VW PASSAT 1998 – Navigation system . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW PASSAT 1998 - Operating electronics control unit - navigation display unit - roof aerial

D	Ignition/starter switch
E20	Switches and instruments - lighting control
J402	Operating electronics control unit, navigation, in centre console under radio
J414	Navigation display unit, in centre dash panel
K	Dash panel insert
R52	Radio/telephone/navigation aerial
S17	Fuse in relay plate fuse box
T10j	10-pin connector, white, left A-pillar coupling station
T18	18-pin connector, on navigation operating electronics control unit
T20	20-pin connector, red, on dash panel insert
501	Screw connection -2- (30), on relay plate
A2	Positive (+) connection (15), in dash panel wiring harness
A19	Connection (58d), in dash panel wiring harness
A52	Positive connection -2- (30), in dash panel wiring harness
V22	Positive connection (30a), in navigation wiring harness
V33	Positive connection (15), in navigation wiring harness

F4	Reversing light switch
J285	Control unit with display in dash panel insert
J401	Navigation system with CD drive control unit, left in luggage compartment
J402	Operating electronics control unit, navigation, in centre console under radio
T10j	10-pin connector, white, left A-pillar coupling station
T18	18-pin connector, on navigation operating electronics control unit
T26	26-pin connector, on control unit for navigation with CD drive
T32b	32-pin connector, green, on dash panel insert
264	Earth connection (external screening), in navigation wiring harness
265	Earth connection (internal screening), in navigation wiring harness
A60	Connection (road speed signal), in dash panel wiring harness
A87	Connection (RL), in dash panel wiring harness

E15	Heated rear window switch
G197	Magnetic field sender (compass), under roof next to roof aerial
J104	ABS with EDL control unit
J401	Navigation system with CD drive control unit, left in luggage compartment
T4	4-pin connector, in roof
T6h	6-pin connector, black, on heated rear window switch
T6w	6-pin connector, grey, right A-pillar coupling station
T10a	10-pin connector, brown, left A-pillar coupling station
T10j	10-pin connector, white, left A-pillar coupling station
T10w	10-pin connector
T26	26-pin connector, on control unit for navigation with CD drive
T31	31-pin connector, on ABS with EDL control unit
Z1	Heated rear window
44	Earth point, A-pillar left, bottom
266	Earth connection, in navigation wiring harness
A64	Connection (speed boost), in dash panel wiring harness
A82	Connection (windscreen heater), in dash panel wiring harness
*	Up to July 1998
**	From August 1998
