COOLING FAN

Cooling Fan Wiring Diagram for Porsche 944 S2 1990

Cooling Fan Wiring Diagram for Porsche 944 S2 1990 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Cooling Fan Wiring Diagram for Porsche 944 S2 1990:

  • 30m1
  • 30m2
  • 944 turbo
  • Central electric (left in water box)
  • Coolant temperature switch
  • Coolant temperature switch (left side of radiator)
  • F22
  • Fan motor 1 (on radiator)
  • Fan motor 2 (on radiator)
  • Fuse 24 30a
  • Fuse 25a
  • G100 (longi- tudinal support)
  • G100 (longitudinal support)
  • H12
  • Hot at all times
  • Hot in accy or run
  • Intake pipe cooling switch (1989-1991)
  • J42
  • L32
  • N22
  • N23
  • N33
  • N34
  • N35
  • O21
  • O23
  • O33
  • Radiator relay
  • Resistor
