| D | Ignition/starter switch |
| E150 | Interior locking switch, driver's side |
| F220 | Central locking lock unit, driver's side |
| J429 | Central locking control unit |
| L99 | Interior lock switch illumination |
| S237 | Fuse in fuse box |
| T5e | 5-pin connector, in front passenger's door |
| T10e | 10-pin connector, black, connector point, electronics box, in plenum chamber, left |
| T10i | 10-pin connector, black, connector point, left A pillar |
| T10r | 10-pin connector, black, connector point, right A pillar |
| T10v | 10-pin connector, brown, connector point, left A pillar |
| T23 | 23-pin connector, black, connector A, central control unit |
| T24 | 24-pin connector, black, connector C, central control unit |
| 205 | Earth connection, in door wiring harness - driver's side |
| A4 | Positive (+) connection (58b), in dash panel wiring harness |
| A21 | Connection (86s), in dash panel wiring harness |
| A116 | Connection -2- (58d), in dash panel wiring harness |
| R51 | Connection (58b), in door wiring harness - driver's side |
| J429 | Central locking control unit |
| K133 | Central locking warning lamp -SAFE- |
| T8 | 8-pin connector |
| T10i | 10-pin connector, black, connector point, A pillar, left |
| T10t | 10-pin connector, blue, connector point, A pillar, left |
| T10v | 10-pin connector, brown, connector point, A pillar, left |
| T23 | 23-pin connector |
| V17 | Mirror adjustment motor, driver's side |
| V149 | Mirror adjustment motor, driver's side |
| Z4 | Heated exterior mirror, driver's side |
| 44 | Earth point, lower part of left A pillar |
| 205 | Earth connection, in door wiring harness - driver's side |
| F221 | Central locking lock unit, front passenger's side |
| J429 | Central locking control unit |
| T5a | 5-pin connector, black, in tailgate/bootlid |
| T10b | 10-pin connector, blue, connector point, electronics box, in plenum chamber, left |
| T10i | 10-pin connector, black, connector point, left A pillar |
| T10u | 10-pin connector, brown, connector point, right A pillar |
| T23 | 23-pin connector, black, connector A, central control unit |
| T24 | 24-pin connector, black, connector C, central control unit |
| 50 | Earth point, on left luggage compartment |
| 98 | Earth connection, in tailgate/bootlid wiring harness |
| 218 | Earth connection -1-, in tailgate/boot lid wiring harness |
| B134 | Connection (central locking closed), in interior wiring harness |
| E204 | Tank filler flap remote release switch |
| J398 | Tailgate/bootlid remote release control motor |
| J429 | Central locking control unit |
| L104 | Remote release switch illumination |
| S228 | Fuse in fuse box |
| T5a | 5-pin connector, black, in tailgate/bootlid |
| T5g | 5-pin connector, brown, connector point, left C pillar |
| T10i | 10-pin connector, black, connector point, left A pillar |
| T23 | 23-pin connector, black, connector A, central control unit |
| V53 | Central locking motor, tailgate/bootlid |
| V155 | Tank filler flap release motor |
| 218 | Earth connection -1-, in tailgate/bootlid wiring harness |
| A66 | Connection (30a, (ZV/DWA/IR (central locking/anti-theft alarm system/infra-red remote control), in dash panel wiring harness |
| * | Only models with central locking |
| ** | Not for models with central locking |
| E15 | Heated rear window switch |
| E198 | Interior locking switch, front passenger side |
| J429 | Central locking control unit |
| L99 | Interior lock switch illumination |
| T5c | 5-pin connector, near wiper motor |
| T8g | 8-pin connector, mirror, front passenger's side |
| T10r | 10-pin connector, black, connector point, right A pillar |
| T10u | 10-pin connector, brown, connector point, right A pillar |
| T10x | 10-pin connector, blue, connector point, right A pillar |
| T24 | 24-pin connector, black, connector C, central control unit |
| V25 | Mirror adjustment motor, front passenger's side |
| V150 | Mirror adjustment motor, front passenger's side |
| Z5 | Heated exterior mirror, front passenger's side |
| 43 | Earth point, lower part of right A-pillar |
| 206 | Earth connection, in door wiring harness - front passenger's side |
| A82 | Connection (windscreen heater), in dash panel wiring harness |
| B133 | Connection (central locking open), in interior wiring harness |
| E188 | Bootlid/tailgate remote control switch |
