Wiring Diagram VW JETTA SPORT WAGEN 2007 - Control unit for front display and information control panel - Vehicle position recognition control unit
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO J523 | Control unit for front display and information control panel |
J603 | Vehicle position recognition control unit |
SC17 | Fuse 17 on fuse holder C |
T8h | 8-pin connector |
T20 | 20-pin connector |
369 | Earth connection 4, in main wiring harness |
377 | Earth connection 12, in main wiring harness |
| |
A178 | Connection (infotainment CAN bus, high), in dash panel wiring harness |
A179 | Connection (infotainment CAN bus, low), in dash panel wiring harness |
A198 | Positive connection 6 (30a) in dash panel wiring harness |
VW JETTA SPORT WAGEN 2007
| VW JETTA SPORT WAGEN 2007 Overview of earth points
1 | Earth strap, battery - body |
12 | Earth point on left in engine compartment |
15 | Earth point on cylinder head |
43 | Earth point, lower part of right A-pillar |
45 | Earth point, behind centre of dash panel |
51 | Earth point, on right in luggage compartment |
602 | Earth point in front left footwell |
605 | Earth point on top end of steering column |
607 | Earth point, on left in plenum chamber |
609 | Earth point, on right in plenum chamber |
638 | Earth point on right A-pillar |
640 | Earth point 2 on left in engine compartment |
642 | Earth point for electronically controlled fan |
652 | Earth point, engine and gearbox earth |
655 | Earth point on left headlight |
656 | Earth point on right headlight |
662 | Earth point in rear left side panel |
Earth points, in engine compartment | | | |
1 | Earth strap, battery - body -arrow A- | 12 | Earth point on left in engine compartment -arrow B- | | | |
15 | Earth point on cylinder head -arrow- | | | |
607 | Earth point on left in plenum chamber -arrow- | | | |
609 | Earth point on right in plenum chamber -arrow- | | | |
640 | Earth point 2 on left in engine compartment -arrow A- | |
| | 652 | Earth point for engine and gearbox earth -arrow D- | 655 | Earth point on left headlight -arrow B- | | | |
656 | Earth point on right headlight -arrow- | | | |
43 | Earth point on lower part of right A-pillar -arrow B- | 638 | Earth point on right A-pillar -arrow A- | | | |
45 | Earth point, behind centre of dash panel -arrow- | | | |
602 | Earth point, in front left footwell -arrow- | | | |
605 | Earth point on top of steering column -arrow- | Earth points in luggage compartment | | | |
51 | Earth point, on right in luggage compartment -arrow- | | | |
662 | Earth point in rear left side panel -arrow- | | | |
