (under left side of dash) Door contact switch Door locking relay Engine room relay & fuse box (at left side of engine room) Exterior lights system Fuse 1 80a Fuse 12 10a Fuse 17 10a Fuse 4 15a G102 (front of left front fender) G201 (below right front of console box) G301 (below left front seat) G303 (below right front seat) Ground Hood open switch Hot at all times Hot in on or start Ign 1 Interior lights system Left turn sig lmp Locking switch Passenger room fuse box (behind left kick panel) Pnk Red Right turn sig lmp S203 (next to passenger room relay box) Serial data Siren Splice pack 302 Status display Trunk lid open Trunk lid/hatch sw
COMPUTER DATA LINES Computer Data Lines for Daewoo Lanos SE 1999 List of elements for Computer Data Lines for Daewoo Lanos SE 1999: 16 Anti-theft control module (below center floor console) B13 Data link connector (under right side of dash) Electronic brake control module (ebcm) (left rear corner of engine room) Engine room relay & fuse box (left side of engine room) Fuel pump (top of fuel tank) Fuel pump relay Fuse 16 15a Fuse 2 10a G104 (on intake manifold) Hot at all times Passenger room fuse box (behind left kick panel) Powertrain control module (pcm) (under right front seat) S201 (behind left kick panel) S303 (below driver seat) Sensing & diagnostic module (sdm) (below center floor console)
COOLING FAN Cooling Fan Wiring Diagram, with A/C for Daewoo Lanos SE 1999 List of elements for Cooling Fan Wiring Diagram, with A/C for Daewoo Lanos SE 1999: 33 87a A/c pressure sensor (at right rear of engine room) Acp sig Air conditioning system B14 C12 C13 Coolant temperature sensor Cooling fan control relay Cooling fan relay a Cooling fan relay b Cts sig E15 Engine control system Engine room relay & fuse box (at left side of engine room) Fuse 10a Fuse 30a G102 (front of left front fender) G103 (front of right front fender) G104 Ground Hot at all times Hot in on Left cooling fan Passenger room fuse box (behind left kick panel) Powertrain control module (under right front seat) Red Relay sw Right cooling fan Sens hi Sens lo Sig Splice pack 101 (engine room relay & fuse box) Cooling Fan Wiring Diagram, without A/C for Daewoo Lanos SE 1999 List of elements for Cooling Fan Wiring Diagram, without A/C for Daewoo Lanos SE 1999: 23 C12 C13 Cooling fan Cooling fan low speed resistor (left front of engine room) Cooling fan relay a Cooling fan relay b Engine controls system Engine coolant temperature sensor (on right side of engine, below intake manifold) Engine room relay & fuse box (at left side of engine room) Fuse 10a Fuse 30a G102 (front of left front fender) G104 (on intake manifold) Gnd Ground Hot at all times Hot in on Passenger room fuse box (behind left kick panel) Powertrain control module (under right front seat) Red Relay sw Sig Splice pack 101 (engine room relay & fuse box)
DEFOGGERS Defogger Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Defogger Wiring Diagram for Daewoo Lanos SE 1999: 15 A/c control switch Defroster Defroster indicator Defroster relay Defroster switch Engine room relay & fuse box (left side of engine room) Fuse 10a Fuse 7 30a G201 (below right front of console box) G305 (inside rear window right pillar trim) Hot at all times Hot in on Passenger room fuse box (behind left kick panel) S101 S203 (behind left kick panel)
ENGINE PERFORMANCE
1.6L 1.6L, Engine Performance Wiring Diagrams (1 of 4) for Daewoo Lanos SE 1999 List of elements for 1.6L, Engine Performance Wiring Diagrams (1 of 4) for Daewoo Lanos SE 1999: 46 2-3 solenoid signal 5v signal A/c pressure signal Data link connector Est a Evap emission canister purge solenoid (cccp) (right side of engine compartment) Evap emission diagnostic solenoid (under rear of vehicle) Fuel gauge Fuel gauge signal Fuel meter Fuel press sensor sig Fuel pressure sensor (on top of fuel tank) Fuse 10a Fuse 15a G104 (on intake manifold) Ground Hot at all times Hot in on & start Iac a hi Iac a lo Iac b hi Iac b lo Idle air control (iac) solenoid (on top front of engine) Instrument cluster system Knock signal Legr signal Nca Passenger compartment fuse box (behind left kick panel) Pnk Pnk a Post o2 sensor Powertrain control module (pcm) (under right front seat) Pre o2 sensor Red Red a Reference hi Reference lo Rough rd sensor sig Rough road sensor (w/o abs) Rpm signal S303 (below passenger seat) Signal (tcc) Speedometer System ground Throttle position (tp) sensor (on top front of engine) Vgis (left side of engine compt) 1.6L, Engine Performance Wiring Diagrams (2 of 4) for Daewoo Lanos SE 1999 List of elements for 1.6L, Engine Performance Wiring Diagrams (2 of 4) for Daewoo Lanos SE 1999: 21 (on intake manifold) (rear of engin) ei module A/c pressure switch (right rear of engine compt) Automatic transmission solenoid (right side of trans) Camshaft position (cmp) sensor (rear of engine) Coil driver D pnk G104 G105 (above flywheel housing) Injectors Knock sensor (dohc) (right side of eng) Manifold absolute pressure (map) sensor (at left side of engine compt) Nca Pcs Pnk Post o2 sensor (in front exhaust pipe, downstream of catalytic converter) Pre (o2) sensor (on exhaust manifold) Solenoid a Solenoid b Spark plugs Tcc solenoid 1.6L, Engine Performance Wiring Diagrams (3 of 4) for Daewoo Lanos SE 1999 List of elements for 1.6L, Engine Performance Wiring Diagrams (3 of 4) for Daewoo Lanos SE 1999: 24 (below right front seat) (front of left front fender) (on intake manifold) Coolant temperature (cts) sensor (on right side of engine, below intake manifold) Crankshaft position (ckp) sensor (on lower front of engine) Engine compartment relay & fuse box (at left side of engine compartment) Fuel pump Fuel pump relay Fuel pump test terminal Fuse 15a G102 G104 G104 (on intake manifold) G303 Hot at all times Iss (a/t) Legr (on top rear of engine) Manifold air temperature (mat) sensor (on air cleaner- to-throttle body hose) Nca Pnk Red S101 Vehicle speed sensor (vss) (a/t) (on lower right front of transaxle) Vehicle speed sensor (vss) (m/t) (on lower right front of transaxle) 1.6L, Engine Performance Wiring Diagrams (4 of 4) for Daewoo Lanos SE 1999 List of elements for 1.6L, Engine Performance Wiring Diagrams (4 of 4) for Daewoo Lanos SE 1999: 54 (below right front console box) (below right front seat) 12v signal 5v signal A/t oil temperature sensor Check engine indicator Cmp sensor D2 lo Data link connector (dlc) (under left side of dash) Driver Ect signal Engine hot warning lmp Est b Exterior lights system Front seat) Fuel pump relay G201 G303 Ground Ig+ Injector 1 ground Injector 3 ground Injector 4 ground Instrument cluster Iss signal Legr low Map signal Module (pcm) (under right Nca Oil pressure switch assy connector P.r.n.d4 Pnk Post o2 sensor Power mode switch Powertrain control Pressure switch assembly Pwr warning lamp S201 (next to passenger compt relay box) S203 (next to passenger compt relay box) S303 (below passenger seat) Serial data Signal Signal a Signal b Signal c Speedometer Stop lmp on signal Tachometer Tcc off Tcc signal Tps signal Vgis ground Vss (m/t) Vss signal
EXTERIOR LIGHTS Back-up Lamps Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Back-up Lamps Wiring Diagram for Daewoo Lanos SE 1999: 13 A/t Fuse 10a G105 (above flywheel housing) Hot in on or start Left M/t Nca Park/neutral position switch (reverse lamp switch) (on top of transaxle) Passenger room fuse box (behind left kick panel) Pnk Reverse lamp (trunk lid tail lamp: sedan) (tailgate tail lamp: hatch back) Reverse lamp switch Right Exterior Lamps Wiring Diagram (1 of 2) for Daewoo Lanos SE 1999 List of elements for Exterior Lamps Wiring Diagram (1 of 2) for Daewoo Lanos SE 1999: 45 (below right front of console box) (front of left front fender) 49a Blinker unit (above passenger room fuse box) Engine room relay & fuse box (at left side of engine room) Fuse 10a Fuse 15a Fuse 20a G102 G102 (front of left front fender) G103 (front of right front fender) G201 G201 (below right front of console box) G301 (below left front seat) G401 (center rear of trunk) Hazard lamp switch Headlamp switch Headlights system Hot at all times Hot in on or start Illumination relay Instrument cluster Interior lights system Left Left front parking