| A | Battery |
| B | Starter |
| D | Ignition/starter switch |
| J59 | X-contact relief relay |
| S162 | Fuse 1 (30), in fuse holder on battery |
| S163 | Fuse 2 (30), in fuse holder on battery |
| S164 | Fuse 3 (30), in fuse holder on battery |
| S176 | Fuse 4 (30), in fuse holder on battery |
| S177 | Fuse 5 (30), in fuse holder on battery |
| S178 | Fuse 6 (30), in fuse holder on battery |
| S179 | Fuse 7 (30), in fuse holder on battery |
| S180 | Fuse 8 (30), in fuse holder on battery |
| T3 | 3-pin connector |
| T6 | 6-pin connector, brown, in connector protective housing, on left in plenum chamber |
| 1 | Earth strap, battery - body |
| 2 | Earth strap, gearbox - body |
| 500 | Screw connection 1 (30), on relay plate |
| 501 | Screw connection 2 (30), on relay plate |
| 503 | Screw connection (75x), on relay plate |
| A2 | Positive connection (15), in dash panel wiring harness |
| A32 | Positive connection (30), in dash panel wiring harness |
| A52 | Positive connection (30), in dash panel wiring harness |
| A80 | Connection 1 (X), in dash panel wiring harness |
| C | Alternator |
| D2 | Immobilizer reader coil |
| H16 | Lights switched on warning buzzer |
| J285 | Control unit with display in dash panel insert |
| J362 | Immobilizer control unit |
| J... | Engine control units |
| K2 | Alternator warning lamp |
| K117 | Immobilizer warning lamp |
| S5 | Fuse 5 in fuse holder |
| S7 | Fuse 7 in fuse holder |
| S11 | Fuse 11 in fuse holder |
| T4g | 4-pin connector, in engine compartment, near starter |
| T6 | 6-pin connector, brown, in connector protective housing, on left in plenum chamber |
| T10 | 10-pin connector, orange, in connector protective housing, on left in plenum chamber |
| T32 | 32-pin connector, blue |
| T32a | 32-pin connector, green |
| 42 | Earth point, next to steering column |
| 81 | Earth connection 1, in dash panel wiring harness |
| A2 | Positive connection (15), in dash panel wiring harness |
| A13 | Connection (door contact switch), in dash panel wiring harness |
| G5 | Rev. counter |
| G22 | Speedometer sender, in gearbox |
| J285 | Control unit with display in dash panel insert |
| J... | Engine control units |
| K105 | Reserve fuel warning lamp |
| L75 | Digital display illumination bulb |
| S22 | Fuse 22 in fuse holder |
| S223 | Fuse 23 in fuse holder |
| T10 | 10-pin connector, orange, in connector protective housing, on left in plenum chamber |
| T10a | 10-pin connector, in cable channel left in engine compartment |
| T14 | 14-pin connector, in engine compartment |
| T32 | 32-pin connector, blue |
| T32a | 32-pin connector, green |
| Y4 | Odometer display |
| A27 | Connection (speed signal), in dash panel wiring harness |
| A43 | Connection (57L), in dash panel wiring harness |
| A44 | Connection (57R), in dash panel wiring harness |
| A84 | Connection (58L), in dash panel wiring harness |
| A85 | Connection (58R), in dash panel wiring harness |
| * | revolution signal engine control unit |
| F9 | Handbrake warning switch |
| F34 | Brake fluid level warning contact |
| J285 | Control unit with display in dash panel insert |
| K1 | Main beam warning lamp |
| K13 | Rear fog light warning lamp |
| K14 | Handbrake warning lamp |
| K65 | Left turn signal warning lamp |
| K94 | Right turn signal warning lamp |
| K118 | Brake system warning lamp |
| T32 | 32-pin connector, blue |
| T32a | 32-pin connector, green |
| Y2 | Digital clock |
| 81 | Earth connection 1, in dash panel wiring harness |
| 135 | Earth connection 2, in dash panel wiring harness |
| 179 | Earth connection, in left headlight wiring harness |
| 238 | Earth connection 1, in interior wiring harness |
| 605 | Earth point, on top end of steering column |
| A5 | Positive connection (right turn signal), in dash panel wiring harness |
| A6 | Positive connection (left turn signal), in dash panel wiring harness |
| A51 | Connection (56), in dash panel wiring harness |
| A88 | Connection (RFL), in dash panel wiring harness |
| * | not for ABS |
| E2 | Turn signal switch |
| E4 | Headlight dipper/flasher switch |
| E19 | Parking light switch |
| L1 | Left twin filament bulb |
| M1 | Left side light bulb |
| M5 | Front left turn signal bulb |
| M18 | Left side mounted turn signal bulb |
| S18 | Fuse 18 in fuse holder |
| S19 | Fuse 19 in fuse holder |
| S21 | Fuse 21 in fuse holder |
| T8l | 10-pin connector, on left headlight |
| T12 | 12-pin connector |
| 12 | Earth point, on left in engine compartment |
| 179 | Earth connection, in left headlight wiring harness |
| B166 | Connection (56a), in interior wiring harness |
