Wiring Diagram VW TOURAN 2017 - Fuse holder C
| SC | Fuse holder C |
| SC8 | Fuse 8 on fuse holder C |
| SC25 | Fuse 25 on fuse holder C |
| SC34 | Fuse 34 on fuse holder C |
| SC39 | Fuse 39 on fuse holder C |
| SC50 | Fuse 50 on fuse holder C |
Wiring Diagram VW TOURAN 2017 - Driver door control unit - Driver side exterior mirror - Driver side mirror adjustment motor 2 - Driver side fold-in mirror motor - Driver side mirror adjustment motor
| J386 | Driver door control unit |
| L131 | Driver side turn signal repeater bulb |
| T2ab | 2-pin connector, black |
| T3df | 3-pin connector, black |
| T3g | 3-pin connector, black |
| T8ba | 8-pin connector, black |
| T16a | 16-pin connector, black |
| VX4 | Driver side exterior mirror |
| V17 | Driver side mirror adjustment motor 2 |
| V121 | Driver side fold-in mirror motor |
| V149 | Driver side mirror adjustment motor |
| Z4 | Heated exterior mirror on driver side |
| Z1 | Connection 1, in mirror adjustment/heating wiring harness |
| * | Pre-wired component |
| *2 | According to equipment |
Wiring Diagram VW TOURAN 2017 - Driver door control unit - Driver side turn signal repeater bulb - Driver side exterior mirror - Driver side automatic anti-dazzle exterior mirror - Heated exterior mirror on driver side
| J386 | Driver door control unit |
| L131 | Driver side turn signal repeater bulb |
| T2qg | 2-pin connector, black |
| T3df | 3-pin connector, black |
| T3dg | 3-pin connector, black |
| T16a | 16-pin connector, black |
| VX4 | Driver side exterior mirror |
| W52 | Driver side entry light in exterior mirror |
| Y20 | Driver side automatic anti-dazzle exterior mirror |
| Z4 | Heated exterior mirror on driver side |
| Z1 | Connection 1, in mirror adjustment/heating wiring harness |
| * | Pre-wired component |
| *2 | According to equipment |
Wiring Diagram VW TOURAN 2017 - Driver side interior locking button for central locking system - Operating unit for window regulator in driver door - Driver door control unit
| E308 | Driver side interior locking button for central locking system |
| E510 | Button for left childproof lock |
| E511 | Button for right childproof lock |
| E512 | Operating unit for window regulator in driver door |
| E710 | Front driver side window regulator button |
| E711 | Rear driver side window regulator button |
| E713 | Rear passenger side window regulator button |
| E716 | Front passenger side window regulator button |
| J386 | Driver door control unit |
| K236 | Warning light for activated childproof lock |
| L76 | Button illumination bulb |
| T4cq | 4-pin connector, blue |
| T10ac | 10-pin connector, black |
| T32c | 32-pin connector, blue |
| 294 | Earth connection 9, in interior wiring harness |
| B116 | Connection (58d), in interior wiring harness |
Wiring Diagram VW TOURAN 2017 - Exterior mirror adjuster - Driver door control unit - Central locking SAFELOCK function warning lamp - Light 1 for front left door background lighting - Light 2 for front left door background lighting - Light for driver side interior door handle illumination - Left window regulator motor - Driver door lock unit - Driver door central locking motor
| EX11 | Exterior mirror adjuster |
| E43 | Mirror adjustment switch |
| E48 | Mirror adjustment changeover switch |
| E231 | Exterior mirror heater button |
| E263 | Fold-in mirror switch |
| J386 | Driver door control unit |
| K133 | Central locking SAFELOCK function warning lamp |
| L78 | Mirror adjustment switch illumination bulb |
| L199 | Light 1 for front left door background lighting |
| L203 | Light 2 for front left door background lighting |
| L219 | Light for driver side interior door handle illumination |
| T2gx | 2-pin connector, black |
| T2gy | 2-pin connector, black |
| T2gz | 2-pin connector, black |
| T2ha | 2-pin connector, black |
| T3v | 3-pin connector, blue |
| T6aj | 6-pin connector, brown |
| T6h | 6-pin connector, black |
| T8g | 8-pin connector, black |
| T20 | 20-pin connector, black |
| T32c | 32-pin connector, blue |
| V14 | Left window regulator motor |
| VX21 | Driver door lock unit |
| V56 | Driver door central locking motor |
| 294 | Earth connection 9, in interior wiring harness |
| R112 | Connection for ambient lighting, in front left door wiring harness |
