VW GOL 2005 – Immobilizer system, 1,9 l – Diesel/47 kW, código de identificação do motor 1Y . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW GOL
  4. >VW GOL 2005
  5. >VW GOL 2005 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW GOL 2005 - Battery - Starter - Alternator - Voltage regulator



Wiring Diagram VW GOL 2005 - Battery - Starter - Alternator - Voltage regulator https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
ABattery
BStarter
CAlternator
C1Voltage regulator
T2bo2-pin connector, on alternator
T2v2-pin connector, near battery
T6e6-pin connector, (brown) next to relay plate
   1 Earth strap, battery body
   49 Earth point, near battery
   501 Screw connection -2- (30), on relay plate
   D26 Positive connection (B+), in alternator wiring harness
   P1 Positive connection (30), in fuse holder on battery

Wiring Diagram VW GOL 2005 - Ignition/starter switch - Immobilizer reading coil - Immobilizer control unit - Fuel shut-off valve



Wiring Diagram VW GOL 2005 - Ignition/starter switch - Immobilizer reading coil - Immobilizer control unit - Fuel shut-off valve https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
DIgnition/starter switch
D2Immobilizer reading coil
J82Ignition cut-off relay
J362Immobilizer control unit
N109Fuel shut-off valve
RRadio
T2bp2-pin connector, on immobilizer control unit
T2cg2-pin connector, near oil filter
T6n6-pin connector, (lilac) behind shelf - front passenger's side
T7c7-pin connector, on ignition/starter switch
T8g8-pin connector, on immobilizer control unit
T8h8-pin connector, on radio
T9k32-pin connector, on dash panel insert
T17b45-pin connector, on 1AV control unit (injection system)
   43 Earth point, lower part of right A-pillar
   213 Earth connection, in dash panel wiring harness
   A2 Positive connection (15), in dash panel wiring harness

Wiring Diagram VW GOL 2005 - Control unit with display in dash panel insert - Dash panel insert - Alternator warning lamp - Immobilizer warning lamp



Wiring Diagram VW GOL 2005 - Control unit with display in dash panel insert - Dash panel insert - Alternator warning lamp - Immobilizer warning lamp https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J285Control unit with display in dash panel insert
KDash panel insert
K2Alternator warning lamp
K117Immobilizer warning lamp
S227Fuse in fuse holder
T16a16-pin connector, behind shelf-driver's side, diagnosis connection
T32a32-pin connector, on dash panel insert