| B167 | Connection (56b), in interior wiring harness |
| E3 | Hazard warning light switch |
| J1 | Turn signal relay |
| K6 | Hazard warning light system warning lamp |
| L2 | Right twin filament bulb |
| M3 | Right side light bulb |
| M7 | Front right turn signal bulb |
| M19 | Right side mounted turn signal bulb |
| S20 | Fuse 20 in fuse holder |
| T7e | 7-pin connector |
| T8l | 8-pin connector |
| 12 | Earth point, on left in engine compartment |
| 42 | Earth point, next to steering column |
| 81 | Earth connection 1, in dash panel wiring harness |
| 179 | Earth connection, in left headlight wiring harness |
| B167 | Connection (56b), in interior wiring harness |
| C28 | Connection 1 (56b), in headlight wiring harness |
| F | Brake light switch |
| F4 | Reversing light switch |
| F47 | Diesel direct injection system brake light switch |
| J248 | Diesel direct injection system control unit |
| L46 | Rear left fog light bulb |
| M6 | Rear left turn signal bulb |
| M16 | Left reversing light bulb |
| M21 | Left brake and tail light bulb |
| M25 | High level brake light bulb (32 LED's) |
| T5 | 5-pin connector, black, coupling station on left C-pillar |
| T10 | 10-pin connector, orange, in connector protective housing, on left in plenum chamber |
| 50 | Earth point, on left in luggage compartment |
| 98 | Earth connection, in rear lid wiring harness |
| 199 | Earth connection 3, in rear lid dash panel wiring harness |
| A6 | Positive connection (left turn signal), in dash panel wiring harness |
| A18 | Connection (54), in dash panel wiring harness |
| B146 | Positive connection 1 (87), in interior wiring harness |
| W3 | Connection, in rear wiring harness |
| --- | only models with diesel engine |
| E204 | Tank filler flap remote release switch |
| L76 | Button illumination bulb |
| M8 | Rear right turn signal bulb |
| M17 | Right reversing light bulb |
| M22 | Right brake and tail light bulb |
| S14 | Fuse 14 in fuse holder |
| S238 | Fuse 38 in fuse holder |
| T5a | 5-pin connector, black |
| T10i | 10-pin connector |
| V155 | Tank filler flap locking motor |
| 98 | Earth connection, in rear lid wiring harness |
| 135 | Earth connection 2, in dash panel wiring harness |
| 199 | Earth connection 3, in dash panel wiring harness |
| 205 | Earth connection, in driver door wiring harness |
| 218 | Earth connection -1-, in rear lid wiring harness |
| A5 | Positive connection (right turn signal), in dash panel wiring harness |
| A66 | Positive connection (30a, CL/ATA/IR), in dash panel wiring harness |
| R37 | Connection 1 (window regulator), in driver door wiring harness |
| L28 | Cigarette lighter illumination bulb |
| L32 | Rear cigarette lighter illumination bulb |
| L42 | Socket illumination bulb |
| R | Radio |
| S15 | Fuse 15 in fuse holder |
| S237 | Fuse 37 in fuse holder |
| S239 | Fuse 39 in fuse holder |
| S240 | Fuse 40 in fuse holder |
| S241 | Fuse 41 in fuse holder |
| S242 | Fuse 42 in fuse holder |
| T8 | 8-pin connector, on radio |
| U | Electric socket |
| U1 | Cigarette lighter |
| U9 | Rear cigarette lighter |
| 45 | Earth point, centre behind dash panel |
| 81 | Earth connection 1, in dash panel wiring harness |
| A1 | Positive connection (30a), in dash panel wiring harness |
| A4 | Positive connection (58b), in dash panel wiring harness |
| A21 | Connection (86s), in dash panel wiring harness |
| A23 | Positive connection (30al), in dash panel wiring harness |
| E26 | Glove compartment light switch |
| H | Horn plate |
| H1 | Dual tone horn |
| J4 | Dual tone horn relay |
| S3 | Fuse 3 in fuse holder |
| S4 | Fuse 4 in fuse holder |
| T2 | 2-pin connector, on left in luggage compartment |
| T5b | 5-pin connector, next to steering column |
| W6 | Glove compartment light |
| X | Number plate lights |
| 81 | Earth connection 1, in dash panel wiring harness |
| 179 | Earth connection, in left headlight wiring harness |
| 199 | Earth connection 3, in dash panel wiring harness |
| 218 | Earth connection -1-, in rear lid wiring harness |
| A90 | Connection (dual tone horn), in dash panel wiring harness |
| W11 | Connection (58), in rear lid wiring harness |
| E20 | Illumination regulators - switches and instruments |
| E102 | Headlight range control regulator |
| L54 | Headlight range control regulator illumination bulb |
| T6c | 6-pin connector |
| T8l | 8-pin connector, on left headlight |
| T8r | 8-pin connector, on right headlight |
| V48 | Left headlight range control motor |
| V49 | Right headlight range control motor |
| 42 | Earth point, on steering column |
| A103 | Connection 2 (56), in dash panel wiring harness |
