Wiring Diagram VW NEW BEETLE 1999 - Door control unit (driver's side) - driver's door electric window lifter - switch for interior locking (driver's side (LHD)
| E40 | Front left electric window switch |
| E81 | Electric window switch, front right |
| E150 | Interior locking switch, driver's side |
| J386 | Door control unit, driver's side |
| L76 | Button illumination |
| L99 | Rinterior locking switch illumination |
| S37 | Electric window single fuse, on the position relay carrier above the relay plate |
| T5d | 5-pin connector |
| T5e | 5-pin connector |
| T5f | 5-pin connector |
| T10i | 10-pin connector, black, coupling station left A-pillar |
| T29 | 29-pin connector |
| V147 | Electric window motor, driver's side |
| 267 | Earth connection -2-, in driver's door wiring harness |
| B110 | Connection (30, electric windows), in interior wiring harness |
| R51 | Connection (58b), in driver's side door wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Door control unit (driver's side) - central locking lock unit (driver's side (LHD)) - central locking warning lamp
| F220 | Central locking lock unit, driver's side |
| J386 | Door control unit, driver's side |
| K133 | Central locking warning lamp -SAFE- |
| T10e | 10-pin connector |
| T29 | 29-pin connector |
Wiring Diagram VW NEW BEETLE 1999 - Door control unit (driver's side) - driver's door electrically adjustable exterior mirror
| J386 | Door control unit, driver's side |
| T8 | 8-pin connector, black |
| T10i | 10-pin connector, black, coupling station left A-pillar |
| T29 | 29-pin connector |
| V17 | Mirror adjustment motor, driver's side |
| V149 | Mirror adjustment motor, driver's side |
| Z4 | Heated exterior mirror, driver's side |
| 44 | Earth point, A-pillar left, bottom |
| 205 | Earth connection, in driver`s door wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Door control unit (driver's side (LHD)) - mirror adjustment switch - mirror adjustment/fold-in function change-over switch
| E43 | Mirror adjustment switch |
| E48 | Mirror adjustment change-over switch |
| J386 | Door control unit, driver's side |
| L78 | Mirror adjustment switch illumination |
| T8a | 8-pin connector |
| T10i | 10-pin connector, black, coupling station left A-pillar |
| T29 | 29-pin connector |
| B146 | Connection (high bus), in interior wiring harness |
| B147 | Connection (low bus), in interior wiring harness |
| R11 | Positive connection -2- (30), in driver's door wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Door control unit (front passenger's side (LHD)) - electric window switch - switch for central locking (front passenger's side)
| E107 | Electric window switch, in front passenger's door |
| F221 | Central locking lock unit, passenger's side |
| J387 | Door control unit, front passenger's side |
| L53 | Electric window switch light bulb |
| T5e | 5-pin connector |
| T10b | 10-pin connector |
| T10r | 10-pin connector, black, coupling station right A-pillar |
| T29a | 29-pin connector |
| V148 | Electric window motor, front passenger's side |
| 206 | Earth connection, in front passenger door wiring harness |
| 268 | Earth connection -2-, in front passenger's door wiring harness |
| A146 | Connection (high bus), in interior wiring harness |
| A147 | Connection (low bus), in interior wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Doer control unit (front passenger's side (LHD)) - electric window switch - switch for central locking (front passenger's side)
| E198 | Interior locking switch, passenger's side |
| J387 | Door control unit, front passenger's side |
| L99 | Rinterior locking switch illumination |
| T5c | 5-pin connector |
| T8g | 8-pin connector |
| T10r | 10-pin connector, black, coupling station right A-pillar |
| T29a | 29-pin connector |
| V25 | Mirror adjustment motor, front passenger side |
| V150 | Mirror adjustment motor, front passenger's side |
| Z5 | Heated exterior mirror, front passenger's side |
| 43 | Earth point, A-pillar, right lower |
| 268 | Earth connection -2-, in front passenger's door wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Front interior lights - digital clock - rear reading lights - anti-theft warning system ultra-sonic sensors - interior monitoring switch
| E183 | Interior monitor switch |
| G170 | Left-hand anti-theft warning system ultra-sonic sensor |
| G171 | Right-hand anti-theft warning system ultra-sonic sensor |
| W | Interior light, front |
| W11 | Reading lamp, rear left |
| W12 | Reading lamp, rear right |
| Y2 | Digital clock |
| B129 | Connection (interior light, 31L), in interior wiring harness |
| B161 | Connection (ATA), in interior wiring harness |
| B169 | Positive connection -1- (30), in interior wiring harness |
| R7 | Positive connection -2-, in interior light wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Convenience system central control unit - luggage compartment light - luggage compartment light switch
| D | Ignition/starter switch |
| E165 | Tailgate/boot lid release switch |
| F5 | Luggage compartment light switch |
| J29 | Diode |
| J285 | Control unit with display in dash panel insert |
