VW GOLF 2000 – Multi-function steering wheel for CCS and radio . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW GOLF 2000 - Operating unit in steering wheel - horn plate - airbag coil connector - airbag igniter - driver's side

E221	Operating unit in steering wheel
F138	Airbag coil connector
H	Horn plate
J234	Airbag control unit
L45	Light for memory operating unit
N95	Airbag igniter, driver's side
T5b	5-pin connector
T5j	5-pin connector
T75	75-pin connector
42	Earth point, next to steering column
81	Earth connection -1-, in dash panel wiring harness
135	Earth connection -2-, in dash panel wiring harness
A20	Connection (15a), in dash panel wiring harness

D	Ignition/starter switch
E20	Switches and instruments - lighting control
J4	Dual tone horn relay
J59	X contact relief relay
J453	Multi-function steering wheel control unit, above the central electrics
R	Radio
S5	Fuse in fuse box
S240	Fuse in fuse box
T6c	6-pin connector
T16	16-pin connector, in dash panel centre, self-diagnosis connection
T18b	18-pin connector
T20	20-pin connector, green
135	Earth connection -2-, in dash panel wiring harness
501	Screw connection -2- (30), on relay plate
A2	Positive (+) connection (15), in dash panel wiring harness
A4	Positive (+) connection (58b), in dash panel wiring harness
A32	Positive (+) connection (30), in dash panel wiring harness
A76	Connection (diagnosis wire K), in dash panel wiring harness
A80	Connection -1- (X), in dash panel wiring harness

E45	Cruise control system switch
H1	Dual tone horn
J...	Engine control units
J453	Multi-function steering wheel control unit, above the central electrics
T10e	10-pin connector, black, in protective housing for connectors, in plenum chamber, left*
T10s	10-pin connector, next to steering column
T18b	18-pin connector
12	Earth point, in engine compartment, left
179	Earth connection, in left headlight wiring harness
A16	Connection (CCS), in dash panel wiring harness
A20	Connection (15a), in dash panel wiring harness
A90	Connection (dual tone horn), in dash panel wiring harness
*	⇒ Current Flow Diagram CCS/ engine
