Электросхема коробки передач АКПП (1 из 4) для Dodge Stratus ES 1995

Электросхема коробки передач АКПП (1 из 4) для Dodge Stratus ES 1995 - Список элементов:

• (near breakout for fog/lamp battery temp sensor)
• (near breakout for output speed sensor)
• 2-4 press sw
• 2-4 pressure switch
• 2-4 sol ctrl
• 2-4 solenoid
• A24
• A41
• Body control module
• C122
• C124
• C213
• C214
• C228
• C229
• C230
• Ccd bus (+)
• Ccd bus (-)
• F11
• Fuse 11 10a
• Fused (b+)
• Fused ign out
• Fused ign sw output (off/run/start)
• G102 (left strut tower)
• Gnd
• Hot in off, run or start
• Input spd sns sig
• Instrument cluster
• Junction block
• K22
• K24
• Low/ reverse pressure switch
• Low/ reverse solenoid
• Low/rev press
• Low/rev sol. ctrl
• Od solenoid ctrl
• Output shaft speed sensor (front of transmission)
• Over- drive solenoid
• Overdrive pressure switch
• Panel lamps driver
• Pnp sw sense
• Prnd3l
• Prndl control
• Prndl illumination l.e.d.
• Prndl indicator
• Prndl sw sense
• S101
• Sensor gnd
• Speed sens gnd
• T10
• T13
• T14
• T15
• T16
• T19
• T20
• T41
• T42
• T47
• T50
• T52
• T59
• T60
• Torq mgmt req
• Tps sig
• Trans rly out
• Transmission control module (left fender side shield)
• Transmission solenoid & pressure switch assembly (front of transmission)
• Turbine speed sensor (front of transmission)
• Ud solenoid ctrl
• Under- drive solenoid
• Vss sig
• Z13
• Z14

Электросхема коробки передач АКПП (2 из 4) для Dodge Stratus ES 1995

Электросхема коробки передач АКПП (2 из 4) для Dodge Stratus ES 1995 - Список элементов:

• (left strut tower) g102
• (not used)
• Acc
• Back-up lamp relay (6)
• C220
• Engine coolant temperature sensor (right front of engine) (2.0l & 2.4l engines) (left side of engine) (2.5l engine)
• Exterior lights system (back-up lamps)
• Fuse 10 10a
• Fuse 3 20a
• Fuse 4 20a
• Fuse 5 20a
• Fuse 8 20a
• Fuse 9 10a
• G102 (left strut tower)
• Hot at all times
• Ignition switch
• Intake air temperature sensor (on intake)
• Lock
• Off
• Park/neutral position switch (front of transmission)
• Power distribution center
• Prndl switch (front of transmission)
• Red
• Red/ tan
• Rn3
• Run
• S101
• S102
• S104
• S105
• S106
• Start
• Transmission control relay (2)

Электросхема коробки передач АКПП (3 из 4) для Dodge Stratus ES 1995

Электросхема коробки передач АКПП (3 из 4) для Dodge Stratus ES 1995 - Список элементов:

• (in breakout for pcm)
• (internal to power distribution center)
• (left strut tower) g102
• (near breakout for pcm)
• (not used)
• 2.0l & 2.4l engines
• 2.5l engine
• A/c compressor clutch relay (7)
• C124
• Ckp sensor signal
• Coil
• Crankshaft position sensor (right rear of engine) (2.0l & 2.4l engines) (rear of distributor) (2.5l engine)
• Engine starter motor relay (9)
• External battery temperature sensor (left side of radiator closure panel)
• Fuse 15a
• Gnd
• High speed radiator fan relay (12)
• Hot in run
• Junction block
• Low speed radiator fan relay (11)
• Manifold absolute pressure sensor (right side of intake)
• Partial splice; (in breakout for pcm)
• Partial splice; (near breakout for fuel injectors) (2.0l & 2.4l engines) (near idle air control motor breakout) (2.5l engine)
• Partial splice; (near breakout for intake air temp sensor) (2.0l & 2.4l engines) (near fuel injector no.6 breakout) (2.5l engine)
• Power distribution center
• Red
• Red/tan
• S109
• Sensor gnd
• Servo on/off switch
• Starting/ charging system (engine starter motor)
• Stop lamp switch (top of brake pedal)
• Throttle position sensor (side of throttle body)
• Tp sens sig
• Vac sol.
• Vehicle speed control servo (left strut tower)
• Vehicle speed control switch
• Vent sol.

Электросхема коробки передач АКПП (4 из 4) для Dodge Stratus ES 1995

Электросхема коробки передач АКПП (4 из 4) для Dodge Stratus ES 1995 - Список элементов:

• (in breakout for left headlamp)
• (left kick panel) g200
• (left strut tower) g102
• (near breakout for intake air temp sensor) (2.0l & 2.4l engines) (near egr breakout) (2.5l engine)
• A/c comp rly ctrl
• A/c press sig
• A/c pressure transducer (top of a/c compressor) (2.0l & 2.4l engines) (right front of engine) (2.5l engine)
• A14
• A21
• Abs control module (right fender side shield)
• Amb temp sns sig
• Body control module
• Brake sw sense
• C108
• C122
• C124
• C125
• C163
• C18
• C225
• C226
• C230
• C24
• C27
• C28
• C314
• Ccd bus (+)
• Ccd bus (-)
• Ckp sens sig
• D20
• D21
• Data link connector (left side of steering column)
• Ect sensor sig
• F12
• Fuse 5 10a
• Fused b (+)
• Fused ign sw out (run/start)
• G200 (left kick panel)
• Gnd
• High spd rly ctrl
• Iat sens sig
• Ign
• Ign (run/start)
• Junction block
• K10
• K21
• K22
• K24
• K25
• K29
• Low spd rly ctrl
• Map sens sig
• P/s press sw sense
• Pnk
• Pnp sw sense
• Power steering pressure switch (left side of steering gear)
• Powertrain control module (left fender side shield)
• Red/tan
• S101
• Sc on/off sw
• Sc sw sig on/off
• Sc vac sol ctrl
• Sc vent sol ctrl
• Sci receive
• Sci transmit
• Sens gnd
• Speed proportional steering module (rear of engine compartment, on steering rack)
• T10
• T41
• Torque req sense
• Tp sens sig
• V32
• V35
• V36
• V37
• Vss signal
• Z12
