Электросхемы ПРИБОРНАЯ ПАНЕЛЬ Isuzu Rodeo Sport 2001

ПРИБОРНАЯ ПАНЕЛЬ

Электросхема панели приборов (1 из 2) для Isuzu Rodeo Sport 2001

Электросхема панели приборов (1 из 2) для Isuzu Rodeo Sport 2001 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file

Электросхема панели приборов (1 из 2) для Isuzu Rodeo Sport 2001 - Список элементов:

  • (2.2l)
  • (3.2l)
  • (a/t)
  • (hot in on or start) engine controls system (pcm main relay)
  • (m/t)
  • (not used)
  • 2 indicator
  • 2.2l
  • 2.2l a/t or 3.2l
  • 2.2l m/t
  • 3 indicator
  • 3.2l
  • A/t gear position indicator
  • Anti-lock brake system
  • Anti-lock brakes system
  • Cruise control system
  • Cruise set indicator light
  • D indicator
  • Dash fuse box (behind dash, left of steering column)
  • Data link connector (lower left side of dash)
  • Driver's seat belt switch (in seat belt buckle)
  • Electronic suspension system
  • Exterior lights system
  • Fuse 11 meter 15a
  • Fuse 14 back up/ turn light 15a
  • G104 (left rear corner of engine compt)
  • G104 (left rear corner of engine compt, on inner fender panel)
  • G120 (right side of intake manifold)
  • G302 (under center console)
  • Gauge assembly
  • Headlights system
  • High beam indicator light
  • Hot in on or start
  • Interior lights system
  • L indicator
  • Left turn indicator light
  • Meter lights (4)
  • Muliti-plexed indicator control unit (under rear of center console)
  • N indicator
  • Oil pressure switch (near oil filter)
  • P indicator
  • Pnk
  • Power drive indicator light
  • R indicator
  • Right turn indicator light
  • Starting/charging system
  • Transmissions system
  • Upshift indicator light
  • Vehicle speed sensor (right side of trans) (rear of trans)
  • Warning systems
  • Winter drive indicator light

Электросхема панели приборов (2 из 2) для Isuzu Rodeo Sport 2001

Электросхема панели приборов (2 из 2) для Isuzu Rodeo Sport 2001 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема панели приборов (2 из 2) для Isuzu Rodeo Sport 2001 - Список элементов:

  • (2.2l)
  • (2.2l) c2
  • (2.2l: on rear of engine, in coolant mainfold)
  • (3.2l)
  • (3.2l) e22
  • (not used)
  • (on parking brake lever)
  • 10.1 ohms
  • 4wd indicator light
  • A/t fluid indicator light
  • A11
  • A12
  • Abs indicator light
  • Air bag readiness indicator light
  • Automatic trans mode switch (beneath center of vehicle, on left side of transmission)
  • B13
  • Brake fluid level switch (in reservoir)
  • Brake system warning light
  • C11
  • Charging system warning light
  • Check trans indicator light
  • Clutch switch (on clutch pedal support)
  • Diode box b
  • E21
  • E22
  • Ect sensor (3.2l: on right front of engine)
  • Electronic brake control module (right rear corner of engine compt)
  • Electronic suspension system
  • Engine controls system
  • Engine coolant temperature gauge
  • Engine or powertrain control module (below center of dash) (left rear of engine compt)
  • F15
  • Fuel gauge
  • Fuel tank sender
  • Fuel tank unit (beneath rear of vehicle, in top of fuel tank)
  • Fuse/ relay box (on right side of engine compt)
  • G104 (left rear corner of engine compt, on inner fender panel)
  • Gauge assembly
  • Intelligent suspension system warning light
  • Low fuel warning light
  • Malfunction indicator light
  • Oil pressure indicator light
  • Park brake switch
  • Pnk
  • Powertrain control module (left rear of engine compt) (below center of dash)
  • Reduced power indicator light
  • Seat belt reminder light
  • Speedometer/ odometer/ trip meter
  • Tachometer