lamp (position lamp) Left front side marker lamp Left rear parking lamp (tail lamp) Left rear side marker lamp Left turn signal light Off Passenger room fuse box (behind left kick panel) Pnk Red Right Right rear side marker lamp Right turn signal light S101 (engine room relay & fuse box) S201 (next to passenger room relay box) S202 (next to passenger room relay box) S203 (next to passenger room relay box) S301 (below driver seat) Sedan Step 1 Step 2 Turn signal lamp switch Exterior Lamps Wiring Diagram (2 of 2) for Daewoo Lanos SE 1999 List of elements for Exterior Lamps Wiring Diagram (2 of 2) for Daewoo Lanos SE 1999: 46 (below left front seat) (center rear of trunk) (front of right front fender) Anti-theft control module (below center floor console) C204 C401 C402 C403 C451 Center high mount stop lamp Center high mount stop light Electronic brake control module (ebcm) (at left rear of engine room) Front seat) g301 Fuse 15a G102 (front of left front fender) G103 G103 (front of right front fender) G301 G301 (below left front seat) G401 G401 (center rear of trunk) Hatch back Hot at all times If equipped Left Left front turn signal lamp Left rear turn signal lamp License plate lamp Nca Parking lamp (trunk lid tail lamp) (sedan) parking lamp (tailgate tail lamp) (hatchback) Passenger room fuse box (behind left kick panel) Powertrain control module (pcm) (under right front seat) Red Right Right front parking lamp (position lamp) Right front side marker lamp Right front turn signal lamp Right rear parking lamp tail lamp Right rear turn signal lamp S301 (below driver seat) S303 (below passenger seat) Sedan Stop- lamp (tail- gate) Stop- lamp (trunk- lid) Stoplamp (taill lamp) Stoplamp switch
GROUND DISTRIBUTION Ground Distribution Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Ground Distribution Wiring Diagram for Daewoo Lanos SE 1999: 27 Airbag control unit Anti-lock brake control module (ebcm) Battery Clock, audio unit, chime bell, drl module, blinker unit, blower motor, cigarette lighter, front wiper relay, a/c control switch, key interlock unit, instrument cluster, dimmer control switch, front fog lamp switch, electric mirror switch, status display (anti-theft), blower motor 4th speed relay, ashtray illumination Diode, fuel pump relay, a/c compressor, cooling fan control relay, cooling fan (w/o a/c), headlamp relay, left headlamp, illumination relay, left front parking lamp, hood open switch, brake oil switch, left front turn signal lamp, rear washer pump, front washer pump, power window relay, front fog lamp relay Dis module, pnp switch (a/t), post o2 sensor, reverse lamp switch Fuel pump, fuel level unit, power mode switch, power window main switch, central door locking relay, anti-theft control module, right anti-theft & door locking switch G101 (behind battery support body ground) G102 (front of left front fender) G103 (front of right front fender) G104 (on intake manifold) G105 (above flywheel housing) G106 (upper bolt of starter motor engine ground) G201 (below right front of console box) G301 (below left front seat) G302 (below right front of console box) G303 (below right front seat) G304 (below glove box) G305 (inside rear window right pillar trim) G306 (center front of roof) G401 (center rear of trunk) Horn, right front turn signal lamp, right front side marker lamp, right front parking lamp, left front side marker lamp, right headlamp right cooling fan (w/ a/c), left front fog lamp, right front fog lamp Left rear parking lamp, right rear parking lamp, right rear turn signal lamp, left rear turn signal lamp, stop lamp (notchback taillamp), stop lamp (hatch back tail light) Pcm, cam sensor, cp sensor shield, data link connector, vehicle speed sensor, abs warning lamp module Rear window defroster (notchback) Room lamp, rear wiper motor, seat belt switch, license plate lamps, rear window defroster (hatch back), tailgate open switch, anti-theft tamper switch, stop lamp (hatchback tailgate), center high mount stop lamp, left anti-theft and door locking switch, left front central door locking switch, parking lamps (trunk lid tail lamp), left rear side marker lamps (notch back), right rear side marker lamps (notch back), trunklid open switch (hatchback), stop lamp (trunk lid, notchback) Sunroof module
