STARTING/CHARGING

Charging Wiring Diagram for Porsche 944 S2 1990

Charging Wiring Diagram for Porsche 944 S2 1990 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file

List of elements for Charging Wiring Diagram for Porsche 944 S2 1990:

  • 1989-91
  • Acc
  • Alarm control unit
  • Alternator
  • Battery
  • Central electric (left rear side of engine compt)
  • Charge indicator
  • D44
  • G123 (right side of safety wall)
  • G129 (on transmission/ transaxle)
  • G23
  • Hot at all times
  • Ignition switch
  • Instrument cluster
  • K13
  • Nca
  • Off
  • Power distribution system
  • Red
  • Start
  • Starter
  • W/ alarm (1988)
  • W/o alarm (1988)

Starting Wiring Diagram for Porsche 944 S2 1990

Starting Wiring Diagram for Porsche 944 S2 1990 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for Starting Wiring Diagram for Porsche 944 S2 1990:

  • 15a
  • A/t
  • Acc
  • Battery
  • Central electric (left rear side of engine compt)
  • Charging system
  • E25
  • G123 (right side of safety wall)
  • G129 (on transmission/ transaxle)
  • G25
  • Hot at all times
  • Ignition switch
  • M/t
  • Off
  • Power distribution system
  • Red
  • Start
  • Starter
  • Starter interlock switch
