| E96 | Backrest adjustment switch, driver's seat |
| E190 | Emergency-off button |
| E208 | Front height adjustment button, upwards, driver's seat |
| E209 | Front height adjustment button, downwards, driver's seat |
| E210 | Rear height adjustment button, upwards, driver's seat |
| E211 | Rear height adjustment button, downwards, driver's seat |
| E212 | Longitudinal adjustment button, forwards, driver's seat |
| E213 | Longitudinal adjustment button, backwards, driver's set |
| E218 | Memory seat driver's 1 button |
| E219 | Memory seat driver's 2 button |
| E220 | Memory seat driver's 3 button |
| J136 | Seat adjustment (with memory) control unit |
| T16 | 16-pin connector, black |
| T28 | 28-pin connector, on seat adjustment (with memory) control unit |
| F4 | Reversing light switch |
| J59 | X contact relief relay |
| J136 | Seat adjustment (with memory) control unit |
| S11 | Fuse in relay plate fuse box |
| T4a | 4-pin connector, black, on front height adjustment motor, driver's seat |
| T4b | 4-pin connector, black, on longitudinal adjustment motor, driver's seat |
| T4c | 4-pin connector, black, on rear height adjustment motor, driver's seat |
| T6 | 6-pin connector, red, near driver's seat |
| T10 | 10-pin connector, brown, near driver's seat |
| T10v | 10-pin connector, pink, right A pillar |
| T12 | 12-pin connector, black, on seat adjustment (with memory) control unit |
| T28 | 28-pin connector, on seat adjustment (with memory) control unit |
| V28 | Longitudinal adjustment motor, driver's seat |
| V29 | Front height adjustment motor, driver's seat |
| V30 | Seat rear height adjustment motor, driver's |
| 503 | Screw connection (75x), on relay plate |
| A80 | Connection -1- (X), in dash panel wiring harness |
| A87 | Connection (RL), in dash panel wiring harness |
| J136 | Seat adjustment (with memory) control unit |
| S44 | Seat adjustment thermo-fuse 1 |
| T2 | 2-pin connector |
| T4d | 4-pin connector, black, on backrest adjustment motor, driver's seat |
| T6 | 6-pin connector |
| T8b | 8-pin connector, on seat adjustment (with memory) control unit |
| T10 | 10-pin connector, brown, near driver's seat |
| T10b | 10-pin connector, green |
| T10g | 10-pin connector, grey, connector point left A-pillar |
| T28 | 28-pin connector, on seat adjustment (with memory) control unit |
| V45 | Backrest adjustment motor, driver's seat |
| 44 | Earth point, lower part of left A-pillar |
| 500 | Screw connection -1- (30), on relay plate |
| J136 | Seat adjustment (with memory) control unit |
| J386 | Door control unit, driver's side |
| S37 | Window lifter thermo-fuse |
| T10 | 10-pin connector, brown, near driver's seat |
| T10b | 10-pin connector, green |
| T10g | 10-pin connector, grey, connector point left A-pillar |
| T10l | 10-pin connector, black |
| T28 | 28-pin connector, on seat adjustment (with memory) control unit |
| T29a | 29-pin connector, in door control unit, driver's side |
| 307 | Earth connection (sender earth), in floor wiring harness |
| 500 | Screw connection -1- (30), on relay plate |
| W3 | Connection in rear wiring harness |
| W39 | Connection (mirror memory), in floor wiring harness |
| W65 | Connection (convenience CAN bus, low), in floor wiring harness |
| J386 | Door control unit, driver's side |
| K133 | Central locking warning lamp -SAFE- |
| T10g | 10-pin connector, grey, connector point left A-pillar |
| T10l | 10-pin connector, black |
| T12a | 12-pin connector, black |
| T29a | 29-pin connector, in door control unit, driver's side |
| V17 | Mirror adjustment motor, driver's side |
| V121 | Folding mirror motor, driver's side |
| V149 | Mirror adjustment motor, driver's side |
| Z4 | Heated exterior mirror, driver's side |
| 44 | Earth point, lower part of left A-pillar |
| 205 | Earth connection, in door wiring harness - driver's side |
| R27 | Connection (mirror adjustment), in door wiring harness - driver's side |
| W64 | Connection (convenience CAN bus, high), in floor wiring harness |
| F221 | Central locking lock unit, front passenger's side |
| J387 | Door control unit, front passenger's side |
| T10w | 10-pin connector, black, connector point, right A pillar |
| T12b | 12-pin connector, black |
| T29b | 29-pin connector, on door control unit, front passenger's side |
| V25 | Mirror adjustment motor, front passenger's side |
| V122 | Folding mirror motor, front passenger's side |
| V150 | Mirror adjustment motor, front passenger's side |
| Z5 | Heated exterior mirror, front passenger's side |
| 43 | Earth point, lower part of right A-pillar |
| 206 | Earth connection, in door wiring harness - front passenger's side |
| R36 | Connection (mirror adjustment), in door wiring harness - front passenger's side |
| W3 | Connection in rear wiring harness |
| W64 | Connection (convenience CAN bus, high), in floor wiring harness |
| W65 | Connection (convenience CAN bus, low), in floor wiring harness |