Wiring Diagram VW TOURAN 2017 - Driver door contact switch - Driver side contact switch in lock cylinder - Driver door central locking actuator for SAFELOCK function - Driver door control unit - Driver door lock unit - Driver door central locking SAFELOCK function motor
| F2 | Driver door contact switch |
| F241 | Driver side contact switch in lock cylinder |
| F243 | Driver door central locking actuator for SAFELOCK function |
| J386 | Driver door control unit |
| T8g | 8-pin connector, black |
| T20 | 20-pin connector, black |
| T27 | 27-pin connector, black |
| T27b | 27-pin connector, black |
| TTVL | Coupling point on front left door |
| VX21 | Driver door lock unit |
| V161 | Driver door central locking SAFELOCK function motor |
| 267 | Earth connection 2, in drive side door wiring harness |
| 279 | Earth connection 5, in interior wiring harness |
| B111 | Positive connection 1 (30a), in interior wiring harness |
| B506 | Connection (convenience CAN bus, high), in interior wiring harness |
| B507 | Connection (convenience CAN bus, low), in interior wiring harness |
Wiring Diagram VW TOURAN 2017 - Front passenger door control unit - Front passenger door lock unit
| F3 | Front passenger door contact switch |
| F244 | Front passenger door central locking actuator for SAFELOCK function |
| J387 | Front passenger door control unit |
| T8h | 8-pin connector, black |
| T20f | 20-pin connector, black |
| T27a | 27-pin connector, black |
| T27c | 27-pin connector, black |
| TTVR | Coupling point on front right door |
| VX22 | Front passenger door lock unit |
| V57 | Front passenger seat central locking motor |
| V162 | Front passenger door central locking SAFELOCK function motor |
| 249 | Earth connection 2, in interior wiring harness |
| 268 | Earth connection 2, in front passenger side door wiring harness |
| 638 | Earth point, on right A-pillar |
| B150 | Positive connection 2 (30a), in interior wiring harness |
Wiring Diagram VW TOURAN 2017 - Window regulator switch in front passenger door - Front passenger door control unit - Light 1 for front right door background lighting - Light 2 for front right door background lighting - Light for passenger side interior door handle illumination - Right window regulator motor
| E107 | Window regulator switch in front passenger door |
| J387 | Front passenger door control unit |
| L200 | Light 1 for front right door background lighting |
| L204 | Light 2 for front right door background lighting |
| L220 | Light for passenger side interior door handle illumination |
| T2hb | 2-pin connector, black |
| T2hc | 2-pin connector, black |
| T2he | 2-pin connector, black |
| T3w | 3-pin connector, blue |
| T4aa | 4-pin connector, black |
| T4ad | 4-pin connector, black |
| T4cs | 4-pin connector, black |
| T6i | 6-pin connector, black |
| T32a | 32-pin connector, blue |
| TTVR | Coupling point on front right door |
| V15 | Right window regulator motor |
| 121 | Earth connection 2, in front right wiring harness |
| 206 | Earth connection, in front passenger door wiring harness |
| K8 | Connection 1, in centre console wiring harness |
Wiring Diagram VW TOURAN 2017 - Front passenger door control unit - Front passenger side exterior mirror - Front passenger side fold-in mirror motor
| J387 | Front passenger door control unit |
| L132 | Front passenger side turn signal repeater bulb |
| T2zt | 2-pin connector, black |
| T3b | 3-pin connector, black |
| T3c | 3-pin connector, black |
| T8bf | 8-pin connector, black |
| T16g | 16-pin connector, black |
| VX5 | Front passenger side exterior mirror |
| V25 | Front passenger side mirror adjustment motor 2 |
| V122 | Front passenger side fold-in mirror motor |
| V150 | Front passenger side mirror adjustment motor |
| Z5 | Heated exterior mirror on front passenger side |
| Z2 | Connection 2, in mirror adjustment/heating wiring harness |
| * | Pre-wired component |
| *2 | According to equipment |
Wiring Diagram VW TOURAN 2017 - Front passenger door control unit - Front passenger side turn signal repeater bulb - Front passenger side exterior mirror - Front passenger side automatic anti-dazzle exterior mirror - Heated exterior mirror on front passenger side
| J387 | Front passenger door control unit |
| L132 | Front passenger side turn signal repeater bulb |
| T2qf | 2-pin connector, black |
| T3ct | 3-pin connector, black |
| T3dh | 3-pin connector, black |
