VW PASSAT 2016 – Earthing concept . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW PASSAT 2016 - Brake servo - Earth point - on left in engine compartment - Earth point - on left in luggage compartment - Earth point - engine and gearbox earth - Earth point 2 - on front of left longitudinal member - Earth point on alternator

A	Battery
CX1	Alternator with voltage regulator
">J367	"> Battery monitor control unit
J500	Power steering control unit
NX6	Brake servo
T2ml	2-pin connector, black
T2nl	2-pin connector, black
T26c	26-pin connector, black
*	Only models with hybrid drive system
*2	Only right-hand drive models
*3	see applicable current flow diagram
*4	Only models with battery in engine compartment
*5	Only models with battery in luggage compartment
*6	From May 2015
*7	According to equipment
*8	Only models with radiator fan control unit 2
*9	Potential equalisation line for power and control electronics for electric drive (P65)

Wiring Diagram VW PASSAT 2016 - Earth point - on cylinder head - Earth point on ignition coil 1 - Earth point on ignition coil 2 - Earth point on ignition coil 3 - Earth point on ignition coil 4

N70	Ignition coil 1 with output stage
N127	Ignition coil 2 with output stage
N291	Ignition coil 3 with output stage
N292	Ignition coil 4 with output stage
T3l	3-pin connector, black
T4fa	4-pin connector, black
T4fb	4-pin connector, black
T4hw	4-pin connector, black
T4r	4-pin connector, black
V188	Charge air cooling pump
221	Earth connection (engine earth), in engine wiring harness
306	Earth connection (ignition coils), in engine prewiring harness
846	Earth point on ignition coil 1
847	Earth point on ignition coil 2
848	Earth point on ignition coil 3
849	Earth point on ignition coil 4
*	see applicable current flow diagram for engine
*2	According to equipment

Wiring Diagram VW PASSAT 2016 - Earth point - on right headlight - Earth point 1 - on front of left longitudinal member

J104	ABS control unit
J293	Radiator fan control unit
J623	Engine control unit
J671	Radiator fan control unit 2
T4gl	4-pin connector, black
T4gn	4-pin connector, black
T46	46-pin connector, black
VX57	Radiator fan
132	Earth connection 3, in engine compartment wiring harness
201	Earth connection 5, in engine compartment wiring harness
317	Earth connection 7, in engine compartment wiring harness
*	see applicable current flow diagram for engine
*2	Pre-wired component
*3	According to equipment
*4	Up to May 2015
*5	Only models with radiator fan control unit 2
*6	Only left-hand drive models
*7	see applicable current flow diagram
*8	Only right-hand drive models
*9	From May 2015

Wiring Diagram VW PASSAT 2016 - Earth connection 2 - in engine compartment wiring harness - Earth point 3 - on front of left longitudinal member

F	Brake light switch
H2	Treble horn
J32	Air conditioning system relay
J120	Coolant shortage indicator control unit
J179	Automatic glow period control unit
J743	Mechatronic unit for dual clutch gearbox
SB	Fuse holder B
T1qi	Single connector, black
T2mb	2-pin connector, black
T3fe	3-pin connector, black
T4gk	4-pin connector, black
T10bb	10-pin connector, black
T10bk	10-pin connector, black
T14ae	14-pin connector, black
T14k	14-pin connector, grey
TML	Coupling point in engine compartment, left
TV32	Jump start connection
V478	Gearbox oil cooling pump
119	Earth connection 1, in headlight wiring harness
131	Earth connection 2, in engine compartment wiring harness
150	Earth connection 2 in automatic gearbox wiring harness
363	Earth connection 8, in engine compartment wiring harness
417	Earth connection 9, in engine compartment wiring harness
*	Only models with hybrid drive system
*2	Up to May 2015
*3	see applicable current flow diagram for dual clutch gearbox
*4	Cross section depends on equipment
*5	see applicable current flow diagram for engine
*6	Only models with diesel engine
*7	Only for countries with hot climate

Wiring Diagram VW PASSAT 2016 - Earth connection 2 - in engine compartment wiring harness

F34	Brake fluid level warning contact
F387	Bonnet contact switch
G295	NOx sender
G476	Clutch position sender
G837	Coolant shortage indicator sender 2
H12	Alarm horn
J428	Adaptive cruise control unit
J745	Control unit for cornering light and headlight range control
T2ln	2-pin connector, black
T2lz	2-pin connector, black
T2mp	2-pin connector, black
T2mq	2-pin connector, black
T2pf	2-pin connector, black
T3du	3-pin connector, black
T5bo	5-pin connector, black
T5bu	5-pin connector, black
T6bh	6-pin connector, grey
T6cv	6-pin connector, black
T8bf	8-pin connector, blue
T10ba	10-pin connector, black
T10bo	10-pin connector, black
T26d	26-pin connector, black
TML	Coupling point in engine compartment, left
Z20	Left washer jet heater element
Z21	Right washer jet heater element
119	Earth connection 1, in headlight wiring harness
131	Earth connection 2, in engine compartment wiring harness
*	Only models with hybrid drive system
*2	Only models with petrol engine

Wiring Diagram VW PASSAT 2016 - Earth connection 2 - in engine compartment wiring harness

G266	Oil level and oil temperature sender
L22	Left fog light bulb
L23	Right fog light bulb
L174	Left daytime running light bulb
L175	Right daytime running light bulb
MX1	Front left headlight
T2ct	2-pin connector, black
T2cv	2-pin connector, black
T2cy	2-pin connector, black
T2eo	2-pin connector, light grey
T2er	2-pin connector, light grey
T3ef	3-pin connector, black
T3ej	3-pin connector, black
T6at	6-pin connector, black
T6bb	6-pin connector, black
T10ay	10-pin connector, black
T10az	10-pin connector, black
T10be	10-pin connector, black
T14af	14-pin connector, grey
T14ag	14-pin connector, black
T14l	14-pin connector, grey
TML	Coupling point in engine compartment, left
TSRA	Coupling point for headlight washer system
V11	Headlight washer system pump
V488	Auxiliary pump for heating
119	Earth connection 1, in headlight wiring harness
131	Earth connection 2, in engine compartment wiring harness
179	Earth connection, in left headlight wiring harness
345	Earth connection, in bumper wiring harness
*	Only models with diesel engine
*2	According to equipment
*3	Only models with halogen headlights
*4	see applicable current flow diagram for LED headlights
*5	Only left-hand drive models
*6	see applicable current flow diagram
*7	Only models with petrol engine

Wiring Diagram VW PASSAT 2016 - Earth connection 2 - in engine compartment wiring harness

N280	Air conditioner compressor regulating valve
T2ei	2-pin connector, black
T3br	3-pin connector, black
T4fe	4-pin connector, black
T4gm	4-pin connector, black
T4hc	4-pin connector, black
T4iq	4-pin connector, black
T6dh	6-pin connector, black
T8aa	8-pin connector, black
T8bo	8-pin connector, blue
TML	Coupling point in engine compartment, left
V188	Charge air cooling pump
V192	Vacuum pump for brakes
85	Earth connection 1, in engine compartment wiring harness
131	Earth connection 2, in engine compartment wiring harness
*	Only models with equipment for Japan
*2	Only models with petrol engine
*3	Only models with diesel engine
*4	Only models with hybrid drive system

Wiring Diagram VW PASSAT 2016 - Earth point 1 at front of right longitudinal member

G35	Front right brake pad wear sender
G238	Air quality sensor
G805	Pressure sender for refrigerant circuit
H7	Bass horn
J364	Auxiliary heater control unit
J400	Wiper motor control unit
MX2	Front right headlight
T2lo	2-pin connector, black
T2lp	2-pin connector, black
T2nh	2-pin connector, black
T3dq	3-pin connector, black
T3dt	3-pin connector, brown
T4ae	4-pin connector, black
T4af	4-pin connector, black
T10ax	10-pin connector, black
T14ad	14-pin connector, black
129	Earth connection, in dual tone horn wiring harness
176	Earth connection, in right headlight wiring harness
D54	Connection (right brake wear indicator), in engine compartment wiring harness
*	Up to May 2015
*2	Only left-hand drive models
*3	Only right-hand drive models
*4	Only models with halogen headlights
*5	see applicable current flow diagram for LED headlights
*6	From May 2015

Wiring Diagram VW PASSAT 2016 - Earth connection 1 - in interior wiring harness

E378	Starter button
J285	Control unit in dash panel insert
J329	Terminal 15 voltage supply relay
J446	Parking aid control unit
J527	Steering column electronics control unit
J533	Data bus diagnostic interface
J764	Control unit for electronic steering column lock
KX2	Dash panel insert
K269	Front right footwell light
SC	Fuse holder C
T2ga	2-pin connector, black
T4dg	4-pin connector, black
T6as	6-pin connector, black
T14u	14-pin connector, black
T16g	16-pin connector
T17	17-pin connector, black
T17h	17-pin connector, black
T18	18-pin connector, black
T20e	20-pin connector, red
T26d	26-pin connector, black
TIUL	Coupling point in interior, below left
238	Earth connection 1, in interior wiring harness
288	Earth connection (HRC), in dash panel wiring harness
*	Only models with no heated steering wheel
*2	Only models with heated steering wheel
*3	Only models with halogen headlights

Wiring Diagram VW PASSAT 2016 - Earth point - lower part of left A-pillar - Earth connection 1 - in interior wiring harness

EX1	Rotary light switch
E102	Headlight range control regulator
J386	Driver door control unit
J519	Onboard supply control unit
L251	Light for front left door contour lighting
T4bx	4-pin connector, black
T4di	4-pin connector, black
T4dk	4-pin connector, brown
T8ag	8-pin connector, black
T8s	8-pin connector, black
T8t	8-pin connector
T16h	16-pin connector, black
T20d	20-pin connector, black
T27	27-pin connector, black
T27g	27-pin connector, black
T29	29-pin connector, white
T29c	29-pin connector, white
T73a	73-pin connector, black
T73c	73-pin connector, black
TTIVL	Coupling point in front left door
TTVL	Coupling point on front left door
U31	Diagnostic connection
VX21	Driver door lock unit
205	Earth connection, in driver door wiring harness
238	Earth connection 1, in interior wiring harness
277	Earth connection 3, in interior wiring harness
279	Earth connection 5, in interior wiring harness
286	Earth connection 8, in interior wiring harness
*	Only models with no overhead view camera
*2	Cross section depends on equipment
*3	Only models with overhead view camera

Wiring Diagram VW PASSAT 2016 - Earth connection 1 - in seat adjustment wiring harness

EX33	Operating unit for front left seat adjustment
J605	Rear lid control unit
J740	Massage control unit
J810	Driver seat adjustment control unit
T4ce	4-pin connector
T4ie	4-pin connector, white
T4if	4-pin connector, white
T6dd	6-pin connector
T6q	6-pin connector
T8ah	8-pin connector, black
T8cg	8-pin connector, black
T10am	10-pin connector, black
T10at	10-pin connector
T10m	10-pin connector, black
T10z	10-pin connector, black
T12g	12-pin connector, black
T12ml	12-pin connector, black
TISVL	Coupling point in front left seat
TSVL	Coupling point for front left seat
V512	Front left seat backrest fan 1
V514	Front left seat cushion fan 1
Z6	Heated seat cushion for driver seat
95	Earth connection 1, in seat adjustment wiring harness
*	Cross section depends on equipment
*2	According to equipment

Wiring Diagram VW PASSAT 2016 - Earth point on left B-pillar - Earth point under seat on front left - Earth point on central tube for dash panel - centre left - Earth point on central tube for dash panel - centre right

J388	Rear left door control unit
J525	Digital sound package control unit
J854	Control unit for front left belt tensioner
L253	Light for rear left door contour lighting
T2hl	2-pin connector, blue
T2ri	2-pin connector, blue
T3cn	3-pin connector, black
T3co	3-pin connector, black
T3es	3-pin connector, black
T4ca	4-pin connector, black
T4io	4-pin connector, black
T5ar	5-pin connector
T8u	8-pin connector, black
T8w	8-pin connector
T8x	8-pin connector, black
T10g	10-pin connector, black
T20b	20-pin connector
T27b	27-pin connector, black
T27f	27-pin connector, black
T38	38-pin connector, black
TSVL	Coupling point for front left seat
TTHL	Coupling point on rear left door
TTIHL	Coupling point in rear left door
U13	DC/AC converter with socket, 12 V - 230 V
U18	12 V socket 2
U19	12 V socket 3
U22	Video socket
VX23	Rear left door lock unit
V26	Rear left window regulator motor
Z35	Auxiliary air heater element
207	Earth connection, in rear left door wiring harness
278	Earth connection 4, in interior wiring harness
296	Earth connection 11, in interior wiring harness
408	Earth connection 3, in rear left door wiring harness
*	Only left-hand drive models
*2	Only right-hand drive models
*3	see applicable current flow diagram

Wiring Diagram VW PASSAT 2016 -

EX21	Heater and air conditioning controls
EX22	Centre switch module in dash panel
EX23	Switch module 1 in centre console
EX30	Switch module 2 in centre console
E265	Operating and display unit for rear air conditioning system
E313	Selector lever
E538	Electromechanical parking brake button
J898	Control unit for Head-up Display
J965	Interface for entry and start system
L121	Cup holder illumination bulb
T2ql	2-pin connector, black
T6at	6-pin connector, black
T8ar	8-pin connector, black
T8bx	8-pin connector, black
T10ag	10-pin connector, black
T10am	10-pin connector, black
T10k	10-pin connector, red
T12g	12-pin connector, black
T12p	12-pin connector, black
T18f	18-pin connector, colourless
T20d	20-pin connector, black
T40	40-pin connector, grey
TI	Coupling point in interior
278	Earth connection 4, in interior wiring harness
*	Only models with ambient lighting, version 2
*2	Up to May 2015
*3	From May 2015

Wiring Diagram VW PASSAT 2016 - Earth point - at front - central in roof

EX5	Interior mirror
F147	Driver vanity mirror contact switch
F148	Front passenger vanity mirror contact switch
G397	Rain and light sensor
G578	Anti-theft alarm sensor
L229	Light for left dashboard ambient lighting
L230	Light for right dashboard ambient lighting
R242	Front camera for driver assist systems
T2dh	2-pin connector, black
T2dj	2-pin connector, black
T3cj	3-pin connector, black
T4ae	4-pin connector, black
T4af	4-pin connector, black
T4ag	4-pin connector, brown
T4ah	4-pin connector, black
T4dp	4-pin connector, black
T4dq	4-pin connector, black
T6ao	6-pin connector, blue
T6p	6-pin connector, black
T8ao	8-pin connector, black
T12o	12-pin connector, black
T16	16-pin connector, black
T16i	16-pin connector
T16j	16-pin connector, black
TH	Coupling point for roof
WX1	Front interior light
WX2	Rear interior light
W47	Rear left interior light
W48	Rear right interior light
Z2	Heated windscreen
178	Earth connection, in sliding sunroof wiring harness
278	Earth connection 4, in interior wiring harness
431	Earth connection 2, in roof wiring harness
459	Earth connection 15, in interior wiring harness
*	Only models with ambient lighting, version 2
*2	According to equipment

Wiring Diagram VW PASSAT 2016 - Earth connection 2 - in interior wiring harness - Earth point - on right A-pillar

E177	Front passenger seat lumbar support adjustment switch
E471	Front passenger seat adjustment operating unit
J126	Fresh air blower control unit
K268	Front left footwell light
L67	Dash panel left vent illumination bulb
T2fz	2-pin connector, black
T2gb	2-pin connector, black
T2gc	2-pin connector, black
T4ar	4-pin connector, black
T4co	4-pin connector
T4ic	4-pin connector, white
T4id	4-pin connector, white
T6ad	6-pin connector
T6ae	6-pin connector, black
T6af	6-pin connector, black
T6aj	6-pin connector, black
T10af	10-pin connector, black
T10q	10-pin connector, black
TISVR	Coupling point in front right seat
TSVR	Coupling point for front right seat
V516	Front right seat backrest fan 1
V518	Front right seat cushion fan 1
W6	Glove compartment light
Z8	Heated seat cushion for front passenger seat
249	Earth connection 2, in interior wiring harness
M18	Connection 1, in front passenger seat adjustment wiring harness
*	Cross section depends on equipment
*2	According to equipment

Wiring Diagram VW PASSAT 2016 - Earth connection 2 - in interior wiring harness

J387	Front passenger door control unit
L69	Dash panel right vent illumination bulb
L252	Light for front right door contour lighting
T2a	2-pin connector, brown
T2b	2-pin connector, brown
T2pf	2-pin connector, brown
T3	3-pin connector, black
T4bz	4-pin connector, black
T5aq	5-pin connector, black
T5b	5-pin connector, blue
T8ah	8-pin connector, black
T8u	8-pin connector
T8v	8-pin connector, black
T20a	20-pin connector, black
T27a	27-pin connector, black
T27d	27-pin connector, black
T29a	29-pin connector, white
T29b	29-pin connector, white
TI	Coupling point in interior
TTIVR	Coupling point in front right door
TTVR	Coupling point on front right door
VX22	Front passenger door lock unit
Y	Analogue clock
110	Earth connection 2, in dash panel wiring harness
206	Earth connection, in front passenger door wiring harness
249	Earth connection 2, in interior wiring harness
*	Only models with no overhead view camera
*2	Only models with overhead view camera

Wiring Diagram VW PASSAT 2016 - Earth point - lower part of right A-pillar

J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
J928	Control unit for overhead view camera
J984	Two-way signal amplifier for mobile telephone/data services
RX6	TV tuner
R189	Reversing camera
R265	Storage compartment with interface for mobile telephone
R293	USB hub
T4ao	4-pin connector
T4dn	4-pin connector, brown
T4dr	4-pin connector, red
T4fg	4-pin connector, black
T4fk	4-pin connector, black
T8al	8-pin connector, black
T8j	8-pin connector, black
T10f	10-pin connector, brown
T10z	10-pin connector, brown
T12f	12-pin connector, black
T12r	12-pin connector, black
T18b	18-pin connector, colourless
THK	Coupling point on rear lid
THRR	Coupling point in luggage compartment, right
256	Earth connection 2, in radio wiring harness
B609	Connection 5, in interior wiring harness
*	According to equipment
*2	Up to May 2015
*3	Saloon
*4	Estate

Wiring Diagram VW PASSAT 2016 - Earth point on right B-pillar

J389	Rear right door control unit
J855	Control unit for front right belt tensioner
L254	Light for rear right door contour lighting
T2qs	2-pin connector, blue
T2rl	2-pin connector, blue
T4ez	4-pin connector, black
T4fa	4-pin connector, white
T4fd	4-pin connector, white
T4fe	4-pin connector, black
T4ii	4-pin connector, black
T4ip	4-pin connector, black
T5as	5-pin connector, colourless
T8aj	8-pin connector, black
T8y	8-pin connector
T8z	8-pin connector, black
T10h	10-pin connector, black
T20c	20-pin connector
T27c	27-pin connector, black
T27f	27-pin connector, black
TSVR	Coupling point for front right seat
TTHR	Coupling point on rear right door
TTIHR	Coupling point in rear right door
U43	Video socket 2
VX24	Rear right door lock unit
V27	Rear right window regulator motor
Z10	Heated bench seat cushion for rear left seat
Z11	Heated backrest for rear left seat
Z12	Heated bench seat cushion for rear right seat
Z13	Heated backrest for rear right seat
208	Earth connection, in rear right door wiring harness
409	Earth connection 3, in rear right door wiring harness
O13	Connection 2, in seat heating wiring harness
O14	Connection 3, in seat heating wiring harness
*	Only models with no rear right door control unit
*2	Only models with rear right door control unit
*3	Only models with ambient lighting, version 2

Wiring Diagram VW PASSAT 2016 - Earth connection 5 - in rear wiring harness - Earth point 1 - on right rear wheel housing

GX1	Fuel delivery unit
GX19	Delivery unit for reducing agent metering system
J538	Fuel pump control unit
J938	Rear lid power opening control unit
MX6	Right tail light 2
T2ik	2-pin connector, black
T2iv	2-pin connector, black
T4am	4-pin connector, black
T4bq	4-pin connector, black
T4br	4-pin connector, black
T4fb	4-pin connector, black
T4hw	4-pin connector, black
T5bb	5-pin connector, black
T6ax	6-pin connector, black
T8bh	8-pin connector, black
T10e	10-pin connector, black
T10x	10-pin connector, blue
THK	Coupling point on rear lid
THRR	Coupling point in luggage compartment, right
VX25	Rear lid lock unit
V54	Metering pump
Z1	Heated rear window
Z104	Heater for reducing-agent line (heater circuit 2)
87	Earth connection 2, in rear wiring harness
219	Earth connection 2, in rear lid wiring harness
298	Earth connection 13, in interior wiring harness
333	Earth connection 5, in rear wiring harness
480	Earth connection, in fuel tank wiring harness
*	Only models with reducing agent metering system
*2	Saloon
*3	Estate
*4	see applicable current flow diagram for engine
*5	Cross section depends on equipment

Wiring Diagram VW PASSAT 2016 - Earth connection 5 - in rear wiring harness

J250	Electronically controlled damping control unit
J502	Tyre Pressure Monitoring System control unit
J769	Lane change assist control unit
J770	Lane change assist control unit 2
MX4	Right tail light
R64	Remote control receiver for auxiliary heater
T3dn	3-pin connector, black
T4fh	4-pin connector, black
T6ay	6-pin connector, blue
T8bb	8-pin connector, green
T8bf	8-pin connector, blue
T8bh	8-pin connector, blue
T47	47-pin connector, black
U5	12 V socket
87	Earth connection 2, in rear wiring harness
333	Earth connection 5, in rear wiring harness
*	Saloon
*2	Estate

Wiring Diagram VW PASSAT 2016 - Earth connection 1 - in rear lid wiring harness - Earth connection 5 - in rear wiring harness

