VW GOLF 2000 – Day driving light . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW GOLF 2000 - Dash panel insert - turn signal switch - headlight dipper/flasher switch - parking light switch

D	Ignition/starter switch
E2	Turn signal switch
E3	Hazard warning light switch
E4	Headlight dipper/flasher switch
E19	Parking light switch
J285	Control unit with display in dash panel insert
K1	Main beam warning lamp
K13	Rear fog light warning lamp
K65	Left turn signal warning lamp
K94	Right turn signal warning lamp
S22	Fuse 22 in fuse holder
S223	Fuse 23 in fuse holder
T8d	8-pin connector
T12	12-pin connector
T32	32-pin connector, blue
12	Earth point, on left in engine compartment
179	Earth connection, in left headlight wiring harness
A5	Positive connection (right turn signal), in dash panel wiring harness
A6	Positive connection (left turn signal), in dash panel wiring harness
A83	Connection (day driving light), in dash panel wiring harness
A84	Connection (58L), in dash panel wiring harness
A85	Connection (58R), in dash panel wiring harness
A95	Connection 1 (56a), in dash panel wiring harness
*	only Bora/ Bora Variant

L1	Left twin filament bulb*
L2	Right twin filament bulb*
M1	Left side light bulb
M3	Right side light bulb
M5	Front left turn signal bulb
M7	Front right turn signal bulb
M18	Left side mounted turn signal bulb
M19	Right side mounted turn signal bulb
M29	Left dipped beam bulb**
M30	Left main beam bulb**
M31	Right dipped beam bulb**
M32	Right main beam bulb**
S18	Fuse 18 in fuse holder
S19	Fuse 19 in fuse holder
S20	Fuse 20 in fuse holder
S21	Fuse 21 in fuse holder
T10b	10-pin connector, on left headlight
T10c	10-pin connector, on right headlight
179	Earth connection, in left headlight wiring harness
A103	Connection 2 (56), in dash panel wiring harness
B166	Connection (56a), in interior wiring harness
B167	Connection (56b), in interior wiring harness
*	only Bora/ Bora Variant
**	only Golf/ Golf Variant

D	Ignition/starter switch
E1	Light switch
E18	Rear fog light switch
E20	Illumination regulators - switches and instruments
L9	Light switch illumination bulb
J31	Automatic intermittent wash and wipe relay
S3	Fuse 3 in fuse holder
S4	Fuse 4 in fuse holder
S236	Fuse 36 in fuse holder
T6c	6-pin connector
T17	17-pin connector
T18a	18-pin connector
42	Earth point, next to steering column
81	Earth connection 1, in dash panel wiring harness
501	Screw connection 2 (30), on relay plate
A4	Positive connection (58b), in dash panel wiring harness
A32	Positive connection (30), in dash panel wiring harness
A80	Connection 1 (X), in dash panel wiring harness
A83	Connection (day driving light), in dash panel wiring harness
A88	Connection (RFL), in dash panel wiring harness
B167	Connection (56b), in interior wiring harness
**	only Golf/ Golf Variant

F4	Reversing light switch
L46	Rear left fog light bulb
M6	Rear left turn signal bulb
M16	Left reversing light bulb
M21	Left brake and tail light bulb
M25	High level brake light bulb
T5	5-pin connector, black, coupling station on left C-pillar
T5h	5-pin connector, near lower left A-pillar, entwined in wiring harness
T5i	5-pin connector, near lower left A-pillar, entwined in wiring harness
T10	10-pin connector, orange, in connector protective housing, on left in plenum chamber
98	Earth connection, in rear lid wiring harness
218	Earth connection -1-, in rear lid wiring harness
A6	Positive connection (left turn signal), in dash panel wiring harness
B182	Connection (RL), in interior wiring harness
W1	Positive connection (54), in rear wiring harness
W28	Positive connection 2 (54), in rear wiring harness
---	only Golf Variant/ Bora Variant
-●-●-	only Golf

F	Brake light switch
M8	Rear right turn signal bulb
M17	Right reversing light bulb
M22	Right brake and tail light bulb
M25	High level brake light bulb (18 LED's)
T5i	5-pin connector, near lower left A-pillar, entwined in wiring harness
86	Earth connection 1, in rear wiring harness
A5	Positive connection (right turn signal), in dash panel wiring harness
A18	Connection (54), in dash panel wiring harness
A89	Connection (54), in dash panel wiring harness
B182	Connection (RL), in interior wiring harness
W1	Positive connection (54), in rear wiring harness
***	only Bora