| T16g | 16-pin connector, black |
| VX5 | Front passenger side exterior mirror |
| W53 | Front passenger side entry light in exterior mirror |
| Y21 | Front passenger side automatic anti-dazzle exterior mirror |
| Z5 | Heated exterior mirror on front passenger side |
| Z2 | Connection 2, in mirror adjustment/heating wiring harness |
| * | Pre-wired component |
| *2 | According to equipment |
Wiring Diagram VW TOURAN 2017 - Rear left door control unit - Rear left door lock unit - Rear left window regulator motor
| F10 | Rear left door contact switch |
| F245 | Rear left door central locking actuator for SAFELOCK function |
| J388 | Rear left door control unit |
| T8ai | 8-pin connector, black |
| T10c | 10-pin connector, black |
| T19 | 19-pin connector, black |
| T19b | 19-pin connector, black |
| T20a | 20-pin connector, black |
| TTHL | Coupling point on rear left door |
| VX23 | Rear left door lock unit |
| V26 | Rear left window regulator motor |
| V214 | Rear left door central locking motor, lock |
| 80 | Earth connection 1, in dash panel wiring harness |
| * | Only models with no rear left door control unit |
| *2 | Only models with rear left door control unit |
Wiring Diagram VW TOURAN 2017 - Rear left window regulator switch - in door - Rear left door control unit
| E52 | Rear left window regulator switch, in door |
| J388 | Rear left door control unit |
| T3x | 3-pin connector, brown |
| T4af | 4-pin connector, black |
| T6j | 6-pin connector, black |
| T10c | 10-pin connector, black |
| T16a | 16-pin connector, black |
| T20a | 20-pin connector, black |
| V26 | Rear left window regulator motor |
| * | Only models with no rear left door control unit |
Wiring Diagram VW TOURAN 2017 - Rear left door control unit - Rear left door lock unit
| F10 | Rear left door contact switch |
| F245 | Rear left door central locking actuator for SAFELOCK function |
| F344 | Rear left childproof lock contact switch |
| F505 | Rear door contact switch, driver side |
| J388 | Rear left door control unit |
| T8i | 8-pin connector, black |
| T20a | 20-pin connector, black |
| VX23 | Rear left door lock unit |
| V142 | Rear left childproof lock motor |
| V214 | Rear left door central locking motor, lock |
| V422 | Rear left rotary latch motor |
| 207 | Earth connection, in rear left door wiring harness |
Wiring Diagram VW TOURAN 2017 - Rear right door contact switch - Rear right door control unit - Rear right door lock unit - Rear right window regulator motor
| F11 | Rear right door contact switch |
| F246 | Rear right door central locking actuator for SAFELOCK function |
| J389 | Rear right door control unit |
| T8aj | 8-pin connector, black |
| T10d | 10-pin connector, black |
| T19a | 19-pin connector, black |
| T19c | 19-pin connector, black |
| T20b | 20-pin connector, black |
| TTHR | Coupling point on rear right door |
| VX24 | Rear right door lock unit |
| V27 | Rear right window regulator motor |
| V215 | Rear right door central locking motor, lock |
| 81 | Earth connection 1, in dash panel wiring harness |
| * | Only models with no rear right door control unit |
| *2 | Only models with rear right door control unit |
Wiring Diagram VW TOURAN 2017 - Rear right window regulator switch - in door - Rear right door control unit - Rear right window regulator motor
| E54 | Rear right window regulator switch, in door |
| J389 | Rear right door control unit |
| T3y | 3-pin connector, brown |
| T4ah | 4-pin connector, black |
| T6k | 6-pin connector, black |
| T10d | 10-pin connector, black |
| T16b | 16-pin connector, black |
| T20b | 20-pin connector, black |
| V27 | Rear right window regulator motor |
| * | Only models with no rear right door control unit |
| *2 | Only models with rear right door control unit |
Wiring Diagram VW TOURAN 2017 - Rear right door contact switch - Rear right door control unit - Rear right door lock unit
| F11 | Rear right door contact switch |
| F246 | Rear right door central locking actuator for SAFELOCK function |
| F345 | Rear right childproof lock contact switch |
| F506 | Rear door contact switch, passenger side |
| J389 | Rear right door control unit |
| T8j | 8-pin connector, black |
| T20b | 20-pin connector, black |
| VX24 | Rear right door lock unit |
| V143 | Rear right childproof lock motor |
| V215 | Rear right door central locking motor, lock |
