| E20 | Switches and instruments, lighting control |
| E102 | Headlight range control adjuster |
| L54 | Headlight range control adjuster light bulb |
| S20 | Fuse in fuse box |
| S21 | Fuse in fuse box |
| T6d | 6-pin connector, yellow, A pillar, right |
| T6k | 6-pin connector, red, connector point, A pillar, right |
| T6z | 6-pin connector, pink, A pillar, right |
| T10s | 10-pin connector, pink, connector point left A pillar |
| T10t | 10-pin connector, red, connector point, left A pillar |
| V48 | Headlight range control motor, left |
| V49 | Headlight range control motor, right |
| 81 | Earth connection -1-, in dash panel wiring harness |
| 135 | Earth connection -2-, in dash panel wiring harness |
| A51 | Connection (56), in dash panel wiring harness |
| A113 | Connection -2- (daytime driving lights), in dash panel wiring harness |
| C17 | Connection (56b) -1-, in front lighting wiring harness |
| C18 | Connection (56b) -2-, in front lighting wiring harness |
| D | Ignition/starter switch |
| E1 | Lighting switch |
| E18 | Rear fog light switch |
| J285 | Control unit with display in dash panel insert |
| K13 | Rear fog light warning lamp |
| L9 | Lighting switch light bulb |
| L46 | Rear fog light bulb, left |
| S3 | Fuse in fuse box |
| S236 | Fuse in fuse box |
| T6c | 6-pin connector, blue |
| T6v | 6-pin connector, violet, connector point, A pillar, right |
| T32a | 32-pin connector, blue, on dash panel insert |
| W6 | Glove box light |
| 32 | Earth point, behind dash panel, left |
| 81 | Earth connection -1-, in dash panel wiring harness |
| 503 | Screw connection (75x), on relay plate |
| A3 | Positive (+) connection (58), in dash panel wiring harness |
| A19 | Connection (58d), in dash panel wiring harness |
| A37 | Connection (58a), in dash panel wiring harness |
| A51 | Connection (56), in dash panel wiring harness |
| A80 | Connection -1- (X), in dash panel wiring harness |
| A83 | Connection (daytime driving lights), in dash panel wiring harness |
| A113 | Connection -2- (daytime driving lights), in dash panel wiring harness |
| E2 | Turn signal switch |
| E3 | Hazard warning light switch |
| E4 | Headlight dipper/flasher switch |
| E19 | Parking light switch |
| M1 | Side light bulb, left |
| M5 | Turn signal bulb, front left |
| M18 | Side turn signal bulb, left |
| M29 | Dipped beam bulb, left |
| M30 | Main beam bulb, left |
| S19 | Fuse in fuse box |
| T7a | 7-pin connector, on hazard warning light switch |
| T10k | 10-pin connector, on headlight, left |
| T10s | 10-pin connector, pink, connector point, left A pillar |
| T12 | 12-pin connector, next to steering column right |
| 44 | Earth point, lower part of left A-pillar |
| 179 | Earth connection, in left headlight wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| A32 | Positive (+) connection (30), in dash panel wiring harness |
| A51 | Connection (56), in dash panel wiring harness |
| A95 | Connection -1- (56a), in dash panel wiring harness |
| C20 | Connection (turn signal, left), in headlight wiring harness |
| K1 | Main beam warning lamp |
| M3 | Side light bulb, right |
| M7 | Turn signal bulb, front right |
| M19 | Side turn signal bulb, right |
| M31 | Dipped beam bulb, right |
| M32 | Main beam bulb, right |
| S18 | Fuse in fuse box |
| T6d | 6-pin connector, pink, connector point, right A pillar |
| T10j | 10-pin connector, on headlight, right |
| T32a | 32-pin connector, blue, on dash panel insert |
| 43 | Earth point, lower part of right A-pillar |
| 176 | Earth connection, in right headlight wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A95 | Connection -1- (56a), in dash panel wiring harness |
| C19 | Connection -1- (turn signal, right), in headlight wiring harness |
| J285 | Control unit with display in dash panel insert |
| M21 | Brake and tail light bulb, left |
| M22 | Brake and tail light bulb, right |
| M25 | High level brake light bulb |
| S4 | Fuse in fuse box |
| S22 | Fuse in fuse box |
| S223 | Fuse in fuse box |
| T2 | 2-pin connector, in tailgate/bootlid |
| T2a | 2-pin connector, on left luggage compartment (not with Variant) |
| T6 | 6-pin connector, black, in luggage compartment, left (only Variant) |
| T10a | 10-pin connector, brown, connector point, left A-pillar |
| T32a | 32-pin connector, blue, on dash panel insert |
| X | Number plate light |
| 57 | Earth point, left rear pillar |
| 87 | Earth connection -2-, in rear wiring harness |
| 196 | Earth connection -3-, in rear wiring harness |
| A85 | Connection (58R), in dash panel wiring harness |
| * | Not Variant |
| --- | Only Variant |
