Электросхема панели приборов (1 из 2) для Dodge Nitro Shock 2010

Электросхема панели приборов (1 из 2) для Dodge Nitro Shock 2010 - Список элементов:

• (base of left "d" pillar)
• (not used)
• 4wd sw sig
• 87a
• A412
• A909
• B(+)
• B20
• B25
• Batt fd 9
• Brake fluid level sig
• Brake lamp sw out
• Btsi unlock sig
• C201
• C307
• C308
• C309
• C316
• C317
• Can c bus (+)
• Can c bus (-)
• Can int bus (+)
• Can int bus (-)
• Circuit board
• Cluster
• Computer data lines system
• Courtesy lamps driver
• D264
• D265
• D506
• D64
• D65
• Dim 3 ip
• Driv ft door ajar switch in
• Driver door latch
• Drlk sw rtn
• Drv door ajar sw sns
• E12
• Exterior lights system
• F943
• Fuel level sig
• Fuel pump ctrl
• Fuse f13 60a
• Fuse m13 20a
• Fuse m15 20a
• Fuse m20 15a
• Fuse m34 10a
• G201 (left kick panel)
• G300
• G304 (under driver's seat)
• G305 (under driver's seat)
• G38
• G74
• G75
• G76
• G77
• G78
• Gnd
• Hot at all times
• Ign rs
• Interior lights system
• Inverter status ind
• Iod fd
• K31
• K321
• K77
• L51
• Left rear door ajar switch sense
• Left rear door latch
• Liftgate ajar sw sns
• Lin ccn
• Lr door ajar sw sns
• M24
• M27
• P37
• P806
• Park brake sw sns
• Park brake switch sns
• Parking brake switch (base of parking brake lever)
• Pass door ajar sw sns
• Pass ft door ajar switch in
• Passenger door latch
• Read/rail lamps driver
• Red
• Rr door ajar sw sns
• Run relay
• Run relay ctrl
• Run/ start relay
• Run/start relay ctrl
• S201
• S210
• S220
• S309
• Sens com rtn
• Shift interlock system
• Sw over drv sig
• Totally integrated power module (left side of engine compt)
• Transmissions system
• Ugdo enable ctrl cir
• X920
• Z910

Электросхема панели приборов (2 из 2) для Dodge Nitro Shock 2010

Электросхема панели приборов (2 из 2) для Dodge Nitro Shock 2010 - Список элементов:

• Ajar lgate
• Brake fluid level sensor (on brake fluid reservoir)
• Brk lvl sw sig
• C201
• C306
• C310
• C312
• C314
• C323
• Can c bus (+) c1
• Can c bus (-)
• Compass module (right rear of headliner)
• Computer data lines system
• D506
• D64
• D65
• Dr lk sw rtn
• Eop sig
• F921
• Fuel pump ctrl c3
• Fuel pump module (in fuel tank)
• Fuel sndr lvl sig primary
• Fused run rly
• G301 (base of left "d" pillar)
• G301 (base of right "d" pillar)
• G304 (under driver's seat)
• Gnd
• Ground
• Heated seats module
• K31
• Left multifunction switch
• Liftgate door latch
• Lin ccn
• Lower bank switch
• Oil pressure switch (lower left front of engine)
• Powertrain control module (right rear of engine compt)
• Right rear door latch
• Right steering wheel switch
• S209 (right side of dash)
• S316 (w/ heated seats) (at breakout for c319)
• S345
• Sig
• Steering control module (on steering column)
• Sw rtn
• Sw sns dr ajar
• Z919