| V423 | Rear right rotary latch motor |
| 208 | Earth connection, in rear right door wiring harness |
| * | Only models with rear right door control unit |
Wiring Diagram VW TOURAN 2017 - Interior mirror - Rain and light sensor - Data bus diagnostic interface
| EX5 | Interior mirror |
| E386 | Anti-dazzle interior mirror button |
| G397 | Rain and light sensor |
| J533 | Data bus diagnostic interface |
| J844 | Main beam assist control unit |
| T3am | 3-pin connector, black |
| T8s | 8-pin connector, black |
| T20c | 20-pin connector, red |
| 277 | Earth connection 3, in interior wiring harness |
| A1 | Positive connection (30a), in dash panel wiring harness |
| A38 | Positive connection 2 (15a) in dash panel wiring harness |
| B108 | Connection 1 (CAN bus extended high), in main wiring harness |
| B109 | Connection 1 (CAN bus extended low), in main wiring harness |
| W71 | Connection (reversing light), in rear wiring harness |
| * | According to equipment |
| *2 | Only models with no main beam assist function |
Wiring Diagram VW TOURAN 2017 - Front left footwell light - Front right footwell light - Front interior light
| K268 | Front left footwell light |
| K269 | Front right footwell light |
| T2bu | 2-pin connector, brown |
| T2cc | 2-pin connector, brown |
| T6q | 6-pin connector, blue |
| WX1 | Front interior light |
| 238 | Earth connection 1, in interior wiring harness |
| 286 | Earth connection 8, in interior wiring harness |
| B433 | Connection (footwell light), in main wiring harness |
Wiring Diagram VW TOURAN 2017 - Driver vanity mirror contact switch - Front passenger vanity mirror contact switch - Front passenger side illuminated vanity mirror - Driver side illuminated vanity mirror - Rear left interior light - Rear right interior light - Interior light
| F147 | Driver vanity mirror contact switch |
| F148 | Front passenger vanity mirror contact switch |
| T2aq | 2-pin connector, black |
| T2ar | 2-pin connector, black |
| T2as | 2-pin connector, black |
| T2at | 2-pin connector, black |
| T4q | 4-pin connector, black |
| T4s | 4-pin connector, brown |
| T4t | 4-pin connector, black |
| T16 | 16-pin connector, brown |
| T16g | 16-pin connector, brown |
| TH | Coupling point for roof |
| W14 | Front passenger side illuminated vanity mirror |
| W20 | Driver side illuminated vanity mirror |
| W47 | Rear left interior light |
| W48 | Rear right interior light |
| W64 | Interior light |
| 347 | Earth connection, in roof wiring harness |
| 438 | Earth connection 3, in roof wiring harness |
| B533 | Connection 1 (DCt), in roof wiring harness |
| R5 | Connection 2, in interior light wiring harness |
| * | Only models with panoramic sliding sunroof |
Wiring Diagram VW TOURAN 2017 - Rear lid release switch - Rear lid lock unit
| E165 | Rear lid release switch |
| F256 | Rear lid lock unit |
| T2bb | 2-pin connector, black |
| T4x | 4-pin connector, black |
| T10 | 10-pin connector, brown |
| T10a | 10-pin connector, black |
| T10k | 10-pin connector, black |
| T10l | 10-pin connector, brown |
| THK | Coupling point on rear lid |
| VX25 | Rear lid lock unit |
| V53 | Rear lid central locking motor |
| 219 | Earth connection 2, in rear lid wiring harness |
| 285 | Earth connection 7, in interior wiring harness |
| * | Only models with electric rear lid opener |
| *2 | Only models with no electric rear lid opener |
Wiring Diagram VW TOURAN 2017 - Rear lid control unit - Motor 1 for rear lid - Motor 2 for rear lid
| G745 | Sensor in motor 1 for rear lid |
| G746 | Sensor in motor 2 for rear lid |
| J605 | Rear lid control unit |
| T10h | 10-pin connector, black |
| T10i | 10-pin connector, black |
| T10j | 10-pin connector, black |
| T32b | 32-pin connector, black |
| V444 | Motor 1 for rear lid |
| V445 | Motor 2 for rear lid |
Wiring Diagram VW TOURAN 2017 - Anti-trapping sender - Anti-trapping sender 2 - Rear lid control unit
| G673 | Anti-trapping sender |
| G753 | Anti-trapping sender 2 |
| J605 | Rear lid control unit |
| T2dj | 2-pin connector, black |
| T2dk | 2-pin connector, blue |
| T10h | 10-pin connector, black |
| T32b | 32-pin connector, black |
| 218 | Earth connection 1, in rear lid wiring harness |
| 295 | Earth connection 10, in interior wiring harness |
| B398 | Connection 2 (convenience CAN bus, high), in main wiring harness |
