Электросхемы ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG Jeep Compass Limited 2007

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag (1 из 2) для Jeep Compass Limited 2007

Электросхема подушек безопасности SRS AirBag (1 из 2) для Jeep Compass Limited 2007 - Список элементов:

72

• (passenger side of instrument panel)
• (rear of steering wheel pad)
• Air bag warning
• B(+)
• Bank switch
• Can b bus (+)
• Can b bus (-)
• Can b(+)
• Can b(-)
• Cluster
• D506
• D54
• D55
• Driver air bag squib 1
• Driver air bag squib 2
• Driver seat belt tensioner (driver side "b" pillar)
• Driver seat track position sensor (right rear of driver seat)
• Electronics
• F100
• F200
• Fuse 10a
• G300 (center body, below instrument panel)
• Ground
• Hot at all times
• Left seat air bag
• Lin bus
• Line
• Line 1
• Line 2
• Occupant restraint controller module (under center console)
• Passenger air bag off
• Passenger air bag squib 1
• Passenger air bag squib 2
• Passenger seat belt tensioner (passenger side "b" pillar)
• Passenger seat track position sensor (right rear of passenger seat)
• R13
• R14
• R15
• R16
• R261
• R262
• R263
• R264
• R42
• R43
• R44
• R45
• R53
• R54
• R55
• R56
• R61
• R62
• R63
• R64
• R79
• R80
• R81
• R82
• Red
• Right seat air bag
• Run
• Run-start
• Run/start
• S207
• S301
• S302
• Signal
• Steering control module (at steering column)
• Totally integrated power module (left side of eng compt)
• Voltage
• Z944

Электросхема подушек безопасности SRS AirBag (2 из 2) для Jeep Compass Limited 2007

Электросхема подушек безопасности SRS AirBag (2 из 2) для Jeep Compass Limited 2007 - Список элементов:

58

• (left side body)
• (passenger seat) left front seat weight sensor
• (passenger seat) left rear seat weight sensor
• (passenger seat) right front seat weight sensor
• (passenger seat) right rear seat weight sensor
• (right front of engine compt)
• 5v sens
• A952
• Can b bus (+)
• Can b bus (-)
• Computer data lines system
• D54
• D55
• Driver seat track position sensor (right rear of driver seat)
• Drv sens data
• Drv sens volt
• Fuse 10a
• Fused b (+)
• G300 (center body below instrument panel)
• Gnd
• Ground
• Hot at all times
• Left front impact sensor
• Left front seat weight signal
• Left rear seat weight signal
• Left side air bag curtain
• Left side impact sensor 1 (base of left "b" pillar)
• Left side impact sensor 2 (above left rear wheelwell)
• Line
• Occupant classification module (front of passenger seat)
• Pass sens data
• Pass sens volt
• Passenger seat track position sensor (right rear of passenger seat)
• R261
• R262
• R263
• R264
• R701
• R705
• R706
• R717
• R718
• R728
• Right front impact sensor
• Right front seat weight signal
• Right side air bag curtain
• Right side impact sensor 1 (base of right "b" pillar)
• Right side impact sensor 2 (above right rear wheelwell)
• S310
• S377
• S378
• Seat weight sensor 5 volt
• Seat weight sensor ground
• Sens gnd
• Sens sig
• Signal
• Totally integrated power module (left side of eng compt)
• Z944
