VW JETTA 2007 – Powertrain CAN bus network and convenience system, BHP . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW JETTA 2007 - Driver door control unit - Front passenger door control unit - Rear left door control unit - Rear right door control unit

J386	Driver door control unit
J387	Front passenger door control unit
J388	Rear left door control unit
J389	Rear right door control unit
J393	Convenience system central control unit
T10k	10-pin connector
T10l	10-pin connector
T10t	10-pin connector
T10u	10-pin connector
T18a	18-pin connector
T18b	18-pin connector
T23	23-pin connector
T29	29-pin connector
T29a	29-pin connector
B229	Connection (high bus), in interior wiring harness
B230	Connection (low bus), in interior wiring harness

D	Ignition/starter switch
J220	Motronic control unit
J248	Diesel direct injection system control unit
J285	Control unit in dash panel insert
S5	Fuse 5 in fuse holder
S12	Fuse 12 in fuse holder
T8	8-pin connector
T16	16-pin connector
T32	32-pin connector
T32a	32-pin connector
T80	80-pin connector
T121	121-pin connector
42	Earth point, next to steering column
49	Earth point, near ...
81	Earth connection 1, in dash panel wiring harness
135	Earth connection 2, in dash panel wiring harness
501	Threaded connection 2 (30), on relay plate
A2	Positive connection (15), in dash panel wiring harness
A20	Positive connection (15a), in dash panel wiring harness
A76	Connection (K-diagnosis wire), in dash panel wiring harness
B229	Connection (high bus), in interior wiring harness
B230	Connection (low bus), in interior wiring harness

J104	ABS control unit
J234	Airbag control unit
J533	Data bus diagnostic interface
T32a	32-pin connector
T47a	47-pin connector
T68a	68-pin connector
T75	75-pin connector
A121	Connection (high bus), in dash panel wiring harness
A122	Connection (low bus), in dash panel wiring harness
B229	Connection (high bus), in interior wiring harness
B230	Connection (low bus), in interior wiring harness

G85	Steering angle sender
J217	Automatic gearbox control unit
J220	Motronic control unit
J248	Diesel direct injection system control unit
T6p	6-pin connector
T10w	10-pin connector
T68	68-pin connector
T80	80-pin connector
T121	121-pin connector
A121	Connection (high bus), in dash panel wiring harness
A122	Connection (low bus), in dash panel wiring harness