E406	Button to close rear lid in luggage compartment
MX5	Left tail light 2
T2dq	2-pin connector, black
T2dr	2-pin connector, black
T3cf	3-pin connector, black
T3dl	3-pin connector, black
T4an	4-pin connector, black
T4ar	4-pin connector, black
T4bu	4-pin connector, black
T4hx	4-pin connector, black
T8q	8-pin connector, brown
T10at	10-pin connector
T10k	10-pin connector, black
THRR	Coupling point in luggage compartment, right
V12	Rear window wiper motor
X4	Left number plate light
X5	Right number plate light
98	Earth connection, in rear lid wiring harness
218	Earth connection 1, in rear lid wiring harness
333	Earth connection 5, in rear wiring harness
470	Earth connection 1, in rear bumper wiring harness
*	Saloon
*2	Only models with parking aid (PDC)
*3	Estate

Wiring Diagram VW PASSAT 2016 - Earth connection 1 - in rear lid wiring harness

E234	Rear lid handle release button
T2dm	2-pin connector, black
T4al	4-pin connector, black
T6q	6-pin connector, black
VX16	Power latching for rear lid
98	Earth connection, in rear lid wiring harness
218	Earth connection 1, in rear lid wiring harness
295	Earth connection 10, in interior wiring harness
*	Estate
*2	Only models with no reversing camera system
*3	Only models with reversing camera system
*4	Saloon

Wiring Diagram VW PASSAT 2016 - Earth connection 3 - in rear lid wiring harness - Earth point - on left rear wheel housing

J262	Rear roller blind control unit
J345	Trailer detector control unit
J605	Rear lid control unit
MX3	Left tail light
M25	High-level brake light bulb
T2hc	2-pin connector, black
T4eh	4-pin connector, black
T6av	6-pin connector, black
T8au	8-pin connector, blue
T10am	10-pin connector, black
T10b	10-pin connector, black
T10y	10-pin connector, black
THK	Coupling point on rear lid
197	Earth connection 4, in rear wiring harness
285	Earth connection 7, in interior wiring harness
294	Earth connection 9, in interior wiring harness
295	Earth connection 10, in interior wiring harness
366	Earth connection 1, in main wiring harness
478	Earth connection 3, in rear lid wiring harness
*	Saloon
*2	Estate
*3	Only models with no hybrid drive system
*4	Only models with hybrid drive system
*5	Only models with trailer socket
*6	Only models with no trailer socket

Wiring Diagram VW PASSAT 2016 - Earth connection 3 - in rear lid wiring harness

J492	All-wheel drive control unit
T4ai	4-pin connector, black
T4ee	4-pin connector, black
T6a	6-pin connector, black
T6au	6-pin connector, grey
T8ad	8-pin connector, black
T8as	8-pin connector, black
T8b	8-pin connector, black
T13b	13-pin connector, black
THRL	Coupling point in luggage compartment, left
TSAA	Coupling point for all-wheel drive
U10	Trailer socket
197	Earth connection 4, in rear wiring harness
478	Earth connection 3, in rear lid wiring harness
*	Saloon
*2	Estate

Wiring Diagram VW PASSAT 2016 - Charging unit 1 for high-voltage battery - Power and control electronics for electric drive - Three-phase current drive - Brake system pressure accumulator

AX4	Charging unit 1 for high-voltage battery
JX1	Power and control electronics for electric drive
T4d	4-pin connector
T4gq	4-pin connector, black
T60c	60-pin connector, black
VX54	Three-phase current drive
VX70	Brake system pressure accumulator
81	Earth point in centre of engine compartment
82	Earth connection 1, in front left wiring harness
125	Earth connection 3, in headlight wiring harness
640	Earth point 2, left in engine compartment
674	Earth point 4, on front of left longitudinal member
779	Earth point 1 for power and control electronics for electric drive
832	Earth connection 14, in engine compartment wiring harness
P7	Connection 1, in high-voltage battery wiring harness
*	Only models with hybrid drive system
*2	Potential equalisation line (P77)
*3	Potential equalisation line for power and control electronics for electric drive (P65)
*4	Up to November 2015
*5	Potential equalisation line for three-phase current drive (P71)
*6	Potential equalisation line for charging unit 1 for high-voltage battery (P68)
*7	High-voltage wire 1 for high-voltage charge current distributor/high-voltage charging socket (P18)
*8	Screening on connector housing
*9	High-voltage wiring harness for high-voltage battery (PX1)

Wiring Diagram VW PASSAT 2016 - High-voltage battery 1 - Module monitor control unit for batteries - Battery regulation control unit - Battery module 4 - Battery module 0

AX2	High-voltage battery 1
J497	Module monitor control unit for batteries
J840	Battery regulation control unit
J994	Battery module 4
J1068	Battery module 0
T10bo	10-pin connector, black
T10bp	10-pin connector, black
T10bq	10-pin connector, red
T10br	10-pin connector, red
T10bv	10-pin connector, black
T10bw	10-pin connector, black
T14v	14-pin connector, black
T14w	14-pin connector, black
T18f	18-pin connector, black
T32j	32-pin connector, colourless
TAHV	Coupling point on high-voltage battery
TIHV	Coupling point in high-voltage battery
782	Earth point 1, on high-voltage battery
791	Earth point, on rear right of underbody
794	Earth point 1, in high-voltage battery
795	Earth point 2, in high-voltage battery
859	Earth connection 1, in high-voltage battery wiring harness
860	Earth connection 2, in high-voltage battery wiring harness
885	Earth connection 3, in high-voltage battery wiring harness
*	Only models with hybrid drive system
*2	Only models with trailer socket
*3	Only models with no trailer socket
*4	Potential equalisation line for high-voltage battery 1 (P73)
*5	High-voltage wiring harness for high-voltage battery (PX1)
*6	Screening on connector housing

VW PASSAT 2016 Overview of control units

Overview of control units

The fitting locations are identical on saloon and estate models.



q	Connector assignment

q	Connector assignment, left-hand drive

q	Fitting location right-hand drive

q	Connector assignment, right-hand drive

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment, left-hand drive

q	Fitting location right-hand drive

q	Connector assignment, right-hand drive

q	Connector assignment

q	Connector assignment

q	Fitting location of 91-pin connector -T91a- / 105-pin connector -T105-

q	Connector assignment with 16-pin connector -T16g-

q	Fitting location with 20-pin connector -T20d-

q	Connector assignment with 20-pin connector -T20d-

q	Fitting location with 25-pin connector -T25-

q	Connector assignment with 25-pin connector -T25-

q	Connector assignment with 4-pin connector -T4ds-

q	Fitting location with 4-pin connector -T4ee-

q	Connector assignment with 4-pin connector -T4ee-

q	Connector assignment

VW PASSAT 2016 Output module for right headlight J668 Output module for right headlight -J668- Fitting location: On right headlight.   Note The output module for right headlight -J668- is fitted on the right headlight .-MX2-

1 -	Output module for right headlight -J668-

A -	44-pin connector -T44-

Back to overview VW PASSAT 2016 Output module 1 for right LED headlight A27 Output module 1 for right LED headlight -A27- Fitting location: On right headlight.   Note The output module 1 for right LED headlight -A27- is fitted on the right headlight .-MX2-

2 -	Output module 1 for right LED headlight -A27-

B -	28-pin connector -T28-

Back to overview VW PASSAT 2016 Control unit for right daytime running light and side light J861 Control unit for right daytime running light and side light -J861- Fitting location: On right headlight.   Note The control unit for right daytime running light and side light -J861- is fitted on the right headlight .-MX2-

3 -	Control unit for right daytime running light and side light -J861-

C -	20-pin connector -T20-

Back to overview VW PASSAT 2016 Auxiliary heater control unit J364 Auxiliary heater control unit -J364- Fitting location: In front right wheel housing.

1 -	Auxiliary heater control unit -J364-

A -	2-pin connector -T2hz-

B -	6-pin connector -T6z-

C -	2-pin connector -T2pm-

Connector assignment of auxiliary heater control unit -J364-

-T2hz- (A)	Designation		-T6z- (B)	Designation		-T2pm- (C)	Designation
1	Terminal 30		1			1	Circulation pump -V55-
2	Terminal 31		2	Remote control receiver for auxiliary heater -R64-		2	Circulation pump -V55-
			3	A179 Connection (infotainment CAN bus, low), in dash panel wiring harness
			4
			5	A178 Connection (infotainment CAN bus, high), in dash panel wiring harness
			6	Metering pump -V54-

Back to overview VW PASSAT 2016 ABS control unit J104 ABS control unit -J104- ABS control unit -J104- , left-hand drive models Fitting location: on right in engine compartment.

1 -	ABS control unit -J104-

A -	46-pin connector -T46-

Connector assignment of ABS control unit -J104-

-T46- (A)	Designation		-T46- (A)	Designation
1	Terminal 30		24	Electromechanical parking brake button -E538-
2	Right parking brake motor -V283-		25
3	Right parking brake motor -V283-		26
4	Front right speed sensor -G45-		27
5	Front right speed sensor -G45-		28
6	Rear left speed sensor -G46-		29
7	Rear left speed sensor -G46-		30	Terminal 30
8	Front left speed sensor -G47-		31	Terminal 30
9	Front left speed sensor -G47-		32	Auto-hold warning lamp -K237-
10	Rear right speed sensor -G44-		33	Clutch position sender -G476-
11	Rear right speed sensor -G44-		34
12	Left parking brake motor -V282-		35	Terminal 15
13	Left parking brake motor -V282-		36	Electromechanical parking brake warning lamp -K213-
14	Terminal 31		37
15			38	Vacuum sender -G608-
16			39	TCS and ESP button -E256-
17	Electromechanical parking brake button -E538-		40
18	Electromechanical parking brake button -E538-		41
19	Electromechanical parking brake button -E538-		42	B672 Connection 1 (running gear/dash panel insert CAN bus, high), in main wiring harness
20			43	B676 Connection 1 (running gear/dash panel insert CAN bus, low), in main wiring harness
21			44	Vacuum sender -G608-
22			45	Vacuum sender -G608-
23	Auto-hold button -E540-		46	Terminal 31

Back to overview ABS control unit -J104- , right-hand drive models Fitting location: on left in engine compartment

1 -	ABS control unit -J104-

A -	46-pin connector -T46-

Connector assignment of ABS control unit -J104-

-T46- (A)	Designation		-T46- (A)	Designation
1	Terminal 30		24	Electromechanical parking brake button -E538-
2	Right parking brake motor -V283-		25
3	Right parking brake motor -V283-		26
4	Front right speed sensor -G45-		27
5	Front right speed sensor -G45-		28
6	Rear left speed sensor -G46-		29
7	Rear left speed sensor -G46-		30	Terminal 30
8	Front left speed sensor -G47-		31	Terminal 30
9	Front left speed sensor -G47-		32	Auto-hold warning lamp -K237-
10	Rear right speed sensor -G44-		33	Clutch position sender -G476-
11	Rear right speed sensor -G44-		34
12	Left parking brake motor -V282-		35	Terminal 15
13	Left parking brake motor -V282-		36	Electromechanical parking brake warning lamp -K213-
14	Terminal 31		37
15			38	Vacuum sender -G608-
16			39	TCS and ESP button -E256-
17	Electromechanical parking brake button -E538-		40
18	Electromechanical parking brake button -E538-		41
19	Electromechanical parking brake button -E538-		42	B672 Connection 1 (running gear/dash panel insert CAN bus, high), in main wiring harness
20			43	B676 Connection 1 (running gear/dash panel insert CAN bus, low), in main wiring harness
21			44	Vacuum sender -G608-
22			45	Vacuum sender -G608-
23	Auto-hold button -E540-		46	Terminal 31

Back to overview VW PASSAT 2016 Power steering control unit J500 Power steering control unit -J500- Fitting location: Near steering box.

1 -	Power steering control unit -J500-

A -	3-pin connector -T3fi-

B -	2-pin connector -T2pq-

C -	5-pin connector -T5cp-

Connector assignment of power steering control unit -J500-

-T2pq- (B)	Designation		-T3fi- (A)	Designation
1	Terminal 31		1	B676 Connection 1 (running gear/dash panel insert CAN bus, low), in main wiring harness
2	Terminal 30		2	B672 Connection 1 (running gear/dash panel insert CAN bus, high), in main wiring harness
			3	Terminal 15

Back to overview VW PASSAT 2016 Turbocharger 1 control unit J724 Turbocharger 1 control unit -J724- Fitting location: on turbocharger.

1 -	Turbocharger 1 control unit -J724-

A -	5-pin connector -T5bt-

Connector assignment of turbocharger 1 control unit -J724-

-T5bt- (A)	Designation
1	D174 Connection 2 (5V) in engine prewiring wiring harness
2	Engine control unit -J623-
3	Terminal 31
4	Engine control unit -J623-
5	Engine control unit -J623-

Back to overview VW PASSAT 2016 Exhaust flap control unit J883 Exhaust flap control unit -J883- Fitting location: on turbocharger.

1 -	Exhaust flap control unit -J883-

A -	5-pin connector -T5bz-

Connector assignment of exhaust flap control unit -J883-

-T5bz- (A)	Designation
1	B369 Connection 1 (5V), in main wiring harness
2	Engine control unit -J623-
3	Terminal 31
4	Engine control unit -J623-
5	Engine control unit -J623-

Back to overview VW PASSAT 2016 Wiper motor control unit J400 Wiper motor control unit -J400- Wiper motor control unit -J400- , left-hand drive models Fitting location: In driver side plenum chamber.

1 -	Wiper motor control unit -J400-

A -	4-pin connector -T4dk-

Connector assignment of wiper motor control unit -J400-

-T4dk- (A)	Designation
1	LIN bus
2
3	Terminal 31
4	Terminal 30

Back to overview Wiper motor control unit -J400- , right-hand drive models Fitting location: In driver side plenum chamber.

1 -	Wiper motor control unit -J400-

A -	4-pin connector -T4dj-

Connector assignment of wiper motor control unit -J400-

-T4dj- (A)	Designation
1	Terminal 30
2	Terminal 31
3
4	LIN bus

Back to overview VW PASSAT 2016 Control unit for NOx sender 2 J881 Control unit for NOx sender 2 -J881- Fitting location: on left in engine compartment

1 -	Control unit for NOx sender 2 -J881-

A -	5-pin connector -T5bg-

Connector assignment of control unit for NOx sender 2 -J881-

-T5bg- (A)	Designation
1	D197 Connection 5 (87a), in engine compartment wiring harness
2	Terminal 31
3	B392 Connection 3 (powertrain CAN bus, low), in main wiring harness
4	B385 Connection 3 (powertrain CAN bus, high), in main wiring harness
5

Back to overview VW PASSAT 2016 Battery monitoring control unit J367 Battery monitoring control unit -J367- Fitting location: On battery.

1 -	Battery monitoring control unit -J367-

A -	2-pin connector -T2jr-

Connector assignment of battery monitor control unit -J367-

-T2jr- (A)	Designation
1	LIN bus
2	Terminal 15

Back to overview VW PASSAT 2016 Engine control unit J623 Engine control unit -J623- Engine control unit -J623- , 60-pin connector -T60a- / 94-pin connector -T94- Fitting location: on left in engine compartment

1 -	Engine control unit -J623-

A -	60-pin connector -T60a-

B -	94-pin connector -T94-

Back to overview Engine control unit -J623- , 91-pin connector -T91a- / 105-pin connector -T105- Fitting location: on left in engine compartment

1 -	Engine control unit -J623-

A -	91-pin connector -T91a-

B -	105-pin connector -T105-

Back to overview VW PASSAT 2016 Output module for left headlight J667 Output module for left headlight -J667- Fitting location: On left headlight.   Note The output module for left headlight -J667- is fitted on the left headlight .-MX1-

1 -	Output module for left headlight -J667-

A -	44-pin connector -T44-

Back to overview VW PASSAT 2016 Output module 1 for left LED headlight A31 Output module 1 for left LED headlight -A31- Fitting location: On left headlight.   Note The output module 1 for left LED headlight -A31- is fitted on the left headlight .-MX1-

2 -	Output module 1 for left LED headlight -A31-

B -	28-pin connector -T28-

Back to overview VW PASSAT 2016 Control unit for left daytime running light and side light J860 Control unit for left daytime running light and side light -J860- Fitting location: On left headlight.   Note The control unit for left daytime running light and side light -J860- is fitted on the left headlight .-MX1-

3 -	Control unit for left daytime running light and side light -J860-

C -	20-pin connector -T20-

Back to overview VW PASSAT 2016 Mechatronic unit for dual clutch gearbox J743 Mechatronic unit for dual clutch gearbox -J743- Mechatronic unit for dual clutch gearbox -J743- , 16-pin connector -T16g- Fitting location: on dual clutch gearbox 0DL.

1 -	Mechatronic unit for dual clutch gearbox -J743-

A -	16-pin connector -T16g-

Connector assignment of mechatronic unit for dual clutch gearbox -J743-

-T16g- (A)	Designation	-T16g- (A)
1		9	U18 Positive connection (30a), in automatic gearbox wiring harness
2	D102 Connection 2, in engine compartment wiring harness	10
3		11
4	Engine control unit -J623-	12
5		13
6	B384 Connection 2 (powertrain CAN bus, high), in main wiring harness	14
7	B391 Connection 2 (powertrain CAN bus, low), in main wiring harness	15	D51 Positive connection 1 (15) in engine compartment wiring harness
8		16	Terminal 31

Back to overview Mechatronic unit for dual clutch gearbox -J743- , 20-pin connector -T20d- Fitting location: on dual clutch gearbox 0D9

1 -	Mechatronic unit for dual clutch gearbox -J743-

A -	20-pin connector -T20d-

Connector assignment of mechatronic unit for dual clutch gearbox -J743-

-T20d- (A)	Designation	-T20d- (A)
1		11	U18 Positive connection (30a), in automatic gearbox wiring harness
2		12
3		13	D51 Positive connection 1 (15) in engine compartment wiring harness
4		14
5		15	B391 Connection 2 (powertrain CAN bus, low), in main wiring harness
6		16	Terminal 31
7	Engine control unit -J623-	17	D102 Connection 2, in engine compartment wiring harness
8		18	U18 Positive connection (30a), in automatic gearbox wiring harness
9		19	Terminal 31
10	B384 Connection 2 (powertrain CAN bus, high), in main wiring harness	20

Back to overview Mechatronic unit for dual clutch gearbox -J743- , 25-pin connector -T25- Fitting location: on dual clutch gearbox 0CW

1 -	Mechatronic unit for dual clutch gearbox -J743-

A -	25-pin connector -T25-

Connector assignment of mechatronic unit for dual clutch gearbox -J743-

-T25- (A)	Designation	-T25- (A)
1		14	Engine control unit -J623-
2		15
3		16	D102 Connection 2, in engine compartment wiring harness
4		17
5		18
6		19
7		20
8	Terminal 31	21
9	U7 Connection (87) in automatic gearbox wiring harness	22
10	D51 Positive connection 1 (15) in engine compartment wiring harness	23
11		24	Terminal 31
12	B391 Connection 2 (powertrain CAN bus, low), in main wiring harness	25	U7 Connection (87) in automatic gearbox wiring harness
13	B384 Connection 2 (powertrain CAN bus, high), in main wiring harness

Back to overview Radiator fan -VX57- Radiator fan -VX57- , 4-pin connector -T4ds- Fitting location: in engine compartment, front left.

1 -	Radiator fan control unit -J293-

A -	4-pin connector -T4ds-

Connector assignment of radiator fan control unit -J293-

-T4ds- (A)	Designation
1	Terminal 30
2	D182 Connection 3 (87a), in engine compartment wiring harness
3	D128 Connection 26, in engine compartment wiring harness
4	Terminal 31

Back to overview Radiator fan -VX57- , 4-pin connector -T4ee- Fitting location: in engine compartment, front left.

1 -	Radiator fan control unit -J293-

2 -	Radiator fan control unit 2 -J671-

A -	4-pin connector -T4ee-

Connector assignment of radiator fan control unit -J293-

-T4ee- (A)	Designation
1	Terminal 30
2	D182 Connection 3 (87a), in engine compartment wiring harness
3	D128 Connection 26, in engine compartment wiring harness
4	Terminal 31

Back to overview VW PASSAT 2016 Adaptive cruise control unit J428 Adaptive cruise control unit -J428- Fitting location: behind radiator grille.

