VW BORA 2002 – Gas discharge headlights with automatic headlight range control . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW BORA 2002 - Left gas discharge light control unit - left gas discharge bulb - left main beam bulb - left side light bulb - front left turn signal bulb

E4	Headlight dipper/flasher switch
J426	Left headlight starter for gaseous discharge light, behind front left wheel housing
L13	Left gas discharge (xenon) bulb
M1	Left side light bulb
M5	Front left turn signal bulb
M30	Left main beam bulb
N195	Gas discharge light starter unit
S18	Fuse 18 in fuse holder
S19	Fuse 19 in fuse holder
S21	Fuse 21 in fuse holder
T2	2-pin connector, in left headlight
T2a	2-pin connector
T4a	4-pin connector, on left headlight
T6a	6-pin connector
T12	12-pin connector
T12a	12-pin connector, on left headlight
119	Earth connection 1, in headlight wiring harness
125	Earth connection 3, in headlight wiring harness
A6	Positive connection (left turn signal), in dash panel wiring harness
B166	Connection (56a), in interior wiring harness
B167	Connection (56b), in interior wiring harness

E3	Hazard warning light switch
J59	X-contact relief relay
J431	Control unit for headlight range control, in left headlight
S2	Fuse 2 in fuse holder
T8d	8-pin connector**
T12a	12-pin connector, on left headlight
T12c	12-pin connector
T12b	12-pin connector, on right headlight
V48	Left headlight range control motor
V49	Right headlight range control motor
503	Screw connection (75x), on relay plate
A12	Positive connection (75a), in dash panel wiring harness
**	Connection numbering of turn signal relay can vary, see foult finding programme!

G76	Rear left vehicle level sender
G78	Front left vehicle level sender
J431	Control unit for headlight range control, in left headlight
T6b	6-pin connector
T6d	6-pin connector
T12a	12-pin connector, on left headlight
T12b	12-pin connector, on right headlight
T12c	12-pin connector
T16	16-pin connector, in centre dash panel, self-diagnosis connection
184	Earth connection (headlight range control), in engine compartment wiring harness
A76	Connection (diagnosis wire K), in dash panel wiring harness
N2	Connection 1, in headlight range control wiring harness
N3	Connection 2, in headlight range control wiring harness
N4	Connection 3, in headlight range control wiring harness
N5	Connection 4, in headlight range control wiring harness

J427	Right headlight starter for gaseous discharge light, behind front right wheel housing
L14	Right gas discharge (xenon) bulb
M3	Right side light bulb
M7	Front right turn signal bulb
M32	Right main beam bulb
N195	Gas discharge light starter unit
S20	Fuse 20 in fuse holder
T2b	2-pin connector, in right headlight
T2c	2-pin connector
T4b	4-pin connector, on right headlight
T6e	6-pin connector
T12b	12-pin connector, on right headlight
12	Earth point, on left in engine compartment
119	Earth connection 1, in headlight wiring harness
120	Earth connection 2, in headlight wiring harness
A5	Positive connection (right turn signal), in dash panel wiring harness
B167	Connection (56b), in interior wiring harness

E1	Light switch
J285	Control unit with display in dash panel insert
K1	Main beam warning lamp
K65	Left turn signal warning lamp
K94	Right turn signal warning lamp
S22	Fuse 22 in fuse holder
S223	Fuse 23 in fuse holder
T17	17-pin connector
T32	32-pin connector, blue
A5	Positive connection (right turn signal), in dash panel wiring harness
A6	Positive connection (left turn signal), in dash panel wiring harness
A43	Connection (57L), in dash panel wiring harness
A44	Connection (57R), in dash panel wiring harness
A84	Connection (58L), in dash panel wiring harness
A85	Connection (58R), in dash panel wiring harness
A95	Connection 1 (56a), in dash panel wiring harness
