VW JETTA 2007 – Body electrical . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW JETTA 2007 - Cigarette lighter - Number plate light

L15	Ashtray illumination bulb
L16	Fresh air regulator illumination bulb
L28	Cigarette lighter illumination bulb
SC21	Fuse 21 on fuse holder C
T2	2-pin connector
U1	Cigarette lighter
X	Number plate light
213	Earth connection, in dash panel wiring harness
390	Earth connection 25, in main wiring harness
437	Earth connection, in number plate wiring harness
670	Earth point 2, left A-pillar
B157	Positive connection 3 (15a), in interior wiring harness
B235	Positive connection 4 (15a), in interior wiring harness
B280	Positive connection 4 (15a) in main wiring harness
B348	Connection 1 (75a), in main wiring harness
W41	Positive connection (58), in number plate lights wiring harness

Wiring Diagram VW JETTA 2007 - Left fog light bulb - Right fog light bulb - Left side light bulb - Front left turn signal bulb - Left headlight dipped beam bulb - Left headlight main beam bulb

Get access to all wiring diagrams of the car

L22	Left fog light bulb
L23	Right fog light bulb
M1	Left side light bulb
M5	Front left turn signal bulb
M29	Left headlight dipped beam bulb
M30	Left headlight main beam bulb
SC1	Fuse 1 on fuse holder C
SC11	Fuse 11 on fuse holder C
T10x	10-pin connector
B554	Connection (fog light), in main wiring harness
C12	Positive connection 1, in headlight wiring harness

Wiring Diagram VW JETTA 2007 - Right side light bulb - Left tail light bulb - Rear left turn signal bulb - Front right turn signal bulb - Left reversing light bulb - Left turn signal repeater bulb - Left brake and tail light bulb - Right headlight dipped beam bulb - Right headlight main beam bulb

Get access to all wiring diagrams of the car

M3	Right side light bulb
M4	Left tail light bulb
M6	Rear left turn signal bulb
M7	Front right turn signal bulb
M16	Left reversing light bulb
M18	Left turn signal repeater bulb
M21	Left brake and tail light bulb
M31	Right headlight dipped beam bulb
M32	Right headlight main beam bulb
SC2	Fuse 2 on fuse holder C
SC12	Fuse 12 on fuse holder C
T5m	5-pin connector
T10y	10-pin connector
119	Earth connection 1, in headlight wiring harness
120	Earth connection 2, in headlight wiring harness
671	Earth point 1, on front of left longitudinal member
685	Earth point 1 at front of right longitudinal member
A84	Connection (58L), in dash panel wiring harness
W6	Connection (left turn signal), in rear wiring harness
W80	Connection 2 in rear wiring harness

Wiring Diagram VW JETTA 2007 - Right tail light bulb - Rear right turn signal bulb - Right reversing light bulb - Right turn signal repeater bulb - Right brake and tail light bulb

Get access to all wiring diagrams of the car

M2	Right tail light bulb
M8	Rear right turn signal bulb
M17	Right reversing light bulb
M19	Right turn signal repeater bulb
M22	Right brake and tail light bulb
T5n	5-pin connector
86	Earth connection 1, in rear wiring harness
701	Earth point in luggage compartment
A85	Connection (58R), in dash panel wiring harness
W7	Connection (right turn signal), in rear wiring harness
W71	Connection (reversing light), in rear wiring harness
W80	Connection 2 in rear wiring harness

Wiring Diagram VW JETTA 2007 - Switch and instrument illumination regulator - Headlight main beam relay - Fuse 2 in fuse holder A

Get access to all wiring diagrams of the car

E20	Switch and instrument illumination regulator
J12	Headlight main beam relay
SA2	Fuse 2 in fuse holder A
T9a	9-pin connector
501	Threaded connection 2 (30), on relay plate
B166	Connection (56a), in interior wiring harness
B167	Connection (56b), in interior wiring harness
B169	Positive connection 1 (30), in interior wiring harness
B170	Positive connection 2 (30), in interior wiring harness
C15	Connection 1, in headlight wiring harness
C16	Connection 2, in headlight wiring harness

Wiring Diagram VW JETTA 2007 - Ignition/starter switch - Turn signal switch - Headlight flasher switch - Parking light switch - Fuse 29 on fuse holder C

Get access to all wiring diagrams of the car

D	Ignition/starter switch
E2	Turn signal switch
E5	Headlight flasher switch
E19	Parking light switch
SC7	Fuse 7 on fuse holder C
SC8	Fuse 8 on fuse holder C
SC29	Fuse 29 on fuse holder C
T5a	5-pin connector
T7a	7-pin connector
A43	Connection (57L), in dash panel wiring harness
A44	Connection (57r), in dash panel wiring harness
B166	Connection (56a), in interior wiring harness
B167	Connection (56b), in interior wiring harness
B298	Positive connection 2 (30), in main wiring harness

Wiring Diagram VW JETTA 2007 - Light switch - Fuse 3 on fuse holder C - Fuse 24 on fuse holder C - Fuse 25 on fuse holder C

