F59 | Tailgate/bootlid central locking switch (driver's side) |
F114 | Tailgate/bootlid central locking switch (front passenger's side) |
T2e | 2-pin connector, behind relay plate |
T6d | 6-pin connector, on lower part of left A pillar |
T6e | 6-pin connector, on lower part of right A pillar |
T16 | 16-pin connector, self-diagnosis connection in left lower console |
W | Interior light, front |
V37 | Central locking motor (bipressure pump) |
60 | Earth point -2-, near right tail light |
87 | Earth connection -2-, in rear wiring harness |
R10 | Positive (+) connection -1- (30), in door wiring harness - driver's side |
R16 | Positive (+) connection -1- (30), in door wiring harness - front passenger's side |
S14 | Connection (open), in central locking wiring harness |
S15 | Connection (closed), in central locking wiring harness |
W9 | Positive (+) connection (30), in rear wiring harness |
F220 | Central locking lock unit, driver's side |
F221 | Central locking lock unit, front passenger's side |
J276 | Control unit for remote control - central locking |
J284 | Anti-theft alarm system control unit, behind dash panel |
T3d | 3-pin connector, in front right footwell |
T6d | 6-pin connector, on lower part of left A pillar |
T6e | 6-pin connector, on lower part of right A pillar |
T8 | 8-pin connector |
T10 | 10-pin connector |
T12 | 12-pin connector |
T12a | 12-pin connector, in front right footwell |
86 | Earth connection -1-, in rear wiring harness |
S14 | Connection (open), in central locking wiring harness |
S15 | Connection (closed), in central locking wiring harness |
S18 | Connection -2- (open), in central locking wiring harness |
S19 | Connection -2- (closed), in central locking wiring harness |
| Does not apply to models with remote control - central locking |
| Only models with Swiss |
* | Does not apply to models with Swiss |
E2 | Turn signal switch |
E3 | Hazard warning light switch |
F2 | Door contact switch, driver's side |
F3 | Door contact switch, front passenger's side |
F10 | Rear left door contact switch |
F11 | Rear right door contact switch |
J284 | Anti-theft alarm system control unit |
M6 | Turn signal bulb, rear left |
M8 | Turn signal bulb, rear right |
T3d | 3-pin connector, in front right footwell |
T6b | 6-pin connector, behind dash panel |
T8 | 8-pin connector |
T12 | 12-pin connector |
T12a | 12-pin connector, in front right footwell |
W | Interior light, front |
86 | Earth connection -1-, in rear wiring harness |
D57 | Connection (right turn signal), in engine compartment wiring harness |
D58 | Connection (left turn signal), in engine compartment wiring harness |
Q51 | Positive (+) connection (30), in anti-theft alarm system wiring harness |
W22 | Connection (door contact switch), in rear wiring harness |
| Only models with Swiss |
* | Does not apply to models with Swiss |
F120 | Anti-theft alarm system contact switch |
F160 | Rear left door contact switch (rear) |
H8 | Anti-theft alarm system horn |
J284 | Anti-theft alarm system control unit |
K95 | Anti-thef system warning lamp, in driver's door |
T6d | Single connector, on lower part of left A pillar |
T3d | 3-pin connector, in front right footwell |
T3e | 3-pin connector, behind relay plate |
T5m | 5-pin connector, near right tail light |
T5o | 5-pin connector, near left tail light |
T12 | 12-pin connector |
T12a | 12-pin connector, in front right footwell |
W43 | Rear interior light, luggage compartment |
86 | Earth connection -1-, in rear wiring harness |
98 | Earth connection, in tailgate/bootlid wiring harness |