1 -	Adaptive cruise control unit -J428-

A -	8-pin connector -T8av-

Connector assignment of adaptive cruise control unit -J428-

-T8av- (A)	Designation
1	Terminal 31
2	B668 Connection 2 (CAN bus extended, high), in main wiring harness
3	B669 Connection 2 (CAN bus extended, low), in main wiring harness
4
5	Front camera for driver assist systems -R242-
6	Front camera for driver assist systems -R242-
7
8	A199 Positive connection 4 (15a) in dash panel wiring harness

Back to overview

VW PASSAT 2016 Earth points in front part of vehicle

Earth points in front part of vehicle

Earth points in front part of vehicle

12	Earth point, on left in engine compartment

q	Specified torque 20 Nm

15	Earth point on cylinder head

q	Specified torque 9 Nm

652	Earth point, engine and gearbox earth

q	Specified torque 20 Nm

656	Earth point on right headlight

q	Specified torque 9 Nm

671	Earth point 1 on front of left longitudinal member

q	Specified torque 9 Nm

673	Earth point 3 on front of left longitudinal member

q	Specified torque 9 Nm

789	Earth point on alternator

q	Specified torque 20 Nm

672	Earth point 2 on front of left longitudinal member

q	Specified torque 20 Nm

685	Earth point 1 on front of right longitudinal member

q	Specified torque 9 Nm

Earth points in middle part of vehicle

Earth points in middle part of vehicle

43	Earth point, lower part of right A-pillar

q	Specified torque 9 Nm

44	Earth point on lower part of left A-pillar

q	Specified torque 9 Nm

79	Earth point on left B-pillar

q	Specified torque 9 Nm

638	Earth point on right A-pillar

q	Specified torque 9 Nm

689	Earth point, at front, central in roof

q	Specified torque 9 Nm

720	Earth point on right B-pillar

q	Specified torque 9 Nm

741	Earth point under seat on front left

q	Specified torque 9 Nm

810	Earth point on central tube for dash panel, centre left

q	Specified torque 9 Nm

q	Only left-hand drive models

811	Earth point on central tube for dash panel, centre right

q	Specified torque 9 Nm

q	Only right-hand drive models

Earth points in rear part of vehicle

Earth points in rear part of vehicle, saloon

730	Earth point 1, on right rear wheel housing

q	Specified torque 9 Nm

q	Figure 730 Earth point 1, on right rear wheel housing in Passat estate

729	Earth point, on left rear wheel housing

q	Specified torque 9 Nm

q	Figure 729 Earth point, on left rear wheel housing in Passat estate

50	Earth point, on left in luggage compartment

q	Specified torque 20 Nm

q	Figure 50 Earth point, on left in luggage compartment in Passat estate

q	Only models with battery at rear

Earth points in rear part of vehicle, estate

730	Earth point 1, on right rear wheel housing

q	Specified torque 9 Nm

729	Earth point, on left rear wheel housing

q	Specified torque 9 Nm

50	Earth point, on left in luggage compartment

q	Specified torque 20 Nm

q	Only models with battery at rear

VW PASSAT 2016

3-pin connector -T3bq- , black / 3-pin connector -T3dj- , black

VW PASSAT 2016 Coupling point in engine compartment, left TML

Coupling point in engine compartment, left -TML-

C -

D -

E -

F -

F -

G -

H -

I -

Coupling point for headlight washer system -TSRA-

6-pin connector -T6- , black / 6-pin connector -T6aa- , black

q	Depending on equipment

Diagnostic connection -U31-

Diagnostic connection -U31- , left-hand drive models

A -	16-pin connector -T16d- , black

Diagnostic connection -U31- , right-hand drive models

A -	16-pin connector -T16d- , black

Coupling point in interior -TI- , left-hand drive models

8-pin connector -T8cn- , black / 8-pin connector -T8co- , black

5-pin connector -T5bq- , black / 5-pin connector -T5ao-

Coupling point in interior -TI- , right-hand drive models

A -	8-pin connector -T8cn- , black / 8-pin connector -T8co- , black

B -	5-pin connector -T5bq- , black / 5-pin connector -T5ao-

Coupling point on front left door -TTVL-

27-pin connector -T27f- , black / 27-pin connector -T27h- , black

q	Only models with no overhead view camera

29-pin connector -T29- , white / 29-pin connector -T29c- , white

q	Only models with overhead view camera

Coupling point in front left door -TTIVL-

4-pin connector -T4fr- , black / 4-pin connector -T4ge- , black

q	Coupling point for driver exterior door handle -EX6-

q	Only models with entry and start authorisation

C -	5-pin connector -T5cm- , blue

q	Coupling point for left overhead view camera -R244-

q	Only models with overhead view camera

4-pin connector -T4fq- , black / 4-pin connector -T4gs- , black

q	Coupling point for loudspeakers

q	Only models with Dynaudio sound system

2-pin connector -T2nu- , black / 2-pin connector -T2nc- , black

q	Coupling point for loudspeakers

q	Depending on equipment

8-pin connector -T8bq- , black / 8-pin connector -T8ce- , black

q	Coupling point for loudspeakers and ambient lighting

q	Only models with ambient lighting, version 2

Coupling point on rear left door -TTHL-

27-pin connector -T27d- , black / 27-pin connector -T27j- , black

Coupling point in rear left door -TTIHL-

4-pin connector -T4he- , black / 4-pin connector -T4fz- , black

q	Coupling point for rear left window regulator motor -V26-

q	Only models with rear door control unit

4-pin connector -T4fw- , black / 4-pin connector -T4gi- , black

q	Only models with entry and start authorisation

8-pin connector -T8bx- , black / 8-pin connector -T8cg- , black

q	Coupling point for loudspeakers and ambient lighting

q	Only models with ambient lighting, version 2

2-pin connector -T2no- , black / 2-pin connector -T2or- , black

q	Coupling point for loudspeakers

q	Only models with Dynaudio sound system

E -	2-pin connector -T2no- , black / 2-pin connector -T2or- , black

q	Coupling point for loudspeakers

q	Depending on equipment

Coupling point for all-wheel drive -TSAA-

B -	6-pin connector -T6y- , black

Coupling point in interior, below left -TIUL-

17-pin connector -T17l- , white / 17-pin connector -T17t- , white

17-pin connector -T17m- , green / 17-pin connector -T17u- , green

5-pin connector -T5ax- / 5-pin connector -T5cp-

q	Coupling point for front overhead view camera -R243-

q	Illustration of connector similar

17-pin connector -T17i- , brown / 17-pin connector -T17q- , brown

17-pin connector -T17k- , blue / 17-pin connector -T17s- , blue

17-pin connector -T17j- , red / 17-pin connector -T17r- , red

17-pin connector -T17h- , black / 17-pin connector -T17p- , black

Coupling point for front left seat -TSVL-

Coupling point for front left seat -TSVL- , left-hand drive models

2-pin connector -T2es- , black / 2-pin connector -T2pb- , black

3-pin connector -T3aj- , yellow / 3-pin connector -T3fz- , yellow

10-pin connector -T10bv- , black / 10-pin connector -T10aj- , black

D -	Not assigned

Coupling point for front left seat -TSVL- , right-hand drive models

A -	4-pin connector -T4ao- , black / 4-pin connector -T4hl- , black

B -	3-pin connector -T3aj- , yellow / 3-pin connector -T3fz- , yellow

C -	10-pin connector -T10bv- , black / 10-pin connector -T10ai- , black

D -	Not assigned

Coupling point for roof -TH-

16-pin connector -T16h- , black / 16-pin connector -T16f- , black

6-pin connector -T6p- , black / 6-pin connector -T6cr- , black

Coupling point on front right door -TTVR-

27-pin connector -T27i- , black / 27-pin connector -T27g- , black

q	Only models with no overhead view camera

29-pin connector -T29a- , white / 29-pin connector -T29d- , white

q	Only models with overhead view camera

Coupling point in front right door -TTIVR-

8-pin connector -T8cf- , black / 8-pin connector -T8bt- , black

q	Coupling point for loudspeakers and ambient lighting

q	Only models with ambient lighting, version 2

4-pin connector -T4ft- , black / 4-pin connector -T4gz- , black

q	Coupling point for loudspeakers

q	Only models with Dynaudio sound system

D -	2-pin connector -T2nj-

q	Coupling point for blind spot monitor warning lamp in right exterior mirror -K304-

q	Only models with lane change assist

4-pin connector -T4fu- , black / 4-pin connector -T4gg- , black

q	Coupling point for driver exterior door handle -EX6-

q	Only models with entry and start authorisation

Coupling point on rear right door -TTHR-

27-pin connector -T27e- , black / 27-pin connector -T27k- , black

Coupling point in rear right door -TTIHR-

2-pin connector -T2nr- , black / 2-pin connector -T2by- , black

q	Coupling point for loudspeakers

q	Only models with Dynaudio sound system

8-pin connector -T8bz- , black / 8-pin connector -T8ch- , black

q	Coupling point for loudspeakers and ambient lighting

q	Only models with ambient lighting, version 2

4-pin connector -T4ga- , black / 4-pin connector -T4gk- , black

q	Only models with entry and start authorisation

4-pin connector -T4gd- , black / 4-pin connector -T4hh- , black

q	Coupling point for rear right window regulator motor -V27-

q	Only models with rear door control unit

E -	2-pin connector -T2nr- , black / 2-pin connector -T2by- , black

q	Coupling point for loudspeakers

q	Depending on equipment

Coupling point in interior, below right -TIUR-

17-pin connector -T17o- , brown / 17-pin connector -T17w- , brown

17-pin connector -T17n- , black / 17-pin connector -T17v- , black

Coupling point for front right seat -TSVR-

Coupling point for front right seat -TSVR- , left-hand drive models

A -	Not assigned

10-pin connector -T10ca- , black / 10-pin connector -T10ak- , black

3-pin connector -T3ak- , yellow / 3-pin connector -T3ga- , yellow

4-pin connector -T4bm- , black / 4-pin connector -T4ia- , black

Coupling point for front right seat -TSVR- , right-hand drive models

A -	10-pin connector -T10ca- , black / 10-pin connector -T10ak- , black

B -	3-pin connector -T3ak- , yellow / 3-pin connector -T3ga- , yellow

2-pin connector -T2bw- , black / 2-pin connector -T2pn- , black

Coupling point for exhaust flap control unit -TAGK-

5-pin connector -T5bb- , black / 5-pin connector -T5co- , black

Coupling point on rear lid -THK- , estate

10-pin connector -T10ae- , brown / 10-pin connector -T10bn- , brown

10-pin connector -T10ac- , black / 10-pin connector -T10bm- , black

10-pin connector -T10ai- , black / 10-pin connector -T10fd- , black

10-pin connector -T10af- , brown / 10-pin connector -T10bk- , brown

10-pin connector -T10ad- , black / 10-pin connector -T10bj- , black

Coupling point in luggage compartment, left -THRL-

Coupling point in luggage compartment, left -THRL- , saloon

8-pin connector -T8cb- , black / 8-pin connector -T8ae-

q	Only models with trailer detection

q	Connector for estate

4-pin connector -T4iz- , black / 4-pin connector -T4bt- , black

3-pin connector -T3dv- , brown / 3-pin connector -T3as- , brown

3-pin connector -T3dw- , black / 3-pin connector -T3ar- , black

4-pin connector -T4fl- , blue / 4-pin connector -T4bu- , blue

4-pin connector -T4fk- , red / 4-pin connector -T4r- , red

4-pin connector -T4fe- , brown / 4-pin connector -T4bs- , brown

4-pin connector -T4ff- , black / 4-pin connector -T4q- , black

Coupling point in luggage compartment, left -THRL- , estate

A -	8-pin connector -T8cb- , black / 8-pin connector -T8ae-

q	Only models with trailer detection

Coupling point in luggage compartment, right -THRR-

Coupling point in luggage compartment, right -THRR- , saloon

10-pin connector -T10av- , black / 10-pin connector -T10bs- , black

q	Only models with parking aid

q	Connector for estate

3-pin connector -T3ba- , black / 3-pin connector -T3et- , black

q	Only models with no parking aid

q	Connector for estate

4-pin connector -T4cj- , black / 4-pin connector -T4fj- black

q	Only models with reversing camera/overhead view camera

5-pin connector -T5ba- , blue / 5-pin connector -T5cj- , blue

q	Only models with overhead view camera

Coupling point in luggage compartment, right -THRR- , estate

A -	10-pin connector -T10av- , black / 10-pin connector -T10bs- , black

q	Only models with parking aid

A -	3-pin connector -T3ba- , black / 3-pin connector -T3et- , black

q	Only models with no parking aid

VW PASSAT 2016 Overview of relay carriers

Overview of relay carriers

Overview of relay carriers, saloon

Overview of relay carriers, estate



Overview of relay carriers, saloon

The fitting locations are identical on LHD and RHD models.

1 -	Relay and fuse carrier 2 -SR2- , on left under dash panel

t	Heated rear window relay -J9-

t	Terminal 15 voltage supply relay -J329-

t	Relay for power sockets -J807-

t	Relay for reducing agent metering system -J963-

q	Fitting locations and relay assignment, left-hand drive models, from September 2014

q	Fitting locations and relay assignment, right-hand drive models, from September 2014

2 -	Relay and fuse carrier 1 -SR1- , on E-box in engine compartment

t	Automatic glow period control unit -J179-

t	Main relay -J271-

t	Heated windscreen relay -J47-

t	Terminal 30 voltage supply relay -J317-

t	Low heat output relay -J359-

t	High heat output relay -J360-

t	Horn relay -J413-

t	Starter relay 1 -J906-

t	Starter relay 2 -J907-

q	Fitting location and relay assignment, equipment version 1, from September 2014

q	Fitting location and relay assignment, equipment version 2, from September 2014

Overview of relay carriers, estate

The fitting locations are identical on LHD and RHD models.

1 -	Relay and fuse carrier 2 -SR2- , on left under dash panel

t	Heated rear window relay -J9-

t	Terminal 15 voltage supply relay -J329-

t	Relay for power sockets -J807-

t	Relay for reducing agent metering system -J963-

q	Fitting locations and relay assignment, left-hand drive models, from September 2014

q	Fitting locations and relay assignment, right-hand drive models, from September 2014

2 -	Relay and fuse carrier 1 -SR1- , on E-box in engine compartment

t	Automatic glow period control unit -J179-

t	Main relay -J271-

t	Heated windscreen relay -J47-

t	Terminal 30 voltage supply relay -J317-

t	Low heat output relay -J359-

t	High heat output relay -J360-

t	Horn relay -J413-

t	Starter relay 1 -J906-

t	Starter relay 2 -J907-

q	Fitting location and relay assignment, equipment version 1, from September 2014

q	Fitting location and relay assignment, equipment version 2, from September 2014

VW PASSAT 2016

Relay and fuse carrier 2 -SR2- , on left under dash panel

Fitting location and relay assignment of relay and fuse carrier 2 -SR2- , left-hand drive models, from September 2014

1 -	Relay and fuse carrier 2 -SR2- , on left under dash panel

R1 -	Relay for reducing agent metering system -J963-

R2 -	Not assigned

R3 -	Not assigned

R4 -	Terminal 15 voltage supply relay -J329-

R5 -	Heated rear window relay -J9-

R6 -	Relay for power sockets -J807-

Back to overview

Fitting location and relay assignment of relay and fuse carrier 2 -SR2- , right-hand drive models, from September 2014

1 -	Relay and fuse carrier 2 -SR2- , on left under dash panel

R1 -	Relay for reducing agent metering system -J963-

R2 -	Not assigned

R3 -	Not assigned

R4 -	Terminal 15 voltage supply relay -J329-

R5 -	Heated rear window relay -J9-

R6 -	Relay for power sockets -J807-

Back to overview

Relay and fuse carrier 1 -SR1- , on E-box in engine compartment

Fitting location and relay assignment of relay and fuse carrier 1 -SR1- , on E-box, equipment version 1, from September 2014

1 -	Relay and fuse carrier 1 -SR1- , on E-box in engine compartment

R1 -	Starter relay 1 -J906-

R2 -	Starter relay 2 -J907-

R3 -	Horn relay -J413-

R4 -	High heat output relay -J360-

q	Only models with auxiliary air heater

R5 -	Main relay -J271-

q	Only models with petrol engine

R5 -	Terminal 30 voltage supply relay -J317-

q	Only models with a diesel engine

R6 -	Automatic glow period control unit -J179-

q	Only models with a diesel engine

R7 -	Low heat output relay -J359-

q	Only models with auxiliary air heater

R8 -	Not assigned

R9 -	Not assigned

R10 -

Not assigned

Back to overview

Fitting location and relay assignment of relay and fuse carrier 1 -SR1- , on E-box, equipment version 2, from September 2014

1 -	Relay and fuse carrier 1 -SR1- , on E-box in engine compartment

R1 -	Starter relay 1 -J906-

R2 -	Starter relay 2 -J907-

R3 -	Horn relay -J413-

R4 -	High heat output relay -J360-

q	Only models with auxiliary air heater

R5 -	Main relay -J271-

q	Only models with petrol engine

R5 -	Terminal 30 voltage supply relay -J317-

q	Only models with a diesel engine

R6 -	Automatic glow period control unit -J179-

q	Only models with a diesel engine

R7 -	Low heat output relay -J359-

q	Only models with auxiliary air heater

R8 -	Not assigned

R11 -

Heated windscreen relay -J47-

q	Only models with heated windscreen

Back to overview

VW PASSAT 2016 Overview of fuse holders

Overview of fuse holders, estate



Overview of fuse holders, saloon

The fitting locations are identical on LHD and RHD models.

q	Fuse assignment, from April 2015

q	Fuse assignment, from April 2015

q	Fuse assignment, from September 2014

Only models with hybrid drive system

q	Fitting location

q	Fuse assignment, from August 2015

q	Fuse assignment, from August 2015

q	Fuse assignment, from April 2015

q	Fitting location right-hand drive

q	Fuse assignment, from September 2014

q	Fuse assignment, from May 2015

q	Fitting location right-hand drive

q	Fuse assignment, from September 2014

q	Fuse assignment, from April 2015

q	Fuse assignment, from September 2014

q	Fuse assignment, from February 2015

q	Fitting location, only models with hybrid drive system

q	Fuse assignment, from September 2014

q	Fuse assignment, from August 2015, only models with hybrid drive system

q	Fuse assignment, from August 2015

Overview of fuse holders, estate

The fitting locations are identical on LHD and RHD models.

1 -	Fuse holder F -SF-

Only for special vehicles

q	Fitting location

q	Fuse assignment, from April 2015

2 -	Fuse holder D -SD-

Only models with battery at rear

q	Fitting location

q	Fuse assignment, from September 2014

3 -	Fuse holder J -SJ-

Only for special vehicles

q	Fitting location

q	Fuse assignment, from April 2015

4 -	Fuse holder K -SK-

Only for special vehicles

q	Fitting location

q	Fuse assignment, from April 2015

5 -	Fuse holder C -SC-

q	Fitting location left-hand drive

q	Fitting location right-hand drive

q	Fuse assignment, from September 2014

q	Fuse assignment, from May 2015

5 -	Front passenger seat adjustment thermal fuse 1 -S46-

q	Fitting location left-hand drive

q	Fitting location right-hand drive

q	Fuse assignment, from September 2014

6 -	Fuse holder H -SH-

q	Fitting location

q	Fuse assignment, from April 2015

7 -	Fuse holder B -SB-

q	Fitting location

q	Fuse assignment, from September 2014

q	Fuse assignment, from February 2015

8 -	Fuse holder A -SA-

q	Fitting location

q	Fuse assignment, from September 2014

VW PASSAT 2016 Fitting location, fuse holder F SF Fitting location, fuse holder F -SF- Fitting location of fuse holder F -SF- , only for special vehicles   Note: The fitting locations are identical on saloon and estate models.

1 -	Fuse holder F -SF-

Fuse colours for J-Case fuse:

t	50 A - red

t	40 A - green

t	30 A - pink

Fuse colours for ATO flat fuse:

t	40 A - orange

t	30 A - light green

t	25 A - natural (white)

t	20 A - yellow

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

t	1A - black

Fuse colours, for mini fuses:

t	20 A - yellow

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

t	1A - black

Back to overview

VW PASSAT 2016 Fuse assignment on fuse holder F SF

Fuse assignment on fuse holder F -SF-

Fuse assignment of fuse holder F -SF- , from April 2015, only for special vehicles

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SF1	Fuse 1 on fuse holder F -SF1-	2) only	Special vehicle fuse 1)	30
SF2	Fuse 2 on fuse holder F -SF2-	2) only	Special vehicle fuse 1)	30
SF3	Fuse 3 on fuse holder F -SF3-	2) only	Special vehicle fuse 1)	30
SF4	Fuse 4 on fuse holder F -SF4-	2) only	Special vehicle fuse 1)	30
SF5	Fuse 5 on fuse holder F -SF5-	2) only	Special vehicle fuse 1)	30
SF6	Fuse 6 on fuse holder F -SF6-	2) only	Special vehicle fuse 1)	30
SF7	Fuse 7 on fuse holder F -SF7-	2) only	Special vehicle fuse 1)	30
SF8	Fuse 8 on fuse holder F -SF8-	2) only	Special vehicle fuse 1)	30
SF9	Fuse 9 on fuse holder F -SF9-	2) only	Special vehicle fuse 1)	30
SF10	Fuse 10 on fuse holder F -SF10-	2) only	Special vehicle fuse 1)	30
SF11	Fuse 11 on fuse holder F -SF11-	2) only	Special vehicle fuse 1)	30
SF12	Fuse 12 on fuse holder F -SF12-	2) only	Special vehicle fuse 1)	30
SF13	Fuse 13 on fuse holder F -SF13-	2) only	Special vehicle fuse 1)	30
SF14	Fuse 14 on fuse holder F -SF14-	2) only	Special vehicle fuse 1)	30
SF15	Fuse 15 on fuse holder F -SF15-	2) only	Special vehicle fuse 1)	30

1) According to equipment

2) Fuse rating, see installation description for special installations

Back to overview

VW PASSAT 2016 Fitting location, fuse holder D SD

Fitting location, fuse holder D -SD-

Fitting location of fuse holder D -SD- , saloon, only models with battery at rear

1 -	Fuse holder D -SD-

A -	Supply 508 Threaded connection (30), on E-box

Back to overview

Fitting location of fuse holder D -SD- , estate, only models with battery at rear

1 -	Fuse holder D -SD-

A -	Supply 508 Threaded connection (30), on E-box

Back to overview

Fitting location of fuse holder D -SD- , only models with hybrid drive system

1 -	Fuse holder D -SD-

Back to overview

VW PASSAT 2016 Fuse assignment on fuse holder D SD

Fuse assignment on fuse holder D -SD-

Fuse assignment of fuse holder D -SD- , from September 2014, only models with battery at rear

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SD1	Fuse 1 on fuse holder D -SD1-	80 A	Supply for fuse 4 on fuse holder A -SA4- t  Terminal 30	30
SD2	Fuse 2 on fuse holder D -SD2-	110 A	Supply for fuse holder C -SC- t  Terminal 30_2 t  Fuse 1 on fuse holder C -SC1- t  Fuse 3 on fuse holder C -SC3- t  Fuse 15 on fuse holder C -SC15- - Fuse 21 on fuse holder C -SC21- t  Fuse 23 on fuse holder C -SC23- - Fuse 28 on fuse holder C -SC28- t  Fuse 43 on fuse holder C -SC43- - Fuse 45 on fuse holder C -SC45- t  Fuse 50 on fuse holder C -SC50-	30
SD3	Fuse 3 on fuse holder D -SD3-	110 A	Supply for fuse holder C -SC- t  Terminal 30_1 t  Fuse 2 on fuse holder C -SC2- t  Fuse 4 on fuse holder C -SC4- - Fuse 14 on fuse holder C -SC14- t  Fuse 22 on fuse holder C -SC22- t  Fuse 31 on fuse holder C -SC31- t  Fuse 38 on fuse holder C -SC38- - Fuse 39 on fuse holder C -SC39- t  Fuse 41 on fuse holder C -SC41- - Fuse 42 on fuse holder C -SC42- t  Fuse 46 on fuse holder C -SC46- t  Fuse 51 on fuse holder C -SC51- t  Fuse 53 on fuse holder C -SC53- t  Relay for power sockets -J807- t  Terminal 15 voltage supply relay -J329-	30

Back to overview

Fuse assignment of fuse holder D -SD- , from July 2014, only models with hybrid drive system

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SD1	Fuse 1 on fuse holder D -SD1-	200 A	508 Threaded connection (30), on E-box	30
SD2	Not assigned	-		-

Back to overview

VW PASSAT 2016 Fitting location of fuse holder J SJ

Fitting location of fuse holder J -SJ-

Fitting location of fuse holder J -SJ- , only for special vehicles

The fitting locations are identical on saloon and estate models.

