VW PASSAT 1999 – 4 Speed automatic gearbox (AG 4), for vehicles with petrol engine . Wiring diagrams, Pin Connector, Location

    HomeVWVW PASSATVW PASSAT 1999VW PASSAT 1999 ALL WIRING DIAGRAMS - ENGLISH
Download PDF file

Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - relay for starter inhibitor and reversing lights



Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - relay for starter inhibitor and reversing lights Download PDF file
BStarter
DIgnition/starter switch
J217Automatic gearbox control unit, in front right footwell
J220Motronic control unit
J226Starter inhibitor and reversing light relay (175), on 13 position additional relay carrier
J361Simos control unit
S15Fuse in relay plate fuse box
T6n6-pin connector, red, on protective housing for control units, in left engine compartment
T99-pin connector
T10i10-pin connector, blue, coupling station right A-pillar
T24b24-pin connector, red, on J220
T68a68-pin connector, on automatic gearbox control unit
T8080-pin connector, on engine control unit
   32 Earth point, behind dash panel, left
   81 Earth connection -1-, in dash panel wiring harness
   135 Earth connection -2-, in dash panel wiring harness
   501 Screw connection -2- (30), on relay plate
   A1 Positive (+) connection (30a), in dash panel wiring harness
   A32 Positive connection (30), in dash panel wiring harness
   A86 Connection (50a), in dash panel wiring harness
   A87 Connection (RL), in dash panel wiring harness

Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - multi-function switch - gearbox speed sender



Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - multi-function switch - gearbox speed senderGet access to all wiring diagrams of the carDownload PDF file
E45Cruise control system switch
F125Multi-function switch
G38Gearbox speed sender
J104ABS with EDL control unit
J217Automatic gearbox control unit, in front right footwell
T3a3-pin connector, black
T77-pin connector, on multi-function switch
T10i10-pin connector, blue, coupling station right A-pillar
T10m10-pin connector, brown, coupling station right A-pillar
T3131-pin connector, on ABS with EDL control unit
T68a68-pin connector, on automatic gearbox control unit
   33 Earth point, behind dash panel, right
   114 Earth connection (dash panel insert), in automatic gearbox wiring harness
---For vehicles with cruise control system only

Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - solenoid valves



Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - solenoid valvesGet access to all wiring diagrams of the carDownload PDF file
FBrake light switch
G68Road speed sender
G93Gearbox oil temperature sender
J217Automatic gearbox control unit, in front right footwell
J285Control unit with display in dash panel insert
N88Solenoid valve 1
N89Solenoid valve 2
N90Solenoid valve 3
N91Solenoid valve 4
N92Solenoid valve 5
N93Solenoid valve 6
N94Solenoid valve 7
T1212-pin connector, on gearbox
T1616-pin connector, self-diagnosis connector for V.A.G. 1551
T10m10-pin connector, brown, coupling station right A-pillar
T32a32-pin connector, blue, on dash panel insert
T68a68-pin connector, on automatic gearbox control unit
   A76 Connection (diagnosis wire K), in dash panel wiring harness
   A89 Connection -2- (54), in dash panel wiring harness
   W1 Positive (+) connection (54), in rear wiring harness

Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - kick-down switch



Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - kick-down switchGet access to all wiring diagrams of the carDownload PDF file
F8Kick-down switch
J217Automatic gearbox control unit, in front right footwell
J220Motronic control unit
J285Control unit with display in dash panel insert
J361Simos control unit
T10h10-pin connector, blue, on protective housing for control units
T10m10-pin connector, brown, coupling station right A-pillar
T10i10-pin connector, blue, coupling station right A-pillar
T24b24-pin connector, red, on engine control unit
T24c24-pin connector, brown, on engine control unit
T32a32-pin connector, blue, on dash panel insert
T68a68-pin connector, on automatic gearbox control unit
T8080-pin connector, on engine control unit
Y5Selector lever position display
   12 Earth point, in engine compartment, left
   124 Earth connection, in engine compartment right wiring harness
   A45 Connection (engine speed signal), in dash panel wiring harness
   A75 Connection (kick-down switch), in dash panel wiring harness

Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - selector lever lock solenoid - selector lever illumination



Wiring Diagram VW PASSAT 1999 - Automatic gearbox control unit - selector lever lock solenoid - selector lever illuminationGet access to all wiring diagrams of the carDownload PDF file
DIgnition/starter switch
E20Switches and instruments - lighting control
J17Fuel pump relay (208)
J217Automatic gearbox control unit, in front right footwell
K142Selector lever position P/N warning lamp
L101Selector lever display illumination
N110Selector lever lock solenoid
S11Fuse in relay plate fuse box
S231Fuse in fuse holder
T44-pin connector, brown, under centre console
T10i10-pin connector, blue, coupling station right A-pillar
T10m10-pin connector, brown, coupling station right A-pillar (air conditioning system)
T68a68-pin connector, on automatic gearbox control unit
   114 Earth connection (dash panel insert), in automatic gearbox wiring harness
   A2 Positive (+) connection (15), in dash panel wiring harness
   A19 Connection (58d), in dash panel wiring harness
   A70 Connection (15a, fuse 231), in dash panel wiring harness
---For vehicles with cruise control system only
