Электросхемы ВНУТРЕННЕЕ ОСВЕЩЕНИЕ Audi Q7 4.2 2008

ВНУТРЕННЕЕ ОСВЕЩЕНИЕ

Электросхема подсветки (1 из 2) для Audi Q7 4.2 2008

Электросхема подсветки (1 из 2) для Audi Q7 4.2 2008 - Список элементов:

• Comfort system central control module (right side of luggage compt)
• Computer data lines system
• Door locks system
• Driver's make-up mirror light/ switch
• G43
• G44
• G51
• G664
• G668
• Glove compart- ment light
• Glove compart- ment light switch
• Left footwell light
• Left luggage compart -ment light
• Left rear central locking unit
• Left rear door control module (in rear door behind inner trim panel)
• Left rear door warning light
• Left rear entry light
• Left rear footwell light
• Pass- enger's make-up mirror light/ switch
• Power windows, mirrors, door locks systems & instrument illumination circuit
• Rear lid courtesy light
• Rear lid lock button
• Right footwell light
• Right luggage compart -ment light
• Right rear central locking unit
• Right rear door control module (in rear door behind inner trim panel)
• Right rear door warning light
• Right rear entry light
• Right rear footwell light
• T15a
• T16i
• T16m
• T20n
• T20o
• T32b
• T32d
• Vehicle electrical system control module

Электросхема подсветки (2 из 2) для Audi Q7 4.2 2008

Электросхема подсветки (2 из 2) для Audi Q7 4.2 2008 - Список элементов:

• Comfort system central control module 2 (right side of luggage compt)
• Computer data lines system
• Door locks system
• Driver's door central locking unit
• Driver's door control module (in driver's door behind inner trim panel)
• Driver's door warning light
• Front passenger's door central locking unit
• Front passenger's door control module (in front passenger's door behind inner trim panel)
• Front passenger's map/reading light
• Front roof control module
• G44
• G658
• If equipped
• Instrument cluster control module
• Interior lights system (instrument illumination circuit)
• Left front entry light
• Left front reading light
• Left interior light
• Mirror system
• Pass- enger's door warning light
• Power windows, mirrors, door locks systems & instrument illumination circuit
• Rear courtesy light (w/ light switch)
• Rear courtesy light (w/o light switch)
• Rear interior lights assembly
• Right front entry light
• Right interior light
• T12a
• T20f
• T20l
• T20m
• T2x
• T32a
• T32f
• T32g
• W/ light switch
• W/o light switch

Электросхема подсветки приборов (1 из 2) для Audi Q7 4.2 2008

Электросхема подсветки приборов (1 из 2) для Audi Q7 4.2 2008 - Список элементов:

• (4)
• 12v socket
• Asr/esp button
• Astray & cup holder light
• Center instru- ment panel vent light
• Cigarette lighter
• Computer data lines system
• Display & glove compart- ment button
• Emergency flasher switch
• Front roof control module
• Front/ center console control head
• G43
• G44
• G45
• G658
• G664
• G67
• G687
• Garage door opener control head
• Instrument cluster control module
• Lane assist- ance button light
• Left instru- ment panel vent light
• Left rear heated seat regul- ating switch
• Light switch
• Load level button
• Rear center air vent light
• Rear sunroof switch
• Right instru- ment panel vent light
• Right rear heated seat regul- ating switch
• Sunroof switch
• Sunroof switch light
• T12a
• T12b
• T2x
• T2y
• T32a
• T32b
• Vehicle electrical system control module

Электросхема подсветки приборов (2 из 2) для Audi Q7 4.2 2008

Электросхема подсветки приборов (2 из 2) для Audi Q7 4.2 2008 - Список элементов:

• Alarm system off switch
• Central locking safe indicator light
• Computer data lines system
• Driver door opener light
• Driver side interior lock switch
• Driver's door control module (in driver's door behind inner trim panel)
• Driver's seat memory program switch
• Front passenger door control module (in front passenger's door, behind inner trim panel)
• Left rear ashtray light
• Left rear door control module (in rear door, behind inner trim panel)
• Left rear door opener light
• Left rear interior switch
• Left rear window switch
• Mirror adjust- ment switch
• Passenger door opener light
• Passenger door window regulator switch
• Passenger seat memory program switch
• Passenger side interior lock switch
• Power window control head
• Power windows, door locks, courtesy lights circuit
• Power windows, mirrors, door locks systems & courtesy lamps circuit
• Rear lid release switch
• Right rear ashtray light
• Right rear door control module (in rear door behind inner trim panel)
• Right rear door opener light
• Right rear interior switch
• Right rear window switch
• T16i
• T16m
• T20l
• T20m
• T20n
• T20o
• T32f
• T32g