1 -	Fuse holder J -SJ-

Fuse colours for J-Case fuse:

t	40 A - green

t	30 A - pink

Fuse colours for ATO flat fuse:

t	40 A - orange

t	30 A - light green

t	25 A - natural (white)

t	20 A - yellow

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

Fuse colours, for mini fuses:

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

t	1A - black

Back to overview

VW PASSAT 2016 Fuse assignment of fuse holder J SJ

Fuse assignment of fuse holder J -SJ-

Fuse assignment of fuse holder J -SJ- , from April 2015, only for special vehicles

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SJ1	Fuse 1 on fuse holder J -SJ1-	2) only	Special vehicle fuse 1)	30
SJ2	Fuse 2 on fuse holder J -SJ2-	2) only	Special vehicle fuse 1)	30
SJ3	Fuse 3 on fuse holder J -SJ3-	2) only	Special vehicle fuse 1)	30

1) According to equipment

2) Fuse rating, see installation description for special installations

Back to overview

VW PASSAT 2016 Fitting location of fuse holder in switching unit for high-voltage battery SX6

Fitting location of fuse holder in switching unit for high-voltage battery -SX6-

Fitting location of fuse holder in switching unit for high-voltage battery -SX6- , only models with hybrid drive system

1 -	Switching unit for high-voltage battery -SX6-

A -	High-voltage system fuse 1 -S350- , in switching unit for high-voltage battery -SX6-

Back to overview

VW PASSAT 2016 Fuse assignment of high-voltage system fuse 1 S350

Fuse assignment of high-voltage system fuse 1 -S350-

Fuse assignment of high-voltage system fuse 1 -S350- , from August 2015, only models with hybrid drive system

Screw location	Current flow diagram designation	Nominal value	Function/component	Terminal
1	High-voltage system fuse 1 -S350-	350 A	High-voltage battery power contactor 1 -J1057-	30

Back to overview

VW PASSAT 2016 Fitting location of fuse holder K SK

Fitting location of fuse holder K -SK-

Fitting location of fuse holder K -SK- , only for special vehicles

The fitting locations are identical on saloon and estate models.

1 -	Fuse holder K -SK-

Fuse colours for J-Case fuse:

t	40 A - green

t	30 A - pink

Fuse colours for ATO flat fuse:

t	40 A - orange

t	30 A - light green

t	25 A - natural (white)

t	20 A - yellow

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

Fuse colours, for mini fuses:

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

t	1A - black

Back to overview VW PASSAT 2016 Fuse assignment of fuse holder K SK Fuse assignment of fuse holder K -SK- Fuse assignment of fuse holder K -SK- , from April 2015, only for special vehicles

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SK1	Fuse 1 on fuse holder K -SK1-	2) only	Special vehicle fuse 1)	30
SK2	Fuse 2 on fuse holder K -SK2-	2) only	Special vehicle fuse 1)	30
SK3	Fuse 3 on fuse holder K -SK3-	2) only	Special vehicle fuse 1)	30
SK4	Fuse 4 on fuse holder K -SK4-	2) only	Special vehicle fuse 1)	30
SK5	Fuse 5 on fuse holder K -SK5-	2) only	Special vehicle fuse 1)	30
SK6	Fuse 6 on fuse holder K -SK6-	2) only	Special vehicle fuse 1)	30
SK7	Fuse 7 on fuse holder K -SK7-	2) only	Special vehicle fuse 1)	30

1) According to equipment 2) Fuse rating, see installation description for special installations Back to overview

VW PASSAT 2016 Fitting location of fuse holder C SC

Fitting location of fuse holder C -SC-

Fitting location of fuse holder C -SC- , left-hand drive models

1 -	Fuse holder C -SC-

Fuse colours for J-Case fuse:

t	40 A - green

t	30 A - pink

Fuse colours for ATO flat fuse:

t	40 A - orange

t	30 A - light green

t	25 A - natural (white)

t	20 A - yellow

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

Fuse colours, for mini fuses:

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

t	1A - black

Back to overview

Fitting location, fuse holder C -SC- , right-hand drive

1 -	Fuse holder C -SC-

Fuse colours for J-Case fuse:

t	50 A - red

t	40 A - green

t	30 A - pink

Fuse colours for ATO flat fuse:

t	40 A - orange

t	30 A - light green

t	25 A - natural (white)

t	20 A - yellow

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

t	1A - black

Fuse colours, for mini fuses:

t	20 A - yellow

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

t	1A - black

Back to overview

Fuse assignment of fuse holder C -SC-

Fuse assignment of fuse holder C -SC- , from September 2014

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SC1	Fuse 1 on fuse holder C -SC1-	30 A	Control unit for reducing-agent heater -J891-	30
SC2	Fuse 2 on fuse holder C -SC2-	10 A	Steering column electronics control unit -J527-4)	30
SC3	Not assigned	-		-
SC4	Not assigned	-		-
SC5	Fuse 5 on fuse holder C -SC5-	5 A	Data bus diagnostic interface -J533-	30
SC6	Fuse 6 on fuse holder C -SC6-	5 A	Anti-theft alarm sensor -G578-	30
SC7	Fuse 7 on fuse holder C -SC7-	10 A	Heater and air conditioning controls -EX21-	30
			Selector lever -E313-
			Remote control receiver for auxiliary coolant heater -R149-
			Heated rear window relay -J9-
			Analogue clock -Y-
			Operating and display unit for rear air conditioning system -E265-
			Tyre Pressure Monitoring System control unit -J502-
SC8	Fuse 8 on fuse holder C -SC8-	10 A	Rotary light switch -EX1-	30
			Electromechanical parking brake button -E538-
			Rain and light sensor -G397-
			Diagnostic connection -U31-
			Front interior light -WX1-3)
			Light for left dashboard ambient lighting -L229-3)
			Light for right dashboard ambient lighting -L230-3)
			Light for front left door contour lighting -L251-3)
			Light for front right door contour lighting -L252-3)
			Light for rear left door contour lighting -L253-3)
			Light for rear right door contour lighting -L254-3)
SC9	Fuse 9 on fuse holder C -SC9-	1 A	Steering column electronics control unit -J527-	30
SC10	Fuse 10 on fuse holder C -SC10-	10 A	Display unit for front information display and operating unit control unit -J685-	30
			TV tuner -RX6-
SC11	Fuse 11 on fuse holder C -SC11-	25 A	Control unit for front left belt tensioner -J854-	30
SC12	Fuse 12 on fuse holder C -SC12-	20 A	Control unit 1 for information electronics -J794-	30
SC13	Fuse 13 on fuse holder C -SC13-	15 A	Electronically controlled damping control unit -J250-	30
SC14	Fuse 14 on fuse holder C -SC14-	30 A	Fresh air blower control unit -J126-	30
SC15	Fuse 15 on fuse holder C -SC15-	10 A	Control unit for electronic steering column lock -J764-	30
SC16	Fuse 16 on fuse holder C -SC16-	7.5 A	Two-way signal amplifier for mobile telephone/data services -J984-	30
			Storage compartment with interface for mobile telephone -R265-
			USB hub -R293-
			Chip card reader -D8-
SC17	Fuse 17 on fuse holder C -SC17-	5 A	Dash panel insert -KX2-	30
SC18	Fuse 18 on fuse holder C -SC18-	7.5 A	Reversing camera -R189-	30
			Rear lid handle release button -E234-
			Control unit for overhead view camera -J928-
			Rear overhead view camera -R246-
SC19	Fuse 19 on fuse holder C -SC19-	7.5 A	Interface for entry and start system -J965-	30
SC20	Fuse 20 on fuse holder C -SC20-	7.5 A	Relay for reducing agent metering system -J963-	30
SC21	Fuse 21 on fuse holder C -SC21-	15 A	All-wheel drive control unit -J492-	30
SC22	Fuse 22 on fuse holder C -SC22-	15 A	Trailer detector control unit -J345-	30
SC23	Fuse 23 on fuse holder C -SC23-	40 A	Onboard supply control unit -J519- t  Front right headlight -MX2-	30
SC24	Fuse 24 on fuse holder C -SC24-	30 A	Sliding sunroof adjustment control unit -J245-	30
SC25	Fuse 25 on fuse holder C -SC25-	30 A	Driver door control unit -J386- 1)	30
			Front passenger door control unit -J387-2)	30
			Rear left door control unit -J388-
			Rear left window regulator motor -V26-
SC26	Fuse 26 on fuse holder C -SC26-	30 A	Onboard supply control unit -J519- t  Seat heating	30
SC27	Fuse 27 on fuse holder C -SC27-	30 A	Digital sound package control unit -J525-	30
SC28	Fuse 28 on fuse holder C -SC28-	20 A	Trailer detector control unit -J345-	30
SC29	Not assigned	-		-
SC30	Not assigned	-		-
SC31	Fuse 31 on fuse holder C -SC31-	40 A	Onboard supply control unit -J519- t  Front left headlight -MX1-	30
SC32	Fuse 32 on fuse holder C -SC32-	7.5 A	Front camera for driver assist systems -R242-	15
		10 A 5)	Adaptive cruise control unit -J428-
			Parking aid control unit -J446-
			Park assist steering control unit -J791-
			Blind Spot Monitor control unit -J1086-
			Blind Spot Monitor control unit 2 -J1087-
SC33	Fuse 33 on fuse holder C -SC33-	5 A	Airbag control unit -J234-	15
			Front passenger airbag deactivated warning lamp -K145-
SC34	Fuse 34 on fuse holder C -SC34-	7.5 A	Electromechanical parking brake button -E538-	15
			Interior mirror -EX5-
			Relay for power sockets -J807-
			Pedestrian protection warning lamp -K288-
			Switch module 2 in centre console -EX30-
			Pressure sender for refrigerant circuit -G805-
			Air quality sensor -G238-
SC35	Fuse 35 on fuse holder C -SC35-	10 A	Diagnostic connection -U31-	15
			Headlight range control and instrument illumination regulator -EX14-
			Control unit for cornering light and headlight range control -J745-
			Front left headlight -MX1- t  Left headlight range control motor -V48-
			Front right headlight -MX2- t  Right headlight range control motor -V49-
SC36	Fuse 36 on fuse holder C -SC36-	5 A	Front left headlight -MX1- t  Output module 1 for left LED headlight -A31-	15
SC37	Fuse 37 on fuse holder C -SC37-	5 A	Front right headlight -MX2- t  Output module 1 for right LED headlight -A27-	15
SC38	Fuse 38 on fuse holder C -SC38-	25 A	Trailer detector control unit -J345-	30
SC39	Fuse 39 on fuse holder C -SC39-	30 A	Front passenger door control unit -J387-1)	30
			Driver door control unit -J386- 2)
			Rear right door control unit -J389-	30
			Rear right window regulator motor -V27-
SC40 6) , 7)	Fuse 40 on fuse holder C -SC40-	20 A	Cigarette lighter -U1- 3)	15 6) / 30 7)
			12 V socket -U5- 3)
			12 V socket 2 -U18-
			12 V socket 3 -U19-
SC41	Fuse 41 on fuse holder C -SC41-	25 A	Control unit for front right belt tensioner -J855-	30
SC42	Fuse 42 on fuse holder C -SC42-	40 A	Onboard supply control unit -J519- t  Central locking	30
SC43	Fuse 43 on fuse holder C -SC43-	30 A	Onboard supply control unit -J519-	30
SC44	Fuse 44 on fuse holder C -SC44-	15 A	Trailer detector control unit -J345-	30
SC45	Fuse 45 on fuse holder C -SC45-	15 A	Driver seat lumbar support adjustment switch -E176-	30
			Driver seat adjustment operating unit -E470-
			Driver seat adjustment control unit -J810-
			Operating unit for front left seat adjustment -EX33-
			Massage control unit -J740-
			Front left seat cushion fan 1 -V514-
			Front left seat backrest fan 1 -V512-
SC46	Fuse 46 on fuse holder C -SC46-	30 A	DC/AC converter with socket, 12 V - 230 V -U13-	30
SC47	Fuse 47 on fuse holder C -SC47-	15 A	Rear window wiper motor -V12-	15
		7.5 A	Rear roller blind control unit -J262-
SC48	Not assigned	-		-
SC49	Fuse 49 on fuse holder C -SC49-	5 A	Clutch position sender -G476-	15
			Starter relay 1 -J906-
			Starter relay 2 -J907-
SC50	Fuse 50 on fuse holder C -SC50-	40 A	Rear lid control unit -J605-	30
SC51	Fuse 51 on fuse holder C -SC51-	25 A	Operating and display unit for rear air conditioning system -E265-	30
SC52	Not assigned	-
SC53	Fuse 53 on fuse holder C -SC53-	30 A	Heated rear window relay -J9-	15

1) Only left-hand drive models

2) Only right-hand drive models

3) Depending on equipment

4) Only models with heated steering wheel

5) Only models with blind spot monitor

6) Factory fitted with power supply from terminal 15

7) Power supply via terminal 30 possible

The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged.

Back to overview

Fuse assignment of fuse holder C -SC- , from May 2015

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SC1	Fuse 1 on fuse holder C -SC1-	30 A	Control unit for reducing-agent heater -J891-	30
SC2	Fuse 2 on fuse holder C -SC2-	10 A	Steering column electronics control unit -J527-4)	30
SC3	Fuse 3 on fuse holder C -SC3-	8) only	Special vehicle fuse	-
SC4	Not assigned	-		-
SC5	Fuse 5 on fuse holder C -SC5-	5 A	Data bus diagnostic interface -J533-	30
SC6	Fuse 6 on fuse holder C -SC6-	5 A	Selector lever -E313-	30
SC7	Fuse 7 on fuse holder C -SC7-	10 A	Heater and air conditioning controls -EX21-	30
			Remote control receiver for auxiliary coolant heater -R149-
			Heated rear window relay -J9-
			Analogue clock -Y-
			Operating and display unit for rear air conditioning system -E265-
			Tyre Pressure Monitoring System control unit -J502-
SC8	Fuse 8 on fuse holder C -SC8-	10 A	Rotary light switch -EX1-	30
			Electromechanical parking brake button -E538-
			Rain and light sensor -G397-
			Diagnostic connection -U31-
			Anti-theft alarm sensor -G578-
			Front interior light -WX1-3)
			Light for left dashboard ambient lighting -L229-3)
			Light for right dashboard ambient lighting -L230-3)
			Light for front left door contour lighting -L251-3)
			Light for front right door contour lighting -L252-3)
			Light for rear left door contour lighting -L253-3)
			Light for rear right door contour lighting -L254-3)
SC9	Fuse 9 on fuse holder C -SC9-	5 A	Steering column electronics control unit -J527-	30
SC10	Fuse 10 on fuse holder C -SC10-	10 A	Display unit for front information display and operating unit control unit -J685-	30
			TV tuner -RX6-
		8) only	Special vehicle fuse
SC11	Fuse 11 on fuse holder C -SC11-	25 A	Control unit for front left belt tensioner -J854-	30
SC12	Fuse 12 on fuse holder C -SC12-	20 A	Control unit 1 for information electronics -J794-	30
SC13	Fuse 13 on fuse holder C -SC13-	15 A	Electronically controlled damping control unit -J250-	30
SC14	Fuse 14 on fuse holder C -SC14-	30 A	Fresh air blower control unit -J126-	30
SC15	Fuse 15 on fuse holder C -SC15-	10 A	Control unit for electronic steering column lock -J764-	30
SC16	Fuse 16 on fuse holder C -SC16-	7.5 A	Two-way signal amplifier for mobile telephone/data services -J984-	30
			Storage compartment with interface for mobile telephone -R265-
			USB hub -R293-
			Chip card reader -D8-
			Control unit for heads-up display -J898-
SC17	Fuse 17 on fuse holder C -SC17-	5 A 7.5A9)	Dash panel insert -KX2-	30
			Emergency call module control unit and communication unit -J949-9)
SC18	Fuse 18 on fuse holder C -SC18-	7.5 A	Reversing camera -R189-	30
			Rear lid handle release button -E234-
			Control unit for overhead view camera -J928-
			Rear overhead view camera -R246-
SC19	Fuse 19 on fuse holder C -SC19-	7.5 A	Interface for entry and start system -J965-	30
SC20	Fuse 20 on fuse holder C -SC20-	7.5 A	Relay for reducing agent metering system -J963-	30
SC21	Fuse 21 on fuse holder C -SC21-	15 A	All-wheel drive control unit -J492-	30
SC22	Fuse 22 on fuse holder C -SC22-	15 A	Trailer detector control unit -J345-	30
SC23	Fuse 23 on fuse holder C -SC23-	40 A	Onboard supply control unit -J519- t  Front right headlight -MX2-	30
SC24	Fuse 24 on fuse holder C -SC24-	30 A	Sliding sunroof adjustment control unit -J245-	30
SC25	Fuse 25 on fuse holder C -SC25-	30 A	Driver door control unit -J386- 1)	30
			Front passenger door control unit -J387-2)	30
			Rear left door control unit -J388-
			Rear left window regulator motor -V26-
SC26	Fuse 26 on fuse holder C -SC26-	30 A	Onboard supply control unit -J519- t  Seat heating	30
SC27	Fuse 27 on fuse holder C -SC27-	30 A	Digital sound package control unit -J525-	30
SC28	Fuse 28 on fuse holder C -SC28-	25 A	Trailer detector control unit -J345-	30
SC29	Fuse 29 on fuse holder C -SC29-	8) only	Special vehicle fuse	-
SC30	Fuse 30 on fuse holder C -SC30-	10A	High-voltage battery 1 -AX2-9)	-
			Maintenance connector for high-voltage system -TW-9)
SC31	Fuse 31 on fuse holder C -SC31-	40 A	Onboard supply control unit -J519- t  Front left headlight -MX1-	30
SC32	Fuse 32 on fuse holder C -SC32-	7.5 A	Front camera for driver assist systems -R242-	15
		10 A 5)	Adaptive cruise control unit -J428-
			Parking aid control unit -J446-
			Park assist steering control unit -J791-
			Blind Spot Monitor control unit -J1086-
			Blind Spot Monitor control unit 2 -J1087-
SC33	Fuse 33 on fuse holder C -SC33-	5 A	Airbag control unit -J234-	15
			Front passenger airbag deactivated warning lamp -K145-
SC34	Fuse 34 on fuse holder C -SC34-	7.5 A	Electromechanical parking brake button -E538-	15
			Interior mirror -EX5-
			Relay for power sockets -J807-
			Pedestrian protection warning lamp -K288-
			Switch module 2 in centre console -EX30-
			Pressure sender for refrigerant circuit -G805-
			Air quality sensor -G238-
SC35	Fuse 35 on fuse holder C -SC35-	10 A	Diagnostic connection -U31-	15
			Headlight range control and instrument illumination regulator -EX14-
			Control unit for cornering light and headlight range control -J745-
			Front left headlight -MX1- t  Left headlight range control motor -V48-
			Front right headlight -MX2- t  Right headlight range control motor -V49-
SC36	Fuse 36 on fuse holder C -SC36-	5 A	Front left headlight -MX1- t  Output module 1 for left LED headlight -A31-	15
SC37	Fuse 37 on fuse holder C -SC37-	5 A	Front right headlight -MX2- t  Output module 1 for right LED headlight -A27-	15
SC38	Fuse 38 on fuse holder C -SC38-	25 A	Trailer detector control unit -J345-	30
SC39	Fuse 39 on fuse holder C -SC39-	30 A	Front passenger door control unit -J387-1)	30
			Driver door control unit -J386- 2)
			Rear right door control unit -J389-	30
			Rear right window regulator motor -V27-
SC40 6) , 7)	Fuse 40 on fuse holder C -SC40-	20 A	Cigarette lighter -U1- 3)	15 6) / 30 7)
			12 V socket -U5- 3)
			12 V socket 2 -U18-
			12 V socket 3 -U19-
SC41	Fuse 41 on fuse holder C -SC41-	25 A	Control unit for front right belt tensioner -J855-	30
SC42	Fuse 42 on fuse holder C -SC42-	40 A	Onboard supply control unit -J519- t  Central locking	30
SC43	Fuse 43 on fuse holder C -SC43-	30 A	Onboard supply control unit -J519-	30
SC44	Fuse 44 on fuse holder C -SC44-	15 A	Trailer detector control unit -J345-	30
SC45	Fuse 45 on fuse holder C -SC45-	15 A	Driver seat lumbar support adjustment switch -E176-	30
			Driver seat adjustment operating unit -E470-
			Driver seat adjustment control unit -J810-
			Operating unit for front left seat adjustment -EX33-
			Massage control unit -J740-
			Front left seat cushion fan 1 -V514-
			Front left seat backrest fan 1 -V512-
SC46	Fuse 46 on fuse holder C -SC46-	30 A	DC/AC converter with socket, 12 V - 230 V -U13-	30
SC47	Fuse 47 on fuse holder C -SC47-	15 A	Rear window wiper motor -V12-	15
		7.5 A	Rear roller blind control unit -J262-3)
SC48	Fuse 48 on fuse holder C -SC48-	7.5A	Engine sound generator control unit -J943-9)	-
SC49	Fuse 49 on fuse holder C -SC49-	5 A	Clutch position sender -G476-	15
			Starter relay 1 -J906-
			Starter relay 2 -J907-
			High-voltage battery 1 -AX2-9)
SC50	Fuse 50 on fuse holder C -SC50-	40 A	Rear lid control unit -J605-	30
SC51	Fuse 51 on fuse holder C -SC51-	25 A	Operating and display unit for rear air conditioning system -E265-	30
SC52	Not assigned	-
SC53	Fuse 53 on fuse holder C -SC53-	30 A	Heated rear window relay -J9-	15

1) Only left-hand drive models

2) Only right-hand drive models

3) Depending on equipment

4) Only models with heated steering wheel

5) Only models with blind spot monitor

6) Factory fitted with power supply from terminal 15

7) Power supply via terminal 30 possible

8) Fuse rating, see installation description for special equipment

9) Only models with hybrid drive system

The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged.