| B407 | Connection 2 (convenience CAN bus, low), in main wiring harness |
| * | Only models with trailer socket |
| *2 | Only models with no trailer socket |
Wiring Diagram VW TOURAN 2017 - Rear lid closure button - Anti-trapping sender 3 - Rear lid warning buzzer - Rear lid control unit - Power latching for rear lid
| E574 | Rear lid closure button |
| G761 | Anti-trapping sender 3 |
| H32 | Rear lid warning buzzer |
| J605 | Rear lid control unit |
| T2az | 2-pin connector, black |
| T2ba | 2-pin connector, black |
| T4w | 4-pin connector, black |
| T6g | 6-pin connector, black |
| T10b | 10-pin connector, black |
| T10h | 10-pin connector, black |
| T10m | 10-pin connector, black |
| T32b | 32-pin connector, black |
| THK | Coupling point on rear lid |
| VX16 | Power latching for rear lid |
| V382 | Power latching motor for rear lid |
| 98 | Earth connection, in rear lid wiring harness |
Wiring Diagram VW TOURAN 2017 - Rear lid power opening sender - Rear lid power opening sender 2 - Onboard supply control unit - Rear lid power opening control unit - Interface for entry and start system
| G750 | Rear lid power opening sender |
| G760 | Rear lid power opening sender 2 |
| J519 | Onboard supply control unit |
| J938 | Rear lid power opening control unit |
| J965 | Interface for entry and start system |
| T2ql | 2-pin connector, black |
| T2qm | 2-pin connector, black |
| T4bj | 4-pin connector, black |
| T4jd | 4-pin connector, black |
| T40 | 40-pin connector, black |
| T73 | 73-pin connector, black |
| T73a | 73-pin connector, black |
| 333 | Earth connection 5, in rear wiring harness |
| * | Only models with no rear right door control unit |
| *2 | Only models with no rear left door control unit |
Wiring Diagram VW TOURAN 2017 - Onboard supply control unit
| J519 | Onboard supply control unit |
| T73 | 73-pin connector, black |
| T73a | 73-pin connector, black |
| A13 | Connection (door contact switch), in dash panel wiring harness |
| * | Only models with no rear left door control unit |
Wiring Diagram VW TOURAN 2017 - Centre switch module in dash panel - Onboard supply control unit
| EX22 | Centre switch module in dash panel |
| E233 | Rear lid remote release button |
| J519 | Onboard supply control unit |
| T6o | 6-pin connector, black |
| T10g | 10-pin connector, black |
| T73 | 73-pin connector, black |
| T73a | 73-pin connector, black |
| 278 | Earth connection 4, in interior wiring harness |
| A116 | Connection 2 (58d), in dash panel wiring harness |
| * | Only models with no rear right door control unit |
| *2 | Only models with no rear left door control unit |
VW TOURAN 2017 Overview of fuse holders
| q | Fitting location, right-hand drive models |
| q | Fuse assignment from September 2015 |
| q | Fuse assignment from September 2015 |
| q | Fuse assignment from September 2015 |
| Fitting location of fuse holder C -SC- |
| Fitting location, fuse holder C -SC- , left-hand drive |
| 1 - | Fuse holder C -SC- |
| Fuse colours for J-Case fuse: |
| t | 50 A - red |
| t | 40 A - green |
| t | 30 A - pink |
| Fuse colours for ATO flat fuse: |
| t | 40 A - orange |
| t | 30 A - light green |
| t | 25 A - natural (white) |
| t | 20 A - yellow |
| t | 15 A - light blue |
| t | 10 A - red |
| t | 7.5 A - brown |
| t | 5 A - light brown |
| t | 1A - black |
| Fuse colours, for mini fuses: |
| t | 20 A - yellow |
| t | 15 A - light blue |
| t | 10 A - red |
| t | 7.5 A - brown |
| t | 5 A - light brown |
| t | 1A - black |
|
| Fitting location, fuse holder C -SC- , right-hand drive |
| 1 - | Fuse holder C -SC- |
| Fuse colours for J-Case fuse: |
| t | 50 A - red |
| t | 40 A - green |
| t | 30 A - pink |
| Fuse colours for ATO flat fuse: |
| t | 40 A - orange |
| t | 30 A - light green |
| t | 25 A - natural (white) |
| t | 20 A - yellow |
| t | 15 A - light blue |
| t | 10 A - red |
| t | 7.5 A - brown |
| t | 5 A - light brown |
| t | 1A - black |
| Fuse colours, for mini fuses: |
| t | 20 A - yellow |
| t | 15 A - light blue |
| t | 10 A - red |
| t | 7.5 A - brown |
| t | 5 A - light brown |
| t | 1A - black |
|
| Fuse assignment of fuse holder C -SC- |
| Fuse assignment of fuse holder C -SC- , from September 2015 |
| Slot | Current flow diagram designation | Nominal value | Function/component | Terminal | ||
