VW JETTA 2007 – Anti-lock brake system (ABS) with electronic differential lock (EDL), traction control system (TCS) and electronic stabilisation program (ESP), RHD, BHP . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW JETTA
  4. >VW JETTA 2007
  5. >VW JETTA 2007 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW JETTA 2007 - TCS and ESP button - ABS control unit - Stabilization program button illumination bulb



Wiring Diagram VW JETTA 2007 - TCS and ESP button - ABS control unit - Stabilization program button illumination bulb https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
A Battery
D Ignition/starter switch
E20 Switch and instrument illumination regulator
E256 TCS and ESP button
J104 ABS control unit
L115 Stabilization program button illumination bulb
S9 Fuse 9 in fuse holder
S178 Fuse 6 (30), in battery fuse holder
S179 Fuse 7 (30), in battery fuse holder
T3 3-pin connector
T3c 3-pin connector
T6q 6-pin connector
T8 8-pin connector
T47a 47-pin connector
  A2 Positive connection (15), in dash panel wiring harness
  A4 Positive connection (58b), in dash panel wiring harness
  A38 Positive connection 2 (15a) in dash panel wiring harness
  A132 Connection (TCS/ESP), in dash panel wiring harness

Wiring Diagram VW JETTA 2007 - Steering angle sender - ABS control unit - Rear right ABS inlet valve - Rear left ABS inlet valve - Rear right ABS outlet valve - Rear left ABS outlet valve - Vehicle stabilization program switch valve 1 - Vehicle stabilization program switch valve 2



Wiring Diagram VW JETTA 2007 - Steering angle sender - ABS control unit - Rear right ABS inlet valve - Rear left ABS inlet valve - Rear right ABS outlet valve - Rear left ABS outlet valve - Vehicle stabilization program switch valve 1 - Vehicle stabilization program switch valve 2 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G85 Steering angle sender
J104 ABS control unit
J217 Automatic gearbox control unit
J220 Motronic control unit
N133 Rear right ABS inlet valve
N134 Rear left ABS inlet valve
N135 Rear right ABS outlet valve
N136 Rear left ABS outlet valve
N225 Vehicle stabilization program switch valve 1
N226 Vehicle stabilization program switch valve 2
T6p 6-pin connector
T10w 10-pin connector
T47a 47-pin connector
T68a 68-pin connector
T121 121-pin connector
  A121 Connection (high bus), in dash panel wiring harness
  A122 Connection (low bus), in dash panel wiring harness
*Only models with automatic gearbox

Wiring Diagram VW JETTA 2007 - Rear right speed sensor - Front right speed sensor - Rear left speed sensor - Front left speed sensor - ABS control unit - Front right ABS outlet valve - Front left ABS outlet valve



Wiring Diagram VW JETTA 2007 - Rear right speed sensor - Front right speed sensor - Rear left speed sensor - Front left speed sensor - ABS control unit - Front right ABS outlet valve - Front left ABS outlet valve https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G44 Rear right speed sensor
G45 Front right speed sensor
G46 Rear left speed sensor
G47 Front left speed sensor
J104 ABS control unit
N99 Front right ABS inlet valve
N100 Front right ABS outlet valve
N101 Front left ABS inlet valve
N102 Front left ABS outlet valve
N227 Vehicle stabilization program high-pressure valve 1
N228 Vehicle stabilization program high-pressure valve 2
T47a 47-pin connector

Wiring Diagram VW JETTA 2007 - Brake pressure sender 1 - ABS control unit - ABS hydraulic pump



Wiring Diagram VW JETTA 2007 - Brake pressure sender 1 - ABS control unit - ABS hydraulic pump https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G200 Lateral acceleration sender
G201 Brake pressure sender 1
G202 Yaw rate sender
G419 ESP sensor unit
J104 ABS control unit
T47a 47-pin connector
V64 ABS hydraulic pump

Wiring Diagram VW JETTA 2007 - Handbrake warning switch - ABS control unit



Wiring Diagram VW JETTA 2007 - Handbrake warning switch - ABS control unit https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
F Brake light switch
F9 Handbrake warning switch
J104 ABS control unit
S15 Fuse 15 in fuse holder
T4y 4-pin connector
T16 16-pin connector
T47a 47-pin connector
  501 Threaded connection 2 (30), on relay plate
  671 Earth point 1, on front of left longitudinal member
  A18 Connection (54), in dash panel wiring harness
  A76 Connection (K-diagnosis wire), in dash panel wiring harness
  A167 Positive connection 3 (30a) in dash panel wiring harness

Wiring Diagram VW JETTA 2007 - Daytime running lights changeover relay - Control unit in dash panel insert - Data bus diagnostic interface - ABS warning lamp - Brake system warning lamp - ESP and TCS warning lamp



Wiring Diagram VW JETTA 2007 - Daytime running lights changeover relay - Control unit in dash panel insert - Data bus diagnostic interface - ABS warning lamp - Brake system warning lamp - ESP and TCS warning lamp https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J89 Daytime running lights changeover relay
J285 Control unit in dash panel insert
J533 Data bus diagnostic interface
K47 ABS warning lamp
K118 Brake system warning lamp
K155 ESP and TCS warning lamp
T32 32-pin connector
T32a 32-pin connector
  A76 Connection (K-diagnosis wire), in dash panel wiring harness

Wiring Diagram VW JETTA 2007 - Brake fluid level warning contact - Front left brake pad wear sender - Control unit in dash panel insert - Brake pad warning lamp



Wiring Diagram VW JETTA 2007 - Brake fluid level warning contact - Front left brake pad wear sender - Control unit in dash panel insert - Brake pad warning lamp https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
F34 Brake fluid level warning contact
G34 Front left brake pad wear sender
J285 Control unit in dash panel insert
K32 Brake pad warning lamp
T2c 2-pin connector
T32 32-pin connector
T32a 32-pin connector
  42 Earth point, next to steering column
  49 Earth point, near ..., near steering column
  81 Earth connection 1, in dash panel wiring harness
  119 Earth connection 1, in headlight wiring harness
  120 Earth connection 2, in headlight wiring harness
  135 Earth connection 2, in dash panel wiring harness
  642 Earth point for electronically controlled fan