Back to overview

VW PASSAT 2016 Fitting location of front passenger seat adjustment thermal fuse 1 S46

Fitting location of front passenger seat adjustment thermal fuse 1 -S46-

Fitting location of front passenger seat adjustment thermal fuse 1 -S46- , left-hand drive models

1 -	Fuse holder for front passenger seat adjustment thermal fuse 1 -S46-

q	behind fuse holder C -SC-

2 -	Not assigned

q	behind fuse holder C -SC-

A -	Front passenger seat adjustment thermal fuse 1 -S46-

B -	Not assigned

Back to overview

Fitting location of front passenger seat adjustment thermal fuse 1 -S46- , right-hand drive models

1 -	Fuse holder for front passenger seat adjustment thermal fuse 1 -S46-

q	behind fuse holder C -SC-

2 -	Not assigned

q	behind fuse holder C -SC-

A -	Front passenger seat adjustment thermal fuse 1 -S46-

B -	Not assigned

Back to overview

Fuse assignment of front passenger seat adjustment thermal fuse 1 -S46-

Fuse assignment of front passenger seat adjustment thermal fuse 1 -S46- , from September 2014

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
A	Front passenger seat adjustment thermal fuse 1 -S46-	15 A	Operating unit for front right seat adjustment -EX34-	30
			Front right lumbar support adjustment switch -E753-
			Front right seat cushion fan 1 -V518-
			Front right seat backrest fan 1 -V516-
B	Not assigned	-		-

Back to overview

VW PASSAT 2016 Fitting location of fuse holder H SH

Fitting location of fuse holder H -SH-

Fitting location of fuse holder H -SH-

The fitting locations are identical on saloon and estate models.

1 -	Fuse holder H -SH-

Fuse colours for J-Case fuse:

t	40 A - green

t	30 A - pink

Fuse colours for ATO flat fuse:

t	40 A - orange

t	30 A - light green

t	25 A - natural (white)

t	20 A - yellow

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

Fuse colours, for mini fuses:

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

t	1A - black

Back to overview VW PASSAT 2016 Fuse assignment on fuse holder H SH Fuse assignment on fuse holder H -SH- Fuse assignment of fuse holder H -SH- , from April 2015

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SH1	Fuse 1 in fuse holder H -SH1-	2) only	Special vehicle fuse 1)	30
SH2	Fuse 2 in fuse holder H -SH2-	2) only	Special vehicle fuse 1)	30
SH3	Fuse 3 in fuse holder H -SH3-	2) only	Special vehicle fuse 1)	30
SH4	Fuse 4 in fuse holder H -SH4-	2) only	Special vehicle fuse 1)	30
SH5	Fuse 5 in fuse holder H -SH5-	7.5 A	Video socket -U22-	30
			Video socket 2 -U43-
SH6	Not assigned
SH7	Not assigned
SH8	Not assigned
SH9	Not assigned
SH10	Not assigned
SH11	Not assigned
SH12	Not assigned

1) According to equipment 2) Fuse rating, see installation description for special installations Back to overview VW PASSAT 2016 Fitting location of fuse holder B SB Fitting location of fuse holder B -SB- Fitting location of fuse holder B -SB-   Note: The fitting locations are identical on LHD and RHD models.

1 -	Fuse holder B -SB-

Fuse colours for J-Case fuse:

t	50 A - red

t	40 A - green

t	30 A - pink

Fuse colours for ATO flat fuse:

t	40 A - orange

t	30 A - light green

t	25 A - natural (white)

t	20 A - yellow

t	15 A - light blue

t	10 A - red

t	7.5 A - brown

t	5 A - light brown

t	1A - black

Back to overview

VW PASSAT 2016 Fuse assignment on fuse holder B SB

Fuse assignment on fuse holder B -SB-

Fuse assignment of fuse holder B -SB- , from September 2014

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SB1	Fuse 1 on fuse holder B -SB1-	40 A	ABS control unit -J104-	30
SB2	Fuse 2 on fuse holder B -SB2-	40 A	ABS control unit -J104- t  ABS hydraulic pump -V64-	30
SB3	Fuse 3 on fuse holder B -SB3-	15 A1) 30 A3)	Engine control unit -J623-	87
SB4	Fuse 4 on fuse holder B -SB4-	10 A2) 5 A3)	Radiator fan -VX57-	87
			Oil level and oil temperature sender -G266-
			Relay for reducing agent metering system -J963-4)
			High heat output relay -J360-3)
			Low heat output relay -J359-3)
			Charge pressure positioner -V465-1)
			Activated charcoal filter solenoid valve 1 -N80-1)
			Exhaust camshaft control valve 1 -N318-1)
			Camshaft control valve 1 -N205-1)
			Valve for oil pressure control -N428-
			Inlet cam actuator for cylinder 2 -N583-2)
			Exhaust cam actuator for cylinder 2 -N587-2)
			Inlet cam actuator for cylinder 3 -N591-2)
			Exhaust cam actuator for cylinder 3 -N595-2)
			Fuel cooling valve -N289-3)
			Exhaust gas recirculation cooler changeover valve -N345-3)
			Charge pressure control solenoid valve -N75-3)
SB5	Fuse 5 on fuse holder B -SB5-	10 A	Fuel pressure regulating valve -N276-3)	87
			Fuel metering valve -N290-3)
			Camshaft control valve 1 -N205-3)
SB6	Fuse 6 on fuse holder B -SB6-	5 A	Brake light switch -F-	87
SB7	Fuse 7 on fuse holder B -SB7-	10 A1),3) 15 A4)	Fuel metering valve -N290-1)	87
			Circulation pump -V55-1)
			Radiator blind control motor -V544-3)
			Coolant valve for cylinder head -N489-3)
			Valve for oil pressure control -N428-3)
			Exhaust gas recirculation cooler changeover valve -N345-3)
			Charge pressure positioner -V465-4)
			Charge air cooling pump -V188-4)
			Auxiliary pump for heating -V488-4)
SB8	Fuse 8 on fuse holder B -SB8-	10 A1) 15 A3)	Lambda probe 1 before catalytic converter -GX10- t  Lambda probe heater -Z19-	87
			Lambda probe 1 after catalytic converter -GX7- t  Lambda probe 1 heater after catalytic converter -Z29-
			NOx sender -G295-4)
SB9	Fuse 9 on fuse holder B -SB9-	20 A1) 5 A3)	Ignition coil 1 with output stage -N70-1)	87
			Ignition coil 2 with output stage -N127-1)
			Ignition coil 3 with output stage -N291-1)
			Ignition coil 4 with output stage -N292-1)
			Heater element for crankcase breather -N79-
			Automatic glow period control unit -J179-
			Air mass meter -G70-
SB10	Fuse 10 on fuse holder B -SB10-	20 A 7) 10 A 7)	Fuel pump control unit -J538-	87
SB11	Fuse 11 on fuse holder B -SB11-	40 A	Auxiliary air heater element -Z35-	87
SB12	Fuse 12 on fuse holder B -SB12-	40 A	Auxiliary air heater element -Z35-	87
SB13	Fuse 13 on fuse holder B -SB13-	30 A	Mechatronic unit for dual clutch gearbox -J743- 7) t  Dual clutch gearbox 0CW	30
		15 A	Mechatronic unit for dual clutch gearbox -J743- 7) t  Dual clutch gearbox 0D9
SB14	Fuse 14 on fuse holder B -SB14-	40 A	Heated windscreen relay -J47-	30
SB15	Fuse 15 on fuse holder B -SB15-	15 A	Horn relay -J413-	30
SB16	Not assigned	-		-
SB17	Fuse 17 on fuse holder B -SB17-	7.5 A	Main relay -J271- 1)	30
			Terminal 30 voltage supply relay -J317- 3)
			Engine control unit -J623-
			ABS control unit -J104-
			Heated windscreen relay -J47-
SB18	Fuse 18 on fuse holder B -SB18-	5 A	Battery monitor control unit -J367-5)	30
			Data bus diagnostic interface -J533- 7)
SB19	Fuse 19 on fuse holder B -SB19-	30 A	Wiper motor control unit -J400-5)	30
SB20	Fuse 20 on fuse holder B -SB20-	10 A	Alarm horn -H12-	30
SB21	Not assigned	-		-
SB22	Fuse 22 on fuse holder B -SB22-	5 A	Engine control unit -J623-	50
SB23	Fuse 23 on fuse holder B -SB23-	30 A	Starter -B-	50
SB24	Fuse 24 on fuse holder B -SB24-	40 A	Auxiliary air heater element -Z35-	87
SB25	Not assigned	-		-
SB26	Not assigned	-		-
SB27	Not assigned	-		-
SB28	Not assigned	-		-
SB29	Not assigned	-		-
SB30	Not assigned	-		-
SB31	Not assigned	-		-
SB32	Not assigned	-		-
SB33	Fuse 33 on fuse holder B -SB33-	15 A	Mechatronic unit for dual clutch gearbox -J743- 7) t  Dual clutch gearbox 0DL	30
SB34	Not assigned	-		-
SB35	Fuse 35 on fuse holder B -SB35-	30 A	Wiper motor control unit -J400-6)	30
SB36	Not assigned	-		-
SB37	Fuse 37 on fuse holder B -SB37-	20 A	Auxiliary heater control unit -J364-	30
SB38	Not assigned	-		-

1) Only models with petrol engine 2) Only models with petrol engine and active cylinder management (ACT) 3) Only models with diesel engine 4) Only models with diesel engine and reducing agent metering system (SCR) 5) Only models with battery at front 6) Only models with battery at rear 7) Depending on equipment Back to overview

Fuse assignment of fuse holder B -SB- , from February 2015

Slot	Current flow diagram designation	Nominal value	Function/component	Terminal
SB1	Fuse 1 on fuse holder B -SB1-	40 A	ABS control unit -J104-	30
SB2	Fuse 2 on fuse holder B -SB2-	40 A	ABS control unit -J104- t  ABS hydraulic pump -V64-	30
SB3	Fuse 3 on fuse holder B -SB3-	15 A1), 10) 30 A3)	Engine control unit -J623-	87
SB4	Fuse 4 on fuse holder B -SB4-	10 A2), 8), 10) 5 A3)	Radiator fan -VX57-	87
			Oil level and oil temperature sender -G266-
			Relay for reducing agent metering system -J963-4)
			High heat output relay -J360-3)
			Low heat output relay -J359-3)
			Charge pressure positioner -V465-1)
			Activated charcoal filter solenoid valve 1 -N80-1)
			Exhaust camshaft control valve 1 -N318-1)
			Camshaft control valve 1 -N205-1)
			Valve for oil pressure control -N428-
			Inlet cam actuator for cylinder 2 -N583-2)
			Exhaust cam actuator for cylinder 2 -N587-2)
			Inlet cam actuator for cylinder 3 -N591-2)
			Exhaust cam actuator for cylinder 3 -N595-2)
			Fuel cooling valve -N289-3)
			Exhaust gas recirculation cooler changeover valve -N345-3)
			Intake manifold flap valve -N316-8)
			Charge pressure control solenoid valve -N75-3)
			Turbocharger air recirculation valve -N249-8)
			Power steering control unit -J500-8)
SB5	Fuse 5 on fuse holder B -SB5-	10 A	Fuel pressure regulating valve -N276-3)	87
			Fuel metering valve -N290-3)
			Camshaft control valve 1 -N205-3)
			Exhaust cam actuator A for cylinder 1 -N580-8)
			Exhaust cam actuator B for cylinder 1 -N581-8)
			Exhaust cam actuator A for cylinder 2 -N588-8)
			Exhaust cam actuator B for cylinder 2 -N589-8)
			Exhaust cam actuator A for cylinder 3 -N596-8)
			Exhaust cam actuator B for cylinder 3 -N597-8)
			Exhaust cam actuator A for cylinder 4 -N604-8)
			Exhaust cam actuator B for cylinder 4 -N605-8)
			Injector, cylinder 1 -N30-8)
			Injector, cylinder 2 -N31-8)
			Injector, cylinder 3 -N32-8)
			Injector, cylinder 4 -N33-8)
			Engine component current supply relay -J757-8)
			Coolant valve for gearbox -N488-10)
			Coolant pump for high-voltage battery -V590-10)
			Coolant pump for high-temperature circuit -V467-10)
SB6	Fuse 6 on fuse holder B -SB6-	5 A	Brake light switch -F-	87
SB7	Fuse 7 on fuse holder B -SB7-	10 A1),3) 15 A4), 10) 7.5 A8)	Fuel metering valve -N290-1)	87
			Circulation pump -V55-1)
			Radiator blind control motor -V544-3)
			Coolant valve for cylinder head -N489-3)
			Valve for oil pressure control -N428-3)
			Exhaust gas recirculation cooler changeover valve -N345-3)
			Charge pressure positioner -V465-4)
			Coolant pump for high-temperature circuit -V467-4)
			Charge air cooling pump -V188-4)
			Coolant valve for gearbox -N488-7), 8)
			Coolant shut-off valve -N82-7), 8)
			Gearbox oil cooling pump -V478-7), 8)
			Fuel pressure regulating valve -N276-10)
			Coolant changeover valve 2 -N633-10)
			Coolant changeover valve 1 -N632-10)
			Coolant pump for low-temperature circuit -V468-10)
SB8	Fuse 8 on fuse holder B -SB8-	10 A1) 15 A3), 8), 10)	Lambda probe 1 before catalytic converter -GX10- t  Lambda probe heater -Z19-	87
			Lambda probe 1 after catalytic converter -GX7- t  Lambda probe 1 heater after catalytic converter -Z29-
			NOx sender -G295-4)
SB9	Fuse 9 on fuse holder B -SB9-	20 A1), 10) 5 A3) 10 A 8)	Ignition coil 1 with output stage -N70-1), 10)	87
			Ignition coil 2 with output stage -N127-1), 10)
			Ignition coil 3 with output stage -N291-1), 10)
			Ignition coil 4 with output stage -N292-1), 10)
			Heater element for crankcase breather -N79-
			Automatic glow period control unit -J179-3)
			Air mass meter -G70-
			Charge air cooling pump -V188-8)
			Activated charcoal filter solenoid valve 1 -N80-8)
			Exhaust camshaft control valve 1 -N318-8)
			Camshaft control valve 1 -N205-8)
SB10	Fuse 10 on fuse holder B -SB10-	20 A7) 15 A7), 10)	Fuel pump control unit -J538-	87
SB11	Fuse 11 on fuse holder B -SB11-	40 A	Auxiliary air heater element -Z35-	87
SB12	Fuse 12 on fuse holder B -SB12-	40 A	Auxiliary air heater element -Z35-	87
SB13	Fuse 13 on fuse holder B -SB13-	30 A	Mechatronic unit for dual clutch gearbox -J743- 7) t  Dual clutch gearbox 0CW	30
		15 A	Mechatronic unit for dual clutch gearbox -J743- 7) t  Dual clutch gearbox 0D9
SB14	Fuse 14 on fuse holder B -SB14-	40 A	Heated windscreen relay -J47-	30
SB15	Fuse 15 on fuse holder B -SB15-	15 A	Horn relay -J413-	30
SB16	Fuse 16 on fuse holder B -SB16-	20 A8) 10A10)	Engine component current supply relay -J757-8)	30
			Power and control electronics for electric drive -JX1-10)
			Charging unit 1 for high-voltage battery -AX4-10)
SB17	Fuse 17 on fuse holder B -SB17-	7.5 A	Main relay -J271- 1)	30
			Terminal 30 voltage supply relay -J317- 3)
			Engine control unit -J623-
			ABS control unit -J104-
			Heated windscreen relay -J47-
SB18	Fuse 18 on fuse holder B -SB18-	5 A	Battery monitor control unit -J367-5)	30
			Data bus diagnostic interface -J533- 7)
SB19	Fuse 19 on fuse holder B -SB19-	30 A	Wiper motor control unit -J400-5)	30
SB20	Fuse 20 on fuse holder B -SB20-	10 A	Alarm horn -H12-	30
SB21	Not assigned	-		-
SB22	Fuse 22 on fuse holder B -SB22-	5 A	Engine control unit -J623-	50
		9) only	Special vehicle fuse
SB23	Fuse 23 on fuse holder B -SB23-	30 A	Starter -B-	50
SB24	Fuse 24 on fuse holder B -SB24-	40 A	Auxiliary air heater element -Z35-3)	87
			Brake servo -NX6-10)
SB25	Not assigned	-		-
SB26	Not assigned	-		-
SB27	Not assigned	-		-
SB28	Not assigned	-		-
SB29	Not assigned	-		-
SB30	Not assigned	-		-
SB31	Not assigned	-		-
SB32	Not assigned	-		-
SB33	Fuse 33 on fuse holder B -SB33-	15 A 30A10)	Mechatronic unit for dual clutch gearbox -J743- 7) t  Dual clutch gearbox 0DL	30
			Brake system pressure accumulator -VX70-10)
SB34	Fuse 34 on fuse holder B -SB34-	5A	Brake servo -NX6-10)	-
SB35	Fuse 35 on fuse holder B -SB35-	30 A 7.5A10)	Wiper motor control unit -J400-6)	30
			Air conditioning system relay -J32-10)
SB36	Not assigned	-		-
SB37	Fuse 37 on fuse holder B -SB37-	20 A	Auxiliary heater control unit -J364-	30
SB38	Not assigned	-		-

1) Only models with petrol engine 2) Only models with petrol engine and active cylinder management (ACT) 3) Only models with diesel engine 4) Only models with diesel engine and reducing agent metering system (SCR) 5) Only models with battery at front 6) Only models with battery at rear 7) Depending on equipment 8) Only models with a 1.8–2.0l petrol engine 9) Fuse rating, see installation description for special installations 10) Only models with hybrid drive system Back to overview

VW PASSAT 2016 Fitting location, fuse holder A SA

Fitting location, fuse holder A -SA-

Fitting location, fuse holder A -SA-

1 -	Fuse holder A -SA-

508 -

Threaded connection (30) on E-box

q	Connection for battery -A-

Multifuse strip fuse → Repair Group  97   Note: The fuse strip (multifuse) must be replaced as a complete unit. Back to overview

Fitting location of fuse holder A -SA- , only models with hybrid drive system

1 -	Fuse holder A -SA-

508 -

Threaded connection (30) on E-box

Multifuse strip fuse → Repair Group  97   Note: The fuse strip (multifuse) must be replaced as a complete unit. Back to overview

VW PASSAT 2016 Fuse assignment on fuse holder A SA

Fuse assignment on fuse holder A -SA-

Fuse assignment of fuse holder A -SA- , from September 2014

Screw location	Current flow diagram designation	Nominal value	Function/component	Terminal
SA1	Fuse 1 on fuse holder A -SA1-	125 A1)	Supply for fuse holder C -SC-1) t  Terminal 30_1 t  Fuse 2 on fuse holder C -SC2- t  Fuse 4 on fuse holder C -SC4- - Fuse 14 on fuse holder C -SC14- t  Fuse 22 on fuse holder C -SC22- t  Fuse 31 on fuse holder C -SC31- t  Fuse 38 on fuse holder C -SC38- - Fuse 39 on fuse holder C -SC39- t  Fuse 41 on fuse holder C -SC41- - Fuse 42 on fuse holder C -SC42- t  Fuse 46 on fuse holder C -SC46- t  Fuse 51 on fuse holder C -SC51- t  Fuse 53 on fuse holder C -SC53- t  Relay for power sockets -J807- t  Terminal 15 voltage supply relay -J329-	30
		80 A2)	Radiator fan -VX57-2)
SA2	Fuse 2 on fuse holder A -SA2-	400 A	Alternator -C-	30
SA3	Fuse 3 on fuse holder A -SA3-	80 A1)	Power steering control unit -J500-1)	30
SA4	Fuse 4 on fuse holder A -SA4-	80 A1)	Supply for fuse holder C -SC-1) t  Terminal 30_2 t  Fuse 1 on fuse holder C -SC1- t  Fuse 3 on fuse holder C -SC3- t  Fuse 15 on fuse holder C -SC15- - Fuse 21 on fuse holder C -SC21- t  Fuse 23 on fuse holder C -SC23- - Fuse 28 on fuse holder C -SC28- t  Fuse 43 on fuse holder C -SC43- - Fuse 45 on fuse holder C -SC45- t  Fuse 50 on fuse holder C -SC50-	30
		80 A2)	Power steering control unit -J500-2)
SA5	Fuse 5 on fuse holder A -SA5-	50 A1)	Radiator fan -VX57-1)	30
		-2)	Supply for fuse 4 on fuse holder A -SA4- t  Power steering control unit -J500-2)