| SC1 | Fuse 1 on fuse holder C -SC1- | 30 A | Control unit for reducing-agent heater -J891- | 30 | ||
| SC2 | Fuse 2 on fuse holder C -SC2- | 10 A | Steering column electronics control unit -J527-6) | 30 | ||
| SC3 | not assigned | - | - | |||
| SC4 | Fuse 4 on fuse holder C -SC4- | 10 A | Onboard supply control unit -J519-
| 30 | ||
| SC5 | Fuse 5 on fuse holder C -SC5- | 5 A | Data bus diagnostic interface -J533- | 30 | ||
| SC6 | Fuse 6 on fuse holder C -SC6- | 5 A | Selector lever -E313- | 30 | ||
| SC7 | Fuse 7 on fuse holder C -SC7- | 10 A | Heater and air conditioning controls -EX21- | 30 | ||
| Heater control unit -J65- | ||||||
| Climatronic control unit -J255- | ||||||
| Air conditioning system control unit -J301- | ||||||
| Remote control receiver for auxiliary coolant heater -R149- | ||||||
| Heated rear window relay -J9- | ||||||
| Tyre Pressure Monitoring System control unit -J502- | ||||||
| SC8 | Fuse 8 on fuse holder C -SC8- | 10 A | Rotary light switch -EX1- | 30 | ||
| Electromechanical parking brake button -E538- | ||||||
| Rain and light sensor -G397- | ||||||
| Diagnostic connection -U31- | ||||||
| Anti-theft alarm sensor -G578- | ||||||
| SC9 | Fuse 9 on fuse holder C -SC9- | 5 A | Steering column electronics control unit -J527- | 30 | ||
| SC10 | Fuse 10 on fuse holder C -SC10- | 7.5 A | Display unit for front information display and operating unit control unit -J685- | 30 | ||
| TV tuner -RX6- | ||||||
| SC11 | Fuse 11 on fuse holder C -SC11- | 25 A | Control unit for front left belt tensioner -J854- | 30 | ||
| SC12 | Fuse 12 on fuse holder C -SC12- | 20 A | Control unit 1 for information electronics -J794- | 30 | ||
| SC13 | Fuse 13 on fuse holder C -SC13- | 15 A | Electronically controlled damping control unit -J250- | 30 | ||
| SC14 | Fuse 14 on fuse holder C -SC14- | 30 A | Fresh air blower control unit -J126- | 30 | ||
| SC15 | Fuse 15 on fuse holder C -SC15- | 10 A | Control unit for electronic steering column lock -J764- | 30 | ||
| SC16 | Fuse 16 on fuse holder C -SC16- | 7.5 A | Control unit 1 for information electronics -J794- | 30 | ||
| Two-way signal amplifier for mobile telephone/data services -J984- | ||||||
| Storage compartment with interface for mobile telephone -R265- | ||||||
| Chip card reader -D8- | ||||||
| USB hub -R293- | ||||||
| SC17 | Fuse 17 on fuse holder C -SC17- | 5 A | Dash panel insert -KX2- | 30 | ||
| Control unit in dash panel insert -J285- | ||||||
| SC18 | Fuse 18 on fuse holder C -SC18- | 7.5 A | Reversing camera -R189- | 30 | ||
| SC19 | Fuse 19 on fuse holder C -SC19- | 7.5 A | Interface for entry and start system -J965- | 30 | ||
| SC20 | Fuse 20 on fuse holder C -SC20- | 7.5 A | Relay for reducing agent metering system -J963- | 30 | ||
| Delivery unit for reducing agent metering system -GX19- | ||||||
| SC21 | not assigned | - | - | |||
| SC22 | Fuse 22 on fuse holder C -SC22- | 15 A | Trailer detector control unit -J345- | 30 | ||
| SC23 | Fuse 23 on fuse holder C -SC23- | 40 A | Onboard supply control unit -J519-
| 30 | ||
| SC24 | Fuse 24 on fuse holder C -SC24- | 30 A | Sliding sunroof adjustment control unit -J245- | 30 | ||
| Sunroof roller blind control unit -J394- | ||||||
| SC25 | Fuse 25 on fuse holder C -SC25- | 30 A | Driver door control unit -J386- 1) | 30 | ||
| Rear left window regulator motor -V26- 1) | 30 | |||||
| Front passenger door control unit -J387-2) | ||||||
| Rear right window regulator motor -V27- 2) | ||||||
| SC26 | Fuse 26 on fuse holder C -SC26- | 30 A | Onboard supply control unit -J519-
| 30 | ||
| SC27 | not assigned | - | - | |||
| SC28 | Fuse 28 on fuse holder C -SC28- | 25 A | Trailer detector control unit -J345- | 30 | ||
| SC29 | not assigned | - | - | |||
| SC30 | not assigned | - | - | |||
| SC31 | Fuse 31 on fuse holder C -SC31- | 40 A | Onboard supply control unit -J519-
| 30 | ||
| SC32 | Fuse 32 on fuse holder C -SC32- | 7.5 A | Front camera for driver assist systems -R242- | 15 | ||
| 10 A8) | Adaptive cruise control unit -J428- | |||||
| Parking aid control unit -J446- | ||||||
| Park assist steering control unit -J791- | ||||||
| Blind Spot Monitor control unit -J1086- | ||||||
| Blind Spot Monitor control unit 2 -J1087- | ||||||
| SC33 | Fuse 33 on fuse holder C -SC33- | 5 A | Airbag control unit -J234- | 15 | ||
| Front passenger airbag deactivated warning lamp -K145- | ||||||
