VW JETTA 2007 – Air conditioning system, BHP . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW JETTA 2007 - Fresh air and air recirculation flap switch - Fresh air and air recirculation warning lamp - Fresh air regulator illumination bulb - Fresh air and air recirculation flap control motor

D	Ignition/starter switch
E20	Switch and instrument illumination regulator
E159	Fresh air and air recirculation flap switch
K114	Fresh air and air recirculation warning lamp
L16	Fresh air regulator illumination bulb
S5	Fuse 5 in fuse holder
T3c	3-pin connector
T8	8-pin connector
T8b	8-pin connector
T10j	10-pin connector
V154	Fresh air and air recirculation flap control motor
162	Earth connection, in blower motor wiring harness
A2	Positive connection (15), in dash panel wiring harness
A4	Positive connection (58b), in dash panel wiring harness
A20	Positive connection (15a), in dash panel wiring harness

E9	Fresh air blower switch
N24	Fresh air blower series resistor with overheating fuse
S225	Fuse 25 in fuse holder
T4c	4-pin connector
T6d	6-pin connector
T10j	10-pin connector
V2	Fresh air blower
45	Earth point, centre behind dash panel
162	Earth connection, in blower motor wiring harness
503	Threaded connection (75x), on relay plate
L45	Connection, in air conditioning system operating unit wiring harness
L66	Connection, in heater blower wiring harness

D	Ignition/starter switch
E35	Selector lever for retarder brake
F38	Ambient temperature switch
J217	Automatic gearbox control unit
J220	Motronic control unit
J248	Diesel direct injection system control unit
J285	Control unit in dash panel insert
J293	Radiator fan control unit
K84	Air conditioning system warning lamp
S16	Fuse 16 in fuse holder
T8	8-pin connector
T8b	8-pin connector
T10	10-pin connector
T10j	10-pin connector
T14	14-pin connector
T32a	32-pin connector
T68	68-pin connector
T80	80-pin connector
T121	121-pin connector
501	Threaded connection 2 (30), on relay plate
A32	Positive connection (30), in dash panel wiring harness
A52	Positive connection 2 (30), in dash panel wiring harness
A98	Positive connection 4 (30), in dash panel wiring harness
L9	Connection 1, in air conditioning system wiring harness
L45	Connection, in air conditioning system operating unit wiring harness
*	Only models with automatic gearbox
*2	Only models with manual gearbox

J293	Radiator fan control unit
N25	Air conditioning system magnetic clutch
T3a	3-pin connector
T3b	3-pin connector
T4	4-pin connector
T4a	4-pin connector
T14	14-pin connector
V7	Radiator fan
V35	Radiator fan on right of radiator
193	Earth connection 1, in coolant fan wiring harness
642	Earth point for electronically controlled fan
C11	Connection in radiator fan wiring harness
K21	Connection 1, in radiator fan wiring harness

A	Battery
F18	Radiator fan thermal switch
G65	High-pressure sender
J293	Radiator fan control unit
S164	Fuse 3 (30), in battery fuse holder
S180	Fuse 8 (30), in battery fuse holder
T3	3-pin connector
T3e	3-pin connector
T4a	4-pin connector
T14	14-pin connector
193	Earth connection 1, in coolant fan wiring harness
D61	Connection (air conditioning system), in engine compartment wiring harness
K20	Positive connection 1 (30), in radiator fan wiring harness
K21	Connection 1, in radiator fan wiring harness