1) Only models with battery at front

2) Only models with battery at rear

Back to overview

Fuse assignment of fuse holder A -SA- , from August 2015, only models with hybrid drive system

Screw location	Current flow diagram designation	Nominal value	Function/component	Terminal
SA1	Fuse 1 on fuse holder A -SA1-	125 A	Supply for fuse holder C -SC- t  Terminal 30_1 t  Fuse 2 on fuse holder C -SC2- t  Fuse 4 on fuse holder C -SC4- - Fuse 14 on fuse holder C -SC14- t  Fuse 22 on fuse holder C -SC22- t  Fuse 31 on fuse holder C -SC31- t  Fuse 38 on fuse holder C -SC38- - Fuse 39 on fuse holder C -SC39- t  Fuse 41 on fuse holder C -SC41- - Fuse 42 on fuse holder C -SC42- t  Fuse 46 on fuse holder C -SC46- t  Fuse 51 on fuse holder C -SC51- t  Fuse 53 on fuse holder C -SC53- t  Relay for power sockets -J807- t  Terminal 15 voltage supply relay -J329-	30
SA2	Fuse 2 on fuse holder A -SA2-	400 A	Alternator -C-	30
			Power and control electronics for electric drive -JX1-
SA3	Fuse 3 on fuse holder A -SA3-	80 A	Power steering control unit -J500-	30
SA4	Fuse 4 on fuse holder A -SA4-	80 A	Supply for fuse holder C -SC- t  Terminal 30_2 t  Fuse 1 on fuse holder C -SC1- t  Fuse 3 on fuse holder C -SC3- t  Fuse 15 on fuse holder C -SC15- - Fuse 21 on fuse holder C -SC21- t  Fuse 23 on fuse holder C -SC23- - Fuse 28 on fuse holder C -SC28- t  Fuse 43 on fuse holder C -SC43- - Fuse 45 on fuse holder C -SC45- t  Fuse 50 on fuse holder C -SC50-	30
SA5	Fuse 5 on fuse holder A -SA5-	80 A	Radiator fan -VX57-	30
SA6	Fuse 6 on fuse holder A -SA6-	50A	Mechatronic unit for dual clutch gearbox -J743- t  Dual clutch gearbox 0DD	30

Back to overview

VW PASSAT 2016 Fitting location of fuse holder in the power and control electronics for electric drive JX1

Fitting location of fuse holder in the power and control electronics for electric drive -JX1-

Fitting location of fuse holder in the power and control electronics for electric drive -JX1- , only models with hybrid drive system

1 -	Power and control electronics for electric drive -JX1-

A -	High-voltage system fuse 3 -S353- in the power and control electronics for electric drive -JX1-

Back to overview

VW PASSAT 2016 Fuse assignment of high-voltage system fuse 3 S353

Fuse assignment of high-voltage system fuse 3 -S353-

Fuse assignment of high-voltage system fuse 3 -S353- , from August 2015, only models with hybrid drive system

Screw location	Current flow diagram designation	Nominal value	Function/component	Terminal
1	High-voltage system fuse 3 -S353-	80 A	Power and control electronics for electric drive -JX1-	30

Back to overview

VW PASSAT 2016 Overview of control units, saloon

Overview of control units, saloon

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment, right-hand drive

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment, models with a petrol engine

q	Fitting locations, models with a diesel engine

q	Connector assignment, models with a diesel engine

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

17 -	Driver seat adjustment control unit -J810-

q	Fitting location left-hand drive

q	Connector assignment, left-hand drive

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

VW PASSAT 2016 Overview of control units, estate

Overview of control units, estate

1 -	Fresh air blower control unit -J126-

q	Fitting location

q	Connector assignment

2 -	Front passenger door control unit -J387-

q	Fitting location

q	Connector assignment

3 -	Chip card reader -D8-

q	Fitting location

4 -	Control unit 1 for information electronics -J794-

q	Fitting location

q	Connector assignment

5 -	Interface for entry and start system -J965-

q	Fitting location

q	Connector assignment

6 -	Climatronic control unit -J255-

q	Fitting location

q	Connector assignment

6 -	Air conditioning system control unit -J301-

q	Fitting location

q	Connector assignment

7 -	Display unit for front information display and operating unit control unit -J685-

q	Fitting location

q	Connector assignment

8 -	Control unit for overhead view camera -J928-

q	Fitting location

q	Connector assignment

8 -	Driver seat adjustment control unit -J810-

q	Fitting location right-hand drive

q	Connector assignment, right-hand drive

9 -	Front camera for driver assist systems -R242-

q	Fitting location

q	Connector assignment

10 -	Main beam assist control unit -J844-

q	Fitting location

q	Connector assignment

11 -	Control unit in dash panel insert -J285-

q	Fitting location

q	Connector assignment

q	Connector assignment

13 -	Fuel pump control unit -J538-

q	Fitting locations, models with a petrol engine

q	Connector assignment, models with a petrol engine

q	Fitting locations, models with a diesel engine

q	Connector assignment, models with a diesel engine

14 -	Sliding sunroof adjustment control unit -J245-

q	Fitting location

q	Connector assignment

15 -	Operating and display unit for rear air conditioning system -E265-

q	Fitting location

q	Connector assignment

16 -	Multifunction steering wheel control unit -J453-

q	Fitting location

q	Connector assignment

17 -	Steering column electronics control unit -J527-

q	Fitting location

q	Connector assignment

18 -	Driver seat adjustment control unit -J810-

q	Fitting location left-hand drive

q	Connector assignment

19 -	Digital sound package control unit -J525-

q	Fitting location

q	Connector assignment

20 -	Driver door control unit -J386-

q	Fitting location

q	Connector assignment

21 -	Onboard supply control unit -J519-

q	Fitting location

q	Connector assignment

22 -	Parking aid control unit -J446-

q	Fitting location

q	Connector assignment

22 -	Park assist steering control unit -J791-

q	Fitting location

q	Connector assignment

23 -	Selector lever -E313-

q	Fitting location

q	Connector assignment

24 -	Data bus diagnostic interface -J533-

q	Fitting location

q	Connector assignment

25 -	Control unit for cornering light and headlight range control -J745-

q	Fitting location

q	Connector assignment

26 -	Airbag control unit -J234-

q	Fitting location

VW PASSAT 2016 Fresh air blower control unit J126 Fresh air blower control unit -J126- Fitting location: on right under dash panel

1 -	Fresh air blower control unit -J126-

A -	4-pin connector -T4bg-

B -	2-pin connector -T2pk-

Connector assignment of fresh air blower control unit -J126-

-T4bg- (A)	Designation		-T2pk- (B)	Designation
1	Terminal 31		1	Fresh air blower -V2-
2			2	Fresh air blower -V2-
3	Terminal 30
4	A209 Connection 1 (LIN bus) in dash panel wiring harness

Back to overview VW PASSAT 2016 Front passenger door control unit J387 Front passenger door control unit -J387- Fitting location: In front passenger door.

1 -	Front passenger door control unit -J387-

A -	32-pin connector -T32h-

B -	16-pin connector -T16g-

C -	20-pin connector -T20g-

D -	6-pin connector -T6at-

Connector assignment of front passenger door control unit -J387-

-T6at- (D)	Designation		-T20g- (C)	Designation		-T16g- (B)	Designation		-T32h- (A)	Designation
1			1			1	Front passenger side entry light in exterior mirror -W53-		1
2			2			2	Front passenger side automatic anti-dazzle exterior mirror -Y21-		2
3	Right window regulator motor -V15-		3			3	Front passenger side turn signal repeater bulb -L132- Heated exterior mirror on front passenger side -Z5-		3
4			4			4	Front passenger side exterior mirror -VX5-		4	Window regulator switch in front passenger door -E107-
5			5	Front passenger door contact switch -F3-		5	Front passenger side mirror adjustment motor 2 -V25-		5	Window regulator switch in front passenger door -E107- Front passenger side door warning lamp -W36-
6	Right window regulator motor -V15-		6	Front passenger door central locking actuator for SAFELOCK function -F244-		6	Front passenger side automatic anti-dazzle exterior mirror -Y21-		6
			7			7	Front passenger side mirror adjustment motor 2 -V25- Front passenger side mirror adjustment motor -V150-		7
			8			8	Front passenger side mirror adjustment motor -V150-		8
			9			9	Front passenger side fold-in mirror motor -V122-		9
			10	Rear right door control unit -J389-		10	Front passenger side fold-in mirror motor -V122-		10
			11	Front passenger door central locking motor -V57- Front passenger door central locking SAFELOCK function motor -V162-		11	Front passenger side turn signal repeater bulb -L132-		11
			12	Central locking SAFE function motor, in front passenger door -V162-		12			12
			13	Front passenger door central locking motor -V57-		13	Front passenger side exterior mirror -VX5-		13
			14	B407 Connection 2 (convenience CAN bus, low), in main wiring harness		14	Front passenger side exterior mirror -VX5-		14
			15	B398 Connection 2 (convenience CAN bus, high), in main wiring harness		15	Heated exterior mirror on front passenger side -Z5-		15
			16			16	Front passenger side exterior mirror -VX5-		16	Front passenger side door warning lamp -W36-
			17						17
			18						18
			19	Terminal 30					19
			20	Terminal 31					20
									21
									22
									23
									24
									25
									26
									27
									28
									29
									30
									31
									32	Window regulator switch in front passenger door -E107-

Back to overview VW PASSAT 2016 Chip card reader D8 Chip card reader -D8- Fitting location: In glove compartment.

1 -	Chip card reader -D8-

A -	2-pin connector -T2-

B -	10-pin connector -T10-

C -	5-pin connector -T5-

Back to overview VW PASSAT 2016 Control unit 1 for information electronics J794 Control unit 1 for information electronics -J794- Fitting location: In glove compartment.

Multiway connector housing J (chambers: 9-18), made up of connectors K, L, M and N.

1 -	Control unit 1 for information electronics -J794-

A -	8-pin connector -T8aa-

B -	12-pin connector -T12n-

C -	12-pin connector -T12o-

D -	12-pin connector -T12p-

E -	8-pin connector -T8v-

F -	2-pin connector -T2ec-

q	Fibre optic cable (FOC)

G -	5-pin connector -T5ad-

q	Display unit for front information display and operating unit control unit -J685-

H -	5-pin connector -T5af-

q	Interface for external multimedia units -R215-

q	Connection for external audio sources -R199-

q	Chip card reader -D8-

I -	4-pin connector -T4da-

q	TV aerial 1 -R55-

q	Radio aerial -R248-

Connector assignment of control unit 1 for information electronics -J794-

-T8v- (E)	Designation		-T8aa- (A)	Designation		-T2ec- (F)	Designation
1	Rear right treble loudspeaker -R16- Rear right bass loudspeaker -R17-		9			1	Dash panel insert -KX2-1 Digital sound package control unit -J525-1)
2	Front right treble loudspeaker -R22- Front right bass loudspeaker -R23-		10			2	TV tuner -RX6-1 Digital sound package control unit -J525-1)
3	Front left treble loudspeaker -R20- Front left bass loudspeaker -R21-		11
4	Rear left treble loudspeaker -R14- Rear left bass loudspeaker -R15-		12
5	Rear right treble loudspeaker -R16- Rear right bass loudspeaker -R17-		13
6	Front right treble loudspeaker -R22- Front right bass loudspeaker -R23-		14
7	Front left treble loudspeaker -R20- Front left bass loudspeaker -R21-		17(1)	Terminal 31
8	Rear left treble loudspeaker -R14- Rear left bass loudspeaker -R15-		18(2)	Terminal 30

1) Depending on equipment

-T12p- (D)	Designation		-T12o- (C)	Designation		-T12n- (B)	Designation
1	H21 Connection 2, in diagnosis wiring harness		1	Connection for external audio sources -R199-1)		1	Telephone microphone -R38-
2	Display unit for front information display and operating unit control unit -J685-1) Dash panel insert -KX2-1)		2	Connection for external audio sources -R199-1)		2
3	TV tuner -RX6-1 B159 Connection (diagnosis) in interior wiring harness1)		3	Connection for external audio sources -R199-1) USB hub -R293-1)		3
4			4	Connection for external audio sources -R199-1)		4
5	Two-way signal amplifier for mobile telephone/data services -J984- Storage compartment with interface for mobile telephone -R265-		5			5
6	A178 Connection (infotainment CAN bus, high), in dash panel wiring harness		6			6	Reversing camera -R189-
7	B444 Connection 1 (diagnosis), in main wiring harness		7	Connection for external audio sources -R199-1)		7	Reversing camera -R189-
8	Display unit for front information display and operating unit control unit -J685-		8			8
9			9			9
10			10			10
11	Storage compartment with interface for mobile telephone -R265-		11			11
12	A179 Connection (infotainment CAN bus, low), in dash panel wiring harness		12			12	Rear overhead view camera -R246-

1) Depending on equipment

Back to overview VW PASSAT 2016 Interface for entry and start system J965 Interface for entry and start system -J965- Fitting location: under dash panel on left.

1 -	Interface for entry and start system -J965-

A -	40-pin connector -T40a-

Connector assignment of interface for entry and start system -J965-

-T40a- (A)	Designation		-T40a- (A)	Designation
1			21	Passenger side aerial for entry and start system -R135-
2	Rear lid power opening control unit -J938-		22	Driver side aerial for entry and start system -R134-
3	Contact sensor for rear right exterior door handle -G418-		23	Luggage compartment aerial for entry and start system -R137-
4	Rear left aerial for entry and start authorisation -R165-		24	Driver side aerial for entry and start system -R134-
5	B407 Connection 2 (convenience CAN bus, low), in main wiring harness		25	Rear left aerial for entry and start authorisation -R165-
6	B398 Connection 2 (convenience CAN bus, high), in main wiring harness		26	Onboard supply control unit -J519-
7	Starter button -E378-		27	Onboard supply control unit -J519-
8	Starter button -E378-		28	Rear right aerial for entry and start authorisation -R166-
9			29	Rear right aerial for entry and start authorisation -R166-
10			30	Terminal 30
11	Driver door exterior handle contact sensor -G415-		31	Rear bumper aerial for entry and start system -R136-
12	Front passenger door exterior handle contact sensor -G416-		32	Passenger side aerial for entry and start system -R135-
13	Contact sensor for rear left door exterior handle -G417-		33	Luggage compartment aerial for entry and start system -R137-
14			34	Rear bumper aerial for entry and start system -R136-
15	Engine control unit -J623-		35	Onboard supply control unit -J519-
16	Rear lid power opening control unit -J938-		36	Interior aerial 1 for entry and start system -R138-
17	Terminal 31		37	Interior aerial 2 for entry and start system -R139-
18			38	Interior aerial 1 for entry and start system -R138-
19	Starter button -E378-		39	Interior aerial 2 for entry and start system -R139-
20			40	Onboard supply control unit -J519-

Back to overview VW PASSAT 2016 Climatronic control unit J255 Climatronic control unit -J255- Fitting location: In centre of dash panel.

1 -	Climatronic control unit -J255-

A -	16-pin connector -T16r-

B -	16-pin connector -T16q-

C -	20-pin connector -T20b-

Connector assignment of Climatronic control unit -J255-

-T16r- (A)	Designation		-T16q- (B)	Designation		-T20b- (C)	Designation
1	Left temperature flap control motor -V158-		1	Potentiometer for defroster flap control motor -G135- Potentiometer for left temperature flap control motor -G220- Potentiometer for right temperature flap control motor -G221- Potentiometer for rear temperature flap control motor -G479- Potentiometer for front air distribution flap control motor -G642- Potentiometer for fresh air/recirculated air, air flow flap control motor -G644-		1	Sunlight penetration photosensor -G107-
2	Left temperature flap control motor -V158-		2	Potentiometer for left temperature flap control motor -G220-		2
3	Defroster flap control motor -V107-		3	Potentiometer for right temperature flap control motor -G221-		3	Sunlight penetration photosensor -G107-
4	Defroster flap control motor -V107-		4	Potentiometer for defroster flap control motor -G135-		4
5	Front air distribution flap control motor -V426-		5	Potentiometer for front air distribution flap control motor -G642-		5	B506 Connection (convenience CAN bus, high), in interior wiring harness
6	Front air distribution flap control motor -V426-		6			6	B507 Connection (convenience CAN bus, low), in interior wiring harness
7			7	Potentiometer for fresh air/recirculated air, air flow flap control motor -G644-		7
8			8	Footwell vent temperature sender -G192-		8
9	Fresh air/recirculated air, air flow flap control motor -V425-		9			9	Sunlight penetration photosensor -G107-
10	Fresh air/recirculated air, air flow flap control motor -V425-		10			10
11	Right temperature flap control motor -V159-		11	Evaporator temperature sensor -G308-		11	Rear vent temperature sender -G174-
12	Right temperature flap control motor -V159-		12	Potentiometer for rear temperature flap control motor -G479-		12
13			13			13	Front left chest vent temperature sensor -G385-
14			14	Potentiometer for defroster flap control motor -G135- Footwell vent temperature sender -G192- Potentiometer for left temperature flap control motor -G220- Potentiometer for right temperature flap control motor -G221- Evaporator temperature sensor -G308- Potentiometer for rear temperature flap control motor -G479- Potentiometer for front air distribution flap control motor -G642- Potentiometer for fresh air/recirculated air, air flow flap control motor -G644-		14	Front right chest vent temperature sensor -G386-
15	Rear temperature flap control motor -V137-		15			15
16	Rear temperature flap control motor -V137-		16			16	A209 Connection 1 (LIN bus) in dash panel wiring harness
						17	Sunlight penetration photosensor -G107- Rear vent temperature sender -G174- Front left chest vent temperature sensor -G385- Front right chest vent temperature sensor -G386-
						18	Air conditioner compressor regulating valve -N280-
						19	Terminal 31
						20	Terminal 30

Back to overview VW PASSAT 2016 Air conditioning system control unit J301 Air conditioning system control unit -J301- Fitting location: In centre of dash panel.

1 -	Air conditioning system control unit -J301-

A -	16-pin connector -T16q-

B -	20-pin connector -T20b-

Connector assignment of air conditioning system control unit -J301-

-T16q- (A)	Designation		-T20b- (B)	Designation
1	Potentiometer for temperature flap control motor -G92- Potentiometer for air distribution flap control motor -G645-		1
2	Potentiometer for temperature flap control motor -G92-		2
3	Potentiometer for air distribution flap control motor -G645-		3
4			4
5	Temperature flap control motor -V68-		5	B506 Connection (convenience CAN bus, high), in interior wiring harness
6	Temperature flap control motor -V68-		6	B507 Connection (convenience CAN bus, low), in interior wiring harness
7	Air distribution flap control motor -V428-		7
8	Air distribution flap control motor -V428-		8
9	Air recirculation flap control motor -V113-		9
10	Air recirculation flap control motor -V113-		10
11	Evaporator temperature sensor -G308-		11
12			12
13			13
14	Potentiometer for temperature flap control motor -G92- Evaporator temperature sensor -G308- Potentiometer for air distribution flap control motor -G645-		14
15			15
16			16	A209 Connection 1 (LIN bus) in dash panel wiring harness
			17
			18	Air conditioner compressor regulating valve -N280-
			19	Terminal 31
			20	A164 Positive connection 2 (30a) in dash panel wiring harness

Back to overview VW PASSAT 2016 Display unit for front information display and operating unit control unit J685 Display unit for front information display and operating unit control unit -J685- Fitting location: Equipment " Composition Touch, Composition Colour (Entry) " : in the centre console.

Multiway connector housing B (chambers: 9-18), made up of connectors C, D, E and F.

1 -	Display unit for front information display and operating unit control unit -J685-

A -	4-pin connector -T4da-

q	Radio aerial -R248-

q	Radio aerial 2 -R93-

B -	8-pin connector -T8aa-

C -	12-pin connector -T12n-

D -	12-pin connector -T12o-

E -	8-pin connector -T8v-

F -	12-pin connector -T12p-

Connector assignment of display unit for front information display and operating unit control unit -J685-

-T8v- (E)	Designation		-T8aa- (B)	Designation
1	Rear right treble loudspeaker -R16- Rear right bass loudspeaker -R17-		9
2	Front right treble loudspeaker -R22- Front right bass loudspeaker -R23-		10
3	Front left treble loudspeaker -R20- Front left bass loudspeaker -R21-		11
4	Rear left treble loudspeaker -R14- Rear left bass loudspeaker -R15-		12
5	Rear right treble loudspeaker -R16- Rear right bass loudspeaker -R17-		13
6	Front right treble loudspeaker -R22- Front right bass loudspeaker -R23-		14
7	Front left treble loudspeaker -R20- Front left bass loudspeaker -R21-		17(1)	Terminal 31
8	Rear left treble loudspeaker -R14- Rear left bass loudspeaker -R15-		18(2)	Terminal 30

-T12p- (F)	Designation		-T12n- (C)	Designation		-T12o- (D)	Designation
1			1			1
2			2			2
3			3			3
4			4			4
5			5			5
6	A178 Connection (infotainment CAN bus, high), in dash panel wiring harness		6			6
7			7			7
8			8			8
9			9			9
10			10			10
11			11			11
12	A179 Connection (infotainment CAN bus, low), in dash panel wiring harness		12			12

Back to overview Display unit for front information display and operating unit control unit -J685- Fitting location: Equipment " Composition Media, Discover Media/Discover Pro (Standard/High) “ : in centre console.

