Wiring Diagram VW GOLF 2000 - Automatic intermittent wash and wipe relay - automatic anti-dazzle interior mirror - rain sensor



Wiring Diagram VW GOLF 2000 - Automatic intermittent wash and wipe relay - automatic anti-dazzle interior mirror - rain sensor https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
DIgnition/starter switch
E38Intermittent wiper regulator
F4Reversing light switch
G213Rain sensor
J31Automatic intermittent wash and wipe relay, on relay plate
S5Fuse 5 in fuse holder
T44-pin connector, near front interior light
T66-pin connector, near front interior light
T6a6-pin connector, near front interior light
T6e6-pin connector
T1010-pin connector, orange, in connector protective housing, on left in plenum chamber
T18a18-pin connector
Y7Automatic anti-dazzle interior mirror
  42 Earth point, next to steering column
  81 Earth connection 1, in dash panel wiring harness
  135 Earth connection 2, in dash panel wiring harness
  303 Earth connection 3, in driver side door wiring harness
  A2 Positive connection (15), in dash panel wiring harness
  A20 Connection (15a), in dash panel wiring harness
  A87 Connection (RL), in dash panel wiring harness

Wiring Diagram VW GOLF 2000 - Intermittent wiper switch - windscreen wiper motor - automatic intermittent wash and wipe relay - windscreen and rear window washer pump



Wiring Diagram VW GOLF 2000 - Intermittent wiper switch - windscreen wiper motor - automatic intermittent wash and wipe relay - windscreen and rear window washer pump https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E22Intermittent wiper switch
J31Automatic intermittent wash and wipe relay, on relay plate
J285Control unit with display in dash panel insert
S224Fuse 24 in fuse holder
T5c5-pin connector, on windscreen wiper motor
T8c8-pin connector
T18a18-pin connector
T3232-pin connector, blue
VWindscreen wiper motor
V59Windscreen and rear window washer pump
  12 Earth point, on left in engine compartment
  179 Earth connection, in left headlight wiring harness
  503 Screw connection (75x), on relay plate
  A27 Connection (speed signal), in dash panel wiring harness
  A96 Connection (53a), in dash panel wiring harness
  A97 Connection (53), in dash panel wiring harness
  A102 Connection (windscreen wiper), in dash panel wiring harness
**only models up to August 2000
---only models from September 2000
