AIR CONDITIONING – Dodge Neon R/T 1998 – SYSTEM WIRING DIAGRAMS

AIR CONDITIONING

A/C Wiring Diagram for Dodge Neon R/T 1998

List of elements for A/C Wiring Diagram for Dodge Neon R/T 1998:

• A/c compressor clutch
• A/c compressor clutch relay
• A/c cycling switch (center of hvac housing)
• A/c heater blower motor
• A/c heater control
• A/c high pressure switch (on top of a/c compressor)
• A/c low pressure switch (on right side of firewall, on expansion valve)
• A/c rly control
• A/c sw sense
• All times
• Bi- level
• Blower motor resistor block (on right side of firewall)
• Blower-hi
• Blower-lo
• Blower-m1
• Blower-m2
• Controller anti-lock brake
• Def
• Def/ flr
• Diode no. 1
• Fan relay (solid state) (on left inner frame, behind radiator)
• Flr
• Fuse 10a
• Fuse 15a
• Fuse 25a
• Fuse 30a
• Fuse block
• G100 (top left side of radiator closure panel)
• G101 (right radiator closure panel)
• G202 (left side of i/p center support)
• Hi-a/c
• Hot at
• Hot at all times
• Hot in run
• Interior lights system
• Lo-a/c
• M1-a/c
• M2-a/c
• Off
• Panel
• Power distribution center
• Powertrain control module (on left front inner fender)
• Rad rly control
• Radiator fan motor
• S109 (engine compt harn, before breakout to left headlamp)
• S111 (engine compt harness, in breakout to pcm)
• S204 (i/p harness, near hvac connector)
• S211 (i/p harness, near breakout to cluster)
• Sunroof system
• Tan

Heater Wiring Diagram for Dodge Neon R/T 1998

List of elements for Heater Wiring Diagram for Dodge Neon R/T 1998:

• (left side of i/p center support)
• Blower motor resistor block (on right side of firewall)
• Fuse 25a
• Fuse block
• G202
• Heater blower motor
• Heater control
• Hot in run
• Interior lights system
• Off
• S204 (i/p harness, near hvac connector)
• Sunroof system
• Tan