HEADLIGHTS Headlight Wiring Diagram, with DRL for Daewoo Lanos SE 1999 List of elements for Headlight Wiring Diagram, with DRL for Daewoo Lanos SE 1999: 55 (below right front of console box) (front of left front fender) Anti-lock brake system Brake oil switch C103 Dimmer & passing switch Dimmer switch Drl module Drl warning lamp Engine room fuse & relay box Engine room relay & fuse box (at left side of engine room) Fog lamp relay Front fog lamp indicator Front fog lamp switch Fuse 10a Fuse 15a Fuse 20a Fuse 25a Fuse 80a G102 G102 (front of left front fender) G103 (front of right front fender) G201 G201 (below right front of console box) Head Head lamp relay Hi beam indicator High High beam Hot at all times Hot in on & start Illumination Indicator Instrument cluster Interior lights system Left front fog lamp Left head lamp Light switch Low Low beam Off Park Parking brake lamp Parking brake lever switch Passenger room fuse box (behind left kick panel) Passing switch Pnk Red Right front fog lamp Right head lamp S101 Splice pack 201 (behind left of dash) Splice pack 201 (left side of dash) Splice pack 202 (left side of dash) Splice pack 203 (left side of dash) Headlight Wiring Diagram, without DRL for Daewoo Lanos SE 1999 List of elements for Headlight Wiring Diagram, without DRL for Daewoo Lanos SE 1999: 43 (below right front of console box) C103 Dimmer & passing switch Dimmer switch Engine room fuse & relay box Engine room relay & fuse box (at left side of engine room) Fog lamp relay Front fog lamp indicator Front fog lamp switch Fuse 10a Fuse 15a Fuse 20a Fuse 25a Fuse 80a G102 (front of left front fender) G103 (front of right front fender) G201 Head Head lamp relay Hi beam indicator High High beam Hot at all times Illumination Indicator Instrument cluster Interior lights system Left front fog lamp Left head lamp Light switch Low Low beam Off Park Passenger room fuse box (behind left kick panel) Passing switch Red Right front fog lamp Right head lamp S101 Splice pack 201 (behind left of dash) Splice pack 202 (left side of dash) Splice pack 203 (left side of dash)
HORN Horn Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Horn Wiring Diagram for Daewoo Lanos SE 1999: 9 Contact coil Engine room relay & fuse box (at left side of engine room) Fuse 80a G103 (front of right front fender) Horn Horn relay Horn switch Hot at all times Nca
INSTRUMENT CLUSTER Instrument Cluster Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Instrument Cluster Wiring Diagram for Daewoo Lanos SE 1999: 52 A/t only Abs warning lamp Air bag system Air bag waring lamp Anti-lock brake system Brake oil switch Charge warning lamp Cluster illumination (4 bulbs) Engine coolant temperature sensor (right side of engine, below intake manifold) Engine hot warning lamp Engine oil pressure switch Exterior lamps system Fog lamp indicator Fuel level warning lamp Fuel meter Fuel pump and sender (top of fuel tank) Fuse 11 10a Fuse 14 15a G102 (front of left front fender) G104 (on intake manifold) G201 (below right front of console box) G303 (below right front seat) Ground Headlamps system High beam indicator Hot in on and start Instrument cluster Interior lamps system Left turn indicator M/t only Malfunction indicator lamp Oil pressure warning lamp Parking brake lever switch Parking brake warning lamp Passenger room fuse box (behind left kick panel) Pnk Powertrain control module (under right front seat) Pwr indicator Right turn indicator Rpm signal S201 (behind left kick panel) S203 (behind left kick panel) Seat belt warning lamp Speedometer Starting/charging system Tachometer Temperature meter Vehicle speed sensor (lower right front of transaxle) Vehicle speed sensor (vss) (lower right front of transaxle) Vss a/t Vss m/t Warnings system
