AIR CONDITIONING – Toyota 4Runner SR5 1998 – SYSTEM WIRING DIAGRAMS

AIR CONDITIONING

A/C Wiring Diagram for Toyota 4Runner SR5 1998

List of elements for A/C Wiring Diagram for Toyota 4Runner SR5 1998:

• (a/c sub wire harness, behind glove box)
• (cowl wire harness, above glove box)
• (cowl wire harness, behind center of dash)
• (engine room main wire harness, left kick panel)
• (left front fender) g102
• (rear heater sub wire harness, below right front seat)
• 2.7l
• 3.4l
• A/c
• A/c amplifier (right side of dash)
• A/c dual pres- sure switch (right rear of engine compt.)
• A/c fuse 10a
• A/c magnetic clutch
• A/c switch
• A/c thermistor (right side of dash)
• Ac1
• Act
• Alt fuse 100a
• B/v
• B8 (rear heater sub wire harness, below right front seat)
• Blower motor (right side of dash)
• Blower resistor (right side of dash)
• Blower switch
• Canadian models
• Center j/b (on left side of engine compart- ment, on inner fender panel)
• Center j/b (on left side of engine compartment, on inner fender panel)
• D10
• D11
• D12
• D16
• Defroster
• Driver side j/b (left side of dash)
• E16
• E17
• Engine control module (right side of dash)
• Engine room r/b (left side of engine compartment)
• G203 (right kick panel)
• G203 (right side kick panel)
• Gauge fuse 10a
• Gnd
• Heater fuse 50a
• Heater relay
• Hot at all times
• Hot in on or start
• I15
• Integration relay
• J/c 9
• Junction connector (left side of engine compartment)
• Mgc
• Mode switch
• Off
• Pnk
• Prs
• Rear heater blower motor (on rear heater unit)
• Rear heater blower resistor (on rear heater unit)
• Rear heater blower switch
• Rear heater relay (on rear heater unit)
• Red
• Rr htr fuse 10a
• U.s. models

Heater Wiring Diagram, Canadian Models for Toyota 4Runner SR5 1998

List of elements for Heater Wiring Diagram, Canadian Models for Toyota 4Runner SR5 1998:

• (cowl wire harness, above glove box)
• (left front fender) g102
• Blower motor (right side of dash)
• Blower resistor (right side of dash)
• Blower switch
• C j1
• Driver side j/b (left side of dash)
• Engine room r/b (left side of engine compartment)
• G203 (right kick panel)
• Gauge fuse 10a
• Heater fuse 50a
• Heater relay
• Hot at all times
• Hot in on or start
• J/c 9
• Junction connector (left side of engine compartment)
• Off
• Red

Heater Wiring Diagram, U.S. Models for Toyota 4Runner SR5 1998

List of elements for Heater Wiring Diagram, U.S. Models for Toyota 4Runner SR5 1998:

• (cowl wire harness, above glove box)
• (left front fender) g102
• Alt fuse 100a
• Blower motor (right side of dash)
• Blower resistor (right side of dash)
• Blower switch
• C j1
• Driver side j/b (left side of dash)
• Engine room r/b (left side of engine compartment)
• G203 (right kick panel)
• Gauge fuse 10a
• Heater fuse 50a
• Heater relay
• Hot at all times
• Hot in on or start
• J/c 9
• Junction connector (left side of engine compartment)
• Off
• Red

Rear Heater Wiring Diagram for Toyota 4Runner SR5 1998

List of elements for Rear Heater Wiring Diagram for Toyota 4Runner SR5 1998:

• (rear heater sub wire harness, below right front seat)
• Driver side j/b (left side of dash)
• Engine room r/b (left side of engine compartment)
• G203 (right kick panel)
• G203 (right side kick panel)
• Gauge fuse 10a
• Hot at all times
• Hot in on or start
• Integration relay
• J/c 9
• Off
• Pnk
• Rear heater blower motor (on rear heater unit)
• Rear heater blower resistor (on rear heater unit)
• Rear heater blower switch
• Rear heater relay (on rear heater unit)
• Rr htr fuse 10a