1 -	Display unit for front information display and operating unit control unit -J685-

A -	12-pin connector -T12l-

B -	5-pin connector -T5ac-

Connector assignment of display unit for front information display and operating unit control unit -J685-

-T12l- (A)	Designation
1	Terminal 30
2
3	H21 Connection 2, in diagnosis wiring harness
4
5	Control unit 1 for information electronics -J794-
6
7	Terminal 31
8
9	B444 Connection 1 (diagnosis), in main wiring harness
10
11	Control unit 1 for information electronics -J794-
12

Back to overview VW PASSAT 2016 Control unit for overhead view camera J928 Control unit for overhead view camera -J928- Fitting location: under front passenger seat

1 -	Control unit for overhead view camera -J928-

A -	5-pin connector -T5ay-

q	Rear overhead view camera -R246-

B -	5-pin connector -T5aw-

q	Front overhead view camera -R243-

C -	5-pin connector -T5av-

q	Right overhead view camera -R245-

D -	5-pin connector -T5au-

q	Left overhead view camera -R244-

E -	2-pin connector -T2et-

q	Rear overhead view camera -R246-

F -	18-pin connector -T18c-

Connector assignment of overhead view control unit -J928-

-T18a- (F)	Designation		-T18a- (F)	Designation
1	A32 Positive connection (30), in dash panel wiring harness		10	B664 Connection (running gear sensors CAN bus, low), in main wiring harness
2	B663 Connection (running gear sensors CAN bus, high), in main wiring harness		11	Parking aid warning lamp -K136-
3	Parking aid button -E266-		12	Terminal 31
4	Rear lid handle release button -E234-		13
5			14
6			15
7			16
8			17
9			18

Back to overview VW PASSAT 2016 Driver seat adjustment control unit -J810- , right-hand drive models Fitting location: Under seat.

1 -	Driver seat adjustment control unit -J810-

A -	12-pin connector -T12x-

B -	10-pin connector -T10-

C -	32-pin connector -T32k-

D -	16-pin connector -T16m-

Connector assignment of driver seat adjustment control unit -J810-

-T12x- (A)	Designation		-T16m- (D)	Designation		-T32k- (C)	Designation
1	Driver seat backrest adjustment motor -V45-		1			1
2			2			2
3	Driver seat height adjustment motor -V245-		3			3
4			4	Driver seat lumbar support longitudinal adjustment motor -V125-		4
5	Driver seat longitudinal adjustment motor -V28-		5			5
6	Driver seat backrest adjustment motor -V45-		6	Lumbar support height adjustment sender -G374-		6	Lumbar support longitudinal adjustment button -E336-
7	Driver seat rake adjustment motor -V243-		7			7	Lumbar support height adjustment button -E335-
8	Driver seat height adjustment motor -V245-		8			8
9	Driver seat longitudinal adjustment motor -V28-		9			9
10	Driver seat rake adjustment motor -V243-		10			10	140 Earth connection 2, in seat adjustment wiring harness
11	Terminal 30a		11	Lumbar support longitudinal adjustment sender -G375-		11	Driver operating unit for memory settings -E464-
12	Terminal 31		12	M9 Connection in adjustable seat wiring harness		12	Seat memory position button 1 -E218- Seat memory position button 2 -E219-
			13	Lumbar support longitudinal adjustment sender -G375-		13
			14			14
			15	Driver seat lumbar support height adjustment motor -V129-		15	B407 Connection 2 (convenience CAN bus, low), in main wiring harness
			16	Driver seat lumbar support height adjustment motor -V129-		16	B398 Connection 2 (convenience CAN bus, high), in main wiring harness
						17
						18
						19
						20
						21
						22	Backrest adjustment button -E425-
						23	Seat height adjustment button -E424-
						24
						25	Seat longitudinal adjustment button -E418-
						26
						27
						28	Seat memory position button 3 -E220-
						29
						30
						31
						32

Back to overview VW PASSAT 2016 Front camera for driver assist systems R242 Front camera for driver assist systems -R242- Fitting location: Near interior mirror.

1 -	Front camera for driver assist systems -R242-

A -	12-pin connector -T12v-

Connector assignment of front camera for driver assist systems -R242-

-T12v- (A)	Designation
1	Adaptive cruise control unit -J428-
2	B109 Connection 1 (CAN bus extended low), in main wiring harness
3
4	Windscreen heater for front sensors -Z113-
5	Terminal 31
6	Terminal 15
7	Adaptive cruise control unit -J428-
8	B108 Connection 1 (CAN bus extended high), in main wiring harness
9
10	Windscreen heater for front sensors -Z113-
11
12

Back to overview VW PASSAT 2016 Main beam assist control unit J844 Main beam assist control unit -J844- Fitting location: On interior mirror.

1 -	Main beam assist control unit -J844-

A -	8-pin connector -T8ad-

Connector assignment of main beam assist control unit -J844-

-T8ad- (A)	Designation
1	A38 Positive connection 2 (15a) in dash panel wiring harness
2	Terminal 31
3	B108 Connection 1 (CAN bus extended, high) in main wiring harness 1) W71 Connection (reversing light) in rear wiring harness
4	A187 Connection 1 (automatic anti-dazzle exterior mirror) in dash panel wiring harness
5	A188 Connection 2 (automatic anti-dazzle exterior mirror) in dash panel wiring harness
6	Front interior light -WX1-
7
8	B109 Connection 1 (CAN bus extended low), in main wiring harness

1) Only models with main beam assist

Back to overview VW PASSAT 2016 Control unit in dash panel insert J285 Control unit in dash panel insert -J285- Fitting location: In dash panel.

1 -	Control unit in dash panel insert -J285-

A -	2-pin connector -T2dx-

q	Fibre optic cable (FOC)

B -	18-pin connector -T18b-

Connector assignment of control unit in dash panel insert -J285-

-T18b- (A)	Designation		-T18b- (A)	Designation
1	Terminal 30		10	Terminal 31
2			11	Fuel gauge sender -G-
3			12	Fuel gauge sender for auxiliary fuel tank -G292-
4			13	Fuel gauge sender for auxiliary fuel tank -G292-
5			14	Fuel gauge sender -G-
6			15	Fuel gauge sender -G-
7			16	B159 Connection (diagnosis), in interior wiring harness
8	Immobiliser reader coil -D2-		17	B507 Connection (convenience CAN bus, low), in interior wiring harness
9	Immobiliser reader coil -D2-		18	B506 Connection (convenience CAN bus, high), in interior wiring harness

Back to overview VW PASSAT 2016 Fuel pump control unit J538 Fuel pump control unit -J538- Fuel pump control unit -J538- , for models with petrol engine Fitting location: Under rear bench seat.

1 -	Fuel pump control unit -J538-

A -	5-pin connector -T5aj-

Connector assignment of fuel pump control unit -J538-

-T5aj- (A)	Designation
1	Fuel system pressurisation pump -G6-
2	Fuel system pressurisation pump -G6-
3	Terminal 87
4	Terminal 31
5	Engine control unit -J623-

Back to overview Fuel pump control unit -J538- , for models with diesel engine Fitting location: Under rear bench seat.

1 -	Fuel pump control unit -J538-

A -	6-pin connector -T6u-

Connector assignment of fuel pump control unit -J538-

-T6u- (A)	Designation
1	Fuel system pressurisation pump -G6-
2	Fuel system pressurisation pump -G6-
3	Fuel system pressurisation pump -G6-
4	Terminal 31
5	Terminal 87
6	Engine control unit -J623-

Back to overview VW PASSAT 2016 VW PASSAT 2016 Operating and display unit for rear air conditioning system E265 Operating and display unit for rear air conditioning system -E265- Fitting location: in rear centre console.

1 -	Operating and display unit for rear air conditioning system -E265-

A -	6-pin connector -T6r-

B -	4-pin connector -T4bo-

Connector assignment of operating and display unit for rear air conditioning system -E265-

-T4bo- (A)	Designation		-T6r- (A)	Designation
1			1	A209 Connection 1 (LIN bus) in dash panel wiring harness
2	Heated bench seat cushion for rear left seat -Z10-1) Heated backrest for rear left seat -Z11-1)		2	Terminal 30
3			3	Terminal 31
4	Heated bench seat cushion for rear right seat -Z12-1) Heated backrest for rear right seat -Z13-1)		4	Heated bench seat cushion for rear left seat -Z10-1)
			5	Heated bench seat cushion for rear right seat -Z12-1)
			6	O12 Connection 1 in seat heater wiring harness 1)

1) Only models with rear seat heating.

Back to overview VW PASSAT 2016 Sliding sunroof adjustment control unit J245 Sliding sunroof adjustment control unit -J245- Sliding sunroof adjustment control unit -J245- , saloon Fitting location: On sliding sunroof.

1 -	Sliding sunroof adjustment control unit -J245-

A -	5-pin connector -T5cr-

B -	4-pin connector -T4iy-

C -	16-pin connector -T16s-

Connector assignment of sliding sunroof adjustment control unit -J245-

-T5cr- (A)	Designation		-T4iy- (B)	Designation		-T16s- (C)	Designation
1	Terminal 31		1			1	Sliding sunroof motor -V1-
2			2			2	Sliding sunroof motor -V1-
3	B398 Connection 2 (convenience CAN bus, high), in main wiring harness		3	Sliding sunroof motor -V1-		3	Sliding sunroof motor -V1-
4	B407 Connection 2 (convenience CAN bus, low), in main wiring harness		4	Sliding sunroof motor -V1-		4	Sunroof button -E325-
5	Terminal 30					5
						6	347 Earth connection in roof wiring harness
						7
						8
						9
						10
						11	Sliding sunroof motor -V1-
						12	Sunroof button -E325-
						13
						14
						15	347 Earth connection in roof wiring harness
						16	Sunroof button -E325-

Back to overview Sliding sunroof adjustment control unit -J245- / sunroof roller blind motor -V260- , estate Fitting location: On sliding sunroof.

1 -	Sliding sunroof adjustment control unit -J245-

2 -	Sunroof roller blind motor -V260-

A -	5-pin connector -T5cr-

B -	4-pin connector -T4iy-

C -	16-pin connector -T16s-

D -	6-pin connector -T6cj-

Connector assignment of sliding sunroof adjustment control unit -J245-

-T5cr- (A)	Designation		-T4iy- (B)	Designation		-T16s- (C)	Designation
1	Terminal 31		1	Sunroof roller blind motor -V260-		1	Sliding sunroof motor -V1-
2			2	Sunroof roller blind motor -V260-		2	Sliding sunroof motor -V1-
3	B398 Connection 2 (convenience CAN bus, high), in main wiring harness		3	Sliding sunroof motor -V1-		3	B264 Connection 1, in roof wiring harness
4	B407 Connection 2 (convenience CAN bus, low), in main wiring harness		4	Sliding sunroof motor -V1-		4	Sunroof button -E325-
5	Terminal 30					5	Button 1 for roof roller blind -E584-
						6	431 Earth connection 2 in roof wiring harness
						7
						8
						9	Sunroof roller blind motor -V260-
						10	Sunroof roller blind motor -V260-
						11	Sunroof roller blind motor -V260-
						12	Sunroof button -E325-
						13
						14
						16	B265 Connection 2, in roof wiring harness

Back to overview VW PASSAT 2016 Multifunction steering wheel control unit J453 Multifunction steering wheel control unit -J453- Fitting location: Inside the operating unit of the multifunction buttons on left of steering wheel -E440- .

1 -	Multifunction steering wheel control unit -J453-

A -	5-pin connector -T5-

B -	12-pin connector -T12ac-

Connector assignment of multifunction steering wheel control unit -J453-

-T5- (A)	Designation		-T12ac- (B)	Designation
1	Terminal 31		1
2	Terminal 30		2
3	LIN bus		3	Driver side airbag igniter -N95-
4			4	Driver side airbag igniter -N95-
5			5
			6
			7	Terminal 31
			8	Horn plate -H-
			9
			10
			11
			12

Back to overview VW PASSAT 2016 Steering column electronics control unit J527 Steering column electronics control unit -J527- Fitting location: On A-pillar.

1 -	Steering column electronics control unit -J527-

A -	16-pin connector -T16e- , for models with no steering wheel heating

A -	14-pin connector -T14q- , for models with steering wheel heating

B -	4-pin connector -T4bi-

Connector assignment of steering column electronics control unit -J527- , for models with no steering wheel heating

-T16e- (A)	Designation		-T16e- (A)	Designation		-T4bi- (B)	Designation
1	Terminal 30		9			1	Airbag control unit -J234-
2	Terminal 31		10			2	Airbag control unit -J234-
3	B507 Connection (convenience CAN bus, low), in interior wiring harness		11	Selector lever -E313-		3
4	B506 Connection (convenience CAN bus, high), in interior wiring harness		12			4
5	Engine control unit -J623-		13
6			14
7			15
8	B549 Connection 2 (LIN bus) in main wiring harness		16

Connector assignment of steering column electronics control unit -J527- , for models with steering wheel heating

-T14q- (A)	Designation		-T14q- (B)	Designation		-T4bi- (B)	Designation
1	Terminal 30 for steering wheel heating		8	Terminal 31 for steering wheel heating		1	Driver side airbag igniter -N95-
2	Terminal 30		9	Selector lever -E313-		2	Driver side airbag igniter -N95-
3			10			3
4	Terminal 31		11			4
5	B507 Connection (convenience CAN bus, low), in interior wiring harness		12
6	B506 Connection (convenience CAN bus, high), in interior wiring harness		13
7	Engine control unit -J623-		14	B549 Connection 2 (LIN bus) in main wiring harness

Back to overview VW PASSAT 2016 Driver seat adjustment control unit -J810- , left-hand drive models Fitting location: Under seat.

1 -	Driver seat adjustment control unit -J810-

A -	12-pin connector -T12x-

B -	10-pin connector -T10-

C -	32-pin connector -T32k-

D -	16-pin connector -T16m-

Connector assignment of driver seat adjustment control unit -J810-

-T12x- (A)	Designation		-T16m- (D)	Designation		-T32k- (C)	Designation
1	Driver seat backrest adjustment motor -V45-		1			1
2			2			2
3	Driver seat height adjustment motor -V245-		3			3
4			4	Driver seat lumbar support longitudinal adjustment motor -V125-		4
5	Driver seat longitudinal adjustment motor -V28-		5			5
6	Driver seat backrest adjustment motor -V45-		6	Lumbar support height adjustment sender -G374-		6	Lumbar support longitudinal adjustment button -E336-
7	Driver seat rake adjustment motor -V243-		7			7	Lumbar support height adjustment button -E335-
8	Driver seat height adjustment motor -V245-		8			8
9	Driver seat longitudinal adjustment motor -V28-		9			9
10	Driver seat rake adjustment motor -V243-		10			10	140 Earth connection 2, in seat adjustment wiring harness
11	Terminal 30a		11	Lumbar support longitudinal adjustment sender -G375-		11	Driver operating unit for memory settings -E464-
12	Terminal 31		12	M9 Connection in adjustable seat wiring harness		12	Seat memory position button 1 -E218- Seat memory position button 2 -E219-
			13	Lumbar support longitudinal adjustment sender -G375-		13
			14			14
			15	Driver seat lumbar support height adjustment motor -V129-		15	B407 Connection 2 (convenience CAN bus, low), in main wiring harness
			16	Driver seat lumbar support height adjustment motor -V129-		16	B398 Connection 2 (convenience CAN bus, high), in main wiring harness
						17
						18
						19
						20
						21
						22	Backrest adjustment button -E425-
						23	Seat height adjustment button -E424-
						24
						25	Seat longitudinal adjustment button -E418-
						26
						27
						28	Seat memory position button 3 -E220-
						29
						30
						31
						32

Back to overview VW PASSAT 2016 Digital sound package control unit J525 Digital sound package control unit -J525- Fitting location: Under driver seat.

1 -	Digital sound package control unit -J525-

A -	38-pin connector -T38a-

B -	2-pin connector -T2ew-

q	Fibre optic cable (FOC)

Connector assignment of digital sound package control unit -J525-

-T38a- (A)	Designation		-T38a- (A)	Designation
1	Terminal 30		20	Rear left bass loudspeaker -R15-
2	Terminal 31		21	Rear right bass loudspeaker -R17-
3			22	Rear right bass loudspeaker -R17-
4	Subwoofer -R211-		23
5	Subwoofer -R211-		24	Front left treble loudspeaker -R20-
6	Centre loudspeaker -R208-		25	Rear left treble loudspeaker -R14-
7	Front left bass loudspeaker -R21-		26	Rear right treble loudspeaker -R16-
8	Front left bass loudspeaker -R21-		27
9	Front right bass loudspeaker -R23-		28
10	Front right bass loudspeaker -R23-		29
11	Front left mid-range loudspeaker -R103-		30
12	Front left mid-range loudspeaker -R103-		31
13	Front right mid-range loudspeaker -R104-		32	Front left treble loudspeaker -R20-
14	Front right mid-range loudspeaker -R104-		33	Rear left treble loudspeaker -R14-
15			34	Rear right treble loudspeaker -R16-
16	Subwoofer -R211-		35
17	Subwoofer -R211-		36
18	Centre loudspeaker -R208-		37
19	Rear left bass loudspeaker -R15-		38	Control unit 1 for information electronics -J794-

Back to overview VW PASSAT 2016 Driver door control unit J386 Driver door control unit -J386- Fitting location: In driver door.

1 -	Driver door control unit -J386-

A -	32-pin connector -T32g-

B -	16-pin connector -T16a-

C -	20-pin connector -T20f-

D -	6-pin connector -T6as-

Connector assignment of driver door control unit -J386-

-T32g- (A)	Designation		-T16a- (B)	Designation		-T20f- (C)	Designation		-T6as- (D)	Designation
1	Central locking SAFE function warning lamp -K133-		1	Driver side entry light in exterior mirror -W52-		1	Driver side contact switch in lock cylinder -F241-		1
2			2	Driver side automatic anti-dazzle exterior mirror -Y20-		2			2
3			3	Driver side turn signal repeater bulb in exterior mirror -L131- Heated exterior mirror on driver side -Z4-		3			3	Left window regulator motor -V14-
4	R81 Connection 1 (58d), in driver side door wiring harness		4	Driver side exterior mirror -VX4-		4			4
5	Terminal 31		5	Driver side mirror adjustment motor 2 -V17- Driver side mirror adjustment motor -V149-		5	Driver door contact switch -F2-		5
6			6	Driver side automatic anti-dazzle exterior mirror -Y20-		6	Driver door central locking actuator for SAFELOCK function -F243-		6	Left window regulator motor -V14-
7			7	Driver side mirror adjustment motor 2 -V17-		7
8			8	Driver side mirror adjustment motor -V149-		8	A187 Connection 1 (automatic anti-dazzle exterior mirror) in dash panel wiring harness
9			9	Driver side fold-in mirror motor -V121-		9
10			10	Driver side fold-in mirror motor -V121-		10	Rear left door control unit -J388-
11			11	Driver side turn signal repeater bulb in exterior mirror -L131-		11	Driver door central locking motor -V56- Driver door central locking SAFELOCK function motor -V161-
12	Operating unit for window regulator in driver door -E512-		12			12	Driver door central locking SAFELOCK function motor -V161-
13	Driver side interior locking button for central locking system -E308-		13	Driver side exterior mirror -VX4-		13	Driver door central locking motor -V56-
14			14	Driver side exterior mirror -VX4-		14	B507 Connection (convenience CAN bus, low), in interior wiring harness
15			15	Heated exterior mirror on driver side -Z4-		15	B506 Connection (convenience CAN bus, high), in interior wiring harness
16	Driver side door warning lamp -W30-		16	Driver side exterior mirror -VX4-		16
17						17	A188 Connection 2 (automatic anti-dazzle exterior mirror) in dash panel wiring harness
18						18
19						19	Terminal 30
20						20	Terminal 31
21
22
23	Rear lid remote release button -E233-
24	Exterior mirror adjuster -EX11-
25	Exterior mirror adjuster -EX11-
26
27	Operating unit for window regulator in driver door -E512-
28	Driver side interior locking button for central locking system -E308-
29	Operating unit for window regulator in driver door -E512-
30	Operating unit for window regulator in driver door -E512-
31	Operating unit for window regulator in driver door -E512-
32	Operating unit for window regulator in driver door -E512-

Back to overview VW PASSAT 2016 Onboard supply control unit J519 Onboard supply control unit -J519- Fitting location: Behind dash panel, left