| J393 | Convenience system central control unit |
| K116 | Tailgate/boot lid released warning lamp |
| S237 | Fuse in fuse holder |
| T5 | 5-pin connector, black |
| T5b | 5-pin connector, brown |
| T23 | 23-pin connector |
| T32 | 32-pin connector, blue |
| W3 | Luggage compartment light |
| A13 | Connection (door contact switch), in dash panel wiring harness |
| A21 | Connection (86s), in dash panel wiring harness |
| A146 | Connection (high bus), in interior wiring harness |
| A147 | Connection (low bus), in interior wiring harness |
| A126 | Connection (tailgate/boot lid contact switch), in dash panel wiring harness |
| B128 | Connection (interior light), in interior wiring harness |
| R6 | Positive connection -1-, in interior light wiring harness |
| R7 | Positive connection -2-, in interior light wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Convenience system central control unit - tailgate/boot lid central locking motor - tank flap remote release
| E204 | Tank filler flap remote release switch |
| J393 | Convenience system central control unit |
| L104 | Remote release switch illumination |
| S14 | Fuse in relay plate fuse box |
| S238 | Fuse in fuse holder |
| T5a | 5-pin connector, black, in the tailgate |
| T5g | 5-pin connector, brown, in tailgate/boot lid |
| T10i | 10-pin connector, black, coupling station left A-pillar |
| T23 | 23-pin connector |
| V53 | Central locking motor, tailgate/boot lid |
| V155 | Tank filler flap locking motor |
| 135 | Earth connection -2-, in dash panel wiring harness |
| 218 | Earth connection -1-, in tailgate/boot lid wiring harness |
| A66 | Connection (30a, CL/ATA/IR), in dash panel wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Convenience system central control unit - tailgate remote control switch - illuminated make-up mirror (driver's and front passenger's sides) - self-diagnosis connection
| E188 | Boot lid/tailgate remote control switch |
| F147 | Vanity mirror contact switch, driver's side |
| F148 | Vanity mirror contact switch, front passenger's side |
| J234 | Airbag control unit |
| J393 | Convenience system central control unit |
| L104 | Remote release switch illumination |
| T4c | 4-pin connector |
| T10i | 10-pin connector, black, coupling station left A-pillar |
| T10r | 10-pin connector, black, coupling station right A-pillar |
| T16 | 16-pin connector, in centre of dash panel, self-diagnosis connection |
| T23 | 23-pin connector |
| T50 | 50-pin connector |
| W14 | Illuminated vanity mirror, front passenger's side |
| W20 | Illuminated vanity mirror, driver's side |
| 135 | Earth connection -2-, in dash panel wiring harness |
| A4 | Positive (+) connection (58b), in dash panel wiring harness |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| A125 | Connection (crash signal), in dash panel wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Convenience system central control unit - contact switch in lock cylinder for tailgate anti-theft alarm system/central locking system
| F124 | Contact switch in lock cylinder for tailgate/boot lid anti-theft alarm system/central locking system |
| J393 | Convenience system central control unit, left behind dash panel |
| S5 | Fuse in relay plate fuse box |
| T5b | 5-pin connector, brown |
| T5g | 5-pin connector, brown, in tailgate/boot lid |
| T5h | 5-pin connector |
| T10t | 10-pin connector, blue, coupling station left A-pillar |
| T23 | 23-pin connector |
| 42 | Earth point, next to steering column |
| 278 | Connection (4), in interior wiring harness |
| A20 | Connection (15a), in dash panel wiring harness |
| A27 | Connection (speed signal), in dash panel wiring harness |
Wiring Diagram VW NEW BEETLE 1999 - Convenience system central control unit - anti-theft alarm horn - aerial for central locking and anti-theft alarm system
| E2 | Turn signal switch |
| J393 | Convenience system central control unit, left behind dash panel |
| H8 | Anti-theft alarm system horn |
| H12 | Alarm horn |
| R47 | Aerial for central locking and anti-theft alarm system |
| S111 | Anti-theft alarm system and immobilizer fuse |
| S144 | Central locking/anti-theft alarm system fuse |
| T15 | 15-pin connector |
| 12 | Earth point, in engine compartment, left |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| ✶ | Not with alarm horn H12 |
| ✶✶ | Great Britain only |
Wiring Diagram VW NEW BEETLE 1999 - Convenience system central control unit - control unit for sliding sunroof adjustment - regulator for sliding sunroof adjustment
| D | Ignition/starter switch |
| E139 | Sliding sunroof adjustment regulator |
| J245 | Sliding sunroof adjustment control unit |
| J393 | Convenience system central control unit, left behind dash panel |
| S6 | Fuse in relay plate fuse box |
| S230 | Fuse in fuse holder |
| T6 | 6-pin connector |
| T23 | 23-pin connector |
| 135 | Earth connection -2-, in dash panel wiring harness |
| 501 | Screw connection -2- (30), on relay plate |
| A20 | Positive (+) connection (15a), in dash panel wiring harness |
| A32 | Positive connection (30), in dash panel wiring harness |
| B130 | Connection (sliding sunroof), in interior wiring harness |