INTERIOR LIGHTS Courtesy Lamps Wiring Diagram, Hatchback for Daewoo Lanos SE 1999 List of elements for Courtesy Lamps Wiring Diagram, Hatchback for Daewoo Lanos SE 1999: 26 (w/ sunroof) (w/o sunroof) (w/o sunroof) (w/ sunroof) Anti- theft system C203 D8 diode Door Door open warning lamp Engine room relay and fuse box F1 fuse 10a F2 fuse 10a Fuse 80a G301 (below left front seat) Hot at all times Instrument cluster Left front door contact switch Nca Off Passenger room fuse box (behind left kick panel) Red Right front door contact switch Room lamp S201 (behind left kick panel) S302 (below driver seat) Tailgate lamp Tailgate open switch Warning systems Courtesy Lamps Wiring Diagram, Notchback for Daewoo Lanos SE 1999 List of elements for Courtesy Lamps Wiring Diagram, Notchback for Daewoo Lanos SE 1999: 28 (w/ sunroof) (w/o sunroof) (w/o sunroof) (w/ sunroof) Anti- theft system C203 D8 diode Door Door open warning lamp Engine room relay and fuse box F1 fuse 10a F2 fuse 10a Fuse 80a G301 (below left front seat) Hot at all times Instrument cluster Left front door contact switch Left rear door contact switch Nca Off Passenger room fuse box (behind left kick panel) Red Right front door contact switch Right rear door contact switch Room lamp S302 (below driver seat) Splice pack 201 Trunk lamp Trunk lid open switch Warning systems Instrument Illumination Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Instrument Illumination Wiring Diagram for Daewoo Lanos SE 1999: 29 Ashtray illumination lamp Audio Cigarette lighter Dimmer control switch Engine room fuse & relay box (left side of engine room) F2 fuse 10a Front fog lamp switch Fuse 10a Fuse 20a Fuse 80a G102 (front of left front fender) G201 (front of left front fender) Hazard switch Head Headlamp switch Hot at all times Hvac switch Illumination relay Illuminaton (4 bulbs) Instrument cluster Off Park Passenger room fuse box (behind left kick panel) Red S101 (left side of engine compt) S201 (behind left kick panel) S203 (behind left kick panel) S204 (above glove box) S301 (below driver seat)
POWER DISTRIBUTION Power Distribution Wiring Diagram (1 of 2) for Daewoo Lanos SE 1999 List of elements for Power Distribution Wiring Diagram (1 of 2) for Daewoo Lanos SE 1999: 47 A/c comp relay Acc Anti-lock brake system Anti-theft system Audio system Battery Cigarette lighter Computer data lines system Door lock system Engine compartment relay and fuse box (left side of engine compartment) Engine control system Exterior lamp system Exterior lamps system Fog lamp relay Fuel pump relay Fuse 10a Fuse 10a red Fuse 15a Fuse 20a red Fuse 25a Fuse 30a Fuse 80a G101 (near battery) G106 (right rear of engine) G201 (below right front of console box) Head lights system Headlamp relay Headlamps system Horn relay Ignition switch Illumination relay Instrument cluster system Interior lamps system Off Passenger compartment fuse box (behind left kick panel) Red S201 (next to passenger compartment fuse box) S203 (next to passenger room relay box) S302 (below drivers seat) S303 (below front passenger seat) Shift interlock system Sound system Start Starting system To engine compartment relay and fuse box (diagram 2 of 2) To passenger compartment fuse box (diagram 2 of 2) Warning system Power Distribution Wiring Diagram (2 of 2) for Daewoo Lanos SE 1999 List of elements for Power Distribution Wiring Diagram (2 of 2) for Daewoo Lanos SE 1999: 34 A/c compressor relay A/c system Anti-lock brake system Anti-lock brakes system Anti-theft system Cooling fan control relay Cooling fan relay 'a' Cooling fan relay 'b' Engine compartment relay and fuse box (left side of engine compartment) Engine control system Exterior lamps system From engine compartment c fuse and relay box (diagram 1 of 2) From ignition switch on (diagram 1 of 2) Fuse 10a Fuse 15a Fuse 20a Fuse 30a Fuse 30a red Fuse 50a Headlights systems Instrument cluster system Passenger compartment fuse box (behind left kick panel) Pnk Power mirrors system Power tops system Power window relay Rear window defroster relay Red S101 S201 (next to passenger compartment fuse box) S303 (below front passenger seat) Starting/ charging system Warning systems Wiper/washer system
