VW GOLF CABRIOLET 2002 – Cabriolet top operation, sales type 1V7 only . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW GOLF CABRIOLET
  4. >VW GOLF CABRIOLET 2002
  5. >VW GOLF CABRIOLET 2002 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW GOLF CABRIOLET 2002 - Convertible top operation control unit - convertible top operation motor - convertible top operation hydraulic pump relay - convertible top operating switch



Wiring Diagram VW GOLF CABRIOLET 2002 - Convertible top operation control unit - convertible top operation motor - convertible top operation hydraulic pump relay - convertible top operating switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
DIgnition and starter switch
E20Switches and instruments illumination regulator
E137Convertible top operating switch
J152Side lights and radio buzzer
J256Convertible top operation control unit, under rear seat
J321Convertible top hydraulic pump relay, in centre behind dash panel, control number 53
KDash panel insert
K47ABS warning lamp
RRadio
T1dSingle connector, behind relay plate
T1nSingle connector, behind relay plate
T2a2-pin connector, behind relay plate
T55-pin connector, in centre behind dash panel
T7c7-pin connector
T88-pin connector
T2828-pin connector, on dash panel insert
TV8Terminal 58b wiring junction, grey
V82Convertible top operation motor
   44 Earth point, lower left A-pillar
   A11 Positive connection (58b), in instruments wiring harness
   A78 Connection (SU), in dash panel wiring harness
   M32 Connection 1, in convertible top operation wiring harness

Wiring Diagram VW GOLF CABRIOLET 2002 - Convertible top operation control unit - handbrake warning switch



Wiring Diagram VW GOLF CABRIOLET 2002 - Convertible top operation control unit - handbrake warning switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
F9Handbrake warning switch
F34Brake fluid level warning contact
J256Convertible top operation control unit, under rear seat
KDash panel insert
K47ABS warning lamp
S68Convertible top motor thermal fuse , above the relay plate
T2a2-pin connector, behind relay plate
T7c7-pin connector
T1616-pin connector, in centre of dash panel, diagnostic socket
T2828-pin connector, on dash panel insert
   50 Earth point, on left in luggage compartment
   A20 Positive connection (15a), in dash panel wiring harness
