E75 | Alarm system switch |
E76 | Two-way radio button |
J85 | Alarm system control unit I, on the position relay carrier above the relay plate |
S57 | Alarm system I fuse, on the position relay carrier above the relay plate |
S181 | Taxi alarm system II fuse, on the position relay carrier above the relay plate |
S182 | Taximeter fuse, on position relay carrier above relay plate |
S183 | Taximeter and alarm system fuse, on position relay carrier above relay plate |
T6 | 6-pin connector, on steering column switch |
T10 | 10-pin connector, black, right on steering column |
T18 | 18-pin connector, on alarm system I control unit |
A32 | Positive connection (30), in dash panel wiring harness |
D | Ignition/starter switch |
E2 | Turn signal switch |
E4 | Headlight dipper/flasher switch |
E217 | Alarm system Off switch, in rear left of luggage compartment |
H1 | Horn/dual tone horn |
J4 | Dual tone horn relay |
J85 | Alarm system control unit I, on the position relay carrier above the relay plate |
J430 | Taxi alarm system II fuse, on the position relay carrier above the relay plate |
S18 | Fuse in relay plate fuse box |
S19 | Fuse in relay plate fuse box |
T2a | 2-pin connector, rear left in luggage compartment |
T9 | 9-pin connector, on control unit for arlarm system II |
T12 | 12-pin connector, right next to steering column |
T18 | 18-pin connector, on alarm system I control unit |
135 | Earth connection -2-, in dash panel wiring harness |
A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
A90 | Connection (dual tone horn), in dash panel wiring harness |
A103 | Connection -2- (56), in dash panel wiring harness |
E216 | Taxi alarm system II switch, in front left footwell |
J430 | Taxi alarm system II fuse, on the position relay carrier above the relay plate |
R8 | Two-way radio |
R11 | Aerial |
S17 | Fuse in relay plate fuse box |
T2f | 2-pin connector, connection for roof sign with alarm display, in front left footwell |
T9 | 9-pin connector, on control unit for alarm system II |
T10 | 10-pin connector, black, right on steering column |
T10n | 10-pin connector, yellow, on two-way radio |
32 | Earth point, behind dash panel, left |
81 | Earth connection -1-, in dash panel wiring harness |
135 | Earth connection -2-, in dash panel wiring harness |
A52 | Positive connection -2- (30), in dash panel wiring harness |
D | Ignition/starter switch |
G41 | Taximeter |
J... | Engine control unit |
J285 | Control unit with display in dash panel insert |
S231 | Fuse in fuse holder |
T6v | 6-pin connector, lilac, coupling station right A-pillar |
T32a | 32-pin connector, blue, on dash panel insert |
135 | Earth connection -2-, in dash panel wiring harness |
A2 | Positive (+) connection (15), in dash panel wiring harness |
A27 | Connection (speed signal), in dash panel wiring harness |
A70 | Connection (15a, fuse 231), in dash panel wiring harness |
E115 | Interior light switch (taxi) |
E138 | Taxi sign switch |
J393 | Central control unit for convenience electrics |
K146 | Roof sign warning lamp |
L36 | Taxi sign light bulb |
L73 | Interior lighting switch illumination (taxi) |
L74 | Taxi sign switch illumination |
T1 | Single connector |
T2e | 2-pin connector, connection for roof sign without alarm display, in front left footwell |
T10o | 10-pin connector, red, coupling station left A-pillar |
T23 | 23-pin connector, on convenience electrics central control unit |
135 | Earth connection -2-, in dash panel wiring harness |
A19 | Connection (58d), in dash panel wiring harness |
R4 | Connection-1-, in interior light/door contact switch wiring harness |
