A | Battery |
B | Starter |
C | Alternator |
C1 | Voltage regulator |
D | Ignition/starter switch |
S231 | Fuse in fuse holder |
S232 | Fuse in fuse holder |
T2 | 2-pin connector, right on engine block |
T6n | 6-pin connector, red, on protective housing, left in engine compartment |
T10d | 10-pin connector, brown, on protective housing, left in engine compartment |
1 | Earth strap, battery body |
2 | Earth strap, gearbox - body |
A2 | Positive (+) connection (15), in dash panel wiring harness |
A17 | Connection (61), in dash panel wiring harness |
A20 | Connection (15a), in dash panel wiring harness |
G2 | Coolant temperature sender |
G40 | Hall sender |
G62 | Coolant temperature sender |
J217 | Automatic gearbox control unit |
J226 | Starter inhibitor and reversing light relay |
J361 | Simos control unit, in protective housing, left in engine compartment |
N152 | Ignition transformer |
P | Spark plug connector |
Q | Flame plug |
T4a | 4-pin connector, on ignition transformer |
T6n | 6-pin connector, red, on protective housing, left in engine compartment |
T8e | 8-pin connector, on starter inhibitor and reversing light relay |
T10b | 10-pin connector, black, on protective housing, left in engine compartment |
T10h | 10-pin connector, blue, on protective housing, left in engine compartment |
T68 | 68-pin connector, on automatic gearbox control unit |
T80 | 80-pin connector, on Simos control unit |
85 | Earth connection -1-, in engine compartment wiring harness |
220 | Earth connection (sender earth), in engine wiring harness |
A20 | Connection (15a), in dash panel wiring harness |
--- | For vehicles with automatic gearbox only |
F60 | Idling switch |
G61 | Knock sensor I |
G69 | Throttle valve potentiometer |
G72 | Intake manifold temperature sender |
G88 | Throttle valve positioner potentiometer |
J338 | Throttle valve control unit |
J361 | Simos control unit, in protective housing, left in engine compartment |
T3a | 3-pin connector, green, left on bulkhead |
T8h | 8-pin connector, on throttle valve control part |
T10d | 10-pin connector, brown, on protective housing, left in engine compartment (air conditioning system, 'air conditioner ready') |
T80 | 80-pin connector, on Simos control unit |
V60 | Throttle valve positioner |
131 | Earth connection -2-, in engine compartment wiring harness |
220 | Earth connection (sender earth), in engine wiring harness |
G28 | Engine speed sender |
J17 | Fuel pump relay, control number (208) |
J361 | Simos control unit, in protective housing, left in engine compartment |
N30 | Injector, cylinder 1 |
N31 | Injector, cylinder 2 |
N32 | Injector, cylinder 3 |
N33 | Injector, cylinder 4 |
S234 | Fuse in fuse holder |
S237 | Fuse in fuse holder |
T3b | 3-pin connector, grey, left on bulkhead |
T6n | 6-pin connector, red, on protective housing, left in engine compartment |
T10e | 10-pin connector, yellow, on protective housing, left in engine compartment |
T80 | 80-pin connector, on Simos control unit |
85 | Earth connection -1-, in engine compartment wiring harness |
131 | Earth connection -2-, in engine compartment wiring harness |
A86 | Connection (50a), in dash panel wiring harness |
D95 | Connection (injectors), in engine compartment wiring harness |
G39 | Lambda probe |
G70 | Air mass meter |
J361 | Simos control unit, in protective housing, left in engine compartment |
N80 | Activated charcoal filter system solenoid valve I (pulsed) |
N121 | Exhaust gas recirculation frequency valve |
S229 | Fuse in fuse holder |
T4 | 4-pin connector, black |
T6n | 6-pin connector, red, on protective housing, left in engine compartment |
T10b | 10-pin connector, black, on protective housing, left in engine compartment |
T10d | 10-pin connector, brown, on protective housing, left in engine compartment |
T10e | 10-pin connector, yellow, on protective housing, left in engine compartment |
T80 | 80-pin connector, on Simos control unit |
A27 | Connection (speed signal), in dash panel wiring harness |
A42 | Connection (fuel gauge), in dash panel wiring harness |
A45 | Connection (engine speed signal), in dash panel wiring harness |
E30 | Connection (87a), in engine wiring harness |
E102 | Headlight range control adjuster |
F1 | Oil pressure switch |
G | Fuel gauge sender |
G6 | Fuel pump (pre-supply pump) |
G17 | Ambient temperature sensor |
G22 | Speedometer sender, left in gearbox |
G32 | Coolant shortage indicator sender |
S228 | Fuse in fuse holder |
T1 | Single connector, brown, coupling station left A-pillar |
T2a | 2-pin connector, front left in engine compartment |
T2c | 2-pin connector, front left in engine compartment |
T6c | 6-pin connector, blue, coupling station left A-pillar |
T10a | 10-pin connector, brown, coupling station left A-pillar |
T10b | 10-pin connector, black, on protective housing, left in engine compartment |
T10e | 10-pin connector, yellow, on protective housing, left in engine compartment |
12 | Earth pointin, in engine compartment, left |
30 | Earth point -1-, next to relay plate |
75 | Earth point, rear pillar, right |
85 | Earth connection -1-, in engine compartment wiring harness |
197 | Earth connection -4-, in rear wiring harness |
269 | Earth connection (sender earth) -1-, in dash panel wiring harness |
G1 | Fuel gauge |
G3 | Coolant temperature gauge |
H11 | Oil pressure warning buzzer |
J285 | Control unit with display in dash panel insert |
L75 | Digital display illumination |
K2 | Alternator warning lamp |
K3 | Oil pressure warning lamp |
K28 | Coolant temperature/coolant shortage warning lamp |
T32a | 32-pin connector, blue, on dash panel insert |
T32b | 32-pin connector, green, on dash panel insert |
Y4 | Odometer display |
A27 | Connection (speed signal), in dash panel wiring harness |
A42 | Connection (fuel gauge), in dash panel wiring harness |
A45 | Connection (engine speed signal), in dash panel wiring harness |
A73 | Connection (ambient temperature display), in dash panel wiring harness |
E86 | Multi-function display call-up button |
E109 | Multi-function display, memory switch |
G21 | Speedometer |
J119 | Multi-function display |
J285 | Control unit with display in dash panel insert |
T4h | 4-pin connector, black, right next to steering column |
T32b | 32-pin connector, green, on dash panel insert |
A92 | Connection (MFA Reset), in dash panel wiring harness |
A93 | Connection (MFA left), in dash panel wiring harness |
A94 | Connection (MFA right), in dash panel wiring harness |