POWER DOOR LOCKS Power Door Lock Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Power Door Lock Wiring Diagram for Daewoo Lanos SE 1999: 28 (hatchback) (notchback) Anti-theft system C351 C361 C371 C381 C403 C451 Central door locking relay (behind right kick panel) Engine room relay & fuse box (left side of engine room) Fuse 1 80a Fuse 4 15a G301 (below left front seat) G303 (below right front seat) Hot at all times Left front central door locking switch Left front door actuator (w/anti theft) Left rear door actuator (notchback) Lock Nca Passenger room fuse box (behind left kick panel) Red Right front door actuator Right rear door actuator S302 (below driver's seat) Tail- gate lock actuator Un- lock
POWER MIRRORS Power Mirror Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Power Mirror Wiring Diagram for Daewoo Lanos SE 1999: 13 Down, (lower) Electric outside rearview mirror switch Fuse 15a G201 (below right front of console box) Hot in on or start Left Left, right motor Passenger room fuse box (behind left kick panel) Pnk Right Right electric outside rearview mirror S203 (next to passenger room fuse box) Upper, lower motor
POWER TOP/SUNROOF Power Top/Sunroof Wiring Diagrams for Daewoo Lanos SE 1999 List of elements for Power Top/Sunroof Wiring Diagrams for Daewoo Lanos SE 1999: 15 Close Engine room relay & fuse box (left side of engine room) Fuse 10a Fuse 30a G306 (center front of roof) Hot at all times Hot in on Open Other Passenger room fuse box (behind left kick panel) Pnk Red Sun roof module (at center front of roof) Sun roof motor (at center front of roof) Sun roof switch
POWER WINDOWS Power Window Wiring Diagram, Hatchback for Daewoo Lanos SE 1999 List of elements for Power Window Wiring Diagram, Hatchback for Daewoo Lanos SE 1999: 15 C361 Engine room relay & fuse box (at left side of engine room) Fuse 10a Fuse 30a G102 (front of left front fender) G303 (below right front seat) Hot at all times Hot in on Left front power window motor Passenger room fuse box (behind left kick panel) Power window relay (in engine room relay & fuse box) Power window switch Red Right front power window motor S101 (in engine room relay & fuse box) Power Window Wiring Diagram, Sedan for Daewoo Lanos SE 1999 List of elements for Power Window Wiring Diagram, Sedan for Daewoo Lanos SE 1999: 23 C361 C381 Down Engine room relay & fuse box (at left side of engine room) Fuse 10a Fuse 30a G102 G303 Hot at all times Hot in on Left front power window motor Left rear power window motor Left rear sub switch Lock Passenger room fuse box (behind left kick panel) Power window main switch Power window relay (in engine room relay & fuse box) Red Right front power window motor Right rear power window motor Right rear sub switch S101 (in engine room relay & fuse box) Unlock
RADIO Radio Wiring Diagrams for Daewoo Lanos SE 1999 List of elements for Radio Wiring Diagrams for Daewoo Lanos SE 1999: 20 Audio Bat Engine room fuse and relay box (left side of engine room) Fuse 1 80a Fuse 6 10a Fuse 9 10a G201 (below right front of console box) Gnd Hot at all times Hot in accy and on Ign Illum Interior lights system Left front speaker Left rear speaker Passenger room fuse box (behind left kick panel) Red Right front speaker Right rear speaker S203 (behind left kick panel)
SHIFT INTERLOCKS Shift Interlock Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Shift Interlock Wiring Diagram for Daewoo Lanos SE 1999: 21 Btsi solenoid Diode (stop lamp s/w upper) Engine room fuse box Exterior lamps system Fuse 10a Fuse 15a Fuse 20a Fuse 80a G105 G201 Hot at all times Hot in accy and on Hot in on Key interlock solenoid Key interlock unit (above passenger room fuse box) Park/neutral position switch (on top of transaxle) Passenger room fuse box (behind left kick panel) Pnk Red Splice pack s203 (behind left kick panel) Stop lamp switch (on brake pedal support bracket)
