Wiring Diagram VW BORA 2005 - Simos control unit - cruise control system switch - clutch pedal switch - cruise control system brake pedal switch - brake light switch
E45 | Cruise control system switch |
E227 | Cruise control system (CCS) button (Set) |
F | Brake light switch |
F36 | Clutch pedal switch |
F47 | Cruise control system brake pedal switch |
J59 | X contact relief relay |
J361 | Simos control unit, in plenum chamber, centre |
S13 | Fuse in fuse box |
S176 | Fuse -4- (30), in battery fuse box |
T10e | 10-pin connector, black, in control unit protective housing, in plenum chamber, left |
T10s | 10-pin connector, next to steering column |
T10w | 10-pin connector, white, in protective housing for connectors, in plenum chamber, left |
T80 | 80-pin connector |
500 | Screw connection -1- (30), on relay plate |
501 | Screw connection -2- (30), on relay plate |
A18 | Connection (54), in dash panel wiring harness |
A20 | Connection (15a), in dash panel wiring harness |
* | Only models with manual gearbox |
Wiring Diagram VW BORA 2005 - Simos control unit - throttle valve control unit
D | Ignition/starter switch |
F60 | Idling switch |
G40 | Hall sender |
G69 | Throttle valve potentiometer |
G88 | Throttle valve positioner potentiometer |
J338 | Throttle valve control unit |
J361 | Simos control unit, centre in plenum chamber |
S5 | Fuse in relay plate fuse box |
T8 | 8-pin connector |
T80 | 80-pin connector |
V60 | Throttle valve positioner |
220 | Earth connection (sender earth), in engine wiring harness, ⇒ Engine Current Flow Diagram |
A2 | Positive (+) connection (15), in dash panel wiring harness |
A20 | Connection (15a), in dash panel wiring harness |
D101 | Connection -1-, in engine compartment wiring harness |
