POWER DOOR LOCKS – Nissan 240SX SE 1997 – SYSTEM WIRING DIAGRAMS

POWER DOOR LOCKS

Door Lock Wiring Diagram for Nissan 240SX SE 1997

List of elements for Door Lock Wiring Diagram for Nissan 240SX SE 1997:

• Bat
• Circuit breaker (behind left side of dash)
• G200 (left kick panel)
• G203 (right kick panel)
• Ground
• Hot at all times
• Left door lock actuator
• Lock
• Lock out
• Power window main switch
• Right door lock actuator
• Right door lock/ unlock switch
• Smart entrance control unit (behind dash, left of steering column)
• Unlock
• Unlock out

Keyless Entry Wiring Diagram for Nissan 240SX SE 1997

List of elements for Keyless Entry Wiring Diagram for Nissan 240SX SE 1997:

• (1996 only)
• (1996)
• Anti-theft system
• Bat
• Between lock full stroke and n
• Between unlock full stroke and n
• Circuit breaker (behind left side of dash)
• Door lock position
• Fuse 7.5a
• Fuse block (behind left kick panel)
• G200 (left kick panel)
• G203 (right kick panel)
• G300 (below left front seat)
• G904 (left "c" pillar)
• Ground
• Hot at all times
• Hot in on or start
• Ign
• Interior lights system
• Key cyl sw
• Key cylinder withdrawn
• L door sw
• Left door key cylinder switch
• Left door lock actuator
• Left door switch
• Lock
• Lock output
• Normal
• Power window main switch
• R door sw
• Right door key cylinder switch
• Right door lock actuator
• Right door lock/ unlock switch
• Right door switch
• Smart entrance control unit (behind dash, left of steering column)
• Tamper sw
• Unlock
• Unlock output
