VW JETTA 2007 – Dash panel insert, BHP . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW JETTA 2007 - Battery - Control unit in dash panel insert - Dash panel insert

A	Battery
B	Starter
D	Ignition/starter switch
F4	Reversing light switch
J285	Control unit in dash panel insert
K	Dash panel insert
S7	Fuse 7 in fuse holder
S11	Fuse 11 in fuse holder
S15	Fuse 15 in fuse holder
S176	Fuse 4 (30), in battery fuse holder
S177	Fuse 5 (30), in battery fuse holder
T8	8-pin connector
T10	10-pin connector
T32	32-pin connector
1	Earth strap, battery - body
2	Earth strap, gearbox - body
500	Threaded connection 1 (30), on relay plate
501	Threaded connection 2 (30), on relay plate
A2	Positive connection (15), in dash panel wiring harness
B163	Positive connection 1 (15), in interior wiring harness

D2	Immobiliser reader coil
G5	Rev. counter
J1	Turn signal relay
J285	Control unit in dash panel insert
J362	Immobiliser control unit
K	Dash panel insert
K117	Immobiliser warning lamp
L75	Digital display illumination bulb
R	Radio
T8a	8-pin connector
T8d	8-pin connector
T16	16-pin connector
T32	32-pin connector
T32a	32-pin connector
A4	Positive connection (58b), in dash panel wiring harness
A76	Connection (K-diagnosis wire), in dash panel wiring harness

G21	Speedometer
G22	Speedometer sender
J31	Automatic intermittent wash and wipe relay
J220	Motronic control unit
J248	Diesel direct injection system control unit
J285	Control unit in dash panel insert
K	Dash panel insert
T10	10-pin connector
T14a	14-pin connector
T18a	18-pin connector
T32	32-pin connector
T32a	32-pin connector
T121	121-pin connector
Y4	Trip counter
A27	Connection (speed signal), in dash panel wiring harness

J220	Motronic control unit
J248	Diesel direct injection system control unit
J285	Control unit in dash panel insert
J533	Data bus diagnostic interface
K	Dash panel insert
K105	Reserve fuel warning lamp
K166	Door open warning lamp
T10w	10-pin connector
T16	16-pin connector
T32a	32-pin connector
T80i	80-pin connector
T121	121-pin connector

C	Alternator
E1	Light switch
J285	Control unit in dash panel insert
K	Dash panel insert
K2	Alternator warning lamp
M1	Left side light bulb
M4	Left tail light bulb
M33	Front left side marker bulb
S223	Fuse 23 in fuse holder
T2e	2-pin connector
T4	4-pin connector
T5h	5-pin connector
T6a	6-pin connector
T10b	10-pin connector
T17	17-pin connector
T32	32-pin connector
Y2	Digital clock
A84	Connection (58L), in dash panel wiring harness
*	Connection for air conditioning system

E4	Headlight dipper and flasher switch
J285	Control unit in dash panel insert
K	Dash panel insert
K1	Main beam warning lamp
K32	Brake pad warning lamp
L1	Left headlight twin filament bulb
L2	Right headlight twin filament bulb
S18	Fuse 18 in fuse holder
S19	Fuse 19 in fuse holder
T10b	10-pin connector
T10c	10-pin connector
T12	12-pin connector
T32	32-pin connector
A51	Connection (56), in dash panel wiring harness
B166	Connection (56a), in interior wiring harness

E1	Light switch
G34	Front left brake pad wear sender
H3	Buzzer and gong
J285	Control unit in dash panel insert
K	Dash panel insert
M2	Right tail light bulb
M3	Right side light bulb
M34	Front right side marker bulb
S22	Fuse 22 in fuse holder
T2c	2-pin connector
T5i	5-pin connector
T6b	6-pin connector
T10c	10-pin connector
T17	17-pin connector
T32	32-pin connector
T32a	32-pin connector
135	Earth connection 2, in dash panel wiring harness
A85	Connection (58R), in dash panel wiring harness

D	Ignition/starter switch
F9	Handbrake warning switch
G33	Windscreen washer fluid level sender
J89	Daytime running lights changeover relay
J285	Control unit in dash panel insert
K	Dash panel insert
K14	Handbrake warning lamp
K118	Brake system warning lamp
R	Radio
S10	Fuse 10 in fuse holder
T8	8-pin connector
T8a	8-pin connector
T32	32-pin connector
T32a	32-pin connector
42	Earth point, next to steering column
49	Earth point, near ..., near steering column
81	Earth connection 1, in dash panel wiring harness
135	Earth connection 2, in dash panel wiring harness
269	Earth connection (sender earth) 1, in dash panel wiring harness
A21	Connection (86s), in dash panel wiring harness

F34	Brake fluid level warning contact
K	Dash panel insert
K37	Washer fluid level warning lamp
K65	Left turn signal warning lamp
K94	Right turn signal warning lamp
M5	Front left turn signal bulb
M7	Front right turn signal bulb
M18	Left turn signal repeater bulb
M19	Right turn signal repeater bulb
T10b	10-pin connector
T10c	10-pin connector
T32	32-pin connector
119	Earth connection 1, in headlight wiring harness
120	Earth connection 2, in headlight wiring harness
642	Earth point for electronically controlled fan
A5	Positive connection (right turn signal), in dash panel wiring harness
A6	Positive connection (left turn signal), in dash panel wiring harness
