| B | Starter |
| D | Ignition/starter switch |
| F4 | Reversing light switch |
| J217 | Automatic gearbox control unit, in front right footwell |
| J226 | Starter inhibitor and reversing light relay (175), on 13 position additional relay carrier |
| S15 | Fuse in fuse holder |
| T9 | 9-pin connector |
| T10d | 10-pin connector, brown, on protective housing for control units on left in engine compartment |
| T15m | 15-pin connector, brown, right A-pillar coupling station |
| T68a | 68-pin connector, on automatic gearbox control unit |
| 30 | Earth point 1, next to relay plate |
| 81 | Earth connection 1, in dash panel wiring harness |
| 135 | Earth connection 2, in dash panel wiring harness |
| 501 | Screw connection 2 (30), on relay plate |
| A1 | Positive connection (30a), in dash panel wiring harness |
| A32 | Positive connection (30), in dash panel wiring harness |
| A86 | Connection (50a), in dash panel wiring harness |
| A87 | Connection (RL), in dash panel wiring harness |
| F125 | Multifunction switch |
| J217 | Automatic gearbox control unit, in front right footwell |
| J280 | Radiator fan V7 relay - 2nd speed |
| T7 | 7-pin connector, on Multifunction switch |
| T15m | 15-pin connector, brown, right A-pillar coupling station |
| T68a | 68-pin connector, on automatic gearbox control unit |
| 43 | Earth point, lower part of right A-pillar |
| 114 | Earth connection, in automatic gearbox wiring harness |
| U3 | Connection 1, in automatic gearbox wiring harness |
| U6 | Connection 2, in automatic gearbox wiring harness |
| * | Only models with diesel engine |
| F | Brake light switch |
| G93 | Gearbox oil temperature sender |
| J217 | Automatic gearbox control unit, in front right footwell |
| J285 | Display control unit, in dash panel insert |
| N88 | Solenoid valve 1 |
| N89 | Solenoid valve 2 |
| N90 | Solenoid valve 3 |
| N91 | Solenoid valve 4 |
| N92 | Solenoid valve 5 |
| N93 | Solenoid valve 6 |
| N94 | Solenoid valve 7 |
| T13 | 13-pin connector, on gearbox |
| T15m | 15-pin connector, brown, right A-pillar coupling station |
| T16 | 16-pin connector, self-diagnosis connection |
| T32a | 32-pin connector, blue, on dash panel insert |
| T68a | 68-pin connector, on automatic gearbox control unit |
| A76 | Connection (K-diagnosis wire), in dash panel wiring harness |
| A89 | Connection 2 (54), in dash panel wiring harness |
| G38 | Gearbox output speed sender |
| G68 | Vehicle speed sender |
| J... | Engine control units |
| J217 | Automatic gearbox control unit, in front right footwell |
| J285 | Control unit in dash panel insert |
| T3 | 3-pin connector, brown |
| T3a | 3-pin connector, black |
| T10h | 10-pin connector, blue, on protective housing for control units, T15m - 15-pin connector, brown, right A-pillar coupling station |
| T32b | 32-pin connector, green |
| T68a | 68-pin connector, on automatic gearbox control unit |
| A121 | Connection (high bus), in dash panel wiring harness |
| A122 | Connection (low bus), in dash panel wiring harness |
| D | Ignition/starter switch |
| E20 | Switch and instrument illumination regulator |
| J217 | Automatic gearbox control unit, in front right footwell |
| K142 | Selector lever position P/N warning lamp |
| L101 | Selector lever display illumination bulb |
| N110 | Selector lever lock solenoid |
| S231 | Fuse in fuse holder |
| T3m | 3-pin connector, brown, right A-pillar coupling station |
| T4 | 4-pin connector, brown, under centre console |
| T15m | 15-pin connector, brown, right A-pillar coupling station |
| T68a | 68-pin connector, on automatic gearbox control unit |
| A2 | Positive connection (15), in dash panel wiring harness |
| A19 | Connection (58d), in dash panel wiring harness |
| A70 | Connection (15a, fuse 231), in dash panel wiring harness |