| SC34 | Fuse 34 on fuse holder C -SC34- | 7.5 A | Rotary light switch -EX1- | 15 | ||
| Interior mirror -EX5- | ||||||
| Relay for power sockets -J807- | ||||||
| Reversing light switch -F4- | ||||||
| Pressure sender for refrigerant circuit -G805- | ||||||
| Air quality sensor -G238- | ||||||
| Electromechanical parking brake button -E538- | ||||||
| Auxiliary air heater element -Z35- | ||||||
| SC35 | Fuse 35 on fuse holder C -SC35- | 10 A | Diagnostic connection -U31- | 15 | ||
| Headlight range control and instrument illumination regulator -EX14- | ||||||
| Control unit for cornering light and headlight range control -J745- | ||||||
| Left headlight range control motor -V48- | ||||||
| Right headlight range control motor -V49- | ||||||
| Front left headlight -MX1- | ||||||
| Front right headlight -MX2- | ||||||
| SC36 | Fuse 36 on fuse holder C -SC36- | 10 A 5 A9) | Front right headlight -MX2- | 15 | ||
| Control unit for right daytime running light and side light -J861- | ||||||
| SC37 | Fuse 37 on fuse holder C -SC37- | 10 A 5 A9) | Front left headlight -MX1- | 15 | ||
| Control unit for left daytime running light and side light -J860- | ||||||
| SC38 | Fuse 38 on fuse holder C -SC38- | 25 A | Trailer detector control unit -J345- | 30 | ||
| SC39 | Fuse 39 on fuse holder C -SC39- | 30 A | Front passenger door control unit -J387-1) | 30 | ||
| Rear right window regulator motor -V27- 1) | ||||||
| Driver door control unit -J386- 2) | ||||||
| Rear left window regulator motor -V26- 2) | ||||||
| SC404), 5) | Fuse 40 on fuse holder C -SC40- | 20 A | Cigarette lighter -U1- 3) | 154) / 305) | ||
| 12 V socket -U5- | ||||||
| 12 V socket 2 -U18- | ||||||
| 12 V socket 3 -U19- | ||||||
| SC41 | Fuse 41 on fuse holder C -SC41- | 25 A | Control unit for front right belt tensioner -J855- | 30 | ||
| SC42 | Fuse 42 on fuse holder C -SC42- | 40 A | Onboard supply control unit -J519-
| 30 | ||
| SC43 | Fuse 43 on fuse holder C -SC43- | 30 A | Onboard supply control unit -J519- | 30 | ||
| SC44 | Fuse 44 on fuse holder C -SC44- | 15 A | Trailer detector control unit -J345- | 30 | ||
| SC45 | Fuse 45 on fuse holder C -SC45- | 15 A | Driver seat lumbar support adjustment switch -E176- | 30 | ||
| Massage control unit -J740- | ||||||
| SC46 | Fuse 46 on fuse holder C -SC46- | 30 A | DC/AC converter with socket, 12 V - 230 V -U13- | 30 | ||
| SC47 | Fuse 47 on fuse holder C -SC47- | 15 A | Rear window wiper motor -V12- | 15 | ||
| SC48 | not assigned | - | - | |||
| SC49 | Fuse 49 on fuse holder C -SC49- | 5 A | Clutch position sender -G476- | 15 | ||
| Starter relay 1 -J906- | ||||||
| Starter relay 2 -J907- | ||||||
| SC50 | Fuse 50 on fuse holder C -SC50- | 40 A | Rear lid control unit -J605- | 30 | ||
| SC51 | Fuse 51 on fuse holder C -SC51- | 25 A | Operating and display unit for rear air conditioning system -E265- | 30 | ||
| SC52 | not assigned | - | - | |||
| SC53 | Fuse 53 on fuse holder C -SC53- | 30 A | Heated rear window relay -J9- | 15 |
| 1) Only left-hand drive models |
| 2) Only right-hand drive models |
| 3) Smokers version |
| 4) Factory fitted with power supply from terminal 15 |
| 5) Power supply via terminal 30 possible |
| 6) Only models with steering wheel heating |
| 7) According to equipment |
| 8) Only models with blind spot monitor |
| 9) Only models with LED headlights |
Note:
| The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged. |
Note:
|
| 1 - | Fuse holder B -SB- |
| Fuse colours for J-Case fuse: |
| t | 50 A - red |
| t | 40 A - green |
| t | 30 A - pink |
| Fuse colours for ATO flat fuse: |
| t | 40 A - orange |
| t | 30 A - light green |
| t | 25 A - natural (white) |
| t | 20 A - yellow |
| t | 15 A - light blue |
| t | 10 A - red |
| t | 7.5 A - brown |
| t | 5 A - light brown |
| t | 1A - black |
|
| Fuse assignment on fuse holder B -SB- |
| Fuse assignment of fuse holder B -SB- , from September 2015 |
| Slot | Current flow diagram designation | Nominal value | Function/component | Terminal | ||
| SB1 | Fuse 1 on fuse holder B -SB1- | 40 A | ABS control unit -J104- | 30 | ||
| SB2 | Fuse 2 on fuse holder B -SB2- | 40 A | ABS control unit -J104- | 30 | ||
| ABS hydraulic pump -V64- | ||||||
| SB3 | Fuse 3 on fuse holder B -SB3- | 15 A 1) 30 A 2) | Engine control unit -J623- | 87 | ||
| SB4 | Fuse 4 on fuse holder B -SB4- | 5 A 2) | Oil level and oil temperature sender -G266- | 87 | ||
