VW NEW BEETLE 1999 – 4 Speed automatic gearbox (AG 4) . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW NEW BEETLE
  4. >VW NEW BEETLE 1999
  5. >VW NEW BEETLE 1999 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW NEW BEETLE 1999 - Starter inhibitor and reversing light relay



Wiring Diagram VW NEW BEETLE 1999 - Starter inhibitor and reversing light relay https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
BStarter
DIgnition/starter switch
F4Reversing light switch
J226Starter inhibitor and reversing light relay, on 13 position additional relay carrier
J285Control unit with display in dash panel insert
S15Fuse in relay plate fuse box
T66-pin connector, brown, in protective housing for connectors, left in plenum chamber
T1010-pin connector, orange, in protective housing for connectors, left in plenum chamber
T10g10-pin connector, grey, in protective housing for connectors, in plenum chamber, left
T3232-pin connector, blue
   114 Earth connection (dash panel insert), in automatic gearbox wiring harness
   501 Screw connection -2- (30), on relay plate
   A32 Positive connection (30), in dash panel wiring harness
   A52 Positive connection -2- (30), in dash panel wiring harness
   A56 Positive connection -2- (30), in dash panel wiring harness
   A87 Connection (RL), in dash panel wiring harness

Wiring Diagram VW NEW BEETLE 1999 - Automatic gearbox control unit - multi-function switch - kick-down switch



Wiring Diagram VW NEW BEETLE 1999 - Automatic gearbox control unit - multi-function switch - kick-down switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
FBrake light switch
F8Kick-down switch
F125Multi-function switch
J...Engine control unit, in plenum chamber, centre
J217Automatic gearbox, in plenum chamber, centre
J285Control unit with display in dash panel insert
T88-pin connector
T1010-pin connector, orange, in protective housing for connectors, in plenum chamber, left
T10g10-pin connector, grey, in protective housing for connectors, in plenum chamber, left
T1616-pin connector, in dash panel centre, self-diagnosis connection
T3232-pin connector, blue
T6868-pin connector
   10 Earth point, in plenum chamber
   114 Earth connection, in automatic gearbox wiring harness
   A18 Connection (54), in dash panel wiring harness
   A56 Positive (+) connection -2- (30), in instruments wiring harness
   A76 Connection (diagnosis wire K), in dash panel wiring harness
*Compressor switch-off

Wiring Diagram VW NEW BEETLE 1999 - Automatic gearbox control unit - solenoid valve - gearbox speed sender



Wiring Diagram VW NEW BEETLE 1999 - Automatic gearbox control unit - solenoid valve - gearbox speed sender https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G38Gearbox speed sender
G93Gearbox oil temperature sender
J...Engine control unit, in plenum chamber, centre
J104ABS/ABS with EDL control unit
J217Automatic gearbox Gearbox, in plenum chamber, centre
N88Solenoid valve 1
N89Solenoid valve 2
N90Solenoid valve 3
N91Solenoid valve 4
N92Solenoid valve 5
N93Solenoid valve 6
N94Solenoid valve 7
T22-pin connector, on gearbox
T10a10-pin connector, green, in protective housing for connectors, in plenum chamber, left
T1212-pin connector
T2525-pin connector
T6868-pin connector
   B229 Connection (high bus), in interior wiring harness
   B230 Connection (low bus), in interior wiring harness

Wiring Diagram VW NEW BEETLE 1999 - Automatic gearbox control unit - road speed sender - selector lever lock solenoid



Wiring Diagram VW NEW BEETLE 1999 - Automatic gearbox control unit - road speed sender - selector lever lock solenoid https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E1Lighting switch
G68Road speed sender
J29Diode
J217Automatic gearbox control unit, centre in plenum chamber
J285Control unit with display in dash panel insert
K142Selector lever position P/N warning lamp
L101Selector lever display illumination
N110Selector lever lock solenoid
S7Fuse in fuse box
S11Fuse in fuse box
S231Fuse in fuse holder
T33-pin connector, on gearbox
T10g10-pin connector, grey, in protective housing for connectors, left plenum chamber
T3232-pin connector, blue
T6868-pin connector
   238 Earth connection -1-, in interior wiring harness
   A2 Positive (+) connection (15), in dash panel wiring harness
   A4 Positive (+) connection (58b), in dash panel wiring harness
   A53 Positive connection (58b), in dash panel wiring harness
   B163 Positive connection -1- (15), in interior wiring harness
   B165 Positive connection -2- (15), in interior wiring harness
   U8 Positive connection (15a), in automatic gearbox wiring harness
