Электросхемы ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG Dodge Grand Caravan SE 2007

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag (1 из 2) для Dodge Grand Caravan SE 2007

Электросхема подушек безопасности SRS AirBag (1 из 2) для Dodge Grand Caravan SE 2007 - Список элементов:

• (behind right side of dash) g201
• Automatic a/c
• D25
• Driver knee blocker air bag squib (below steering column)
• Driver seat belt tensioner (on seat harness)
• Drv belt sw sens
• Drv ke squib ln 1
• Drv ke squib ln 2
• Drv squib 1 ln 1
• Drv squib 1 ln 2
• Drv squib 2 ln 1
• Drv squib 2 ln 2
• Except occupant sensing
• F100
• F201
• Front control module
• G104
• Ground
• Instrument panel switch bank
• Integrated power module (left side of engine compartment)
• Left front impact sensor (near break out for c101)
• Left side impact sensor 3 (at left quarterpanel)
• Left squib ln 1
• Left squib ln 2
• Line 1
• Line 2
• Manual a/c
• Nca
• Occupant restraint controller (behind right side of dash)
• Occupant sensing
• Orc run driver
• Orc run-start
• Orc run-start driver
• Pass belt sw sens
• Pass belt tens ln1
• Pass belt tens ln2
• Pass squib 1 ln 1
• Pass squib 1 ln 2
• Pass squib 2 ln 1
• Pass squib 2 ln 2
• Passenger air bag (right side of dash)
• Passenger air bag on/off indicator lamp
• Passenger seat belt switch (occupant sensing) (at switch on seat harness)
• Pci bus
• R11
• R13
• R14
• R15
• R16
• R17
• R18
• R19
• R20
• R21
• R22
• R23
• R24
• R42
• R43
• R44
• R45
• R53
• R54
• R55
• R56
• R57
• R58
• R59
• R60
• R61
• R62
• R63
• R64
• R79
• R80
• R81
• R82
• Right curtain air bag squib (at rear of right roof rail)
• Right front impact sensor
• Right side impact sensor 3 (at right quarterpanel)
• Right squib ln 1
• Right squib ln 2
• S223 (near breakout for multi- function switch)
• S373 (in floor pan track wiring)
• Sensor ground
• Sensor signal
• Signal
• Sw sense
• W/ occupant sensing
• W/ side air bag
• W/o side air bag
• Z12

Электросхема подушек безопасности SRS AirBag (2 из 2) для Dodge Grand Caravan SE 2007

Электросхема подушек безопасности SRS AirBag (2 из 2) для Dodge Grand Caravan SE 2007 - Список элементов:

• (at right "b" pillar) g301
• (near breakout for a/c heater control) s207
• Air bag warning indicator
• Battery b(+)
• Belt tension sensor
• Clockspring
• Computer data lines system
• D105
• D25
• Driver air bag squib 1
• Driver air bag squib 2
• Driver seat belt switch (at switch on seat harness)
• Except side air bag
• F201
• G200 (behind left side of dash)
• Ground
• Hot at all times
• In steering column)
• Instrument cluster
• Left curtain air bag squib (rear of left roof rail)
• Left side impact sensor 1 (at left "b" pillar)
• Left side impact sensor 2 (in left sliding door)
• Line
• Line 1
• Line 2
• Nca sens pwr nca sens ground nca sens signal
• Occupant classification module (in passenger seat)
• Orc run-start
• Passenger seat belt tensioner (base of right "b" pillar)
• Passenger seat weight sensor (in passenger seat)
• Pci bus
• R740
• R741
• R86
• R941
• R986
• Right side impact sensor 1 (at right "b" pillar)
• Right side impact sensor 2 (in right sliding door)
• Sens ground
• Sens pwr
• Sens signal
• Side air bag
• Signal
• Sw sense
• Z104