| 10 A 1) | Radiator fan control unit -J293- | |||||
| Relay for reducing agent metering system -J963-2) | ||||||
| Activated charcoal filter solenoid valve 1 -N80-1) | ||||||
| Camshaft control valve 1 -N205-1) | ||||||
| Exhaust camshaft control valve 1 -N318-1) | ||||||
| Valve for oil pressure control -N428-1) | ||||||
| Coolant valve for cylinder head -N489- | ||||||
| High heat output relay -J360-2) | ||||||
| Exhaust gas recirculation cooler changeover valve -N345-2) | ||||||
| Low heat output relay -J359-2) | ||||||
| Charge pressure control solenoid valve -N75-2) | ||||||
| SB5 | Fuse 5 on fuse holder B -SB5- | 10 A | Fuel pressure regulating valve -N276-2) | 87 | ||
| Fuel metering valve -N290-2) | ||||||
| Camshaft control valve 1 -N205-2) | ||||||
| SB6 | Fuse 6 on fuse holder B -SB6- | 5 A | Brake light switch -F- | 87 | ||
| SB7 | Fuse 7 on fuse holder B -SB7- | 10 A | Fuel pressure regulating valve -N276-1) | 87 | ||
| Charge air cooling pump -V188-1) | ||||||
| Valve for oil pressure control -N428-2) | ||||||
| Coolant valve for cylinder head -N489-2) | ||||||
| Auxiliary pump for heating -V488-2) | ||||||
| Radiator blind control motor -V544-4) | ||||||
| SB8 | Fuse 8 on fuse holder B -SB8- | 10 A 1) 15 A 2) | Lambda probe 1 before catalytic converter -GX10-
| 87 | ||
Lambda probe 1 after catalytic converter -GX7-
| ||||||
| NOx sender -G295-2) | ||||||
| SB9 | Fuse 9 on fuse holder B -SB9- | 5 A 2) | Ignition coil 1 with output stage -N70-1) | 87 | ||
| 20 A 1) | Ignition coil 2 with output stage -N127-1) | |||||
| Ignition coil 3 with output stage -N291-1) | ||||||
| Ignition coil 4 with output stage -N292-1) | ||||||
| Air mass meter -G70-2) | ||||||
| Automatic glow period control unit -J179-2) | ||||||
| Heater element for crankcase breather -N79-2) | ||||||
| SB10 | Fuse 10 on fuse holder B -SB10- | 15 A 1) 20 A 2) | Fuel pump control unit -J538-
| 87 | ||
| SB11 | Fuse 11 on fuse holder B -SB11- | 40 A | Auxiliary air heater element -Z35-2) | 87 | ||
| SB12 | Fuse 12 on fuse holder B -SB12- | 40 A | Auxiliary air heater element -Z35-2) | 87 | ||
| SB13 | Fuse 13 on fuse holder B -SB13- | 30 A | Mechatronic unit for dual clutch gearbox -J743-
| 30 | ||
| 15 A | Mechatronic unit for dual clutch gearbox -J743-
| |||||
| SB14 | Fuse 14 on fuse holder B -SB14- | 30 A | Heated windscreen relay -J47- | 30 | ||
| SB15 | Fuse 15 on fuse holder B -SB15- | 15 A | Horn relay -J413- | 30 | ||
| SB16 | not assigned | - | - | |||
| SB17 | Fuse 17 on fuse holder B -SB17- | 7.5 A | Main relay -J271- 1) | 30 | ||
| Terminal 30 voltage supply relay -J317- 2) | ||||||
| Engine control unit -J623- | ||||||
| ABS control unit -J104- | ||||||
| Heated windscreen relay -J47- | ||||||
| SB18 | Fuse 18 on fuse holder B -SB18- | 5 A | Battery monitor control unit -J367- | 30 | ||
| Data bus diagnostic interface -J533- 3) | ||||||
| SB19 | Fuse 19 on fuse holder B -SB19- | 30 A | Wiper motor control unit -J400- | 30 | ||
| SB20 | Fuse 20 on fuse holder B -SB20- | 10 A | Alarm horn -H12- | 30 | ||
| SB21 | Fuse 21 on fuse holder B -SB21- | 30A | Heated windscreen relay 2 -J611- | 30 | ||
| SB22 | Fuse 22 on fuse holder B -SB22- | 5 A | Engine control unit -J623- | 50 | ||
| SB23 | Fuse 23 on fuse holder B -SB23- | 30 A | Starter -B- | 50 | ||
| SB24 | Fuse 24 on fuse holder B -SB24- | 40 A | Auxiliary air heater element -Z35-2) | 87 | ||
| SB25 | not assigned | - | - | |||
| SB26 | not assigned | - | - | |||
| SB27 | not assigned | - | - | |||
| SB28 | not assigned | - | - | |||
| SB29 | not assigned | - | - | |||
| SB30 | not assigned | - | - | |||
| SB31 | Fuse 31 on fuse holder B -SB31- | 15 A | Vacuum pump for brakes -V192-4) | 87 | ||
| SB32 | not assigned | - | - | |||
| SB33 | not assigned | - | - | |||
| SB34 | not assigned | - | - | |||
| SB35 | not assigned | - | - | |||
| SB36 | not assigned | - | - | |||
| SB37 | Fuse 37 on fuse holder B -SB37- | 20 A | Auxiliary heater control unit -J364- | 30 | ||
| SB38 | not assigned | - | - |
| 1) Only models with petrol engine |
| 2) for models with diesel engine only |
| 3 Only models with no start/stop system |
| 4) According to equipment |
|
| Fitting location, fuse holder A -SA- |
| 1 - | Fuse holder A -SA- |
| 508 - | Threaded connection (30) on E-box |
Note:
|
