Wiring Diagram VW NEW BORA 2012 - Multifunction switch - Automatic gearbox control unit
F125 | Multifunction switch |
J217 | Automatic gearbox control unit |
SC13 | Fuse 13 on fuse holder C |
SC28 | Fuse 28 on fuse holder C |
T10 | 10-pin connector |
T52 | 52-pin connector |
114 | Earth connection, in automatic gearbox wiring harness |
608 | Earth point, central in plenum chamber |
A167 | Positive connection 3 (30a) in dash panel wiring harness |
U8 | Positive connection (15a), in automatic gearbox wiring harness |
Wiring Diagram VW NEW BORA 2012 - Automatic gearbox control unit - Solenoid valve 1 - Solenoid valve 2 - Solenoid valve 3 - Solenoid valve 4 - Solenoid valve 5 - Solenoid valve 6 - Solenoid valve 9 - Solenoid valve 10
J217 | Automatic gearbox control unit |
N88 | Solenoid valve 1 |
N89 | Solenoid valve 2 |
N90 | Solenoid valve 3 |
N91 | Solenoid valve 4 |
N92 | Solenoid valve 5 |
N93 | Solenoid valve 6 |
N282 | Solenoid valve 9 |
N283 | Solenoid valve 10 |
T14 | 14-pin connector |
T52 | 52-pin connector |
Wiring Diagram VW NEW BORA 2012 - Gearbox oil temperature sender - Gearbox input speed sender - Gearbox output speed sender - Automatic gearbox control unit
G93 | Gearbox oil temperature sender |
G182 | Gearbox input speed sender |
G195 | Gearbox output speed sender |
J217 | Automatic gearbox control unit |
J220 | Motronic control unit |
J361 | Simos control unit |
J623 | Engine control unit |
T8 | 8-pin connector |
T16 | 16-pin connector |
T52 | 52-pin connector |
T80 | 80-pin connector |
U31 | Diagnostic connection |
A76 | Connection (K-diagnosis wire), in dash panel wiring harness |
Wiring Diagram VW NEW BORA 2012 - Tiptronic switch - Automatic gearbox control unit - Selector lever lock solenoid
F189 | Tiptronic switch |
J217 | Automatic gearbox control unit |
N110 | Selector lever lock solenoid |
SC2 | Fuse 2 on fuse holder C |
SC19 | Fuse 19 on fuse holder C |
T2z | 2-pin connector |
T8e | 8-pin connector |
T52 | 52-pin connector |
45 | Earth point, centre behind dash panel |
371 | Earth connection 6, in main wiring harness |
A20 | Positive connection (15a), in dash panel wiring harness |
A37 | Connection (58a), in dash panel wiring harness |
U3 | Connection 1, in automatic gearbox wiring harness |
Wiring Diagram VW NEW BORA 2012 - Tiptronic switch - Automatic gearbox control unit - Selector lever display illumination bulb - Selector lever position display
F189 | Tiptronic switch |
J217 | Automatic gearbox control unit |
L101 | Selector lever display illumination bulb |
T10m | 10-pin connector |
T52 | 52-pin connector |
Y6 | Selector lever position display |
B383 | Connection 1 (powertrain CAN bus, high), in main wiring harness |
B390 | Connection 1 (powertrain CAN bus, low), in main wiring harness |
Wiring Diagram VW NEW BORA 2012 - Multifunction indicator - Control unit in dash panel insert - Onboard supply control unit - Selector lever lock warning lamp
J119 | Multifunction indicator |
J285 | Control unit in dash panel insert |
J519 | Onboard supply control unit |
K169 | Selector lever lock warning lamp |
SB5 | Fuse 5 on fuse holder B |
SC16 | Fuse 16 on fuse holder C |
T32 | 32-pin connector |
T73a | 73-pin connector |
B383 | Connection 1 (powertrain CAN bus, high), in main wiring harness |
B390 | Connection 1 (powertrain CAN bus, low), in main wiring harness |
