Электросхемы БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ Isuzu Trooper Limited 2001

БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ

Электросхема блока предохранителей и реле (1 из 3) для Isuzu Trooper Limited 2001

Электросхема блока предохранителей и реле (1 из 3) для Isuzu Trooper Limited 2001 - Список элементов:

• A/t
• Alarm & relay control unit
• Alternator
• Anti-theft horn
• Anti-theft indicator light
• B-6
• Battery
• Brake switch
• C-14 stoplight a/t cont fuse 15a
• C-15 (audio [b]) fuse 20a
• C-16 clock [b] dome light fuse 10a
• C-17 rr defog fuse 25a
• C-18 (door lock) fuse 20a
• C/b-2 (p/w, p/s, s/r) cb 30a
• Clock
• D-5
• Dash fuse box
• Dash fuse box (left kick panel)
• Data link connector (dlc)
• Dome light
• Driver's power seat switch
• Ecm or pcm main relay
• Electronic brake control module (ebcm)
• Engine control module (ecm) or powertrain control module (pcm)
• F-12 tail fuse 15a
• F-3 horn hazard fuse 15a
• F-8 front fog fuse 15a
• F-9 abs fuse 20a
• Fl-1 main fuse 80a
• Fl-2 key sw fuse 50a
• Fl-3 pcm fuse 30a
• Fl-6 (abs 4/wheel only) fuse 40a
• Fog- light relay
• Fuel pump relay
• Fuse/ relay box
• Fuse/ relay box (right side of engine compt)
• Hazard warning switch
• Heater & a/c relay
• Horn relay
• I-10
• I-15
• Key remind switch
• Keyless entry & security control unit
• Left front courtesy light
• Left front door power window & lock switch
• Left rear courtesy light
• Lighting relay
• Luggage room light
• Map lights
• Meter assembly
• P-2
• P-4
• P-9
• Power window relay
• Radio
• Rear window defogger relay
• Red
• Red/
• Right front courtesy light
• Right front power seat switch
• Right rear courtesy light
• Shift lock controller
• Starter
• Starter relay
• Starter solenoid
• Starter switch
• Taillight relay
• To starter switch (diagram 2 of 3)

Электросхема блока предохранителей и реле (2 из 3) для Isuzu Trooper Limited 2001

Электросхема блока предохранителей и реле (2 из 3) для Isuzu Trooper Limited 2001 - Список элементов:

• 4wd control unit
• 4wd switch
• A/t
• Acc
• Accessory meter
• Alarm & relay control unit
• B-48
• B-49
• B-52
• B-6
• B-7
• Brake switch
• C-11 (audio [acc]) mirror fuse 10a
• C-12 cigar fuse 20a
• C-13 (anti- theft) fuse 10a
• C-2 (seat heater) fuse 15a
• C-4 elec ign fuse 15a
• C-5 frt wiper & washer fuse 15a
• C-6 rr wiper & washer fuse 10a
• C-7 (not used)
• Cigarette lighter
• Clock
• Clutch switch
• Combination switch
• Cruise control main switch
• Cruise control switch
• Dash fuse box (left kick panel)
• Driver's seat heater switch
• Electronic brake control module (ebcm)
• From fuse fl-2 a (diagram 1 of 3)
• G-sensor abs
• G203 (right kick panel)
• I-15
• I-21
• I-22
• Keyless entry & security control unit
• Lock
• M/t
• Mirror control switch
• Mirror defogger switch
• Mirror folding switch
• Off
• Power window relay
• Radio
• Rear defogger switch
• Rear window defogger relay
• Rear wiper motor
• Rear wiper/washer switch
• Red
• Right front seat heater switch
• Shift lock controller
• Start
• Starter switch
• To dash fuse box fuse c-3 (turn-back) fuse (diagram 3 of 3)
• To fuse c-1 (diagram 3 of 3)
• To fuse c-8 (diagram 3 of 3)
• Tod control unit
• Transmission switch 1-2
• Windshield wiper motor

Электросхема блока предохранителей и реле (3 из 3) для Isuzu Trooper Limited 2001

Электросхема блока предохранителей и реле (3 из 3) для Isuzu Trooper Limited 2001 - Список элементов:

• (diagram 2 of 3)
• (except s model)
• (s model)
• A/t
• A/t shift indicator control unit
• Alternator
• Automatic transmission mode switch
• Back-up light switch
• C-1 starter relay fuse 10a
• C-10 meter gauge fuse 10a
• C-21 srs-1 fuse 10a
• C-3 turn back fuse 15a
• C-8 engine fuse 15a
• C-9 ign coil fuse 15a
• Clutch start switch
• Condenser
• Cornering light relay
• Dash fuse box (left kick panel)
• Ecm or pcm main relay
• Evaporative emission (evap) canister cut valve
• Evaporative emission (evap) canister purge valve
• From dash fuse box c-4 elec ign fuse (diagram 2 of 3)
• From starter switch b
• From starter switch c
• Fuse/ relay box (right side of engine compt)
• Hazard warning switch
• I-9
• Ignition coil 1
• Ignition coil 2
• Ignition coil 3
• Ignition coil 4
• Ignition coil 5
• Ignition coil 6
• Ion sensing module
• M/t
• Mass air- flow (maf) sensor
• Meter assembly
• P-8
• Srs fuse box (left kick panel)
• Srs unit
• Variable intake manifold vacuum switching valve
• Vehicle speed sensor (vss)