Get access to all wiring diagrams of the car

E1	Light switch
E7	Fog light switch
E18	Rear fog light switch
J5	Fog light relay
K17	Fog light warning lamp
L9	Light switch illumination bulb
SC3	Fuse 3 on fuse holder C
SC24	Fuse 24 on fuse holder C
SC25	Fuse 25 on fuse holder C
SC43	Fuse 43 on fuse holder C
T17	17-pin connector
X3	Rear fog light
B226	Connection 3 (radio), in interior wiring harness
*	Up to September 2007
*2	From September 2007

Wiring Diagram VW JETTA 2007 - Hazard warning light switch - Heated rear window switch - Air conditioning system switch - Rear lid release switch - Warning lamp - Heated rear window

Get access to all wiring diagrams of the car

E3	Hazard warning light switch
E9	Fresh air blower switch
E15	Heated rear window switch
E30	Air conditioning system switch
E165	Rear lid release switch
F38	Ambient temperature switch
K6	Indicator lamp for hazard warning light
K10	Heated rear window warning lamp
K84	Air conditioning system warning lamp
K96	Warning lamp
N63	Two-way valve for fresh air and air recirculation flap
SC17	Fuse 17 on fuse holder C
SC18	Fuse 18 on fuse holder C
SC35	Fuse 35 on fuse holder C
SC48	Fuse 48 on fuse holder C
T6	6-pin connector
T6c	6-pin connector
T17a	17-pin connector
Z1	Heated rear window
51	Earth point, on right in luggage compartment
B622	Connection (windscreen wiper), in main wiring harness

Wiring Diagram VW JETTA 2007 - Luggage compartment light switch - Dual tone horn relay - Fuse 14 on fuse holder C - Rear lid release motor - Luggage compartment light

Get access to all wiring diagrams of the car

F4	Reversing light switch
F5	Luggage compartment light switch
H	Horn plate
H1	Horn or dual tone horn
J4	Dual tone horn relay
SC13	Fuse 13 on fuse holder C
SC14	Fuse 14 on fuse holder C
SC20	Fuse 20 on fuse holder C
T7a	7-pin connector
T10d	10-pin connector
V139	Rear lid release motor
W3	Luggage compartment light
50	Earth point, on left in luggage compartment
87	Earth connection 2, in rear wiring harness
B610	Connection 6, in interior wiring harness
E112	Connection (horn, 87h), in dash panel wiring harness

Wiring Diagram VW JETTA 2007 - Brake light switch - Clutch pedal switch - Brake pedal switch - Main relay - Additional brake light bulb

Get access to all wiring diagrams of the car

F	Brake light switch
F36	Clutch pedal switch
F47	Brake pedal switch
J104	ABS control unit
J271	Main relay
J361	Simos control unit
M25	Additional brake light bulb
N152	Ignition transformer
SC41	Fuse 41 on fuse holder C
SC46	Fuse 46 on fuse holder C
SC51	Fuse 51 on fuse holder C
T4a	4-pin connector
T4h	4-pin connector
T9	9-pin connector
T10	10-pin connector
T10a	10-pin connector
T26	26-pin connector
T121	121-pin connector
A20	Positive connection (15a), in dash panel wiring harness
B432	Connection (foot operated parking brake), in main wiring harness
B611	Connection 7, in interior wiring harness
*	Only models with manual gearbox

Wiring Diagram VW JETTA 2007 - Alternator - Control unit in dash panel insert

Get access to all wiring diagrams of the car

C	Alternator
G2	Coolant temperature display sender
J285	Control unit in dash panel insert
SC26	Fuse 26 on fuse holder C
T2	2-pin connector
T4	4-pin connector
T4y	4-pin connector
T10b	10-pin connector
T10c	10-pin connector
T32	32-pin connector
277	Earth connection 3, in interior wiring harness
639	Earth point, left A-pillar
B225	Connection 2 (radio), in interior wiring harness
*	According to equipment

Wiring Diagram VW JETTA 2007 - Speedometer sender - Control unit in dash panel insert - Simos control unit

Get access to all wiring diagrams of the car

G	Fuel gauge sender
G22	Speedometer sender
J285	Control unit in dash panel insert
J361	Simos control unit
SC15	Fuse 15 on fuse holder C
SC16	Fuse 16 on fuse holder C
T3m	3-pin connector
T4i	4-pin connector
T10b	10-pin connector
T10d	10-pin connector
T32	32-pin connector
T32a	32-pin connector
T121	121-pin connector
B383	Connection 1 (powertrain CAN bus, high), in main wiring harness
B390	Connection 1 (powertrain CAN bus, low), in main wiring harness

Wiring Diagram VW JETTA 2007 - Immobiliser reader coil - Oil pressure switch - Handbrake warning switch - Brake fluid level warning contact - Control unit in dash panel insert

Get access to all wiring diagrams of the car

D2	Immobiliser reader coil
F1	Oil pressure switch
F9	Handbrake warning switch
F34	Brake fluid level warning contact
J285	Control unit in dash panel insert
T10c	10-pin connector
T32	32-pin connector
T32a	32-pin connector
A115	Connection (handbrake warning), in dash panel wiring harness

Wiring Diagram VW JETTA 2007 - Diagnostic connection

Get access to all wiring diagrams of the car

SC31	Fuse 31 on fuse holder C
T16	16-pin connector
U31	Diagnostic connection
A76	Connection (K-diagnosis wire), in dash panel wiring harness