1 -	Onboard supply control unit -J519-

A -	73-pin connector -T73b-

B -	46-pin connector -T46b-

C -	73-pin connector -T73c-

Connector assignment of onboard supply control unit -J519-

-T73b- (A)	Designation		-T46b- (B)	Designation		-T73c- (C)	Designation
1	Terminal 30		1	Right headlight dipped beam bulb -M31-		1	Terminal 30 left light supply
2	Heated seat cushion for driver seat -Z6-		2	Right headlight main beam bulb -M32-		2
3	Fuel tank filler flap central locking actuator -F219-		3			3	Left tail light bulb -M4-
4	Fuel tank filler flap central locking actuator -F219-		4	Left daytime running light bulb -L174-		4	Terminal 15
5	Heated seat cushion for front passenger seat -Z8-		5	Right fog light bulb -L23-		5	Left headlight dipped beam bulb -M29-
6	Rear right door central locking motor, lock -V215-		6			6
7	Rear right door central locking motor, lock -V215-		7	Washer pump -V5-		7
8			8	Washer pump -V5-		8	Right brake light bulb -M10-
9	Rear lid central locking motor -V53-		9	Left washer jet heater element -Z20- Right washer jet heater element -Z21-		9	Right tail light bulb -M2-
10			10	Front left headlight -MX1-		10	Left brake and tail light bulb -M21-
11			11	Reversing light switch -F4-		11
12	Term. 31		12	Front right brake pad wear sender -G35-		12	Glove compartment light switch -E26- Luggage compartment light -W3- Front interior light -WX1-
13	Terminal 15 voltage supply relay -J329-		13	Brake fluid level warning contact -F34-		13
14	A192 Positive connection 3 (15a) in dash panel wiring harness		14	Bonnet contact switch -F387-		14	Interface for entry and start system -J965-
15	Anti-theft alarm sensor -G578-		15			15
16	B506 Connection (convenience CAN bus, high), in interior wiring harness		16	Coolant shortage indicator sender -G32-		16
17	B507 Connection (convenience CAN bus, low), in interior wiring harness		17			17
18			18			18
19			19	Ambient temperature sensor -G17- , - coolant shortage indicator sender -G32- , - windscreen washer fluid level sender -G33- , -		19
20			20	Front right turn signal bulb -M7-		20
21			21	Front right headlight -MX2-		21	Driving mode selection button -E735-
22	Rear lid release switch -E165-		22	Front right headlight -MX2-		22
23			23	Front left headlight -MX1-		23
24			24	Horn relay -J413-		24	Heated rear window relay -J9-
25			25			25
26			26	Heated windscreen relay -J47-		26
27			27	Ambient temperature sensor -G17-		27
28			28	Windscreen washer fluid level sender -G33-		28	Rotary light switch -EX1-
29	Rotary light switch -EX1-		29			29	Interior mirror -EX5- Front interior light -WX1- Rear interior light -WX2-
30			30	Wiper motor control unit -J400-		30
31			31	Alarm horn -H12-		31	Rear right turn signal bulb -M8-
32	Rear lid release switch -E165-		32	Right daytime running light bulb -L175-		32	Warning lamp for deactivation of interior monitoring and vehicle inclination -K248-
33	Rear right door central locking actuator for SAFELOCK function -F246-		33			33
34			34			34	Driving mode selection button -E735-
35	Rear left door central locking actuator for SAFELOCK function -F245-		35			35
36	Rear left door central locking motor, lock -V214- , safe +		36	Front left turn signal bulb -M5-		36
37	Rear right door central locking motor, lock -V215- , safe +		37			37
38			38			38
39			39	Left headlight main beam bulb -M30-		39
40			40			40	Front right seat temperature sender -G345-
41			41			41
42	B698 Connection 3 (LIN bus) in main wiring harness		42			42	Hazard warning light switch -EX3-
43			43			43	Front left seat temperature sender -G344-
44	Interface for entry and start system -J965-		44			44
45			45	Left fog light bulb -L22-		45
46	Light switch -E1- , zero position		46	Headlight washer system pump -V11-		46
47	Interface for entry and start system -J965-					47
48	Rear right door contact switch -F11-					48	Indicator lamp for hazard warning light -K6-
49						49
50	Rear left door contact switch -F10-					50
51	Button for deactivating interior monitoring and vehicle inclination sensor -E616-					51	Start/Stop operation button -E693-
52	Rear lid lock unit -F256-					52
53	Terminal 31					53
54	Interface for entry and start system -J965-					54
55						55
56						56	Front left seat temperature sender -G344-
57	High-level brake light bulb -M25-					57
58						58	B160 Connection (brake system monitor), in interior wiring harness
59	Left number plate light -X4- Right number plate light -X5-					59
60	Rear left turn signal bulb -M6-					60	Start/Stop operation button -E693-
61	Rear window wiper motor -V12-					61
62	Rear window wiper motor -V12-					62	A19 Connection (58d), in dash panel wiring harness
63	Terminal 31					63	Terminal 31
64	W71 Connection (reversing light) in rear wiring harness					64
65	Right brake and tail light bulb -M22-					65
66	Terminal 30, right light supply					66
67						67	Front interior light -WX1-
68	Rear left door central locking motor, lock -V214-					68
69	Rear left door central locking motor, lock -V214-					69
70						70
71	Left brake light bulb -M9-					71
72	Rear left fog light bulb -L46- Rear right fog light bulb -L47-					72	Front left footwell light -K268- Front right footwell light -K269-
73	Terminal 30 central locking supply					73	Terminal 30

Back to overview VW PASSAT 2016 Parking aid control unit -J446- / park assist steering control unit -J791- Fitting location: Behind dash panel on driver side.

1 -	Parking aid control unit -J446- / park assist steering control unit -J791-

A -	18-pin connector -T18d-

B -	26-pin connector -T26a-

Connector assignment of parking aid control unit -J446- / park assist steering control unit -J791-

	-T18d- (A)	Designation	-T26a- (B)	Designation
	1		1
	2	Front left sender for park assist steering on left side of vehicle -G568-	2	Front parking aid warning buzzer -H22-
	3	Front centre left parking aid sender -G254-	3
	4	Front right parking aid sender -G252-	4	Warning light for park​ assist steering​ -K241-
	5		5
	6		6	Rear left parking aid sender -G203-
	7		7	Rear centre right parking aid sender -G205-
	8		8	Rear right park assist steering sender -G717-
	9		9	Rear parking aid warning buzzer -H15-
	10	348 Earth connection (parking aid), in front bumper wiring harness	10	Front parking aid warning buzzer -H22-
	11	Front left parking aid sender -G255-	11
	12	Front centre right parking aid sender -G253-	12
	13	Front right sender for park assist steering on right side of vehicle -G569-	13	Terminal 31
	14	X151 Connection (5V), in front bumper wiring harness	14	A199 Positive connection 4 (15a) in dash panel wiring harness
	15		15	Rear parking aid warning buzzer -H15-
	16		16	Parking aid button -E266-
	17		17	Parking aid warning lamp -K136-
	18		18	X149 Connection (5V), in rear bumper wiring harness
			19	Rear left park assist steering sender -G716-
			20	Rear centre left parking aid sender -G204-
			21	Rear right parking aid sender -G206-
			22	352 Earth connection (parking aid), in rear bumper wiring harness
			23	B664 Connection (running gear sensors CAN bus, low), in main wiring harness
			24	B663 Connection (running gear sensors CAN bus, high), in main wiring harness
			25
			26

Back to overview VW PASSAT 2016 Selector lever E313 Selector lever -E313- Fitting location: In centre console, on selector lever bracket.

1 -	Selector lever -E313-

A -	10-pin connector -T10am-

Connector assignment of selector lever -E313-

-T10am- (A)	Designation
1	Terminal 31
2	Steering column electronics control unit -J527-
3
4
5	A19 Connection (58d), in dash panel wiring harness
6
7	B383 Connection 1 (powertrain CAN bus, high), in main wiring harness
8	B390 Connection 1 (powertrain CAN bus, low), in main wiring harness
9	A192 Positive connection 3 (15a) in dash panel wiring harness
10	A164 Positive connection 2 (30a) in dash panel wiring harness

Back to overview VW PASSAT 2016 Data bus diagnostic interface J533 Data bus diagnostic interface -J533- Fitting location: Below the dash panel.

1 -	Data bus diagnostic interface -J533-

A -	20-pin connector -T20-

Connector assignment of data bus diagnostic interface -J533-

-T20- (A)	Designation		-T20- (A)	Designation
1	Terminal 30		11	Terminal 31
2	Terminal 30		12	Terminal 31
3			13	B549 Connection 2 (LIN bus) in main wiring harness
4			14	Terminal 15
5	B407 Connection 2 (convenience CAN bus, low), in main wiring harness		15	B398 Connection 2 (convenience CAN bus, high), in main wiring harness
6	B390 Connection 1 (powertrain CAN bus, low), in main wiring harness		16	B383 Connection 1 (powertrain CAN bus, high), in main wiring harness
7	B109 Connection 1 (CAN bus extended low), in main wiring harness		17	B108 Connection 1 (CAN bus extended high), in main wiring harness
8	B664 Connection (running gear sensors CAN bus, low), in main wiring harness		18	B663 Connection (running gear sensors CAN bus, high), in main wiring harness
9	Diagnostic connection -U31-		19	Diagnostic connection -U31-
10	A179 Connection (infotainment CAN bus, low), in dash panel wiring harness		20	A178 Connection (infotainment CAN bus, high), in dash panel wiring harness

Back to overview VW PASSAT 2016 Control unit for cornering light and headlight range control J745 Control unit for cornering light and headlight range control -J745- Fitting location: Behind dash panel on driver side.

1 -	Control unit for cornering light and headlight range control -J745-

A -	26-pin connector -T26d-

q	Only models with automatic headlight control

A -	26-pin connector -T26e-

q	Only models without automatic headlight control

Connector assignment of control unit for cornering light and headlight range control -J745-

-T26d- (A)	Designation		-T26d- (A)	Designation
1			14
2	B668 Connection 2 (CAN bus extended high) in main wiring harness 1) B108 Connection 1 (CAN bus extended high) in main wiring harness 1)		15	Right headlight range control motor -V49-
3	B669 Connection 2 (CAN bus extended low) in main wiring harness 1) B109 Connection 1 (CAN bus extended low) in main wiring harness 1)		16	Left headlight range control motor -V48-
4	C67 Connection (CAN bus high) in headlight wiring harness t  front left headlight -MX1- t  Front right headlight -MX2-		17	Left headlight range control motor -V48-
5	C68 Connection (CAN bus low) in headlight wiring harness t  front left headlight -MX1- t  Front right headlight -MX2-		18	Left headlight range control motor -V48-
6			19	Left headlight range control motor -V48-
7	Rear left vehicle level sender -G76-		20	Right headlight range control motor -V49-
8			21	Right headlight range control motor -V49-
9			22	Right headlight range control motor -V49-
10	Rear left vehicle level sender -G76-		23	Terminal 15
11	Rear left vehicle level sender -G76-		24	Terminal 31
12			25
13			26

1) Depending on equipment

Back to overview VW PASSAT 2016 Airbag control unit J234 Airbag control unit -J234- Fitting location: Behind centre console.

1 -	Airbag control unit -J234-

A -	90-pin connector -T90b-

Back to overview

VW PASSAT 2016 Overview of control units, saloon

Overview of control units, saloon

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

VW PASSAT 2016 Overview of control units, estate

Overview of control units, estate

1 -	Electronically controlled damping control unit -J250-

q	Fitting location

q	Connector assignment

2 -	TV tuner -RX6-

q	Fitting location

q	Connector assignment

3 -	Control unit for reducing agent metering system -J880-

q	Fitting location

q	Connector assignment

4 -	Remote control receiver for auxiliary heater -R64-

q	Fitting location

q	Connector assignment

5 -	Lane change assist control unit -J769-

q	Fitting location

q	Connector assignment

6 -	Rear lid power opening control unit -J938-

q	Fitting location

7 -	Rear lid control unit -J605-

q	Fitting location

q	Connector assignment

8 -	Lane change assist control unit 2 -J770-

q	Fitting location

q	Connector assignment

9 -	Battery monitoring control unit -J367-

q	Fitting location only in vehicles with battery at rear

q	Connector assignment

10 -	Trailer detector control unit -J345-

q	Fitting location

q	Connector assignment

11 -	Delivery unit for reducing agent metering system -GX19-

q	Fitting location

q	Connector assignment

12 -	All-wheel drive control unit -J492-

q	Fitting location

q	Connector assignment

VW PASSAT 2016 Electronically controlled damping control unit J250 Electronically controlled damping control unit -J250- Electronically controlled damping control unit -J250- , saloon Fitting location: on right in luggage compartment.

1 -	Electronically controlled damping control unit -J250-

A -	47-pin connector -T47b-

Connector assignment of electronically controlled damping control unit -J250- Electronically controlled damping control unit -J250- , estate Fitting location: on right in luggage compartment.

1 -	Electronically controlled damping control unit -J250-

A -	47-pin connector -T47b-

Connector assignment of electronically controlled damping control unit -J250- VW PASSAT 2016 TV tuner RX6 TV tuner -RX6- TV tuner -RX6- , saloon Fitting location: on right in luggage compartment.

1 -	TV tuner -RX6-

A -	12-pin connector -T12s-

B -	2-pin connector -T2fk-

q	Fibre optic cable (FOC)

C -	2-pin connector -T2-

D -	2-pin connector -T2hg-

q	Aerial amplifier 1 for TV -R82-

E -	4-pin connector -T4dg-

q	Aerial amplifier 2 for TV -R83-

q	Aerial amplifier 3 for TV -R84-

Connector assignment of TV tuner -RX6- TV tuner -RX6- , estate Fitting location: on right in luggage compartment.

1 -	TV tuner -RX6-

A -	12-pin connector -T12s-

B -	2-pin connector -T2fk-

q	Fibre optic cable (FOC)

C -	2-pin connector -T2-

D -	2-pin connector -T2hg-

q	Aerial amplifier 1 for TV -R82-

E -	4-pin connector -T4dg-

q	Aerial amplifier 2 for TV -R83-

q	Aerial amplifier 3 for TV -R84-

Connector assignment of TV tuner -RX6- VW PASSAT 2016 Control unit for reducing agent metering system J880 Control unit for reducing agent metering system -J880- Control unit for reducing agent metering system -J880- , saloon Fitting location: on right in luggage compartment.

1 -	Control unit for reducing agent metering system -J880-

A -	4-pin connector -T4cg-

B -	5-pin connector -T5ak-

Connector assignment of control unit for reducing agent metering system -J880- Control unit for reducing agent metering system -J880- , estate Fitting location: on right in luggage compartment.

1 -	Control unit for reducing agent metering system -J880-

A -	4-pin connector -T4cg-

B -	5-pin connector -T5ak-

Connector assignment of control unit for reducing agent metering system -J880- VW PASSAT 2016 Remote control receiver for auxiliary heater R64 Remote control receiver for auxiliary heater -R64- Remote control receiver for auxiliary heater -R64- , saloon Fitting location: on right in luggage compartment.

1 -	Remote control receiver for auxiliary heater -R64-

A -	6-pin connector -T6v-

B -	2-pin connector -T2gv-

Connector assignment of remote control receiver for auxiliary heater -R64- Remote control receiver for auxiliary heater -R64- , estate Fitting location: on right in luggage compartment.

1 -	Remote control receiver for auxiliary heater -R64-

A -	6-pin connector -T6v-

B -	2-pin connector -T2gv-

Connector assignment of remote control receiver for auxiliary heater -R64- VW PASSAT 2016 Lane change assist control unit J769 Lane change assist control unit -J769- Fitting location: under bumper on right   Note The fitting locations are identical on saloon and estate models.

1 -	Lane change assist control unit -J769-

A -	8-pin connector -T8am-

Connector assignment of lane change assist control unit -J769-

-T8am- (A)	Designation
1	Terminal 31
2	B108 Connection 1 (CAN bus extended high), in main wiring harness
3	B109 Connection 1 (CAN bus extended low), in main wiring harness
4	Blind spot monitor warning lamp in right exterior mirror -K304-
5	Lane change assist control unit 2 -J770-
6	Lane change assist control unit 2 -J770-
7	Blind spot monitor warning lamp in right exterior mirror -K304-
8	Terminal 15

Back to overview VW PASSAT 2016 Rear lid power opening control unit J938 Rear lid power opening control unit -J938- Fitting location: under bumper on right   Note The fitting locations are identical on saloon and estate models.

1 -	Rear lid power opening control unit -J938-

A -	5-pin connector -T5-

B -	4-pin connector -T4gm-

Back to overview VW PASSAT 2016 Rear roller blind control unit J262 Rear roller blind control unit -J262- Fitting location: under rear shelf

1 -	Rear roller blind control unit -J262-

A -	4-pin connector -T4bw-

Connector assignment of rear roller blind control unit -J262-

-T4bw- (A)	Designation
1	Terminal 15
2	Terminal 31
3	Rear roller blind switch -E149-
4

Back to overview VW PASSAT 2016 Rear lid control unit J605 Rear lid control unit -J605- Rear lid control unit -J605- , saloon Fitting location: on left in luggage compartment.

1 -	Rear lid control unit -J605-

A -	10-pin connector -T10au-

B -	32-pin connector -T32f-

Connector assignment of rear lid control unit -J605-

-T10au- (A)	Designation		-T32f- (B)	Designation		-T32f- (B)	Designation
1	Terminal 30		1	Anti-trapping sender 2 -G753-		17
2	Motor 1 for rear lid -V444-		2	Anti-trapping sender -G673-		18
3	Motor 2 for rear lid -V445-		3	Anti-trapping sender -G673- Anti-trapping sender 2 -G753-		19
4	Motor 1 for rear lid -V444-		4			20
5	Power latching motor for rear lid -V382-		5	Rear lid warning buzzer -H32-		21	Rear lid warning buzzer -H32-
6	Terminal 31		6			22
7			7	Power latching for rear lid -VX16-		23
8			8			24	Sensor in motor 2 for rear lid -G746-
9	Motor 2 for rear lid -V445-		9			25	Sensor in motor 2 for rear lid -G746-
10	Power latching motor for rear lid -V382-		10	Sensor in motor 1 for rear lid -G745-		26	Sensor in motor 1 for rear lid -G745-
			11	Sensor in motor 2 for rear lid -G746-		27	Sensor in motor 1 for rear lid -G745-
			12	Sensor in motor 2 for rear lid -G746-		28	Sensor in motor 1 for rear lid -G745-
			13			29
			14	Rear lid closure button -E574-		30
			15			31	B507 Connection (convenience CAN bus, low), in interior wiring harness
			16			32	B506 Connection (convenience CAN bus, high), in interior wiring harness

Back to overview Rear lid control unit -J605- , estate Fitting location: on left in luggage compartment.

1 -	Rear lid control unit -J605-

A -	10-pin connector -T10au-

B -	32-pin connector -T32f-

Connector assignment of rear lid control unit -J605- VW PASSAT 2016 Lane change assist control unit 2 J770 Lane change assist control unit 2 -J770- Fitting location: under bumper on left   Note The fitting locations are identical on saloon and estate models.

1 -	Lane change assist control unit 2 -J770-

A -	8-pin connector -T8al-

Connector assignment of lane change assist control unit 2 -J770-

-T8al- (A)	Designation
1	Terminal 31
2	B108 Connection 1 (CAN bus extended high), in main wiring harness
3	B109 Connection 1 (CAN bus extended low), in main wiring harness
4	Blind spot monitor warning lamp in left exterior mirror -K303-
5	Lane change assist control unit -J769-
6	Lane change assist control unit -J769-
7	Blind spot monitor warning lamp in left exterior mirror -K303-
8	Terminal 15

Back to overview VW PASSAT 2016 Battery monitoring control unit J367 Battery monitoring control unit -J367- Fitting location: on battery at rear.   Note t  Only on vehicles with battery at the rear. t  Fitting location is identical for saloon and estate.

1 -	Battery monitoring control unit -J367-

A -	2-pin connector -T2jr-

Connector assignment of battery monitor control unit -J367-

-T2jr- (A)	Designation
1	LIN bus
2	Terminal 15

Back to overview VW PASSAT 2016 Trailer detector control unit J345 Trailer detector control unit -J345- Trailer detector control unit -J345- , saloon Fitting location: on left in luggage compartment.

1 -	Trailer detector control unit -J345-

A -	24-pin connector -T24-

B -	6-pin connector -T6s-

C -	10-pin connector -T10ap-

D -	10-pin connector -T10aq-

Connector assignment of trailer detector control unit -J345-

-T24- (A)	Designation		-T24- (A)	Designation
1	Trailer socket -U10-		13	Hinged tow attachment ball head motor -V317-
2	Trailer socket -U10-		14	Hinged tow attachment ball head motor -V317-
3	Trailer socket -U10-		15	Trailer socket -U10-
4			16
5	Trailer towing coupling -VX15-		17
6	Trailer towing coupling -VX15-		18	Trailer socket -U10-
7	Trailer towing coupling -VX15-		19	Trailer socket -U10-
8			20
9	Trailer towing coupling -VX15-		21
10	Trailer towing coupling -VX15-		22
11			23	Trailer socket -U10-
12	Trailer socket -U10-		24	Trailer socket -U10-

-T6s- (B)	Designation		-T10ap- (C)	Designation		-T10aq- (D)	Designation
1	Terminal 30		1	A192 Positive connection 3 (15a) in dash panel wiring harness		1	Electric hinged tow coupling attachment button -E474-
2	Terminal 31		2	B160 Connection (brake system monitor), in interior wiring harness		2
3	Terminal 30		3	B506 Connection (convenience CAN bus, high), in interior wiring harness		3	Electric hinged tow coupling attachment button -E474-
4	Terminal 30		4	B507 Connection (convenience CAN bus, low), in interior wiring harness		4	Electric hinged tow coupling attachment button -E474-
5	Terminal 30		5			5
6	Terminal 30		6			6
			7			7
			8			8	Electric hinged tow coupling attachment button -E474-
			9			9
			10			10

Back to overview Trailer detector control unit -J345- , estate Fitting location: on left in luggage compartment.

1 -	Trailer detector control unit -J345-

A -	24-pin connector -T24-

B -	6-pin connector -T6s-

C -	10-pin connector -T10ap-

D -	10-pin connector -T10aq-

Connector assignment of trailer detector control unit -J345- VW PASSAT 2016 Delivery unit for reducing agent metering system GX19 Delivery unit for reducing agent metering system -GX19- Fitting location: at bottom of rear right wheel housing   Note The fitting locations are identical on saloon and estate models.

1 -	Delivery unit for reducing agent metering system -GX19-

A -	4-pin connector -T4l-

B -	5-pin connector -T5j-

Connector assignment of delivery unit for reducing agent metering system -GX19-

-T4l- (A)	Designation		-T5j- (B)	Designation
1	B600 Positive connection 4 (87a), in interior wiring harness		1	Terminal 31
2	Engine control unit -J623-		2	Control unit for reducing agent metering system -J880-
3	Engine control unit -J623-		3	B600 Positive connection 4 (87a), in interior wiring harness
4	B600 Positive connection 4 (87a), in interior wiring harness		4	Terminal 31
			5	Engine control unit -J623-

Back to overview VW PASSAT 2016 All-wheel drive control unit J492 All-wheel drive control unit -J492- Fitting location: on rear axle   Note The fitting locations are identical on saloon and estate models.

1 -	All-wheel drive control unit -J492-

A -	10-pin connector -T10-

Connector assignment of all-wheel drive control unit -J492-

-T10- (A)	Designation		-T10- (A)	Designation
1	Terminal 15		6
2	B664 Connection (running gear sensors CAN bus, low), in main wiring harness		7	Terminal 31
3	Terminal 30		8
4	B663 Connection (running gear sensors CAN bus, high), in main wiring harness		9	Haldex coupling pump -V181-
5			10	Haldex coupling pump -V181-

Back to overview