STARTING/CHARGING Charging Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Charging Wiring Diagram for Daewoo Lanos SE 1999: 20 Acc Alternator Battery C201 C206 Charging warning lamp Engine room relay and fuse box (left side of engine room) Fuse 15a Fuse 30a G101 (behind battery) G106 (upper bolt of starter motor) Ignition switch Instrument cluster Off Passenger room fuse box (behind kick panel) Pnk Red S201 (behind right side of dash) Start Starter motor Starting Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Starting Wiring Diagram for Daewoo Lanos SE 1999: 18 A/t Acc Alternator Battery C104 C201 Clutch switch Engine room relay and fuse box (left side of engine room) Fuse 30a G101 (behind battery) G106 (upper bolt of starter) Ignition switch M/t Off Park/neutral position switch (nsbu switch) (behind left side of dash) Red Start Starter motor
SUPPLEMENTAL RESTRAINTS Supplemental Restraint Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Supplemental Restraint Wiring Diagram for Daewoo Lanos SE 1999: 16 Air bag ind Airbag control unit(sdm) Cluster Contact coil Data Driver air bag module Fuse 10a Fuse 15a G302 (below right front of console) Hot in run or start Link connector Nca Passenger air bag module Passenger room fuse box Pnk S201
TRANSMISSION Transmission Wiring Diagram (1 of 2) for Daewoo Lanos SE 1999 List of elements for Transmission Wiring Diagram (1 of 2) for Daewoo Lanos SE 1999: 20 2-3 solenoid signal Automatic transmission solenoid (right side of trans) Engine coolant temperature (ect) sensor (on right side of engine, below intake manifold) Fuse 10a Fuse 15a Ground Hot at all times Hot in on & start Nca Passenger compartment fuse box (behind left kick panel) Pcs Pnk Powertrain control module (pcm) (under right front seat) Red S303 (below passenger seat) Signal (tcc) Solenoid a Solenoid b Tcc solenoid Throttle position (tp) sensor (on top front of engine) Transmission Wiring Diagram (2 of 2) for Daewoo Lanos SE 1999 List of elements for Transmission Wiring Diagram (2 of 2) for Daewoo Lanos SE 1999: 36 (1999) (2000-01) (below right front seat) 12v signal 5v signal D2 lo Driver Ect signal Front seat) G301 G303 Ground Ig+ Injector 4 ground signal Instrument cluster Iss Iss signal Module (pcm) (under right Nca Oil pressure switch assy connector P.r.n.d4 Pnk Power mode switch Powertrain control Pressure switch assembly Pwr warning lamp S201 (next to passenger compt relay box) Signal a Signal b Signal c Tcc off Tcc signal Tps signal Transmission fluid temperature sensor Vehicle speed sensor (vss) (on lower right front of transaxle) Vss signal
WARNING SYSTEMS Warning System Wiring Diagrams for Daewoo Lanos SE 1999 List of elements for Warning System Wiring Diagrams for Daewoo Lanos SE 1999: 24 Chime bell (behind left kick panel) Diode Engine room relay & fuse box (left side of engine room) Fuse 10a Fuse 80a G201 (below right front of console box) G301 (below left front seat) Hot at all times Hot in on or start Hot w/ illumination relay energized Instrument cluster Interior lights system Key reminder switch Left front door contact switch Nca Passenger room fuse box (behind left kick panel) Pnk Red S201 (behind left kick panel) S203 (behind left kick panel) S204 (above glove box) S301 (below left front seat) Seat belt switch Seat belt warning lamp
WIPER/WASHER Front Wiper/Washer Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Front Wiper/Washer Wiring Diagram for Daewoo Lanos SE 1999: 20 31b 53c 53e Front washer switch Front windshield washer pump (left corner of engine room, on washer reservoir) Front wiper motor Front wiper relay (above passenger room fuse box) Front wiper switch Fuse 10a G102 (front of left front fender) G201 (below right front of console) Hot in on Int Multifunction switch Off Passenger room fuse box (behind left kick panel) Pnk S201 (next to passenger room relay box) S202 (next to passenger room relay box) S203 (next to passenger room relay box) Rear Wiper/Washer Wiring Diagram for Daewoo Lanos SE 1999 List of elements for Rear Wiper/Washer Wiring Diagram for Daewoo Lanos SE 1999: 15 Front wiper motor Front wiper motor switch Front wiper relay Fuse 18 20a G102 (front of left front fender) G301 (below left front seat) Hot in on Multifunction switch Passenger room fuse box (behind left kick panel) Pnk Rear washer pump Rear washer switch Rear wiper motor Rear wiper switch S201 (next to passenger room relay box)