| A114 | Connection (headlight range control), in dash panel wiring harness |
| A11 | Connection 2 (58b), in dash panel wiring harness |
| 119 | Earth connection 1, in headlight wiring harness |
| E9 | Fresh air blower switch |
| E159 | Fresh air/air recirculation flap switch |
| K114 | Fresh air and air recirculation warning lamp |
| L16 | Fresh air regulator illumination bulb |
| N24 | Fresh air blower series resistor with overheating fuse |
| S2 | Fuse 2 in fuse holder |
| S225 | Fuse 25 in fuse holder |
| T4c | 4-pin connector |
| T6d | 6-pin connector |
| T8b | 8-pin connector |
| T10j | 10-pin connector, behind centre dash panel |
| V2 | Fresh air blower |
| V154 | Fresh air/recirculated air flap control motor |
| 44 | Earth point, lower part of left A-pillar |
| 162 | Earth connection, in blower motor wiring harness |
| A1 | Positive connection (30a), in dash panel wiring harness |
| A20 | Connection (15a), in dash panel wiring harness |
| L66 | Connection, in heater blower wiring harness |
| E15 | Heated rear window switch |
| K10 | Heated rear window warning lamp |
| L39 | Heated rear window switch illumination bulb |
| S224 | Fuse 24 in fuse holder |
| S226 | Fuse 26 in fuse holder |
| T5 | 5-pin connector, black, coupling station on left C-pillar |
| T7 | 7-pin connector |
| V5 | Washer pump |
| Z1 | Heated rear window |
| Z4 | Driver side heated exterior mirror |
| Z5 | Front passenger heated exterior mirror |
| 81 | Earth connection 1, in dash panel wiring harness |
| 98 | Earth connection, in rear lid wiring harness |
| A82 | Connection (windscreen heater), in dash panel wiring harness |
| A96 | Connection (53a), in dash panel wiring harness |
| A97 | Connection (53), in dash panel wiring harness |
| A102 | Connection (windscreen wiper), in dash panel wiring harness |
| E22 | Intermittent wiper switch |
| E38 | Intermittent wiper regulator |
| J31 | Automatic intermittent wash and wipe relay, on relay plate |
| T5c | 5-pin connector, on windscreen wiper motor |
| T6d | 6-pin connector |
| T8c | 8-pin connector |
| T18a | 18-pin connector |
| V | Windscreen wiper motor |
| 81 | Earth connection 1, in dash panel wiring harness |
| 179 | Earth connection, in left headlight wiring harness |
| A96 | Connection (53a), in dash panel wiring harness |
| A97 | Connection (53), in dash panel wiring harness |
| A102 | Connection (windscreen wiper), in dash panel wiring harness |
| F2 | Driver door contact switch |
| G17 | Ambient temperature sensor |
| J29 | Blocking diode |
| M27 | Left door warning lamp |
| T10i | 10-pin connector, black, coupling station on left A-pillar |
| W | Front interior light |
| Y2 | Digital clock |
| 128 | Earth connection 1, in interior light wiring harness |
| 238 | Earth connection 1, in interior wiring harness |
| B129 | Connection (interior light, 31), in interior wiring harness |
| R5 | Connection 2, in interior light wiring harness |
| R6 | Positive connection 1, in interior light wiring harness |
| R7 | Positive connection 2, in interior light wiring harness |
| F3 | Front passenger door contact switch |
| F5 | Luggage compartment light switch |
| J29 | Blocking diode |
| M28 | Right door warning lamp |
| T5 | 5-pin connector, black |
| T5b | 5-pin connector, brown |
| T10r | 10-pin connector, black, coupling station right A-pillar |
| W3 | Luggage compartment light |
| W11 | Rear left reading light |
| W12 | Rear right reading light |
| 128 | Earth connection 1, in interior light wiring harness |
| 218 | Earth connection -1-, in rear lid wiring harness |
| B129 | Connection (interior light, 31l), in interior wiring harness |
| R5 | Connection 2, in interior light wiring harness |
| R6 | Positive connection 1, in interior light wiring harness |
| R7 | Positive connection 2, in interior light wiring harness |
| R48 | Connection, in front passenger side door wiring harness |
| J... | Control units |
| T10a | 10-pin connector, black, coupling station on left A-pillar |
| T16 | 16-pin connector, in centre dash panel, self-diagnosis connection |
| 81 | Earth connection 1, in dash panel wiring harness |
| 128 | Earth connection 1, in interior light wiring harness |
| 135 | Earth connection 2, in dash panel wiring harness |
| 238 | Earth connection 1, in interior wiring harness |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| A81 | Connection 2 (X), in dash panel wiring harness |
| --- | only models with diesel engine |
Čeština
Dansk
Deutsch
Ελληνικά
English
Español
Suomi
Français
Français
עברית
Hrvatski
Magyar
Italiano
日本語
한국어
Nederlands
Polski
Português
Português
Română
Русский
Slovenčina
Slovenščina
Svenska
Türkçe
中文 (中国)
