AIR CONDITIONING – Nissan 350Z 2006 – SYSTEM WIRING DIAGRAMS

AIR CONDITIONING

Automatic A/C Wiring Diagram (1 of 2) for Nissan 350Z 2006

List of elements for Automatic A/C Wiring Diagram (1 of 2) for Nissan 350Z 2006:

• (power) gnd
• 2a m4
• 3b m5
• A/c controller
• A/c led
• Air mix door motor (behind center of dash)
• Amb sens
• Ambient sensor (near right front corner of vehicle)
• B5 (w/ navigation) (on left front side
• Bat
• Blower motor (behind right side of dash)
• Body control module (bcm) (behind left kick panel)
• Can-h
• Can-l
• Comp on
• Comp on sig
• Computer data lines system
• Defogger system
• Fan on
• Fan on sig
• Fan pwm out
• Fan sw
• Fre led
• Fuse 10a
• Fuse 15a
• Fuse block (j/b) (behind left kick panel)
• Gnd
• Hot at all times
• Hot in acc or on
• Hot in on or start
• Ign
• Ign2
• Ill
• In-vehicle sensor (behind left center of dash)
• Incar sens
• Intake door motor (behind right side of dash)
• Intake sens
• Intake sensor (behind right center of dash)
• Interior lights system
• Lan sig
• M48
• M49
• M50
• M66 (behind left center of dash)
• M66 (w/o navigation) (behind left center of dash)
• M90
• Mode door motor (behind center of dash)
• Mode sw
• Nca
• Of passenger's compt floor)
• Pnk
• Push sw
• Rec led
• Red
• Rr def f/b
• Rr def on
• Rr/def led
• Rx (comb meter)
• Sens gnd
• Sun sens
• Sunload sensor (on right defroster grille)
• Sw sel 1
• Sw sel 2
• Sw sel 3
• Temp sw
• Tx (comb meter)
• Unified meter & a/c amplifier (behind center of dash)
• Vactr
• Vbl
• Vbl2
• Vdd

Automatic A/C Wiring Diagram (2 of 2) for Nissan 350Z 2006

List of elements for Automatic A/C Wiring Diagram (2 of 2) for Nissan 350Z 2006:

• +ig
• A/c relay
• Air comp
• Avcc gnd
• Can-h
• Can-l
• Compressor (left front side of engine)
• Computer data lines system
• Cooling fan motor 1 (in front of radiator)
• Cooling fan motor 2 (in front of radiator)
• Cooling fan relay 1
• Cooling fan relay 2
• Cooling fan relay 3
• Cpu
• E17 (on right front side of engine compt)
• E43 (on left front side of engine compt)
• Engine control module (ecm) (right end of dash)
• Engine coolant temperature sensor (on top right rear of engine)
• Fuse 10a
• Fuse 15a
• Fuse, fusible link & relay box (right rear side of engine compt)
• Fusible link h 40a
• Fusible link i 40a
• Gnd (power)
• Gnd(signal)
• Gnd-a
• Hot at all times
• Hot in on or start
• Ignition relay
• Ipdm e/r (intelligent power distribution module engine room) (right rear corner of engine compartment)
• Motor fan 1
• Motor fan 2
• Motor fan 3
• Nca
• Pd- pres
• Pnk
• Refrigerant pressure sensor (on a/c liquid tank)