| F147 | Vanity mirror contact switch, driver side |
| F148 | Vanity mirror contact switch, front passenger side |
| J234 | Airbag control unit |
| J429 | Central locking control unit |
| L104 | Remote release switch illumination |
| T4c | 4-pin connector, on fresh air blower |
| T10i | 10-pin connector, black, connector point, left A pillar |
| T16 | 16-pin connector, diagnostic connector |
| T24 | 24-pin connector, black, connector C, central control unit |
| T50 | 50-pin connector |
| W14 | Illuminated vanity mirror, front passenger's side |
| W20 | Illuminated vanity mirror, driver's side |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| A125 | Connection (crash signal), in dash panel wiring harness |
| * | Only models with central locking |
| ** | Not with models with central locking |
| E2 | Turn signal switch |
| F124 | Contact switch in lock cylinder for tailgate anti-theft alarm system/central locking system |
| H8 | Anti-theft alarm system horn |
| H12 | Alarm horn |
| J429 | Central locking control unit |
| T5b | 5-pin connector, brown, in tailgate/bootlid |
| T5g | 5-pin connector, brown, connector point, left C pillar |
| T15 | 15-pin connector, black, connector B, central control unit |
| T23 | 23-pin connector, black, connector A, central control unit |
| T24 | 24-pin connector |
| R47 | Central locking and anti-theft alarm system aerial |
| 12 | Earth point, in engine compartment, left |
| 135 | Earth connection -2-, in dash panel wiring harness |
| 278 | Earth connection -4-, in interior wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| A27 | Connection (speed signal), in dash panel wiring harness |
| * | Does not apply to models with alarm horn H12 |
| ** | Only Great Britain |
| D | Ignition/starter switch |
| E139 | Sliding sunroof adjustment regulator |
| J223 | Adjustable rear spoiler control unit |
| J245 | Sliding sunroof adjustment control unit |
| J429 | Central locking control unit |
| S6 | Fuse in fuse box |
| S111 | Fuse for anti-theft alarm system and immobilizer |
| S144 | Anti-theft alarm system/ central locking fuse |
| S230 | Fuse in fuse box |
| T6 | 6-pin connector |
| T15 | 15-pin connector |
| T23 | 23-pin connector |
| T24 | 24-pin connector |
| 42 | Earth point, next to steering column |
| 81 | Earth connection -1-, in dash panel wiring harness |
| 135 | Earth connection -2-, in dash panel wiring harness |
| 278 | Earth connection -4-, in interior wiring harness |
| 501 | Screw connection -2- (30), on relay plate |
| A20 | Connection (15a), in dash panel wiring harness |
| A32 | Positive (+) connection (30), in dash panel wiring harness |
| * | Only models with central locking |
| ** | Not for models with central locking |
| E165 | Tailgate/bootlid release switch |
| F5 | Luggage compartment light switch |
| F266 | Bonnet contact switch |
| J29 | Diode |
| J429 | Central locking control unit |
| T5 | 5-pin connector, black, connector point, left A pillar |
| T5a | 5-pin connector, black, in tailgate/bootlid |
| T5b | 5-pin connector, brown, in tailgate/bootlid |
| T15 | 15-pin connector, black, connector B, central control unit |
| T23 | 23-pin connector, black, connector A, central control unit |
| T24 | 24-pin connector, black, connector C, central control unit |
| W3 | Luggage compartment light |
| A13 | Connection (door contact switch), in dash panel wiring harness |
| A126 | Connection (tailgate/bootlid contact switch), in dash panel wiring harness |
| B128 | Connection (luggage compartment light), in interior wiring harness |
| B155 | Connection -2- (TK (door contact)), in interior wiring harness |
| R6 | Positive (+) connection -1-, in interior light wiring harness |
| * | Only models with central locking |
| ** | Not for models with central locking |
| E183 | Interior monitor switch |
| G170 | Left ultra-sonic sensor for anti-theft alarm system |
| G171 | Right ultra-sonic sensor for anti-theft alarm system |
| W | Interior light, front |
| W11 | Reading lamp, rear left |
| W12 | Reading lamp, rear right |
| Y2 | Digital clock |
| B129 | Connection (interior light, 311), in interior wiring harness |
| B161 | Connection (anti-theft alarm), in interior wiring harness |
| B169 | Positive (+) connection -1- (30), in interior wiring harness |
| R7 | Positive (+) connection -2-, in interior light wiring harness |
