Электросхемы ПРИБОРНАЯ ПАНЕЛЬ Isuzu Amigo XS 1994

ПРИБОРНАЯ ПАНЕЛЬ

Электросхема панели приборов (1 из 2) для Isuzu Amigo XS 1994

Электросхема панели приборов (1 из 2) для Isuzu Amigo XS 1994 - Список элементов:

• & 2.6l
• (2.3l) (2.6l) (3.1l)
• (2.6l 0nly)
• (left side kick panel)
• (right front fender)
• 2.3l
• 2.3l 2.6l
• 2.6l
• 3.1l
• 4wd indicator light
• 4wd indicator switch (on right side of transmission)
• A10
• A11
• A12
• B10
• B11
• B12
• Brake warning light
• C214 c211 c218
• C274
• C275
• Charge warning light
• Combination valve pressure differential switch (left rear of eng compt, in brake fluid valve)
• Diode box d (behind left side of i/p, taped to harness)
• Engine control module (left side of i/p, at kick panel)
• Engine controls system
• Engine controls system (ecm)
• Engine coolant temperature gauge
• Exterior lights system
• Fuel gauge
• G101
• G200
• Head- lights system
• Hi beam indicator light
• Ignition coil (right rear corner of eng)
• Ignition coil (top center of eng, on valve cover)
• Illumination (w/o tacho- meter: 2 bulbs, w/ tacho- meter: 9 bulbs)
• Instrument cluster
• Interior lights system
• Internal voltage regulator
• Left turn signal indi- cator light
• Low fuel warning light
• Malfunction indicator lamp (mil) (check engine)
• O/d off indicator light (2.6l a/t)
• O2 sensor indicator light
• Oil pressure gauge (2.3l federal 3.1l)
• Oil pressure warning light
• Parking brake switch (on parking brake lever)
• Pnk
• Rear anti- lock brake warning light
• Rear wheel anti-lock brake controller (below right front seat)
• Right turn signal indi- cator light
• Seat belt warning light
• Starting/ charging system
• Tachometer (2.6l & 3.1l)
• To anti-lock brakes system (rear wheel anti-lock brake controller)
• Vehicle speed sensor
• Vehicle speed sensor buffer (beneath right front seat)
• Voltage meter (2.6l & 3.1l)
• Warning systems

Электросхема панели приборов (2 из 2) для Isuzu Amigo XS 1994

Электросхема панели приборов (2 из 2) для Isuzu Amigo XS 1994 - Список элементов:

• (rear of left fender)
• (right side of i/p)
• 10a
• 2.3l
• 2.6l
• 3.1l
• Bulb check relay (left side of eng compt, on inner fender panel)
• Clutch start switch (on clutch pedal support)
• Dash fuse box (left side of i/p)
• Diode box c (left side of i/p, taped to harness)
• Engine controls system (diode box a)
• Engine coolant temperature (ect) gauge sender (2.3l & 2.6l: right front of eng, below intake manifold) (3.1l: left front corner of eng, near power steering)
• Fuel tank unit (right side fuel tank)
• Fuse 12
• Fuse 7
• G104
• G114 (left rear of engine)
• G201
• G409 (rear of cargo bed)
• Hot in on or start
• Hot in start
• Oil pressure sending unit (w/ tachometer) (lower right front of eng, near oil filter)
• Oil pressure switch (lower right rear of eng, above oil pan)
• Oil pressure switch (lower right rear of eng, below oil filter)
• Overdrive cancel relay (in fuse/relay box)
• Overdrive off solenoid (on left side of transmission)
• Overdrive off switch (at the base of transmission lever, beneath trim)
• Pnk
• Starting/ charging system (ecm & starter relay)
